CD changer BMW 5 SERIES 2001 E39 Basic handsfree retrokit for updating various mobile phones Instalation Instruction Manual

EN/4
Retrofit/Installation kit No. 65 90 0 028 873 84 64 25,805 (others see cover sheet)
Installation Instructions no. 01 29 0 029 541 01 29 0 029 544 Issue date: 04.2001
2. Preparations
TIS
instruction
No.
Conduct a brief test (print out error memory) -
Disconnect the battery 12 00...
Remove the radio (cars without an on-board monitor radio only) 65 11 030
Remove the heater/air conditioning control 64 11 749
Remove the cover on the gearshift lever. 51 16 210
Remove the base of the centre console 51 16 200
Remove the driver’s seat 52 13 000
Remove the rear seat bench 52 24 005
Remove the rear seat backrest (cars without a split rear seat backrest only) 52 24 010
Remove the side pad on the left (cars with a split rear seat backrest only) -
Remove the front left door sill trim 51 47 000
Remove the rear left door sill trim 51 47 030
Remove the footwell trim on the driver’s side 51 45 030
Remove the side footwell trim on the left A pillar -
Remove the left A pillar trim (refer to instructions for head airbag) 51 43 201
Remove the left sun visor 51 16 080
Lower the front headlining slightly -
Remove the cover on cars with a glass slide/tilt sunroof 51 44 011
Remove the left boot / wheel arch trim. 51 47 101
Remove the CD changer (if fitted) 65 11 070
Remove the audio amplifier (if fitted) 65 12 070
Remove the navigation computer (if fitted) 65 90 510
Also on E39 cars
Remove the video module (if fitted) 65 50 510
Also on E39/2 cars
Remove the combination roller blind (if fitted) -
Remove the boot floor 51 47 101
Remove the spare wheel cover 51 47 131
Remove the spare wheel -
Remove the cover on the on-board monitor radio 65 52 520
Remove the tool holder-
Remove the right boot / wheel arch trim. 51 47 101
Remove the rear boot floor supports on both sides 65 11 055
Remove the front boot floor supports on both sides 65 11 055
