wheel torque BMW 540I SEDAN 2000 Owners Manual

175n
RepairsIndexOverview Controls Car care Technology Data
Changing tires
the wheel and hub. Clean the lug
bolts.
11 Position the spare wheel. Secure
the wheel by turning at least two lug
bolts into opposite bolt holes.
12 Screw in the remaining lug bolts.
Tighten all the bolts securely.
13 Lower the jack and remove it from
beneath the car.
14 Tighten the lug bolts in a diagonal
pattern.
15 Wheels with full wheel covers: Place
the wheel cover with the valve
opening over the valve (arrow). Use
both hands to press the cover se-
curely onto the rim.
For this light-weight wheel, use
only the full wheel cover installed 390de360
by the factory. Other wheel covers may
not fit securely.<
16 Wheels with hub covers:
Position the hub cover and press it
on tightly.
17 If equipped with lug bolt covers:
Align the arrow on the cover with
the line in the wheel and press the
cover into place.
18 Check and correct the air pressure
at the earliest opportunity.
For vehicles with Tire Pressure Con-
trol (RDC)
*:
After mounting the spare tire or cor-
recting the inflation pressure, reacti-
vate the system. Refer to page 92.The vehicle jack is designed for
changing tires only. Do not
attempt to raise another vehicle model
with it or to raise any load of any kind.
To do so could cause accidents and
personal injury.
To ensure continued safety, have the
lug bolts checked with a calibrated
torque wrench [torque specification
72 lb-ft (100 Nm)] at the earliest
opportunity.<
When storing the wheel, take care to
ensure that you do not damage the
retaining pin in the spare tire recess.
If light-alloy wheels other than original
BMW light-alloy wheels have been
mounted, it may be necessary to use
different lug bolts for those wheels.
Replace the defective tire as soon as
possible and have the new wheel/tire
balanced.

189n
RepairsIndexOverview Controls Car care Technology Data
In order to take driving conditions into
account, ATC registers corners and
both uphill and downhill gradients. For
example, if you maintain speed through
a curve, the transmission does not up-
shift.
On uphill gradients, it shifts only when
the engine speed increases in order to
make more efficient use of power
reserves. On downhill gradients ATC
downshifts when the speed of the vehi-
cles increases, causing the driver to
step on the brakes.Precision sensors monitor the number
of revolutions of the wheels. When
equipped with DSC, they also monitor
steering angle, lateral acceleration,
brake pressure and the movement of
the vehicle around its vertical axis.
If differences in the wheel speeds
occur, the system counteracts the dan-
ger of wheelspin by reducing torque. If
necessary, the system also responds
with additional applications of the
brakes at the rear wheels.
If the system detects an instability in the
vehicle's condition, the braking action
can also be directed to help the front
wheels by the DSC in order to help sta-
bilize the vehicle.
You may need some time to become
accustomed to this system intervention.
However, it guarantees optimum drive
force and driving stability.
The braking intervention may be
accompanied by a certain degree of
noise.ATC
*
ASC+T/DSC
*

Everything from A to Z Third brake lamp, bulb
replacement171
Through-loading
system112
Tilt alarm38
Tire134
Change173
Code137
Damage134
Inflation pressure30, 134
Monitoring inflation
pressure92, 194
Renewal135
Rotation between
axles135
Tread134
Valve caps138
Tire Pressure Control
(RDC)92, 194
Tools166
Torque198
Tow fittings183
Towing183
Tow-starting183
Track width199
Transmission70
Tread depth, tires134
Trip odometer82
Trunk, capacity201
Turn signal77
Bulb replacement169
Turning circle199
U
Universal Transmitter105
Used oil151

V
Valve caps138
Vanity mirror55
Vehicle battery176
Vehicle care, exterior156
Vehicle care, interior158
Vehicle Identification
Number153
Vehicle painting156
Vehicle removal from
service160
Vehicle storage160
Ventilation98, 102
Ventilation in the rear102
Ventilation while parked104
Ventilation, draft-free102
Vinyl upholstery, care158
Viscosity150

W
Warning lamps22
Warranty and Service Guide
Booklet (Canadian
models)154
Washer fluid reservoir
Capacity203
Filling148Washing your car155
Water on the roads125
Waxing, paintwork157
Weights201
Wheelbase199
Wheels and tires137
Width199
Windows
Convenience
operation36
Windows, convenience
operating mode36, 37
Windshield washer fluid
reservoir, capacity203
Windshield washer nozzle
adjustment148
Windshield washer reservoir,
filling148
Windshield wipers77
Winter driving130
Winter operation130
Winter tires138
Wiper blade
replacement166
Wiper/Washer system77
Work in the engine
compartment143

X
Xenon lamps94, 168, 195
