Under the engine hood
94
Washer fluid
Windshield and headlamp washer
system
Antifreeze agent for the washer sys-
tems is inflammable. For this reason,
keep it away from sources of flame and
store it only in its original containers. Store
it so that it is inaccessible to children.
Always observe the instructions for use
provided on the containers.<
We recommend that you mix the
washer ßuid before adding it to the
reservoir.<
Capacity:
approx. 6.9 US quarts/6.5 liters.
Fill with water and, if required, with an anti-
freeze additive according to manufac-
turer's recommendations.
Engine oil
Indicator lamp
Engine oil pressure
The indicator lamp lights up red:
Stop the vehicle immediately and
switch off the engine. Check the
engine oil level; top up as required. If the oil
level is correct: contact the nearest BMW
Sports Activity Vehicle Center.
Do not continue driving. The engine
could be damaged because of inade-
quate lubrication.<
Engine oil level
The indicator lamp lights up yellow
while driving:
The oil level is at the absolute mini-
mum. Add engine oil as soon as possible.
Until then, do not drive more than
approx. 30 miles/50 km.
The indicator lamp lights up yellow
after the engine is switched off:
Top up engine oil at the earliest
opportunity Ð when refueling.
Engine oil sensor
The indicator lamp lights up yellow
within 20 seconds after starting the
engine:
The oil level sensor is defective. Please
have it checked by a BMW Sports Activity
Vehicle Center.
Checking oil level
1.Park the vehicle on a level surface
2.Switch the engine off after it has
reached normal operating temperature
3.After approx. 5 minutes, pull the dip-
stick out and wipe it off with a clean lint-
free cloth, paper towel, or similar mate-
rial
4.Carefully push the dipstick all the way
into the guide tube and pull it out again
5.The oil should extend to between the
two marks on the dipstick.
As is the case with fuel economy, the rate
at which the engine uses oil is strongly
influenced by driving style and operating
conditions.
The oil quantity between the two marks of
the dipstick is approx. 1.1 US quarts/1 liter.

Reference
At a glance
Controls
Driving tips
Mobility
121
Coolant 95
Ð indicator lamp 95
Ð level 96
Ð temperature gauge 45
Coolant temperature
gauge 45
Cooling, refer to
Temperature 61
Copyright 2
Cruise control
Ð buttons in steering
wheel 14
Ð indicator lamp 43
Cruise control, refer to
Ð Programmable cruise
control 43
Cruising range 48
Cup holder, refer to
Beverage holders 67
Curb weight 116
Cylinders, refer to Engine
data 114
D
Dashboard system, refer to
Cockpit 10
Data, technical
Ð dimensions 115
Ð engine 114
Ð filling capacities 117
Ð weights 116
Daytime driving lamp 57
DBC Dynamic Brake
Control 50
Ð indicator lamp 50
Decommissioning the
vehicle, refer to Caring for
your vehicle brochure 97
Defect, refer to Manual
operation
Defects 7
Defrosting, windows 61
Ð air conditioner 62
Ð automatic climate
control 64
Ð rear window
defroster 61, 65Defrosting windows and
removing condensation
Ð air conditioner 62
Ð automatic climate
control 64
Defrosting windshield, refer
to Defrosting
windows 62, 64
Defrost position, refer to
Defrosting
windows 62, 64
Digital clock 46
Dimensions 115
Dipstick, engine oil 94
Directional indicators, refer
to Turn signal
indicators 41
Discs brakes 76, 77
Displacement, refer to
Engine data 114
Display lighting, refer to
Instrument lighting 58
Displays, refer to
Instrument
cluster 11
Disposal
Ð batteries 106
Ð oil 95
Doors
Ð locking and unlocking 20
Ð manual operation 20
DOT Quality Grades 88
Draft-free ventilation 61, 65
Drawbar support load 116
Driving lamps, refer to
Parking lamps/low
beams 57
Driving notes 76
Driving on bad roads 80
Driving stability control
systems 50
Driving through water 80
DSC Dynamic Stability
Control 50
Ð indicator lamp 51
E
Electrical malfunction
Ð door lock 20
Ð doors 20
Ð driver's door 20
Ð fuel filler door 84
Ð panorama glass roof 24
Ð tailgate 21
Electric power windows 22
Electronic Stability
Program ESP, refer to
Dynamic Stability
Control 50
Emergency actuation, refer
to Manual operation
Emergency call 107
Engine
Ð breaking in 76
Ð data 114
Ð indicator lamp 37
Ð malfunction in electronic
circuitry 38
Ð speed 45
Engine compartment 93
Engine coolant 95
Engine hood 92
Engine oil 95
Ð indicator/warning
lamp 94
Ð prescribed oils 95
Engine oil grades 95
Engine oil level 94
Ð indicator/warning
lamp 94
Engine oil pressure 94
Ð indicator/warning
lamp 94
Engine oil sensor 94
Ð indicator/warning
lamp 94
Engine output, refer to
Engine data 114
Engine temperature, refer
to Coolant
temperature 45
Equipment range, refer to
Service and Warranty
Information Booklet for

Reference
At a glance
Controls
Driving tips
Mobility
123
High beams
Ð bulb replacement 100
Ð headlamp flasher 58
Ð indicator lamp 12
High Performance
Synthetic Oil 95
Hill-climbing ability, refer to
Driving on bad roads 80
Hill descent assistance,
refer to HDC 51
Hill Descent Control
HDC 51
Hills 77
Holder for beverage
cans 67
Horn 10
Hydraulic Brake Assistant,
refer to DBC 50
Hydroplaning 77
I
Ice warning 47
Ignition 37
Ignition key 18
Ignition lock 37
Imprint 2
Indicator/warning lamp
Ð airbags 55
Ð alarm system 25
Ð brake system 96
Ð DSC 51
Ð Flat Tire Monitor 53
Ð fog lamps 58
Ð reserve 45
Ð safety belt warning 30
Indicator/warning lamps 12
Individual settings, refer to
Vehicle Memory, Key
Memory 33
Inflation pressure, tires 86
Inflation pressure
monitoring, refer to Flat
Tire Monitor 53
Instrument cluster 10, 11
Instrument illumination 58
Instrument lighting 58
Integrated universal remote
control 66
Interior lamps 58Interior mirror
Ð automatic dimming
feature 32
Interior motion
sensor 22, 25
Ð switching off 19
Interior rearview mirror 32
Interlock, refer to Ignition
lock 37
Intermittent
Ð operation, wipers 41
J
Jacking points 104
Jumping, refer to Jump-
starting 108
Jump-starting 108
K
Key Memory 33
Keys 18
Kickdown 40
L
Lamps and bulbs 99
Lashing eyes, refer to
Securing the load 79
Leather care, refer to
Caring for your vehicle
brochure
LEDs light-emitting
diodes 103
License plate lamp
Ð bulb replacement 102
Lifting handle, compact
wheel 104
Light-alloy wheels, care,
refer to Caring for your
vehicle brochure
Light-emitting diodes
LEDs 103
Lighter 69
Lighter socket 69
Lighting of instruments 58
Lighting of the instruments,
refer to Instrument
lighting 58Lights, refer to Parking
lamps/low beams 57
Lights on warning 57
Load, refer to Loading 78
Loading
Ð securing the load 79
Ð stowing cargo 79
Ð vehicle 78
Loading area
Ð lid, refer to Tailgate 21
Load securing devices 79
Locking
Ð from inside 20
Ð from outside 18
Locking and unlocking
doors
Ð from inside 20
Ð from outside 18
Longlife oils
Ð approved oils 95
Low beams 57
Ð automatic 57
Ð bulb replacement 100
Ð indicator lamp 57
Low-fuel warning light,
refer to Fuel gauge 45
Lug bolts 104
Luggage compartment,
refer to Cargo area
Luggage rack, refer to
Roof-mounted luggage
rack 79
Lumbar support 29
M
Maintenance 97
Maintenance system,
BMW 97
Malfunction in automatic
transmission system 41
Manual operation
Ð doors 20
Ð driver's door 20
Ð fuel filler door 84
Ð glass roof 24
Ð panorama glass roof 24
Ð tailgate 21
Manual transmission 39
Master keys with remote
control 18

Everything from A to Z
124 Maximum axle loads 116
Maximum roof weight 116
MD operation, refer to
Owner's Manual for
Radio/Onboard computer
Mechanical seats 28
Memory, refer to Seat and
mirror memory 29
Memory, refer to Vehicle
Memory, Key Memory 33
Microfilter
Ð air conditioner 62
Ð automatic climate
control 65
Microphone, refer to Car
phone preparation 70
Microphone for
telephone 70
Mileage, refer to Engine
data 114
Mini-Disc operation, refer
to Owner's Manual for
Radio/Onboard computer
Mirror
Ð automatic curb
monitor 32
Ð mirror heating 32
Ð mirror memory, refer to
Seat and mirror
memory 29
Mirror dimming feature 32
Mirrors 31
Mobile Service, refer to
Roadside Assistance 107
Modifications, technical 6
Multifunction switch
Ð turn signal indicators/
headlamp flasher 41
Ð washer/wiper system 41
N
Neck support, refer to Head
restraints 28
Next Service
indicator 46, 97
Nozzles, refer to
Ventilation 61, 65
Nylon rope 109
O
OBD connector 98
Octane number, refer to
Fuel quality 85
Odometer 45
Oil
Ð approved engine oils 95
Ð dipstick 94
Oil change interval, refer to
Next Service indicator 97
Oil change interval, refer to
Service Manual
Oil consumption 94
Oil grades 95
Oil level 94
Oil pressure 94
Oil sensor
Ð indicator lamp 94
OILSERVICE 46, 97
Onboard Diagnostic OBD
interface socket 98
Onboard tool kit 99
Opening and closing 18
Ð from inside 20
Ð from outside 18
Ð using the door lock 20
Ð using the remote
control 18
Operating on bad roads 80
Output, refer to Engine
data 114
Outside air 61
Ð air conditioner 61
Ð automatic climate
control 64
Outside temperature
display
Ð changing unit of
measure 47
Ð in computer 47
Overview indicator/warning
lamps 12
P
Package tray, refer to
Cargo area 71Panorama glass roof 23
Ð comfort operation 20
Ð manual operation 24
Ð protective function 24
Park Distance Control
PDC 49
Parking
Ð vehicle 38
Parking aid, refer to Park
Distance Control PDC 49
Parking brake, refer to
Handbrake 38
Parking lamps 57
Ð bulb replacement 101
Parking lamps/low
beams 57
Parking the vehicle 38
Particulate filter, refer to
Microfilter 62
Partition net 72
PDC Park Distance
Control 49
Plastic, refer to Caring for
your vehicle brochure
Pollen, refer to
Microfilter 62
Pollen, refer to Microfilter/
Activated charcoal
filter 65
Power seat 29
Pressure, tires 86
Pressure monitoring,
tires 53
Ð Flat Tire Monitor 53
Programming settings,
refer to Vehicle Memory,
Key Memory 33
Protective function
Ð panorama glass roof 24
Puncture
Ð Flat Tire Monitor 53
R
Radiator, refer to
Coolant 95
Radio, refer to separate
Owner's Manual
Radio navigation, refer to
separate Owner's Manual
Rain sensor 42

Everything from A to Z
126 Starting assistance, refer to
Jump-starting 108
Starting difficulties
Ð temperature 38
Starting-off assistance,
DSC 50
Starting the engine 38
Startup difficulties
Ð jump-starting 108
Status of this Owner's
Manual at time of
printing 5
Steering lock 37
Steering wheel 10, 14
Ð adjustment 31
Ð lock 37
Steering wheel heater 31
Steering wheel with
buttons 14
Steptronic 39
Storage compartments 68
Storage package 68
Storage package nets 68
Storage space, refer to
Cargo area 71
Storing seat position, refer
to Seat and mirror
memory 29
Storing the seat
adjustment 29
Straps, refer to Loading 78
Stroke, refer to Engine
data 114
Supply reservoir cleaning
systems 94
Switches, refer to
Cockpit 10
Switching off the engine 38
Symbols 4
T
Table of contents 3
Tachometer 45
Tailgate
Ð closing 21
Ð emergency operation 21
Ð opening from the
outside 21
Ð remote control 19Tailgate lamp
Ð bulb replacement 103
Tail lamps
Ð bulb replacement 102
Ð indicator lamp 57
Tank capacity 117
Technical modifications 6
Telephone, refer to
separate Owner's Manual
Temperature
Ð air conditioner 61
Ð automatic climate
control 64
Temperature, tires 88
Temperature display
Ð ice warning 47
Ð outside temperature 47
Ð setting the units 47
Temperature gauge 45
Thigh support
adjustment 28, 29
Three-point belt 30
Tightening torque 105
Tilt alarm sensor 25
Ð switching off 25
Tilt function, passenger-
side mirror 32
Tire inflation pressures 86
Tire pressure monitoring,
refer to Flat Tire
Monitor 53
Tires
Ð age 88
Ð break-in procedure 76
Ð changing 89
Ð condition 89
Ð DOT Quality Grades 88
Ð flat 103
Ð inflation pressure 86, 87
Ð replacing 89
Ð storage 90
Ð temperature 88
Ð traction 88
Ð treadwear 88
Ð Uniform Tire Quality
Grading 89
Ð wear indicators, refer to
Tire tread/damage 89
Ð wheel change 103
Tools, refer to Onboard tool
kit 99Torque of lug bolts 105
Tow bar 109
Tow fittings 109
Towing 109
Towing the vehicle 109
Tow rope 109
Tow sockets for tow
fitting 109
Tow-starting 109
Track width, refer to
Dimensions 115
Traction 88
Traction control
Ð DSC 50
Trailer loads 116
Transmission 39
Ð automatic transmission
with Steptronic 39
Ð manual transmission 39
Transmission lockout, refer
to P Parking 40
Transmission
malfunction 41
Transporting children 34
Transporting children
safely 34
Tread depth, refer to Tire
tread 89
Treadwear 88
Trip-distance counter, refer
to Trip odometer 45
Trip odometer 45
Trunk, refer to Cargo
area 71
Trunk lid, refer to
Tailgate 21
Turning circle, refer to
Dimensions 115
Turn signal indicators 41
Ð bulb replacement 101
Turn signal indicators, side
Ð bulb replacement 101
U
Underbody protection,
refer to Caring for your
vehicle brochure
Uniform Tire Quality
Grading 89
