technical data BMW X3 2.5I 2004 E83 Owner's Manual

Reference
At a glance
Controls
Driving tips
Mobility

Contents
The fastest way to find specific topics is to
use the index, refer to page 119.

Using this Owner's Manual

4Notes

At a glance

10Cockpit

Controls

18Opening and closing
27Adjustments
34Transporting children safely
37Driving
45Everything under control
49Technology for comfort, convenience
and safety
57Lamps
60A congenial climate
66Practical interior accessories

Driving tips

76Things to remember when driving

Mobility

84Refueling
86Wheels and tires
92Under the engine hood
97Maintenance
98Laws and regulations
99Replacing components
107Giving and receiving assistance

Reference

114Technical data
117Everything from A to Z

Reference
At a glance
Controls
Driving tips
Mobility
79
Stowing cargo
>Load heavy cargo as far forward and as
low as possible, placing it directly
behind the bulkhead behind the rear
seats
>Cover sharp edges and corners
>Pull out the partition net, refer to
page 72, making sure that objects can-
not penetrate the partition net
>For very heavy cargo when the rear seat
is not occupied, secure each safety belt
in the opposite buckle.
Cargo, securing
>Use the luggage net* to hold down
small and lightweight luggage and
cargo, refer to page 72
>For larger and heavier pieces, load
securing equipment
* is available from
your BMW Sports Activity Vehicle Cen-
ter. Lashing eyes for attaching these
heavy-duty straps have been provided
in your vehicle's luggage compartment,
refer to page 73
>Read and comply with the information
enclosed with the load-securing
devices.Always position and secure the load
correctly. If you do not, it can even
endanger the passengers during braking or
evasive maneuvers.
Never exceed either the approved gross
vehicle weight or either of the approved
axle loads, refer to page 116, as excessive
loads can pose a safety hazard, and may
also place you in violation of freeway safety
laws.
You should never transport heavy or hard
objects unsecured in the passenger com-
partment, as they could fly around and
pose a safety hazard to the vehicle's occu-
pants even during abrupt braking or eva-
sive maneuvers .<
Roof-mounted luggage
rack*
Because roof racks raise the vehicle's cen-
ter of gravity when loaded, they have a
major effect on its handling and steering
response.
You should therefore always remember not
to exceed the approved roof weight, the
approved gross vehicle weight or the axle
loads when loading the rack.
You can find the specified weights in the
Technical data section on page 116.
Make sure that the load is not too heavy,
and that it does not extend outward to
beyond the limits of the loading surface.
Always load the heaviest pieces first Ð on
the bottom. Be sure that adequate clear-
ance is maintained for raising the glass
roof, and that objects do not project into
the opening path of the tailgate.
Secure roof-mounted cargo correctly and
securely to prevent it from shifting or being
lost during the trip.
Drive smoothly. Avoid sudden acceleration
and braking maneuvers. Take corners gen-
tly.

Technical data
114
Technical data
Engine specifications
An engine performance test is authorized only on an appropriate chassis dynamometer.
BMW X3 2.5iBMW X3 3.0i
Displacement
Number of cylinderscu in/cmm152.2/2,494
6181.8/2,979
6
Maximum output
at engine speedhp
rpm184
6,000225
5,900
Maximum torque
at engine speedlb ft/Nm
rpm175/237
3,500214/290
3,500
Compression ratioe10.5 10.2
Stroke
Borein/mm
in/mm2.95/75
3.31/843.53/89.6
3.31/84
Fuel-injection system Digital electronic engine-management system DME

Technical data
116
Weights
Never exceed either the approved axle loads or the gross vehicle weight.
BMW X3 2.5iBMW X3 3.0i
Curb weight
with manual transmission
with automatic transmissionlbs/kg
lbs/kg4,001/1,815
4,045/1,8354,023/1,825
4,067/1,845
Approved gross vehicle weight
with manual transmission
with automatic transmissionlbs/kg
lbs/kg4,993/2,265
5,049/2,2905,049/2,290
5,104/2,315
Load
with manual transmission
with automatic transmissionlbs/kg
lbs/kg992/450
1,003/4551,025/465
1,036/470
Approved front axle load lbs/kg 2,425/1,100 2,425/1,100
Approved rear axle load lbs/kg 2,756/1,250 2,778/1,260
Approved roof load capacity lbs/kg 165/75 165/75
Cargo area capacity cu ft/l 71/2,010 71/2,010

Technical data
118

Everything from A to Z
120 Bottle holder, refer to
Beverage holders 67
Brake fluid 96
Ð indicator lamp 96
Ð level 96
Ð replacing 96
Brake force display 54
Brake lamps
Ð defect 57
Ð indicator lamp 12
Ð replacing the bulbs 102
Brake pads and rotors
Ð breaking-in procedure 76
Brakes 77, 96
Ð ABS 77
Ð brake fluid 96
Ð break-in procedure 76
Ð handbrake 38
Ð indicator/warning
lamp 38
Brake system
Ð brake-fluid level 96
Ð brake pads 96
Ð corrosion 77
Ð disc brakes 76, 77
Ð indicator lamp 96
Ð rotors 76, 77
Brake wear warning
Ð brake pads 96
Ð indicator lamp 96
Break-in procedures 76
Bulbs and lamps 99
Buttons in steering
wheel 14
C
California Proposition
65 Warning 98
Capacities 117
Car care, refer to Caring for
your vehicle brochure
Car-care products, refer to
Caring for your vehicle
brochure
Care, refer to Caring for
your vehicle brochureCargo area 71
Ð capacity 116
Ð cover 71
Ð floor cover 72
Ð folding rear seat
backrest 71
Ð increasing volume 71
Ð lashing eyes 73
Ð manual unlocking 21
Ð opening, remote
control 19
Ð opening/closing 21
Ð opening from the
outside 21
Ð sockets 73
Ð volume 116
Cargo bay, refer to Cargo
area 71
Cargo loading 78
Caring for leather, refer to
Caring for your vehicle
brochure
Caring for the carpet, refer
to Caring for your vehicle
brochure
Caring for the vehicle finish,
refer to Caring for your
vehicle brochure
Car keys, refer to Key
set 18
Car phone preparation 70
Car wash 77
Car wash, refer to Caring
for your vehicle brochure
Catalytic converter, refer to
High temperatures 76
Central locking system 18
Ð interior 20
Changes, technical, refer to
For your own safety 6
Changing a wheel 103
Check Gas Cap
Ð indicator lamp 12, 84
Checking inflation
pressure 86
Child's seats, refer to
Child-restraint
systems 34
Child-restraint systems 34
Child-safety locks 36
Chock 103Chrome parts, care, refer to
Caring for your vehicle
brochure
Cigarette lighter
Ð front 69
Ð rear 69
Circulation of air, refer to
Recirculated-air
mode 61, 64
Cleaning, vehicle, refer to
Caring for your vehicle
brochure
Cleaning the windshield 42
Cleaning windows,
reservoir 94
Clean the rear window 42
Clock 46
Ð 12/24 hour mode 48
Ð setting, refer also to
Owner's Manual for
Radio/Onboard
computer 46
Clutch 76
Ð breaking in 76
Cockpit 10
Cold start, refer to Starting
the engine 37
Comfort operation
Ð panorama glass roof 20
Compact wheel
Ð wheel changes 103
Compression ratio, refer to
Engine data 114
Computer 47
Computer, functions 48
Condensation, refer to A/C
operation 61, 64
Connecting a vacuum
cleaner, refer to Lighter
socket 69
Consumption, refer to
Average fuel
consumption 48
Consumption indicator,
refer to Fuel gauge 45
Contents 3
Controls, refer to
Cockpit 10
Convenience operation
Ð from outside 20
Ð windows 20

Reference
At a glance
Controls
Driving tips
Mobility
121
Coolant 95
Ð indicator lamp 95
Ð level 96
Ð temperature gauge 45
Coolant temperature
gauge 45
Cooling, refer to
Temperature 61
Copyright 2
Cruise control
Ð buttons in steering
wheel 14
Ð indicator lamp 43
Cruise control, refer to
Ð Programmable cruise
control 43
Cruising range 48
Cup holder, refer to
Beverage holders 67
Curb weight 116
Cylinders, refer to Engine
data 114
D
Dashboard system, refer to
Cockpit 10
Data, technical
Ð dimensions 115
Ð engine 114
Ð filling capacities 117
Ð weights 116
Daytime driving lamp 57
DBC Dynamic Brake
Control 50
Ð indicator lamp 50
Decommissioning the
vehicle, refer to Caring for
your vehicle brochure 97
Defect, refer to Manual
operation
Defects 7
Defrosting, windows 61
Ð air conditioner 62
Ð automatic climate
control 64
Ð rear window
defroster 61, 65Defrosting windows and
removing condensation
Ð air conditioner 62
Ð automatic climate
control 64
Defrosting windshield, refer
to Defrosting
windows 62, 64
Defrost position, refer to
Defrosting
windows 62, 64
Digital clock 46
Dimensions 115
Dipstick, engine oil 94
Directional indicators, refer
to Turn signal
indicators 41
Discs brakes 76, 77
Displacement, refer to
Engine data 114
Display lighting, refer to
Instrument lighting 58
Displays, refer to
Instrument
cluster 11
Disposal
Ð batteries 106
Ð oil 95
Doors
Ð locking and unlocking 20
Ð manual operation 20
DOT Quality Grades 88
Draft-free ventilation 61, 65
Drawbar support load 116
Driving lamps, refer to
Parking lamps/low
beams 57
Driving notes 76
Driving on bad roads 80
Driving stability control
systems 50
Driving through water 80
DSC Dynamic Stability
Control 50
Ð indicator lamp 51
E
Electrical malfunction
Ð door lock 20
Ð doors 20
Ð driver's door 20
Ð fuel filler door 84
Ð panorama glass roof 24
Ð tailgate 21
Electric power windows 22
Electronic Stability
Program ESP, refer to
Dynamic Stability
Control 50
Emergency actuation, refer
to Manual operation
Emergency call 107
Engine
Ð breaking in 76
Ð data 114
Ð indicator lamp 37
Ð malfunction in electronic
circuitry 38
Ð speed 45
Engine compartment 93
Engine coolant 95
Engine hood 92
Engine oil 95
Ð indicator/warning
lamp 94
Ð prescribed oils 95
Engine oil grades 95
Engine oil level 94
Ð indicator/warning
lamp 94
Engine oil pressure 94
Ð indicator/warning
lamp 94
Engine oil sensor 94
Ð indicator/warning
lamp 94
Engine output, refer to
Engine data 114
Engine temperature, refer
to Coolant
temperature 45
Equipment range, refer to
Service and Warranty
Information Booklet for

Everything from A to Z
124 Maximum axle loads 116
Maximum roof weight 116
MD operation, refer to
Owner's Manual for
Radio/Onboard computer
Mechanical seats 28
Memory, refer to Seat and
mirror memory 29
Memory, refer to Vehicle
Memory, Key Memory 33
Microfilter
Ð air conditioner 62
Ð automatic climate
control 65
Microphone, refer to Car
phone preparation 70
Microphone for
telephone 70
Mileage, refer to Engine
data 114
Mini-Disc operation, refer
to Owner's Manual for
Radio/Onboard computer
Mirror
Ð automatic curb
monitor 32
Ð mirror heating 32
Ð mirror memory, refer to
Seat and mirror
memory 29
Mirror dimming feature 32
Mirrors 31
Mobile Service, refer to
Roadside Assistance 107
Modifications, technical 6
Multifunction switch
Ð turn signal indicators/
headlamp flasher 41
Ð washer/wiper system 41
N
Neck support, refer to Head
restraints 28
Next Service
indicator 46, 97
Nozzles, refer to
Ventilation 61, 65
Nylon rope 109
O
OBD connector 98
Octane number, refer to
Fuel quality 85
Odometer 45
Oil
Ð approved engine oils 95
Ð dipstick 94
Oil change interval, refer to
Next Service indicator 97
Oil change interval, refer to
Service Manual
Oil consumption 94
Oil grades 95
Oil level 94
Oil pressure 94
Oil sensor
Ð indicator lamp 94
OILSERVICE 46, 97
Onboard Diagnostic OBD
interface socket 98
Onboard tool kit 99
Opening and closing 18
Ð from inside 20
Ð from outside 18
Ð using the door lock 20
Ð using the remote
control 18
Operating on bad roads 80
Output, refer to Engine
data 114
Outside air 61
Ð air conditioner 61
Ð automatic climate
control 64
Outside temperature
display
Ð changing unit of
measure 47
Ð in computer 47
Overview indicator/warning
lamps 12
P
Package tray, refer to
Cargo area 71Panorama glass roof 23
Ð comfort operation 20
Ð manual operation 24
Ð protective function 24
Park Distance Control
PDC 49
Parking
Ð vehicle 38
Parking aid, refer to Park
Distance Control PDC 49
Parking brake, refer to
Handbrake 38
Parking lamps 57
Ð bulb replacement 101
Parking lamps/low
beams 57
Parking the vehicle 38
Particulate filter, refer to
Microfilter 62
Partition net 72
PDC Park Distance
Control 49
Plastic, refer to Caring for
your vehicle brochure
Pollen, refer to
Microfilter 62
Pollen, refer to Microfilter/
Activated charcoal
filter 65
Power seat 29
Pressure, tires 86
Pressure monitoring,
tires 53
Ð Flat Tire Monitor 53
Programming settings,
refer to Vehicle Memory,
Key Memory 33
Protective function
Ð panorama glass roof 24
Puncture
Ð Flat Tire Monitor 53
R
Radiator, refer to
Coolant 95
Radio, refer to separate
Owner's Manual
Radio navigation, refer to
separate Owner's Manual
Rain sensor 42

Everything from A to Z
126 Starting assistance, refer to
Jump-starting 108
Starting difficulties
Ð temperature 38
Starting-off assistance,
DSC 50
Starting the engine 38
Startup difficulties
Ð jump-starting 108
Status of this Owner's
Manual at time of
printing 5
Steering lock 37
Steering wheel 10, 14
Ð adjustment 31
Ð lock 37
Steering wheel heater 31
Steering wheel with
buttons 14
Steptronic 39
Storage compartments 68
Storage package 68
Storage package nets 68
Storage space, refer to
Cargo area 71
Storing seat position, refer
to Seat and mirror
memory 29
Storing the seat
adjustment 29
Straps, refer to Loading 78
Stroke, refer to Engine
data 114
Supply reservoir cleaning
systems 94
Switches, refer to
Cockpit 10
Switching off the engine 38
Symbols 4
T
Table of contents 3
Tachometer 45
Tailgate
Ð closing 21
Ð emergency operation 21
Ð opening from the
outside 21
Ð remote control 19Tailgate lamp
Ð bulb replacement 103
Tail lamps
Ð bulb replacement 102
Ð indicator lamp 57
Tank capacity 117
Technical modifications 6
Telephone, refer to
separate Owner's Manual
Temperature
Ð air conditioner 61
Ð automatic climate
control 64
Temperature, tires 88
Temperature display
Ð ice warning 47
Ð outside temperature 47
Ð setting the units 47
Temperature gauge 45
Thigh support
adjustment 28, 29
Three-point belt 30
Tightening torque 105
Tilt alarm sensor 25
Ð switching off 25
Tilt function, passenger-
side mirror 32
Tire inflation pressures 86
Tire pressure monitoring,
refer to Flat Tire
Monitor 53
Tires
Ð age 88
Ð break-in procedure 76
Ð changing 89
Ð condition 89
Ð DOT Quality Grades 88
Ð flat 103
Ð inflation pressure 86, 87
Ð replacing 89
Ð storage 90
Ð temperature 88
Ð traction 88
Ð treadwear 88
Ð Uniform Tire Quality
Grading 89
Ð wear indicators, refer to
Tire tread/damage 89
Ð wheel change 103
Tools, refer to Onboard tool
kit 99Torque of lug bolts 105
Tow bar 109
Tow fittings 109
Towing 109
Towing the vehicle 109
Tow rope 109
Tow sockets for tow
fitting 109
Tow-starting 109
Track width, refer to
Dimensions 115
Traction 88
Traction control
Ð DSC 50
Trailer loads 116
Transmission 39
Ð automatic transmission
with Steptronic 39
Ð manual transmission 39
Transmission lockout, refer
to P Parking 40
Transmission
malfunction 41
Transporting children 34
Transporting children
safely 34
Tread depth, refer to Tire
tread 89
Treadwear 88
Trip-distance counter, refer
to Trip odometer 45
Trip odometer 45
Trunk, refer to Cargo
area 71
Trunk lid, refer to
Tailgate 21
Turning circle, refer to
Dimensions 115
Turn signal indicators 41
Ð bulb replacement 101
Turn signal indicators, side
Ð bulb replacement 101
U
Underbody protection,
refer to Caring for your
vehicle brochure
Uniform Tire Quality
Grading 89
