adding oil BMW X3 3.0I 2006 E83 Owner's Manual

Under the hood
94
Engine oil
Engine oil consumption depends on driving
style and operating conditions.
Warning lamp
Engine oil pressure
The warning lamp lights up red:
The engine oil pressure is too low.
Stop the vehicle immediately and
switch off the engine. Check the engine oil level
and top off as needed. If the oil level is correct:
have the system checked immediately.
Do not continue driving. The engine could
be damaged because of inadequate lubri-
cation.<
Engine oil level
The warning lamp lights up yellow dur-
ing driving. In addition, an acoustic sig-
nal sounds.
The oil level is at the absolute minimum. Add
engine oil as soon as possible. Until then, do not
drive more than approx. 30 miles/50 km.
The warning lamp lights up yellow after
the engine is switched off. In addition,
an acoustic signal sounds.
Top off engine oil at the earliest opportunity,
e.g. when refueling.
Engine oil sensor
The warning lamp lights up yellow
within 30 seconds after starting the
engine:
The oil level sensor is defective. Have it
checked as soon as possible.
Checking oil level
1.With the engine at operating temperature,
i.e. after at least 6 miles/10 km of uninter-
rupted driving, park the vehicle in a horizon-
tal position.
2.Switch off engine.
3.After approx. 5 minutes, pull the dipstick out
and wipe it off with a clean lint-free cloth,
paper towel, or similar material.4.Carefully push the dipstick all the way into
the guide tube and pull it out again.
The oil should extend to between the two
marks on the dipstick.
5.Push the oil dipstick into the dipstick tube
as far as possible again.
The oil quantity between the two marks of the
dipstick is approx. 1.1 US quarts/1 liter.
Do not fill beyond the upper mark on the
dipstick. Excess oil can damage the
engine.<
Adding engine oil
Do not add oil until the oil level has dropped to
just above the lower marking on the dipstick,
refer to page94.
Add oil within the next 30 miles/50 km;
otherwise, engine damage could result.<
Keep oil, grease, etc. out of reach of chil-
dren and heed warnings on the contain-
ers. Otherwise, you could endanger your
health.<
Oil change
Have the oil changed only by your BMW Sports
Activity Vehicle Center or a workshop that

Everything from A to Z
118
Everything from A to Z
Index
A
ABS Antilock Brake
System48
– indicator lamp12
Accessories, refer to For your
own safety6
Accident, refer to Receiving
assistance107
Acknowledgment signal for
locking/unlocking
vehicle19,20
Activated-charcoal filter64
Adaptive Head Light57
Adding engine oil94
Adjusting seats27
– electrically27
– mechanically27
– mechanically Sports seat28
Airbags53
– deactivating front passenger
side33,54
– indicator lamp for front
passenger airbags54
– sitting safely26
– warning lamp54
Air circulation, refer to Recir-
culated-air mode60,63
Air conditioner59
Air distribution
– air conditioner60
– automatic climate control63
Airing, refer to
Ventilation61,64
Air outlets, refer to
Ventilation61,64
Air pressure, refer to Tire
inflation pressure86
Air vents, refer to
Ventilation61,64
Air volume60
– adjusting manually63AKI, refer to Fuel
specifications85
Alarm system24
– avoiding unintentional
alarms25
All-season tires, refer to
Special characteristics of
winter tires90
All wheel drive, refer to
xDrive49
Anchorage points73
Antifreeze
– coolant95
– washer fluid41
Antifreeze protection,
coolant95
Antilock Brake System
ABS48
– indicator lamp12
Anti-theft alarm system, refer
to Alarm system18,24
Approved axle load, refer to
Weights116
Approved engine oils95
Approved gross vehicle
weight, refer to Weights116
Armrest
– front67
– rear68
Artificial leather, refer to
Caring for your vehicle
brochure
Ashtray68
AUC Automatic recirculated-
air control63
Automatic
– air distribution63
– air volume63
– recirculated-air control
AUC63
Automatic car wash, refer to
Caring for your vehicle
brochureAutomatic climate control62
Automatic cruise control41
Automatic curb monitor31
Automatic deactivation of
front passenger airbags54
Automatic headlamp
control56
Automatic transmission with
Steptronic38
– indicator lamp39
– interlock36
– selector lever interlock38
– shiftlock38
– towing109
– tow starting110
AUTO program63
Average fuel consumption46
– setting units45
Average speed46
– setting units45
Avoiding unintentional
alarms25
Axle loads, refer to
Weights116
B
Backrest, refer to Seats27
Backrest contour, refer to
Lumbar support28
Backup lamps
– bulb replacement102
– refer to Tail lamps102
Bandages, refer to First-aid
kit108
Bar, towing110
Battery105
– disposal106
– indicator lamp12
– jump starting108
– power failure106
– remote control18
– warning lamp105

Everything from A to Z
124 Master key18
– with remote control18
Maximum speed, with winter
tires90
Mechanical seats27
Memory, refer to
– Seat and mirror memory29
– Vehicle Memory, Key
Memory32
Microfilter
– air conditioner61
– automatic climate control64
Microphone, refer to Car
phone preparation69
Microphone for telephone69
Mirrors30
– automatic curb monitor31
– mirror heating31
– mirror memory, refer to Seat
and mirror memory29
Mobile communications
devices in vehicle77
Mobile phone, refer to
separate Owner's Manual
Monitoring tire pressure, refer
to Flat Tire Monitor50
Monitoring tire pressure, refer
to Tire Pressure Monitor52
Multi-function steering wheel,
refer to Buttons on steering
wheel13
Multifunction switch
– turn signals/headlamp
flasher39
– washer/wiper system40
N
Navigation system, refer to
separate Owner's Manual
Neck support, refer to Head
restraints28
Nets68
Nonsmoker's equipment
package68,69
Nozzles, refer to
Ventilation61,64
Nylon rope, refer to Tow
starting and towing109
O
OBD socket97
Octane rating, refer to Fuel
quality85
Odometer43
Oil
– additives, refer to Approved
engine oils95
– approved engine oils95
– capacity116
– consumption, refer to
Checking engine oil level94
– dipstick94
– level94
– refilling, refer to Adding
engine oil94
Oil change interval, refer to
Service Interval Display44
Oil grades95
Oil level94
– warning lamp94
Oil pressure94
– warning lamp94
Oil sensor94
– warning lamp94
OILSERVICE44
Old batteries, refer to
Disposal106
Onboard Diagnostics OBD
interface socket97
On-board monitor, refer to
separate Owner's Manual
Onboard tool kit99
Opening and closing
– from inside20
– from outside19
– using the door lock20
– using the remote control19
Output, refer to Engine
data114
Outside air
– air conditioner60
– automatic climate control63
Outside temperature display
– changing unit of measure45
– on computer45
Overheating of engine, refer to
Coolant thermometer44
P
Panic mode19
Panorama glass sunroof23
– automatic opening and
closing23
– closing with electrical
malfunction24
– comfort operation20
– comfort position23
– initializing23
– power failure23
– remote control19
Parcel shelf, refer to Cargo
area cover71
Park Distance Control PDC47
Parking aid, refer to PDC Park
Distance Control47
Parking assistant, refer to
PDC Park Distance
Control47
Parking brake, refer to
Handbrake37
Parking lamps56
Parking lamps/low beams56
Partition net72
Parts and accessories, refer to
For your own safety6
Passenger airbags, status54
Passenger-side mirror tilt
function31
Pathway lighting56
PDC Park Distance Control47
Pinch protection
system22,23
– panorama glass sunroof23
– power windows22
Plastic, refer to Caring for your
vehicle brochure
Pollen, refer to
– Microfilter61
– Microfilter/activated
charcoal filter64
Power failure
– battery106
– panorama glass sunroof23
– windows22
Power seat adjustment27
