washer fluid BMW X5 4.4I 2000 Owners Manual

Contents

Operation, care and maintenance
Owner service procedures
Advanced technology

Under the hood:

Hood133
Engine compartment134
Washer fluid136
Washer nozzles136
Engine oil137
Coolant140
Brake fluid141
Vehicle Identification No.141

Care and maintenance:

The BMW Maintenance
System142
Caring for your vehicle143
Airbags148
Vehicle storage148

Laws and regulations:

Technical modifications149
OBD interface socket150

Replacement procedures:

Onboard tool kit154
Wiper blades154
Lamps and bulbs155
Changing a wheel160
Battery165
Fuses167

In case of electrical
malfunction:

Fuel filler door168
Sliding/Tilt sunroof168
Liftgate168
Tailgate169

Assistance, giving and
receiving:

Jump-starting170
Towing the vehicle171Airbags176
Adaptive Transmission Control
(ATC)176
Four-wheel drive177
Dynamic Stability Control
(DSC)177
Radio reception178
Safety belt tensioner178
DSP sound system179
Rearview mirrors with automatic
dimmer179
Rain sensor180
Integrated rear suspension180
Level control system181
Xenon lamps181

70n
Washer/Wiper system 1 Intermittent wipe or rain
sensor
*
Intermittent wipe:
You can set the wipe interval to four
stages with rotary dial 7.
In addition, the wipe interval is varied
automatically depending on road
speed.
Rain sensor:
When the rain sensor is activated, the
windshield wiper is controlled automati-
cally, depending on the degree of wet-
ness of the windshield (in both snow
and rain). You do not have to be con-
cerned with switching the windshield
wiper on or off or adjusting the wipe
interval between intermittent and full
wipe. Instead, you can concentrate fully
on the traffic conditions. This is espe-
cially important under adverse weather
conditions.
The rain sensor is positioned on the
windshield, directly in front of the inte-
rior rearview mirror.
To activate the rain sensor:
Move the lever to position 1 with the
ignition key in position 1 or higher. The
wipers travel once across the wind-
shield, regardless of the weather condi-
tions. You can leave the lever permanently in
position 1. It is then only necessary to
activate the rain sensor from ignition
key position 1 and up. To do this,
>turn rotary dial 7 briefly or
>clean the windshield 5 or use the
special wash program 6.
To adjust the sensitivity of the rain
sensor:
Turn rotary dial 7.
Turn the rain sensor off in auto-
matic car washes. If you do not,
damage may occur if the wipers switch
on unintentionally.<
2 Normal wiper speed The system switches automatically to
intermittent operation when the vehicle
is not moving (not on vehicles with the
rain sensor
*).
3 Fast wiper speed The wipers operate at normal speed
when the vehicle is not moving (not on
vehicles with the rain sensor
*).
5 Clean the windshield The system sprays washer fluid against
the windshield and activates the wipers
for a brief period.
If you pull the lever only briefly, the sys-
tem sprays washer fluid onto the wind-
shield without activating the wipers. 6 Special wash program
*
As at 5; there are also several additional
wash cycles, and the headlamps are
cleaned
*.
This program is recommended after you
have driven on extremely dirty roads.
Headlamp washers
*
>With the Special wash program 6
>With every fifth actuation of Clean
windshield 5 when the vehicle's
lighting is switched on.
Do not use the washers if there is
any danger that the fluid will
freeze on the windshield. If you do so,
your vision could be obscured. For this
reason, use an antifreeze agent. Refer
to page 136.
Do not use the washers when the reser-
voir is empty. This could cause damage
to the washer pump.< Windshield washer jets The windshield washer jets are warmed
automatically when the ignition key is in
position 2.

IndexDataTechnologyRepairsCar careControlsOverview
77n
Check Control Graphic display
*
The following alerts or status messages
are displayed with icons from ignition
key position 2 and up until the defects
are corrected:
1 Check low beams.
2 Add washer fluid (goes out after ap-
prox. 1 minute).
3 Door open.
4 Tailgate open.
5 Check brake and tail lamps.
A defective center brake lamp is indi-
cated by the upper symbol.
When you open the door after stopping,
a warning signal sounds without a vi-
sual indicator for:
>LIGHTS ON and
>KEY IN IGNITION LOCK. 390de121
Alphanumeric display
*
Text messages are used to alert the
driver to system malfunctions when the
ignition key is turned to position 2. The
alert is accompanied by a gong.
1 Status report symbol
2 Display
3 CHECK button
Messages concerning system faults are
differentiated based on two priorities: 390us111
Priority 1
These defects are immediately indi-
cated by a gong and a flashing warning
symbol 1. Simultaneous defects will be
displayed consecutively. These status
messages remain in the display until the
defects are corrected. They cannot be
deleted by pressing the CHECK
button 3:
>RELEASE PARKINGBRAKE
>COOLANT TEMPERATURE
The coolant is overheated. Stop the
vehicle immediately and switch off
the engine. Refer to pages 76
and 140.
>STOP! ENGINE OILPRESS
The oil pressure is too low. Stop the
vehicle immediately and switch off
the engine. Refer to page 22.

78n
Check Control >CHECK BRAKE FLUID
Indicates that brake fluid is down to
approximately the minimum level.
Top up the brake fluid at the next op-
portunity. Refer to page 141. Have
the cause of the brake fluid loss diag-
nosed and corrected by your BMW
center.
>SELFLEVEL. SUSP. INACT
Please consult the nearest authorized
BMW center. Refer to page 125.
>SPEED LIMIT
*
You will see this message if the pro-
grammed speed limit has been ex-
ceeded.Priority 2
These displays appear for 20 seconds
when the ignition key is turned to posi-
tion 2. The warning symbols remain
after the message disappears. You can
call up the messages again for display
by pressing the CHECK button.
>TRUNKLID OPEN
This message appears only at the
start of a trip.
>DOOR OPEN
This message appears after a mini-
mal defined road speed has been
exceeded.
>FASTEN SEAT BELTS
*
In addition to this message, an indi-
cator lamp with the safety belt icon
appears and an acoustical signal is
sounded.
>WASHER FLUID LOW
The fluid level is too low; top up at
the next opportunity. Refer to
page 136.
>CHECK ENGINE OIL LEV
Add engine oil as soon as possible.
Refer to page 137.>OUTSIDE TEMP. +23 7 (Ð5 6)
This display is only an example. The
current temperature is displayed at
outside temperatures of +37.5 7
(+3 6) and below. Refer also to
page 74.
>CHECK BRAKE LIGHTS
A lamp has failed or the electrical
circuit has a fault. Refer to pages 157
and 158 or consult an authorized
BMW center.
>CHECK LOWBEAM LIGHTS
CHECK SIDE LIGHTS
CHECK REAR LIGHTS
CHECK FRONT FOGLAMPS
CHECK LICPLATE LIGHTS
CHECK HIGHBEAM LIGHTS
CHECK BACK UP LIGHTS
Defective bulb or circuit. Refer to
page 155 or consult an authorized
BMW center.

IndexDataTechnologyRepairsCar careControlsOverview
Overview
Controls and features
Operation, care
and maintenance
Owner service procedures
Technical data
Index Advanced technology
115n
Car care Special operating instructions:
Break-in procedures116
Driving your BMW X5117
General driving notes118
Catalytic converter118
Antilock Brake System
(ABS)119
Disc brakes122
Brake system123
Winter operation123
Power steering125
Level control system125
Cellular phone126
Radio reception126
Wheels and tires:
Tire inflation pressure127
Tire condition127
Tire replacement128
Tire rotation129
Wheel and tire
combinations130
Winter tires131
Snow chains131
Approved wheel and tire
specifications132Under the hood:
Hood133
Engine compartment134
Washer fluid136
Washer nozzles136
Engine oil137
Coolant140
Brake fluid141
Vehicle Identification No.141
Care and maintenance:
The BMW Maintenance
System142
Caring for your vehicle143
Airbags148
Vehicle storage148
Laws and regulations:
Technical modifications149
OBD interface socket150

IndexDataTechnologyRepairsCar careControlsOverview
135n
Engine compartment Ð BMW X5 4.4i 1 Reservoir for brake fluid
(under the microfilter
trim panel)141
2 Auxiliary terminal for jump
starting170
3 Coolant expansion tank140
4 Engine oil dipstick137
5 Engine oil filler neck137
6 Reservoir for windshield and
headlamp washer system
*
136

136n
Washer fluid Washer nozzles Headlamp
* and windshield
washer system
Capacity in US quarts (liters).
Approx. 8.2 (7.8)
Fill with water and Ñ if required Ñ with a
washer antifreeze (according to manu-
facturer's recommendations).
It is more convenient to mix the
washer fluid before adding it to
the reservoir.< 530us098
Windshield washer Windshield:
The nozzles are directed so as to
ensure effective cleaning, even at high
speeds.
Rear window:
Have this system adjusted by your
BMW center as required. Headlamp washer
*
Have the nozzles adjusted by your
BMW center as required.

IndexDataTechnologyRepairsCar careControlsOverview
187n
Capacities
Notes
Fuel tank
Reserve gal. (liters)
gal. (liters) approx. 24.2 (approx. 92)
approx. 2.6 (approx. 10) Fuel specification: page 30
Windshield washer system
with headlamp washer system quarts (liters) approx. 8.2 (approx. 7.8) For details: page 136
Cooling system including
heater circuit quarts (liters) 12.7 (12.0) For details: page 140
Engine oil and filter change quarts (liters) 8.5 (8.0) "BMW High Performance
Synthetic Oil".
For details: page 138
Automatic transmission, transfer box
and differential Ð Ð Lifetime fluid, no fluid
change required

Everything from A to ZAABS (Antilock Brake
System)119
Accessories6
Activated-charcoal filter95
Adaptive Transmission
Control (ATC)176
Adding engine oil137
Adding washer fluid136
Adjusting seats48
Adjusting the steering
wheel51
Adjusting the
temperature92
Air conditioner93
Air distribution92
Air nozzles90
Air outlets90
Air pressure30, 127
Air supply93
Airbags23, 57, 148, 176
Alarm system43
Antennas126
Antifreeze140
Antifreeze, radiator123
Antilock Brake System
(ABS)119
Anti-theft alarm system43
Anti-theft protection37
Approved gross vehicle
weight186
Aquaplaning118, 127
Ashtray103AUC (Automatic recirculated
air control)93
Automatic car washes143
Automatic climate
control90
Removing condensation
from the windows93
Automatic cruise control72
Automatic curb monitor54
Automatic dimming, interior
rearview mirror53
Automatic recirculated air
control (AUC)93
Automatic steering wheel
adjustment52
Automatic transmission with
Steptronic66
Average fuel
consumption80
Average speed80
Axle loads186
BBackup lamps67
Bulb replacement157
Battery165, 188
Capacity188
Charge166
Discharged170
Belts56
Beverage holder102
Blower93
BMW comfort seat50BMW High Performance
Synthetic Oil138
BMW sports seat50
BMW Universal
Transmitter98
Body-cavity protectant144
Brake fluid141
Brake hydraulic system22
Brake lamps, bulb
replacement157
Brake pads24
Brakes122
Malfunctions123
Break-in procedures116
Bulb replacement155
CCapacities187
Car Memory55
Car radio
reception126, 178
Car wash143
Care, exterior144
Care, interior146
Cargo area42, 107
Capacity186
Opening from the
inside41
Cargo area cover107
Cargo area lamps87
Cargo floor, pull-out111
Cargo loading112Caring for the vehicle
finish145
Catalytic converter118
CBC (Cornering Brake
Control)120
Cellular phones102, 126
refer to the separate
Owner's Manual
Center (high-mount) brake
lamp157
Central locking system36
Button40
Changing a tire160
Changing a wheel160
Charge indicator lamp22
Check air pressure30
CHECK button77
Check Control77
Check engine oil level137
Checking tire pressure30
Child restraint systems57
Child's seat57
Child-safety locks62
Cigarette lighter103
Clean the windshield70
Climate control in the rear
passenger area94
Clock, refer to the Radio or
Onboard Computer
Owner's Manual
Cockpit16
Code, refer to the Radio
Owner's Manual126

Owner service proceduresAAdding brake fluid141
Adding coolant140
Adding engine oil137
Adding washer fluid136
Adjusting washer
nozzles136
Air pressure30, 127
Avoiding unintentional
alarms44BBattery, discharged170
Brakes, brake faults123CChanging a wheel160
Charging the battery166
Check Control77
Check oil level137
Checking tire pressure30DDeactivating the interior
motion sensor38, 44
Deactivating the tilt sensor
alarm system38, 44
Defrosting the windows93
Difficult steering125
Doors, manual operation36
EElectrical malfunction
Fuel filler door168
Liftgate168
Sliding/Tilt sunroof168
Tailgate169
Emergency operation
Doors36
Fuel filler door168
Liftgate168
Sliding/Tilt sunroof168
Tailgate169
Engine oil grades138FFailure messages77
Failure of an electrical
accessory167
Fault displays77
Filling the windshield washer
reservoir136
First-aid kit28
Fittings, tow-starting and
towing171
Flat tire160
Fog lamp, bulb
replacement156
Footwell lamps, bulb
replacement158
GGlove compartment lamp,
bulb replacement158HHazard warning flashers28
Hazard warning triangle28
Headlamp covers,
care143, 155
High beams, bulb
replacement155
Hood release133IIndicator lamps22
Interior lamps, bulb
replacement158JJump-starting170LLevel control system,
inactive125
License plate lamps, bulb
replacement158
Liftgate
Release following an
electrical malfunction168Low beams, bulb
replacement155
Lug wrench160
MMaintenance76, 142
Malfunction displays77
Manual operation
Doors36
Liftgate168
Sliding/Tilt sunroof168
Tailgate169OOil grades138
Onboard tool kit154PPressure, tires30, 127RRear window wiper, wiper
blade replacement154
Releasing the fuel filler door
following an electrical
malfunction168
Releasing the hood133
Releasing the tailgate
following an electrical
malfunction169
