The following only applies to vehicles owned and operated in the US.

REPORTING SAFETY DEFECTS

If you believe that your vehicle has a defect which could cause a crash \
or could cause injury or death, you should
immediately inform the National Highway Traffic Safety Administration (\
NHTSA) in addition to notifying BMW of
North America, LLC, P.O. Box 1227, Westwood, New Jersey 07675-1227, Tele\
phone (201) 307-4000.
If NHTSA receives similar complaints, it may open an investigation, and \
if it finds that a safety defect exists in a
group of vehicles, it may order a recall and remedy campaign. However, N\
HTSA cannot become involved in indi-
vidual problems between you, your dealer or BMW of North America, LLC.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free \
at 1-800-424-9393 (or 366-0123 in
Washington, D.C. area) or write to: NHTSA, U.S. Department of Transport\
ation, Washington, D.C. 20590. You can
also obtain other information about motor vehicle safety from the Hotlin\
e.

12n

13n

OverviewControlsMaintenanceRepairsDataIndex

Overview
Controls and features
Operation, maintenance
Owner service procedures
Index Technical data

Overview

14n
1 Parking lamps/Low beams100
2 Fog lamps101
3

>

Turn signal indicator69

>

Standing lamps101

>

High beams101

>

Headlamp flasher68

>

Computer804 Wiper/Washer system69
5 Rear window defroster104, 109
6 Central locking system307 Hazard warning flashers
8 Horn, the entire surface
9 Adjusting steering wheel52

Cockpit
530de328

15n

OverviewControlsMaintenanceRepairsDataIndex

1 Fuel gauge75
2 Indicator lamp for turn signals21
3 Speedometer
4 Indicator lamp for high beams21
5 Tachometer and Energy Control756 Coolant temperature gauge76
7 Indicator and warning
lamps18 to 21
8 Selector lever and program display
for automatic transmission

*
66
9 Service Interval Display7610 Computer display Ð
operation via the turn signal lever,
refer to page 80:

>

Outside temperature

>

Average fuel consumption

>

Cruising range

>

Average speed

Instrument cluster
530us220

16n

Instrument cluster

11 Indicator lamp for Dynamic Stability
Control (DSC)20
12 Variable Ride Height

*
9513 Odometer and trip odometer74
14 Indicator for Check Control7715 Reset button for trip odometer74
16 Indicator and warning
lamps18 to 21
530us220

17n

OverviewControlsMaintenanceRepairsDataIndex

Instrument cluster

*
1 Fuel gauge75
2 Indicator lamp for turn signals21
3 Speedometer
4 Indicator lamp for high beams21
5 Tachometer and Energy Control75
6 Coolant temperature gauge767 Indicator and warning
lamps18 to 21
8 CHECK button77
9 Selector lever and program display
for automatic transmission

*
66
10 Outside temperature display74
11 Indicator lamp for Dynamic Stability
Control (DSC)2012 Trip odometer74
13 Indicator for Check Control77
14 Odometer74
15 Service Interval Display76
16 Reset button for trip odometer74
17 Indicator and warning
lamps18 to 21
530us221

18n

Indicator and warning lamps

Technology that monitors itself

Indicator and warning lamps that are
identified by "

l

" are tested for proper
functioning whenever the ignition key is
turned. They each light up once for
different periods of time.
If a fault should occur in one of these
systems, the corresponding lamp does
not go out after the engine is started or
it lights up while the vehicle is moving.
You will see how to react to this in the
following section.

Red: stop immediately

Battery charge current

l

The battery is no longer being
charged. There is a malfunction
of the alternator drive belt or in the
charging circuit of the alternator. Please
contact the nearest BMW Sports
Activity Vehicle center.
If the drive belt is defective, do not
continue driving. The engine could
be damaged due to overheating. If the
drive belt is defective, increased
steering effort is also required.

<


Engine oil pressure

l

Stop the vehicle immediately
and switch off the engine.
Check the engine oil level; top off as
required. If the oil level is correct:
please contact the nearest BMW Sports
Activity Vehicle center.
Do not continue driving. The
engine could be damaged
because of inadequate lubrication.

<



Parking brake

* /
Brake hydraulic system
l

Comes on when you engage the
parking brake. For additional informa-
tion: refer to page 64.
Comes on although the parking brake
is released: have the brake fluid level
checked. Before continuing your
journey, be sure to read the notes on
pages 135 and 146.
Also comes on in the Check Control
with the message "CHECK BRAKE
LININGS".
Parking brake warning lamp

*
/
Brake hydraulic system warning
lamp for Canadian models.
Tire Pressure Monitor (RDC)

*


l

In addition, an acoustic signal is
sounded: a flat tire has
occurred. Reduce vehicle speed imme-
diately and stop the vehicle. Avoid hard
brake applications. As you steer the
vehicle, use caution and avoid overcor-
recting.
For additional information: refer to
page 98

19n

OverviewControlsMaintenanceRepairsDataIndex

Indicator and warning lamps

Red or yellow: continue to drive;
drive cautiously

If the brake warning lamp
comes on red together with the
yellow warning lamps for ABS
and DSC:
Continue to drive; drive
cautiously and defensively and
avoid full brake applications.
Have the system checked by the
nearest BMW Sports Activity Vehicle
center.
For additional information: refer to
pages 92 and 134.
If all three warning lamps come on
yellow:
Continue to drive; drive cautiously and
defensively and avoid full brake appli-
cations.
Have the system checked by your
BMW Sports Activity Vehicle center as
soon as possible.
Warning lamps for Canadian
models.

Red: an important reminder

Parking brake

*
Comes on when the parking
brake is engaged.
For additional information: refer to
page 64.
Parking brake warning lamp

*
for
Canadian models.
Please fasten safety belts

l

Together with an acoustic signal
or a message

*
in the Check
Control. Comes on until the safety belts
are fastened. For additional information
on safety belts: refer to page 49.
Airbags

l

Please have the system
inspected by your BMW Sports
Activity Vehicle center.
For additional information: refer to
page 55.

Yellow: check as soon as possible

Antilock Brake System (ABS)
l
ABS has been deactivated in
response to system malfunction.
Conventional braking performance
remains available with no loss of effi-
ciency. Please have the system
inspected by your BMW Sports Activity
Vehicle center.
For additional information: refer to
page 134
ABS warning lamp for Canadian
models.
Engine oil level
Comes on while driving:
The oil level is at the absolute
minimum; refill as soon as possible. Do
not drive more than approx. 30 miles
(50 km) until you do.
For additional information: refer to
page 143.
Engine oil level
Comes on after the engine has
been switched off: add engine
oil at your earliest opportunity (when
you stop to refuel).
For additional information: refer to
page 143.

20n

Indicator and warning lamps

Automatic transmission

*
Because of a malfunction, the
automatic transmission shifts
only in the emergency program. Please
consult the nearest BMW Sports
Activity Vehicle center.
For additional information: refer to
page 68.
Brake pads

*


l

Have the brake pads checked.
For additional information: refer
to page 135.
Variable Ride Height

*
l

Variable Ride Height is inactive.
Please consult the nearest
BMW Sports Activity Vehicle center.
For additional information: refer to
page 95
Dynamic Brake Control (DBC)

l

Fault in the DBC system.
Conventional braking perfor-
mance remains available with no loss of
efficiency. Please have the system
checked and repaired by your
BMW Sports Activity Vehicle center.
For additional information: refer to
page 93
Dynamic Brake Control (DBC)
warning lamp for Canadian
models

Dynamic Stability Control
(DSC)


l


Indicator lamp flashes:
The system is active and governs drive
and braking force.
The warning lamp comes on and stays
on while driving:
DSC has been switched off with the
button. If, after repeatedly pressing the
DSC button, the warning lamp still does
not go off, then that means that the
DSC, HDC and the vehicle's road-
holding ability are defective.
Please have the system checked by the
nearest BMW Sports Activity Vehicle
center.
For additional information: refer to
pages 92 and 94.
Engine electronics

*
There is a fault in the engine's
electronic control system. You
can continue to drive with reduced
engine output or engine speed. Please
have the system inspected by your
BMW Sports Activity Vehicle center.
Tire Pressure Monitor (RDC)

*


l

Check tire inflation pressures,
refer to pages 26, 98

Service Engine Soon

l

If the indicator lamp comes on
either continuously or intermit-
tently, this indicates a fault in the
emissions-related electronic systems.
Although the vehicle remains opera-
tional, you should have the systems
checked by your BMW Sports Activity
Vehicle center at the earliest possible
opportunity.
For additional information: refer to
page 149.
Service Engine Soon warning
lamp for Canadian models.
Check Filler Cap

*


l

If the indicator lamp comes on
although the fuel cap is secured
correctly: this indicates a malfunction in
the fuel system. Have the system
inspected by your BMW Sports Activity
Vehicle center at the earliest opportu-
nity.
Additional information: refer to page 25
