service BMW X5 4.4I 2002 Owners Manual

Congratulations, and thank you for choosing a BMW.
Thorough familiarity with your vehicle will provide you with enhanced control and
security when you drive it. We therefore have this request:
Please take the time to read this Owner's Manual and familiarize yourself with the
information that we have compiled for you before starting off in your new vehicle. It
contains important data and instructions intended to assist you in gaining maximum
use and satisfaction from the unique range of technical features on your BMW. The
manual also contains information on vehicle maintenance designed to enhance
operating safety and contribute to maintaining the value of your BMW throughout an
extended service life.
For additional information refer to the supplemental manuals.
This Owner's Manual should be considered a permanent part of this vehicle. It
should stay with the vehicle when sold to provide the next owner with important
operating, safety and maintenance information.
This manual is supplemented by a Service and Warranty Information Booklet
(US models) or a Warranty and Service Guide Booklet (Canadian models).
We recommend that you read this publication thoroughly.
Your BMW is covered by the following warranties:
Ð New Vehicle Limited Warranty
Ð Limited Rust Perforation Warranty
Ð Federal Emissions System Defect Warranty
Ð Federal Emissions Performance Warranty
Ð California Emission Control System Limited Warranty
Detailed information about these warranties is listed in the Service and Warranty
Information Booklet (US models) or in the Warranty and Service Guide Booklet
(Canadian models).
We wish you an enjoyable driving experience.
BMW AG

Vorwort

Contents

© 2001 Bayerische Motoren Werke
Aktiengesellschaft
Munich, Germany
Reprinting, including excerpts, only with the
written consent of BMW AG, Munich.
Order no. 01 41 0 156 416
US English IX/2001
Printed in Germany
Printed on environmentally friendly paper
(bleached without chlorine, suitable for recycling).
Overview
Controls and features

Cockpit14
Instrument cluster15
Indicator and warning lamps18
Steering wheel with multifunction
buttons22
Warning triangle23
First-aid kit23
Refueling24
Fuel specifications25
Tire inflation pressures26

Locks and security systems:

Keys30
Central locking system30
Opening and closing
Ð via the door lock31
Opening and closing
Ð via the remote control32
Opening and closing
Ð from the inside35
Liftgate36
Tailgate37
Alarm system39
Electric power windows40
Sliding/tilt sunroof with glass
moonroof42

Adjustments:

Correct sitting posture44
Seats44
Mechanical seat45
Power seat46
Head restraints47
Power rear-seat backrest
adjustment48
Safety belt49
Seat, mirror and steering wheel
memory50
Seat heating51
Adjusting steering wheel52
Steering wheel heating53
Mirrors53

Passenger safety systems:

Airbags55
Transporting children safely58
Vehicle Memory, Key
Memory61

Driving:

Ignition lock62
Starting the engine62
Switching off the engine64
Parking brake64
Manual transmission65
Automatic transmission with
Steptronic66
Indicator/Headlamp flasher68
Washer/Wiper system/Rain
sensor69
Cruise control71

Everything under control:

Odometer, outside temperature
display74
Tachometer75
Energy control75
Fuel gauge75
Coolant temperature gauge76
Service Interval Display76
Check Control77
Computer80
Multi-Information Display
(MID)82
Digital clock in the MID83
Computer in the MID86

Inhalt

Contents

Operation, maintenance
Owner service procedures
Technical data

Under the hood:

Hood141
Engine compartment
essentials142
Washer fluid143
Engine oil143
Coolant145
Brake fluid146

Care and maintenance:

The BMW Maintenance
System147

Laws and regulations:

Technical modifications148
California Proposition
65 Warning148
OBD interface socket149

Replacement procedures:

Onboard tool kit152
Windshield wiper blades152
Lamps and bulbs153
Changing a wheel156
Battery162
Fuses163

Assistance, giving and
receiving:

Jump-starting164
Towing the vehicle166Engine specifications170
Dimensions171
Weights172
Capacities173

8n Notes on the Owner's Manual We have made every effort to ensure
that you are able to find what you need
in this Owner's Manual as quickly as
possible. The fastest way to find certain
topics is by using the detailed index at
the end. If you desire an initial overview
of your vehicle, this can be found in the
first chapter. The detailed table of
contents on the preceeding pages is
intended to stimulate your curiosity
regarding your BMW and to encourage
you to read the Owner's Manual.
Should you wish to sell your BMW at
some time in the future, please
remember to hand over the Owner's
Manual to the new owner; it is legal part
of the vehicle.
If you have any questions, your
BMW Sports Activity Vehicle center
will be glad to advise you.
Symbols used

Indicates precautions that must
be followed precisely in order to
avoid the possibility of personal injury
and serious damage to the vehicle.

<


Contains information that will
assist you in gaining the optimum
benefit from your vehicle and enable
you to care more effectively for your
vehicle.

<


Refers to measures that can
be taken to help protect the
environment.

<



<

Marks the end of a specific item of
information.

*
Indicates special equipment, country-
specific equipment and optional extras.

t

Identifies index entries that refer to
owner service procedures or topics on
vehicle maintenance.
Identifies systems or components,
which can either be activated or
adapted to suit an individual driver's
requirements ("Vehicle Memory", "Key
Memory"), refer to page 61.
Remember that activation and adjust-
ments on some of these systems can
only be performed at your BMW Sports
Activity Vehicle center.

<



Notes
Symbols
The individual vehicle

13n

OverviewControlsMaintenanceRepairsDataIndex

Overview
Controls and features
Operation, maintenance
Owner service procedures
Index Technical data

Overview

15n

OverviewControlsMaintenanceRepairsDataIndex

1 Fuel gauge75
2 Indicator lamp for turn signals21
3 Speedometer
4 Indicator lamp for high beams21
5 Tachometer and Energy Control756 Coolant temperature gauge76
7 Indicator and warning
lamps18 to 21
8 Selector lever and program display
for automatic transmission

*
66
9 Service Interval Display7610 Computer display Ð
operation via the turn signal lever,
refer to page 80:

>

Outside temperature

>

Average fuel consumption

>

Cruising range

>

Average speed

Instrument cluster
530us220

17n

OverviewControlsMaintenanceRepairsDataIndex

Instrument cluster

*
1 Fuel gauge75
2 Indicator lamp for turn signals21
3 Speedometer
4 Indicator lamp for high beams21
5 Tachometer and Energy Control75
6 Coolant temperature gauge767 Indicator and warning
lamps18 to 21
8 CHECK button77
9 Selector lever and program display
for automatic transmission

*
66
10 Outside temperature display74
11 Indicator lamp for Dynamic Stability
Control (DSC)2012 Trip odometer74
13 Indicator for Check Control77
14 Odometer74
15 Service Interval Display76
16 Reset button for trip odometer74
17 Indicator and warning
lamps18 to 21
530us221

20n

Indicator and warning lamps

Automatic transmission

*
Because of a malfunction, the
automatic transmission shifts
only in the emergency program. Please
consult the nearest BMW Sports
Activity Vehicle center.
For additional information: refer to
page 68.
Brake pads

*


l

Have the brake pads checked.
For additional information: refer
to page 135.
Variable Ride Height

*
l

Variable Ride Height is inactive.
Please consult the nearest
BMW Sports Activity Vehicle center.
For additional information: refer to
page 95
Dynamic Brake Control (DBC)

l

Fault in the DBC system.
Conventional braking perfor-
mance remains available with no loss of
efficiency. Please have the system
checked and repaired by your
BMW Sports Activity Vehicle center.
For additional information: refer to
page 93
Dynamic Brake Control (DBC)
warning lamp for Canadian
models

Dynamic Stability Control
(DSC)


l


Indicator lamp flashes:
The system is active and governs drive
and braking force.
The warning lamp comes on and stays
on while driving:
DSC has been switched off with the
button. If, after repeatedly pressing the
DSC button, the warning lamp still does
not go off, then that means that the
DSC, HDC and the vehicle's road-
holding ability are defective.
Please have the system checked by the
nearest BMW Sports Activity Vehicle
center.
For additional information: refer to
pages 92 and 94.
Engine electronics

*
There is a fault in the engine's
electronic control system. You
can continue to drive with reduced
engine output or engine speed. Please
have the system inspected by your
BMW Sports Activity Vehicle center.
Tire Pressure Monitor (RDC)

*


l

Check tire inflation pressures,
refer to pages 26, 98

Service Engine Soon

l

If the indicator lamp comes on
either continuously or intermit-
tently, this indicates a fault in the
emissions-related electronic systems.
Although the vehicle remains opera-
tional, you should have the systems
checked by your BMW Sports Activity
Vehicle center at the earliest possible
opportunity.
For additional information: refer to
page 149.
Service Engine Soon warning
lamp for Canadian models.
Check Filler Cap

*


l

If the indicator lamp comes on
although the fuel cap is secured
correctly: this indicates a malfunction in
the fuel system. Have the system
inspected by your BMW Sports Activity
Vehicle center at the earliest opportu-
nity.
Additional information: refer to page 25

24n
Refueling Fuel filler door
Before filling the tank, switch off
the engine. If you do not, fuel
cannot be filled into the tank and the
"Service Engine Soon" lamp may come
on.<
To open the fuel filler door, press on the
front edge.
In the event of an electrical malfunction,
you can also open the fuel filler door
manually:
1. Open the cover on the right in the
cargo area: lift the handle on the
cover
2. Pull the knob with the fuel pump
symbol.
530de243
When handling fuels, comply with
all of the applicable safety precau-
tions and regulations pertaining to
fuels. Never carry spare fuel containers
in your vehicle. Whether empty or full,
these containers can leak, cause an
explosion, or lead to fire in the event of
a collision.<
Simple and environmentally
friendly
Open the filler cap carefully to
prevent fuel from spraying out.
Fuel spray may cause injury.
Do not top off. Topping off may cause
fuel spillage.<
Keep the filler cap in the bracket
attached to the fuel filler door.
When refueling, insert the filler nozzle
completely into the filler pipe. Pulling
the nozzle out of the pipe during refu-
eling
>results in premature pump shutoff
>and will reduce the effect of the vapor
recovery system on the pump.
530us008

29n
OverviewControlsMaintenanceRepairsDataIndex
Overview
Controls and features
Operation, maintenance
Index Technical data
Owner service procedures
