fuse BMW Z3M COUPE 2000 E36 Electrical Troubleshooting Manual



6320.0 LICENSE PLATE/LUGGAGE COMPARTMENT LIGHTS


FUSE DETAILS
0670.3
8S8
LIGHT SWITCH
0) OFF
1) PARK LIGHTS
ON
2) HEADLIGHTS
ON
P90
FRONT POWER
DISTRIBUTION BOX
5 X503
14F37
10A
X10018











0 21
1 GR/SW
58
4
86
85 87b
GROUND
DISTRIBUTION
0670.4
X9633
X5092
6 X509
V9
UNCOUPLING
DIODE (LIGHTS)
30
87
.75 GR/SW
FUSE DETAILS
0670.3
10F25
5A
X10017
FUSE DETAILS
0670.3
14F37
10A
X10018
.75 GR/GE
X50312
PARK/TAIL/UNDER-
HOOD LIGHTS
6314.0
0 2
1
X94111
X94101 .5 GR/GE
X1232
.5 GR/WSV10
UNCOUPLING
DIODE (LIGHTS)
X15291
X15301
.5 GR/WS.5 GR/WS
K25
RIGHT PARK
LIGHT/LICENSE
PLATE LIGHT
RELAY
CANADA LATE PRODUCTION



LICENSE PLATE/LUGGAGE COMPARTMENT LIGHTS


FUSE DETAILS
0670.3
X5038S8
LIGHT SWITCH
0) OFF
1) PARK LIGHTS
ON
2) HEADLIGHTS
ON
X196
2
E43
LEFT LICENSE
PLATE LIGHT
1X709
X709
2
E44
RIGHT LICENSE
PLATE LIGHT
1X710
X710
GROUND
DISTRIBUTION
0670.4
P90
FRONT POWER
DISTRIBUTION BOX
5 X503
.75 GR/SW
.75 GR/SW
14F37
10A
X13006
X10018
A51
WIPER/WASHER
MODULE 4 X285










0 21
A104
BODY
ELECTRONICS
CONTROL MODULE
(ZKE IV) 2 X10182
.5 GR/SW
1 GR/SW
3 X9023
.75 GR/SW
X9461
X196X196X196
.75 GR/WS.75 GR/WS
3 X114023 X11403
Z3 VERSIONS M COUPE M ROADSTER
.5 GR/SW.75 GR/SW
USA AND CANADA EARLY PRODUCTION

3COUPE


LICENSE PLATE/LUGGAGE COMPARTMENT LIGHTS


FUSE DETAILS
0670.3
E32
LUGGAGE
COMPARTMENT
LIGHT
0) OFF
1) MANUAL
2) AUTOMATIC
GROUND
DISTRIBUTION
0670.4 P90
FRONT POWER
DISTRIBUTION BOX
6F33
10A
X13006
X10018










E32
LUGGAGE
COMPARTMENT
LIGHT 1 X712
1 X18080
.75 BR/WS
2 X712
1
.5 BR/WS
ROADSTERCOUPE
3 X712
ROADSTERCOUPE
1 2
0
S826
LUGGAGE COMPART-
MENT LIGHT SWITCH
1) REAR LID CLOSED
2) REAR LID OPEN 211 X711
2 X711
X465
GROUND
DISTRIBUTION
0670.4
X13006
.5 BR/WS.5 BR/WS
N12w
ANTI–THEFT
CONTROL MODULE
(ALPINE)
14 X13254
.75 BR/WS
A104
BODY
ELECTRONICS
CONTROL MODULE
(ZKE IV)11 X13025

1 BL/GE1 BL/GE
Z3 VERSIONS WITHOUT EGS
1 BL/GEX8074


6
6322.0 BACK UP LIGHTS













P90
FRONT POWER
DISTRIBUTION BOX
12
X10017
F2610A

3 X511
2 X511
X319
20S3
AUTOMATIC
TRANSMISSION
RANGE SWITCH
0) OFF (LOW)
2) CLOSED IN RE-
VERSE
FUSE DETAILS
0670.3
Z3 VERSIONS WITH EGS
H27
LEFT BACK UP
LIGHT
5X319

X318
H28
RIGHT BACK UP
LIGHT X318

1 BL/GE
1 BL/GE .75 BL/GE
E16
LEFT REAR LIGHT
ASSEMBLYE17
RIGHT REAR LIGHT
ASSEMBLY
1.5 BR 1.5 BR
X13006
RS8511
REVERSING LIGHT
SWITCH
1) OPEN
2) CLOSED IN R 1 X8511
2 X8511
21
10 X20
1 BL/GE
1 BL/GE
1
15 M VERSIONS
GROUND
DISTRIBUTION
0670.4
1 BL/GEX1169
1 X8511
2 X8511
21S8511
REVERSING LIGHT
SWITCH
1) OPEN
2) CLOSED IN R
1 BL/GE
1 BL/GEX1169
.75 BL/GE3 X6021
NOT USED
X1169
1 BL/GE
3 X6021
.75 BL/GE
LATE PRODUCTION

13X1170
4 X13146
.5 BL/RT















6325.0 BRAKE LIGHTS
.5 BL/RT
10 X8500
A8500
TRANSMISSION
CONTROL MODULE
(EGS)
21
X181
X10018
F4615A
FUSE DETAILS
0670.3
2P90
FRONT POWER
DISTRIBUTION BOX
32
1
1.5 BL/RT
1.5 BL/RTS30
BRAKE LIGHT SWITCH
1) BRAKE PEDAL RE-
LEASED
2) BRAKE PEDAL
DEPRESSED
3) BRAKE PEDAL
DEPRESSED (TEST)
4) BRAKE PEDAL RE-
LEASED (NORMAL)
X13006
GROUND
DISTRIBUTION
0670.4 X318
X318
E17
RIGHT REAR LIGHT
ASSEMBLY X319
X319
E16
LEFT REAR LIGHT
ASSEMBLY H24
LEFT BRAKE LIGHTH31
RIGHT BRAKE
LIGHT
5 1 7H34
HIGH LEVEL STOP
LIGHT X4132
X4131 .75 BL/RT
2 3
.75 BL/RT
34
34 X78
X78
A52
SLIP CONTROL
MODULE
(ABS/ASC) .75 BL/RT
2 X6031
.35 BL/RT
K18363
CONVERTIBLE TOP
RELAY I (CLOSE) .5 BL/RTK18364
CONVERTIBLE TOP
RELAY II (OPEN)
X1215
.5 BL/RT .5 BL/RT
8 X18363
8 X18364
Z3 VERSIONS
X10016
F137.5A
FUSE DETAILS
0670.3 6
28 X60004
A6000
ENGINE CONTROL
MODULE (DME) .35 RT/GE40X1746A65
DYNAMIC STABIL-
ITY CONTROL UNIT
(DSC) .75 BL/RT
.75 BL/RT
WITH DSC WITH ASC
24 .5 BL/RT

2
48X1175
4 X13146
.5 BL/RT


S32
CLUTCH SWITCH
1) NORMAL STATE
2) CLUTCH PEDAL
DEPRESSED












BRAKE LIGHTS
X1211
.75 BL/RT
21
X181
X10018
F4615A
FUSE DETAILS
0670.3
2P90
FRONT POWER
DISTRIBUTION BOX
32
1
1.5 BL/RT
1.5 BL/RTS30
BRAKE LIGHT
SWITCH
1) BRAKE PEDAL
RELEASED
2) BRAKE PEDAL
DEPRESSED
X13006
GROUND
DISTRIBUTION
0670.4 X318
X318
E17
RIGHT REAR LIGHT
ASSEMBLY X319
X319
E16
LEFT REAR LIGHT
ASSEMBLY H24
LEFT BRAKE LIGHTH31
RIGHT BRAKE
LIGHT
5 1 7
.75 BL/RT
2 3
.75 BL/RT
18 X22A8
CRUISE CONTROL
MODULE
(TEMPOMAT) .5 BL/BR
X1212
CRUISE CONTROL
(TEMPOMAT)
6571.0
X197
21
.75 BL/BR
.75 BL/BR
X78
X78
A52
SLIP CONTROL
MODULE
(ABS/ASC) .75 BL/RT
K18363
CONVERTIBLE TOP
RELAY I (CLOSE) .5 BL/RTK18364
CONVERTIBLE TOP
RELAY II (OPEN)
X1215
.5 BL/RT .5 BL/RT
8 X18363
8 X18364
M VERSIONS
H34
HIGH LEVEL STOP
LIGHT X4133
X4131
COUPE
ROADSTER

1
POWER
DISTRIBUTION
0670.2


6330.3 INTERIOR LIGHTS












A104
BODY ELECTRONICS
CONTROL MODULE
(ZKE IV)
2
X13006
S14
DRIVER’S DOOR
JAMB SWITCH
1) DOOR OPEN
2) DOOR CLOSED X352
X352
2
1
GROUND
DISTRIBUTION
0670.4 .75 BR/GR/GE
S13
PASSENGER’S DOOR
JAMB SWITCH
1) DOOR OPEN
2) DOOR CLOSED X351
X351
2
1
GROUND
DISTRIBUTION
0670.4 .75 BR/BL/GEX13254
3
X13004X13004
X111061
GROUND
DISTRIBUTION
0670.4P90
FRONT POWER
DISTRIBUTION BOX F33
10A
X100186
FUSE DETAILS
0670.3
X3572
X357
X111041
X3363.75 BR/SWX13252
4
.75 SW
X111051
ANTI–THEFT
SYSTEM (ALPINE)
6575.2
S408
INTERIOR LIGHT
SWITCH
0) OFF
1) AUTOMATIC
2) MANUAL
E800
FRONT LEFT
INTERIOR LIGHT X443X445
.75 BR/GR/GE .75 BR/BL/GE.75 BR/SW
2 12 1
4FUSE DETAILS
0670.3
X2
POWER
DISTRIBUTION
0670.2
26 X10018
X0
F435A
18 X1018212 X13252
120
Z3 VERSIONS
E34
FRONT DOME
LIGHT/MAP READ-
ING ASSEMBLY
0) OFF
1) MANUAL
2) AUTOMATIC
3) INTERIOR
LIGHT
4) READING
LIGHT
5) ON
31 X9336
1 20
2
X13004
GROUND
DISTRIBUTION
0670.4
X9336
FUSE DETAILS
0670.3
4 X10015
F210A
M VERSIONS
ROADSTERCOUPE
0505
4 3 0
M VERSIONSX9633
















6332.0 INTERIOR ACCESSORIES
P90
FRONT POWER
DISTRIBUTION BOX F32
30A
LIGHT SWITCH
DETAILS
6300.0X10018
414F37
10A
5
6S8
LIGHT SWITCH
0) OFF
1) PARK LIGHTS
ON
2) HEADLIGHTS
ON
3) DIMMER FUSE DETAILS
0670.3
2.5 GR/RTX503
FUSE DETAILS
0670.3
X503
X595
X101411 X531
GROUND
DISTRIBUTION
0670.4
2.5 BR
1.5 GR/RT
E25
FRONT ASHTRAY
LIGHT X1213
X1213
2
1
.5 GR/RT
X532
X532
1
2 .5 GR/RT
.5 BR .5 BR
GROUND
DISTRIBUTION
0670.4
X18170
X878
E29
FRONT CIGAR
LIGHTER LIGHTE28
FRONT CIGAR
LIGHTER
0
21
3
X18170Z3 VERSIONS
X13004
M VERSIONS

X10017


HEADLIGHTS/FOG
LIGHTS
6312.0














X5034P90
FRONT POWER
DISTRIBUTION BOX F25
5A
K16
HAZARD FLASHER
RELAY
X50310
.5 GEFUSE DETAILS
0670.3
X9633
GROUND
DISTRIBUTION
0670.4
6350.0-01
TURN/HAZARD
LIGHTS
6313.0FUSE DETAILS
0670.3F34
15A
.5 WS/BL/GE
6 X64
4 8 9 X64
S8
LIGHT SWITCH
0) OFF
1) PARK LIGHTS
ON
2) HEADLIGHTS
ON
1 BL/GN
.5 BL/GNX184
.5 GE
8 X1001810
X1029
6350.0 CRASH CONTROL MODULE
1.5 RT/WS/GE 1.5 RT/WS/GE
0 2
1
CANADA
LATE PRODUCTIONUSA AND CANADA
EARLY
PRODUCTION FUSE DETAILS
0670.3
















6424.0 REAR WINDOW DEFOGGER
.5 GR/RT
23
X8981
X898
S76
REAR WINDOW DE-
FOGGER SWITCH
1) OFF
2) ON
F235A
X10017
6
FUSE DETAILS
0670.3LIGHT SWITCH
DETAILS
6300.0
GROUND
DISTRIBUTION
0670.4
X18170
1 2
4
P90
FRONT POWER
DISTRIBUTION BOXF620A
X10015
12
FUSE DETAILS
0670.3
X6324
86X63
K9
UNLOADER RELAY,
TERMINAL 1586
8530
87
.5 BR/WS 2.5 SW
M COUPE AND ROADSTER
X3801
E99
HARD TOP
CONNECTOR 1
1
2.5 SW
GROUND
DISTRIBUTION
0670.4
X13006
1 X12661 X1265
2 X130171
E9
REAR DEFOGGER I
2.5 SW 2.5 SW
X379
4 X11209
2.5 SW
GROUND
DISTRIBUTION
0670.4
X13006
1 X379E9
REAR DEFOGGER I
1 X380
ROADSTER COUPE
2.5 SW
