check engine BMW Z3M ROADSTER 1998 E36 Electrical Troubleshooting Manual


#""$
Pin Assignments
 !""





E = Input, A = Output, M = Ground
X6000
Pin Type Description/Function Connection
1
ACyl. 2 ignition coil controlCyl. 2 ignition coil
2ACyl. 4 ignition coil controlCyl. 4 ignition coil
3ACyl. 6 ignition coil controlCyl. 6 ignition coil
4MGroundGround point
5ACyl. 2 fuel injection valve controlCyl. 2 fuel injection valve
6ACyl. 1 fuel injection valve controlCyl. 1 fuel injection valve
7MGroundHot wire air mass meter
8EHot wire air mass meterHot wire air mass meter
9ETI-measurement signal (fuel consumption)Board computer (Z3 Roadster)
10EEngine coolant temperatureEngine coolant temperature sensor
11EFuel tank pressureFuel tank pressure sensor
12EThrottle position signalThrottle position sensor
13Not used
14EIntake air temperatureIntake air temperature sensor
15ERight rear speed signalABS/ASC control module
16EActivate A/CPressure switch
17Not used
18EDrive-away protection signal (code)Electronic immobilizer control module
(EWS II)
19EA/C-ON-signalAir conditioning operating unit
20A“Check engine” indicator controlInstrument cluster
21ACamshaft controlVariable camshaft control valve
22ACyl. 3 fuel injection valve controlCyl. 3 fuel injection valve
23ACyl. 6 fuel injection valve controlCyl. 6 fuel injection valve
24ACyl. 4 fuel injection valve controlCyl. 4 fuel injection valve
25MOxygen sensor heating groundOxygen sensor (in front of catalytic
converter)
26EBattery voltageB+ jump start junction point
27AActivate valveIdle speed control valve
28MGroundGround point
29ACyl. 1 ignition coil controlCyl. 1 ignition coil



#""$
Pin Assignments
 !""





E = Input, A = Output, M = Ground
X6000
Pin Type Description/Function Connection
89
AOxygen sensor heating (–)Oxygen sensor (behind catalytic converter)
90AActivate valveIdle speed control valve
91AActivate valveCyl. 1 fuel injection valve
92AActivate valveCyl. 4 fuel injection valve
93Not used
94MGround, fuel injection valve output stagesGround point
95Not used
96A“Check engine” indicator controlInstrument cluster
97Not used
98EDrive-away protection signalElectronic immobilizer control module
(EWS II)
99EActivate A/CPressure switch
100Not used
101Not used
102Not used
103Not used
104EIntake air temperatureIntake air temperature sensor
105MGroundHot film air mass meter
106Not used
107EOxygen sensor signalOxygen sensor (in front of catalytic
converter)
108ECrankshaft position/RPMCrankshaft position/RPM sensor
109ECamshaft positionHall effect camshaft sensor
11 0ACyl. 3 ignition coil controlCyl. 3 ignition coil
111ACyl. 4 ignition coil controlCyl. 4 ignition coil
11 2Not used
11 3Not used
11 4EBattery voltageB+ jump start junction point
11 5AEngine control module relay controlEngine control module relay, terminal 85
11 6MGround for electronics and shielding of
sensorsGround point





#""$
Pin Assignments
 !""





E = Input, A = Output, M = Ground
X16
Pin Type Description/Function Connection
1
EHigh beam indicator controlCombination switch
2ETerminal 58g, instrument illumination powerLight switch (dimmer)
3ERight turn signal indicator controlHazard flasher relay
4ELeft turn signal indicator controlHazard flasher relay
5EWarning lamp for EGS fault (information
signal transmission oil temperature)Transmission control module (EGS)
6Not used
7Not used
8Not used
9Not used
10Not used
11ADiagnosis RxD signalData link connector (M Roadster)
12E/ADiagnosis TxD signalData link connector
13Not used
14EAirbag warning lamp (SRS) controlSupplemental restraint system control
module
15Not used
16E“Check engine” indicator controlEngine control module (DME)
17EPark brake warning lamp controlPark brake switch
18EBrake fluid warning lamp controlBrake fluid level switch
19EBrake pad wear warning lamp controlBrake pad sensors
20ECrankshaft RPM speed signal TDEngine control module (DME)
21Not used
22EVoltage supply, terminal 30Front power distribution box, fuse 31
23EVoltage supply, terminal 15 for indicator and
warning lampsFront power distribution box, fuse 27
24MGround supply, terminal 31 for instrument
cluster electronicsGround point
25Not used
26Not used

.5 BR/RTM ROADSTER
.5 BR/RT






FUSE DETAILS
0670.3
P90
FRONT POWER
DISTRIBUTION BOX
X1623
X1001714
 !""



#""$


INDICATORS
INSTRUMENT CLUSTER
A2w
INSTRUMENT
CLUSTER
3) ENGINE SPEED
INPUT
7) TACHOMETER
X62321B6232
ENGINE COOLANT
TEMPERATURE
SENSOR
18X1620
.5 SW
GROUND
DISTRIBUTION
0670.4.5 BR/VI
3
TACHOMETER
31
1112
17
.5 BR/GE 24
X16
31
TEMPERATURE
GAUGE
X1047
A6000
ENGINE CONTROL
MODULE (DME) X6000
.5 SW
B6231
OIL PRESSURE
SWITCH
1) PRESSURE
BETWEEN
0.2–0.5 BAR
2) NORMAL
PRESSURE
X1719
2 X6232
23
X20
.5 SW20 X20
.5 BR/GN
.5 BR/GE
X6231
1
X8015
.5 SWX17
A836
ELECTRONIC
IMMOBILIZER
CONTROL MODULE
(EWS II) 12 X1659TD .35 SW
TD .5 BR/GN
A8500
TRANSMISSION
CONTROL MODULE
(EGS) 40 X8500TD .5 SW X6091
23
.5 BR/GN .5 BR/VI .5 BR/GE
18 17
.5 BR/VI
7
X6002
15 .5 WS/GN
X2019
.5 WS/GND100
DATA LINK
CONNECTOR
80
F275A
RCHECK
ENGINE15
16
1
X6031
8
D100
DATA LINK
CONNECTOR.5 SW .5 GR
.5 GR
2 1
1
X6002
7
X8051X8071X80106–CYLINDER 4–CYLINDER
36 20 6–CYLINDER
A52
SLIP CONTROL
MODULE
(ABS/ASC) 41 X1171
.5 SW6–CYLINDER
4–CYLINDER .5 WS/GNX8072
6–CYLINDER
+##
M ROADSTER20 X1175M ROADSTER
