BUICK CASCADA 2018 Owner's Guide

Buick Cascada Owner Manual (GMNA-Localizing-U.S-11373983) - 2018 -
CRC - 7/10/17
30 Keys, Doors, and Windows Warning (Continued).
Adjust the climate control
system to a setting that
brings in only outside air
and set the fan speed to the
highest setting. See
“ Climate Control Systems ”
in the Index.
.
If the vehicle is equipped
with a power liftgate, disable
the power liftgate function.
See Engine Exhaust 0 150 .
Trunk Release To open the trunk, the vehicle must
be off or the shift lever must be in
P (Park). .
Press the lower half of the
emblem on the trunk lid.
.
Press and hold
V on the
Remote Keyless Entry (RKE)
transmitter. Emergency Trunk Release
Handle
CautionDo not use the emergency trunk
release handle as a tie-down or
anchor point when securing items
in the trunk as it could damage
the handle.

Buick Cascada Owner Manual (GMNA-Localizing-U.S-11373983) - 2018 -
CRC - 7/10/17
Keys, Doors, and Windows 31There is a glow-in-the-dark
emergency trunk release handle on
the trunk lid. This handle will glow
following exposure to light. Pull the
release handle to open the trunk
from the inside.
After pulling the emergency trunk
release handle, push the handle
back into the bezel Vehicle Security This vehicle has theft-deterrent
features; however, they do not make
the vehicle impossible to steal.
Vehicle Alarm System This vehicle has an anti-theft alarm
system.
The indicator light, on the
instrument panel near the
windshield, indicates the status of
the system:
Off : Alarm system is disarmed. On Solid : Vehicle is secured
during the delay to arm the system.
Fast Flash : Vehicle is unsecured.
A door, the hood, the convertible
top, or the trunk is open.
Slow Flash : Alarm system is
armed.
Arming the Alarm System 1. Close the trunk and the hood.
Turn off the vehicle.
2. Lock the vehicle in one of
two ways:
.
Use the RKE transmitter.
.
With a door open, press the
inside
Q .
3. After 30 seconds the alarm
system will arm, and the
indicator light will begin to
slowly flash indicating the
alarm system is operating.
Pressing
Q on the RKE
transmitter a second time will
bypass the 30-second delay
and immediately arm the alarm
system.

Buick Cascada Owner Manual (GMNA-Localizing-U.S-11373983) - 2018 -
CRC - 7/10/17
32 Keys, Doors, and Windows The vehicle alarm system will not
arm if the doors are locked with
the key.
If the driver door is opened without
first unlocking with the RKE
transmitter, the horn will chirp and
the turn signal lights will flash to
indicate pre-alarm. If the vehicle is
not started, or the door is not
unlocked by pressing
K on the RKE
transmitter during the 10-second
pre-alarm, the alarm will be
activated.
If a door, the hood, or the trunk is
opened without first disarming the
system, the turn signals will flash
and the horn will sound for about
30 seconds. The alarm system will
then re-arm to monitor for the next
unauthorized event.
Disarming the Alarm System
Do one of the following to disarm
the alarm system or turn off the
alarm if it has been activated:
.
Press
K and
Q on the RKE
transmitter.
.
Start the vehicle. To avoid setting off the alarm by
accident:
.
Lock the vehicle after all
occupants have left the vehicle
and all doors are closed.
.
Always unlock a door with the
RKE transmitter.
Unlocking the driver door with the
key will not disarm the system or
turn off the alarm.
How to Detect a Tamper
Condition If
K is pressed on the RKE
transmitter and the horn chirps and
the turn signal lights flash three
times, an alarm occurred previously
while the alarm system was armed.
If the alarm has been activated, a
message will appear on the DIC.
Immobilizer See Radio Frequency Statement
0 276 . Immobilizer Operation This vehicle has a passive
theft-deterrent system.
The system does not have to be
manually armed or disarmed.
The vehicle is automatically
immobilized when the key is
removed from the ignition.
The system is automatically
disarmed when the vehicle is
started with the correct key. The key
uses a transponder that matches an
immobilizer control unit in the
vehicle and automatically disarms
the system. Only the correct key
starts the vehicle. The vehicle may
not start if the key is damaged.
The security light in the instrument
cluster comes on if there is a
problem with arming or disarming
the theft-deterrent system.

Buick Cascada Owner Manual (GMNA-Localizing-U.S-11373983) - 2018 -
CRC - 7/10/17
Keys, Doors, and Windows 33When trying to start the vehicle, the
security light comes on briefly when
the ignition is turned on.
If the engine does not start and the
security light stays on, there is a
problem with the system. Turn the
ignition off and try again.
If the engine still does not start, and
the key appears to be undamaged
or the light continues to stay on, try
another ignition key.
If the engine still does not start with
the other key, the vehicle needs
service. If the vehicle does start, the
first key may be damaged. See your
dealer who can service the
theft-deterrent system and have a
new key made.
Do not leave the transmitter or
device that disarms or deactivates
the theft-deterrent system in the
vehicle. Exterior Mirrors Convex Mirrors
{ WarningA convex mirror can make things,
like other vehicles, look farther
away than they really are. If you
cut too sharply into the right lane,
you could hit a vehicle on the
right. Check the inside mirror or
glance over your shoulder before
changing lanes.
The passenger side mirror is convex
shaped. A convex mirror's surface is
curved so more can be seen from
the driver seat. Power Mirrors
1. Turn the selector switch to L
(Left) or R (Right) to choose
the driver or passenger mirror.
2. Move the control to adjust the
mirror.
3. Turn the selector switch to
9 to deselect the mirror.

Buick Cascada Owner Manual (GMNA-Localizing-U.S-11373983) - 2018 -
CRC - 7/10/17
34 Keys, Doors, and Windows
Folding Mirrors Manual Folding Mirrors The vehicle has manual folding
mirrors. These mirrors can be folded
inward to prevent damage when
going through an automatic car
wash. To fold, pull the mirror toward
the vehicle. Push the mirror outward
to return it to the original position.
Heated Mirrors If equipped with heated mirrors:
= : The rear window defogger also
heats the outside mirrors.
See Dual Automatic Climate Control
System 0 129 . Interior Mirrors Interior Rearview Mirrors Adjust the rearview mirror for a clear
view of the area behind the vehicle.
Do not spray glass cleaner directly
on the mirror. Use a soft towel
dampened with water.
Automatic Dimming
Rearview Mirror The rearview mirror automatically
dims to reduce the glare of the
headlamps from behind. This
feature comes on when the vehicle
is started.
The vehicle may also have a Rear
Vision Camera (RVC). See
Assistance Systems for Parking or
Backing 0 162 .Windows
{ WarningNever leave a child, a helpless
adult, or a pet alone in a vehicle,
especially with the windows
closed in warm or hot weather.
They can be overcome by the
extreme heat and suffer
permanent injuries or even death
from heat stroke.

Buick Cascada Owner Manual (GMNA-Localizing-U.S-11373983) - 2018 -
CRC - 7/10/17
Keys, Doors, and Windows 35The vehicle aerodynamics are
designed to improve fuel economy
performance. This may result in a
pulsing sound when either rear
window is down and the front
windows are up. To reduce the
sound, open either a front window
or the sunroof, if equipped.
Power Windows
{ WarningChildren could be seriously
injured or killed if caught in the
path of a closing window. Never
leave the Remote Keyless Entry
(RKE) transmitter in a vehicle with
children. When there are children
in the rear seat, use the window
lockout switch to prevent
operation of the windows. See
Keys 0 21 . Power windows work when the
ignition is on, in ACC/ACCESSORY,
or when Retained Accessory Power
(RAP) is active. See Retained
Accessory Power (RAP) 0 148 .
Using the window switch, press to
open or pull to close the window.
The windows may be temporarily
disabled if they are used repeatedly
within a short time. Window Express Movement All windows can be opened without
holding the window switch. Press
the switch down fully and quickly
release to express open the
window.
If equipped, pull the window switch
up fully and quickly release to
express close the window.
Briefly press or pull the window
switch in the same direction to stop
that window ’ s express movement.
All Window Switch

Buick Cascada Owner Manual (GMNA-Localizing-U.S-11373983) - 2018 -
CRC - 7/10/17
36 Keys, Doors, and Windows Press to express open or pull to
express close all windows.
Window Automatic Reversal
System The express-close feature will
reverse window movement if it
comes in contact with an object.
Extreme cold or ice could cause the
window to auto-reverse. The
window will operate normally after
the object or condition is removed.
Window Operation with
Convertible Top Windows will automatically lower
fully when the convertible top is
lowered or raised. See Convertible
Top 0 37 .
Automatic Reversal System
Override
{ Warning
If automatic reversal system
override is active, the window will
not reverse automatically. You or
(Continued) Warning (Continued) others could be injured and the
window could be damaged.
Before using automatic reversal
system override, make sure that
all people and obstructions are
clear of the window path.
When the engine is on, override the
automatic reversal system by pulling
and holding the window switch if
conditions prevent it from closing.
Programming the Power
Windows If the battery on the vehicle has
been recharged or disconnected,
or is not working, the windows with
the express-up feature will need to
be reprogrammed for the feature to
work. If power is lost, the rear
windows must be reprogrammed
first. Before reprogramming, replace
or recharge the vehicle's battery. To program a window:
1. With the ignition on or in ACC/
ACCESSORY, or when
Retained Accessory Power
(RAP) is active, close all doors.
2. Pull and hold the power
window switch until the window
is fully closed. Continue
holding the switch up for
approximately five seconds
after the window is completely
closed.
3. Press the power window switch
down until the window is fully
open. Continue holding the
switch down for approximately
five seconds after the window
is completely open.
The window is now reprogrammed.
Repeat the process for the other
windows.
Window Indexing
When fully closed, indexing
automatically lowers the window a
small amount when the door is

Buick Cascada Owner Manual (GMNA-Localizing-U.S-11373983) - 2018 -
CRC - 7/10/17
Keys, Doors, and Windows 37opened. When the door is closed,
the window will raise to its previous
position.
If the window freezes to the door:
1. Push the top of the window
inward while opening the door.
2. Clear all snow and ice from the
door and glass.
3. Open the window completely
and then close it.
4. Close the door.
If either window does not index
properly, it could be due to loss of
power. Before seeing your dealer for
service, program the power
windows.
Remote Window Operation This feature allows all the windows
to be opened remotely. Press and
hold
K on the RKE transmitter. Sun Visors
Pull the sun visor down to block
glare. Detach the sun visor from the
center mount to pivot to the side
window and, if equipped, extend
along the rod. Roof Convertible Top Review the following before
operating:
{ WarningWhile opening or closing the
convertible top, people can be
injured by the moving parts of the
tonneau cover or convertible top.
Maintain visual contact with the
top while it is being operated.
Caution
Follow these guidelines when
operating the convertible top or
damage can occur:
.
Remove all items from the
roof, trunk lid, or tonneau
cover before operating.
(Continued)

Buick Cascada Owner Manual (GMNA-Localizing-U.S-11373983) - 2018 -
CRC - 7/10/17
38 Keys, Doors, and Windows Caution (Continued).
Remove all objects from the
trunk that may contact the
convertible top when it is
operated.
.
Do not leave the vehicle
with the convertible
top open.
.
Do not exceed 50 km/h
(31 mph) until the top has
completely closed or
opened.
.
Do not open or close the top
while driving in high wind
conditions.
.
Do not operate the
convertible top multiple
times in a short period of
time without starting the
engine to avoid draining the
vehicle battery.
(Continued) Caution (Continued) .
Do not open or store the
convertible top when it is
dirty or wet. This could
result in stains, mildew,
or other damage.
.
Only store the vehicle with
the top fully closed.
Opening the Convertible Top
1. Fold out the rear trunk partition
into the upright position. See
Rear Storage 0 90 .
2. Close the trunk.
3. Start the vehicle or place it in
ACC/ACCESSORY.
4. When possible, operate the
convertible top when the
vehicle is stopped. The top can
be operated while driving
below 50 km/h (31 mph) and
will stop if that speed is
exceeded. The top operation
will take approximately 25 seconds. Make sure the top
operation can be completed
before that speed is reached.
5. Pull and hold the front of the
convertible top switch. The
windows will automatically
lower.
6. Continue holding until the
convertible top is completely
open. A chime will sound.
Release the switch.
7. Briefly pull the all window
switch to close all windows.

Buick Cascada Owner Manual (GMNA-Localizing-U.S-11373983) - 2018 -
CRC - 7/10/17
Keys, Doors, and Windows 39If the radio is on, the sound may be
muted for a brief time due to a new
audio system equalization being
loaded.
Closing the Convertible Top
1. Make sure the sun visor mirror
covers are closed and the sun
visors are stored in the center
mount position.
2. Close the trunk.
3. Start the vehicle or place it in
ACC/ACCESSORY.
4. When possible, operate the
convertible top when the
vehicle is stopped. The top can
be operated while driving
below 50 km/h (31 mph) and
will stop if that speed is
exceeded. The top operation
will take approximately
25 seconds. Make sure the top
operation can be completed
before that speed is reached. 5. Press and hold the front of the
convertible top switch. The
windows will automatically
lower.
6. After the convertible top is
completely closed, a chime will
sound. Release the switch.
7. Briefly pull the all window
switch to close all windows.
If the radio is on, the sound may be
muted for a brief time due to a new
audio system equalization being
loaded. Troubleshooting
Check the following if the
convertible top switch is not
operating:
.
The ignition should be on or in
ACC/ACCESSORY, or Retained
Accessory Power (RAP) should
be active.
.
The trunk lid should be closed
with the rear trunk partition in
place. A Driver Information
Center (DIC) message will
display.
.
If the ONLY MANUAL
OPERATION OF TOP
POSSIBLE message is
displayed on the DIC, see
“ Manual Closing of Top ” later in
this section.
.
At cooler outside temperatures,
the convertible top may not
open. It is possible to close the
top down to temperatures of
about − 20 °C ( − 4 °F). A DIC
message will display if the top
will not open due to low
