yellowblue
1-26
CAUTION:
When an air bag inflates, there is dust in the air.
This dust could cause breathing problems for
people with a history of asthma or other
breathing trouble. To avoid this, everyone in the
vehicle should get out as soon as it is safe to do so.
If you have breathing problems but can't get out
of the vehicle after an air bag inflates, then get
fresh air by opening a window or door.
In many crashes severe enough to inflate an air bag,
windshields are broken by vehicle deformation.
Additional windshield breakage may also occur from the
right front passenger air bag.

Air bags are designed to inflate only once. After they
inflate, you'll need some new parts for your air bag
system. If you don't get them, the air bag system
won't be there to help protect you in another crash.
A new system will include air bag modules and
possibly other parts. The service manual for your
vehicle covers the need to replace other parts.
Your vehicle is equipped with a crash sensing
and diagnostic module, which records information
about the air bag system. The module records
information about the readiness of the system, when
the sensors are activated and driver's safety belt
usage at deployment.

Let only qualified technicians work on your air
bag system. Improper service can mean that your
air bag system won't work properly. See your dealer
for service.
NOTICE:
If you damage the covering for the driver's or the
right front passenger's air bag, the bag may not
work properly. You may have to replace the air
bag module in the steering wheel or both the air
bag module and the instrument panel for the
right front passenger's air bag. Do not open or
break the air bag coverings.

yellowblue
1-27
If your vehicle ever gets into a lot of water -- such as
water up to the carpeting or higher
-- or if water enters
your vehicle and soaks the carpet, the air bag controller
can be soaked and ruined. If this ever happens, and then
you start your vehicle, the damage could make the air
bags inflate, even if there's no crash. You would have to
replace the air bags as well as the sensors and related
parts. If your vehicle is ever in a flood, or if it's exposed
to water that soaks the carpet, you can avoid needless
repair costs by turning off the vehicle immediately and
disconnecting the battery cables. Don't let anyone start
the vehicle under any circumstances. See your dealer
for service.
Servicing Your Air Bag-Equipped Vehicle
Air bags affect how your vehicle should be serviced.
There are parts of the air bag system in several places
around your vehicle. You don't want the system to
inflate while someone is working on your vehicle. Your
dealer and the Riviera Service Manual have information
about servicing your vehicle and the air bag system. To
purchase a service manual, see ªService and Owner
Publicationsº in the Index.
CAUTION:
For up to 10 minutes after the ignition key is
turned off and the battery is disconnected, an air
bag can still inflate during improper service. You
can be injured if you are close to an air bag when
it inflates. Avoid yellow connectors. They are
probably part of the air bag system. Be sure to
follow proper service procedures, and make sure
the person performing work for you is qualified
to do so.
The air bag system does not need regular maintenance.

yellowblue
2-41

Sidemarker Lamps

Instrument Panel Lights

Interior Courtesy Lamps
Pull the knob toward you to the first setting to turn on
the parking lamps and other operating lamps without the
headlamps. Pull the knob toward you to the second
setting to turn on the headlamps as well as the other
operating lamps.
Turn the knob from left to right to control brightness of
the instrument panel lights.
Lamps On Reminder
If the headlamp switch is left on, you'll hear a warning
chime when you turn the ignition off, remove the key
from the ignition and open the driver's door.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier for
others to see the front of your vehicle during the day.
DRL can be helpful in many different driving
conditions, but they can be especially helpful in the
short periods after dawn and before sunset.
A light sensor on top of the instrument panel makes the
DRL work, so be sure it isn't covered.
The DRL system will make your high
-beam headlamps
come on at reduced brightness in daylight when:

the ignition is on,

the headlamp switch is off and

the transaxle is not in PARK (P).
When DRL are on, only your high
-beam headlamps will
be on. The parking lamps, taillamps, sidemarker and
other lamps won't be on. Your instrument panel won't
be lit up either.
When it's dark enough outside, your high
-beam
headlamps will turn off and your low
-beam and parking
lamps will become active. The other lamps that come on
with your headlamps will also come on. When it's bright
enough outside, the regular lamps will go off, and your
high
-beam headlamps change to the reduced brightness
of DRL.

yellowblue
2-42
To idle your vehicle with the DRL off, shift the
transaxle into PARK (P). The DRL will stay off until
you shift out of PARK (P).
To turn off all exterior lamps at night when you are in
PARK (P), turn off the headlamps and move the twilight
sentinel control, located on the lower area of the
headlamp switch, all the way toward AUTO MIN. When
released, the spring control will return to the twilight
sentinel minimum delay position, and all exterior lamps
will turn off.
As with any vehicle, you should turn on the regular
headlamp system when you need it.
Cornering Lamps (Option)
The cornering lamps are designed to come on when you
signal a turn. This will provide more light for cornering
at night.
Twilight Sentinel

Twilight sentinel turns your headlamps, taillamps and
parking lamps on and off by sensing how dark it is
outside. The control is located on the lower area of the
headlamp switch.To operate this feature, leave the headlamp switch off.
The vehicle's twilight sentinel is always enabled.
Twenty
-three seconds after entering a darkened
environment, the headlamps and parking lamps will turn
on. If the ignition is turned on at night, the exterior
lamps will come on.
To turn off all exterior lamps at night when you are in
PARK (P), turn off the headlamps and move the twilight
sentinel control, located on the lower area of the
headlamp switch, all the way toward AUTO MIN. When
released, the spring control will return to the twilight
sentinel minimum delay position, and all exterior lamps
will turn off.
If you move the control all the way to AUTO MAX,
your lamps will remain on for three minutes after you
turn off your engine. If you move the control toward
AUTO MIN, the lamps will go off quickly when you
turn off your engine. You can set this delay time for only
a few seconds or up to three minutes.
Light Sensor
Your twilight sentinel and daytime running lamps work
with the light sensor on top of the instrument panel.
Don't cover it up. If you do, it will read ªdarkº and the
headlamps will come on.

yellowblue
2-43
Interior Lamps
Instrument Panel Brightness
By turning the headlamp knob you can make the
instrument panel lights brighten or dim. See
ªHeadlampsº in the Index.
Courtesy Lamps
When any door is opened, several lamps go on. They
make it easy for you to enter and leave the car. To turn
on these lamps without opening the door, turn the
headlamp knob to the right.
Illuminated Entry
Press the UNLOCK button on the remote keyless entry
transmitter and the interior courtesy lamps will come on
and stay on for up to one minute. The lamps will turn off
immediately when pressing the LOCK button on the
transmitter, starting the ignition or activating the power
door locks.
Delayed Entry Lighting
When you open the door to enter your vehicle, the
interior lamps will come on. When you close the door
with the ignition off, the interior lamps will stay on for
25 seconds or until the ignition is turned to an on
position. Note that locking the doors will override the
delayed entry lighting feature and the lamps will turn off
right away.
Theater Dimming
This feature allows for a three to five-second fade out of
the courtesy lamps instead of immediate turn off.
Delayed Exit Lighting
With this feature, the interior lamps will come on for
25 seconds after you remove the key from the ignition.
This will give you time to find the door pull handle or
lock switches when you exit the vehicle.
Parade Dimming
This feature prohibits the dimming of your instrument
panel displays during daylight while your headlamps are
on. This feature operates with the light sensor for the
twilight sentinel and is fully automatic. When the light
sensor reads darkness outside, you will be able to dim
your instrument panel displays once again.

yellowblue
2-69 Air Bag Readiness Light
There is an air bag readiness light on the instrument
panel, which shows AIR BAG. The system checks the
air bag's electrical system for malfunctions. The light
tells you if there is an electrical problem. The system
check includes the air bag sensors, the air bag modules,
the wiring and the crash sensing and diagnostic module.
For more information on the air bag system, see ªAir
Bagº in the Index.
This light will come on
when you start your engine,
and it will flash for a few
seconds. Then the light
should go out. This means
the system is ready.
If the air bag readiness light stays on after you start the
engine or comes on when you are driving, your air bag
system may not work properly. Have your vehicle
serviced right away.The air bag readiness light should flash for a few
seconds when you turn the ignition key to RUN. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.
Battery Light
When you turn the key to
RUN, this light will come
on briefly, to show that your
generator and battery
charging systems
are working.
If the light stays on, your vehicle needs service and you
should take your vehicle to the dealer at once. To save
your battery until you get there, turn off all accessories,
and set your climate control system to OFF.

yellowblue
3-2
Comfort Controls
This section describes how to operate your climate
control system. Your climate control system uses
ozone
-friendly R-134a refrigerant.
Dual Automatic ComforTemp
Climate Control
Your vehicle has the Dual Automatic ComforTemp
Climate Control system. The following information tells
you how it works.
You will hear a beep each time a button is pushed and a
small light on the button will indicate which buttons are
active. The lights are on all buttons except TEMP, FAN
and AIR FLOW. The display will show fan speed,
comfort level setting and airflow direction for a few
seconds whenever AUTO is selected, and then it will
display the outside temperature. The outside temperature
reading is most accurate when the vehicle is moving.
During stops, the display shows the previous
temperature for best accuracy and system control.
If the display is flashing after the climate control system
is started, there is a problem with the system and you
should see your dealer for service.
Sun and temperature sensors automatically adjust the air
temperature, the airflow direction and the fan speed to
maintain your comfort setting. The system may supply
cooler air to the side toward the sun. Be careful not to
put anything over the sensors on top of the dash.

yellowblue
3-9

When the engine idles for a long time, the exterior
temperature sensor retains the temperature setting
that was present when the vehicle was last moving.
The system will try to maintain the set temperature
inside your vehicle.
Steering Wheel Controls for Climate
Control (Option)
If your vehicle has this
feature, you can control the
temperature comfort setting
by using the control button
on your steering wheel.
TEMP: Press either arrow once and the current comfort
setting will be displayed. Press the up arrow again to
choose a warmer comfort setting and press the down
arrow again to choose a cooler comfort setting.
Audio Systems
Your Delco Electronics audio system has been designed
to operate easily and give years of listening pleasure.
You will get the most enjoyment out of it if you acquaint
yourself with it first. Find out what your Delco
Electronics system can do and how to operate all its
controls, to be sure you're getting the most out of the
advanced engineering that went into it.
Setting the Clock
Press and hold HRS until the correct hour appears. Press
and hold MIN until the correct minute appears.
You may set the clock with the ignition off if you
press RECALL first and follow the same procedure
described above.

yellowblue
6-59
Instrument Panel Fuse BlockFuse Usage
1 Air Bag
2 Injectors
3 Anti
-Lock Brake System
4 Left Exterior Lamps
5 Turn Signal Lamps
6 Oxygen Sensor
7 Climate Control
8 Right Exterior Lamps
9 HVAC Relay
10 MAF
11 Auxiliary Power
12 Interior Lamps
13 Chime
14 TMNSS
15 Cruise Control
16 Perimeter Lights
17 Not Used

yellowblue
9-6
Instrument Panel 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brightness Control 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cluster 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse Block 6-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jack, Tire 5-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key Lock Cylinders Service 7-32 . . . . . . . . . . . . . . . . . . . . .
Key Reminder Warning 2-14 . . . . . . . . . . . . . . . . . . . . . . . . . .
Keyless Entry 2-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keys 2-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Labels
Certification 4-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Parts Identification 6-56 . . . . . . . . . . . . . . . . . . . . .
Tire-Loading Information 4-30 . . . . . . . . . . . . . . . . . . . . . .
Vehicle Identification Number 6-56 . . . . . . . . . . . . . . . . . . .
Lamp, Trunk 2-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lamps 2-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cornering 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Courtesy 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Latches, Seatback 1-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Leaving Your Vehicle with the Engine Running 2
-29 . . . . . . .
License Plate Holder 2-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Light Sensor, Twilight Sentinel 2-42 . . . . . . . . . . . . . . . . . . . .
Lighter 2-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lights
Air Bag Readiness 1
-23, 2-69 . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock Brake System Warning 2-71, 4-7 . . . . . . . . . . . .
Battery Warning 2-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake System Warning 2-70 . . . . . . . . . . . . . . . . . . . . . . . . .
Brake to Shift 2-78 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check Oil 2-77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cruise 2-78 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Ajar 2-78 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Coolant Temperature Warning 2-72 . . . . . . . . . . . . .
Hazard Warning 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Coolant Warning 2-73 . . . . . . . . . . . . . . . . . . . . . . . . .
Low Fuel 2-79 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Pressure 2-77 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Belt Reminder 1-9, 2-68 . . . . . . . . . . . . . . . . . . . . . .
Security 2-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Engine Soon 2-74 . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction Control System Warning 2-71, 4-9 . . . . . . . . . . . .
Washer Fluid Low 2-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Loading Your Vehicle 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Locks 2-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door 2-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door, Delayed Locking 2-7 . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Transaxle Lock Check 7-34 . . . . . . . . . . . . . . . . . .
Key Lock Cylinder Service 7-32 . . . . . . . . . . . . . . . . . . . . .
Lockout Protection 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
