BUICK CENTURY 1999 Owner's Manual

yellowblue
6-61
Fuse Description
24 Stoplamps
26 Parking Lamps
27 Auxiliary Power Connection
(Power Drop)
-- Hot in ACC and Run
28 Crank Signal
-- Body Control Module,
Cluster, Powertrain Control Modules
29 Ignition Signal
-- HVAC Control Head
30 Brake Transmission Shift Interlock (BTSI)
31 Air Bag
32 Body Control Module
33 Hazard Flashers
34 Not UsedFuse Description
36 Ignition Signal
-- Hot in ACC and
Run
-- Body Control Module
38 Low Blower
39 Anti
-Lock Brakes
40 Turn Signals
41 Radio, HVAC Head, Remote Keyless
Entry, Cluster
42 High Blower
43 Not Used
44 Audio Steering Wheel Controls
45 Wipers

yellowblue
6-62
Underhood Electrical Center -- Passenger's Side
Some fuses and relays are located in the underhood
electrical center on the passenger's side of the
engine compartment.Fuse Description
1 ABS
2 Starter Solenoid
3 Power Seats, Rear Defog
4 High Blower, Hazard Flasher,
Stoplamps, Power Mirror, Door Locks
5 Ignition Switch, BTSI, Stoplamps,
ABS, Turn Signals, Cluster, Air Bag,
DRL Module
6 Cooling Fan
7 Interior Lamps, Retained Accessory
Power, Keyless Entry, Data Link, HVAC
Head, Cluster, Radio, AUX Power
(Power Drop), Cigarette Lighter
8 Ignition Switch, Wipers, Radio, Steering
Wheel Controls, Body Control Module,
AUX Power (Power Drop), Power
Windows, Sunroof, HVAC Controls,
DRL, Rear Defog Relay

yellowblue
6-63
Relay Description
9 Cooling Fan 2
10 Cooling Fan 3
11 Starter Solenoid
12 Cooling Fan 1
13 Ignition Main
14 Not Used
15 A/C Clutch
16 Horn
17 Not Used
18 Not Used
19 Fuel Pump
20 Not Used
21 Generator
22 ECM
23 A/C Compressor Clutch
24 Cooling Fan
25 Electronic Ignition
26 TransaxleFuse Description
27 Horn
28 Fuel Injector
29 Oxygen Sensor
30 Engine Emissions
31 Not Used
32 Headlamp (Right)
33 Rear Compartment Release
34 Parking Lamps
35 Fuel Pump
36 Headlamp (Left)
37 Spare
38 Spare
39 Spare
40 Spare
41 Spare
42 Spare
43 Fuse Puller
SYMBOL A/C Compressor Clutch Diode

yellowblue
6-64
Replacement Bulbs
Exterior Lamps Bulb Number
Back
-up 1156. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stop 3155. . . . . . . . . . . . . . .
Front Parking/Turn Signal 4157NAK. . . . . . . . . . .
Headlamp, High Beam 9005. . . . . . . . . . . . . . . . . .
Headlamp, Low Beam 9006. . . . . . . . . . . . . . . . . . .
Stop/Tail/Turn Signal 3057. . . . . . . . . . . . . . . . . . .
Tail (Applique) 194. . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps Bulb Number
Dome Lamp 9425542. . . . . . . . . . . . . . . . . . . . . . .
*For service information on these bulbs, contact your
dealer service department.
Capacities and Specifications
4T60E:
Automatic Transaxle
Pan Removal and Replacement 7.0 quarts (6.7 L). . .
After Complete Overhaul 9.6 quarts (9.2 L). . . . . .
* When draining/replacing converter, more fluid will
be needed.
Cooling System Including
Reservoir 11.6 quarts (10.9 L) . . . . . . . . . . . . . . . . .
Refrigerant (R
-134a),
Air Conditioning*1.88 lbs. (0.85 kg) . . . . . . . . . . .
*See ªAir Conditioning Refrigerantsº later in
this section.
Engine Crankcase
Oil and Filter Change 4.5 quarts (4.3 L). . . . . . . . .
Wheel Nut Torque100 lb
-ft (140 N´m) . . . . . . . . . .
Fuel Tank17.5 gallons (66.2 L) . . . . . . . . . . . . . . . . .
*Note: All capacities are approximate. When adding, be
sure to fill to the approximate level, as recommended in
this manual. See ªRecommended Fluids and Lubricantsº
in the Index.

yellowblue
6-65 Engine Specifications
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 191 CID. . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-2-3-4-5-6 . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 195
F (91
C) . . . . . . . . . . .
Horsepower 160 @ 5200. . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same. If the
air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used. If
you're not sure, ask your dealer.
Normal Maintenance
Replacement Parts
Engine/Air Cleaner Filter AC Type A1208C . . . . .
Passenger Compartment Air Filter 10406026 . . . .
Battery AC Type 600 CCA . . . . . . . . . . . . . . . . . . . .
Engine Oil Filter AC Type PF47 . . . . . . . . . . . . . . . PCV Valve AC Type CV892C . . . . . . . . . . . . . . . . . .
Radiator Cap AC Type RC27 . . . . . . . . . . . . . . . . . .
RKE Batteries Type CR2032 (2) or equivalent . . . .
Spark Plugs
3100 (Code M) V6 AC Type 41
-940 . . . . . . . . . . . .
Gap: 0.060 inches (1.52 mm) . . . . . . . . . . . . . . . . . .
Wiper Blade
Type Hook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Length 22 inches (56 cm). . . . . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Wheelbase 109.0 inches (276.9 cm). . . . . . . . . . . . . .
Tread (Front) 62.0 inches (157.6 cm). . . . . . . . . . . . .
Tread (Rear) 61.1 inches (155.3 cm). . . . . . . . . . . . . .
Overall Length 194.6 inches (494.2 cm). . . . . . . . . . .
Overall Width 72.7 inches (184.5 cm). . . . . . . . . . . . .
Overall Height 56.6 inches (143.8 cm). . . . . . . . . . . .

yellowblue
6-66
-NOTES

7-
yellowblue
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-4 Part A: Scheduled Maintenance Services
7
-5 Scheduled Maintenance
7
-14 Part B: Owner Checks and Services7
-18 Part C: Periodic Maintenance Inspections
7
-20 Part D: Recommended Fluids and Lubricants
7
-21 Part E: Maintenance Record

yellowblue
7-2
Have you purchased the GM Protection Plan? The Plan
supplements your new vehicle warranties. See your
Warranty and Owner Assistance booklet, or your dealer
for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.

yellowblue
7-3 How This Section is Organized
This maintenance schedule is divided into five parts:
ªPart A: Scheduled Maintenance Servicesº shows
what to have done and how often. Some of these
services can be complex, so unless you are technically
qualified and have the necessary equipment, you should
let your dealer's service department or another qualified
service center do these jobs.
CAUTION:
Performing maintenance work on a vehicle can
be dangerous. In trying to do some jobs, you can
be seriously injured. Do your own maintenance
work only if you have the required know
-how
and the proper tools and equipment for the job.
If you have any doubt, have a qualified
technician do the work.
If you are skilled enough to do some work on your
vehicle, you will probably want to get the service
information. See ªService and Owner Publicationsº in
the Index.ªPart B: Owner Checks and Servicesº tells you
what should be checked and when. It also explains what
you can easily do to help keep your vehicle in
good condition.
ªPart C: Periodic Maintenance Inspectionsº
explains important inspections that your dealer's service
department or another qualified service center
should perform.
ªPart D: Recommended Fluids and Lubricantsº
lists some recommended products to help keep your
vehicle properly maintained. These products, or their
equivalents, should be used whether you do the work
yourself or have it done.
ªPart E: Maintenance Recordº provides a place
for you to record the maintenance performed on your
vehicle. Whenever any maintenance is performed, be
sure to write it down in this part. This will help you
determine when your next maintenance should be done.
In addition, it is a good idea to keep your maintenance
receipts. They may be needed to qualify your vehicle for
warranty repairs.

yellowblue
7-4
Part A: Scheduled Maintenance
Services
Using Your Maintenance Schedule
We at General Motors want to help you keep your
vehicle in good working condition. But we don't know
exactly how you'll drive it. You may drive very short
distances only a few times a week. Or you may drive
long distances all the time in very hot, dusty weather.
You may use your vehicle in making deliveries. Or
you may drive it to work, to do errands or in many
other ways.
Because of all the different ways people use their
vehicles, maintenance needs vary. You may need more
frequent checks and replacements. So please read the
following and note how you drive. If you have any
questions on how to keep your vehicle in good
condition, see your dealer.This part tells you the maintenance services you should
have done and when you should schedule them. If you
go to your dealer for your service needs, you'll know
that GM
-trained and supported service people will
perform the work using genuine GM parts.
The proper fluids and lubricants to use are listed in
Part D. Make sure whoever services your vehicle uses
these. All parts should be replaced and all necessary
repairs done before you or anyone else drives
the vehicle.
This schedule is for vehicles that:

carry passengers and cargo within recommended
limits. You will find these limits on your vehicle's
Tire
-Loading Information label. See ªLoading Your
Vehicleº in the Index.

are driven on reasonable road surfaces within legal
driving limits.

use the recommended fuel. See ªFuelº in the Index.
