2-23
LOCK (B): Before you put the key into the ignition
switch, the switch is in LOCK. It's also the only position
from which you can remove your key. This position
locks your ignition, steering wheel and transaxle.
It's a theft
-deterrent feature.
NOTICE:
If your key seems stuck in LOCK and you can't
turn it, be sure you are using the correct key;
if so, is it all the way in? If it is, then turn the
steering wheel left and right while you turn the
key hard. But turn the key only with your hand.
Using a tool to force it could break the key or the
ignition switch. If none of this works, then your
vehicle needs service.
OFF (C): This position lets you turn off the engine but
still turn the steering wheel. It doesn't lock the steering
wheel. Use OFF if you must have your vehicle pushed
or towed.
RUN (D): This position is where the key returns after
you start your vehicle. With the engine off, you can
use RUN to display some of your warning and
indicator lights.
START (E): This position starts your engine.
A warning chime will sound if you open the driver's
door when the ignition is in OFF, LOCK or ACC
and the key is in the ignition.

2-26
4. Before starting the engine, be sure to unplug and
store the cord as it was before to keep it away
from moving engine parts. If you don't, it could
be damaged.
How long should you keep the coolant heater plugged
in? The answer depends on the outside temperature, the
kind of oil you have, and some other things. Instead of
trying to list everything here, we ask that you contact
your dealer in the area where you'll be parking your
vehicle. The dealer can give you the best advice for that
particular area.Automatic Transaxle Operation
Your automatic transaxle will have a shift lever on the
steering column.
The graphic shown above is displayed on your
instrument panel cluster in reference to your steering
column shift lever.
Maximum engine speed is limited on automatic transaxle
vehicles when you're in PARK (P) or NEUTRAL (N) to
protect driveline components from improper operation.

3-4
On cool, but sunny days, the sun may warm your upper
body, but your lower body may not be warm enough.
You can use BI
-LEV and set the temperature levers to a
comfortable setting. The system will bring in outside air
and direct it to your upper body, while sending slightly
warmed air to your lower body. You may notice this
temperature difference more at some times than others.
Push the A/C button on for cooling.
Dual Automatic ComforTemp Climate
Control (If Equipped)
With this system, you set a temperature. You can
then either let the system automatically control airflow
direction and force to maintain the temperature, or you
can manually adjust it. The system works best if you
keep your windows closed while using it.
Automatic Control
For the most efficient operation, you should set the
system temperature and press AUTO. The system will
select the best fan speed and airflow settings to keep
you comfortable. The air conditioning compressor will
run if the outside temperature is above 40
F (4
C).
You may notice a delay of two to three minutes before
the fan comes on at start up in cool weather.
Temperature Control
The TEMP switch sets the temperature for the entire
system when the light on the DUAL button isn't lit.
If the DUAL button light is lit, this master temperature
control sets the temperature for the driver only. Press the
up arrow to raise the temperature and press the down
arrow to lower the temperature. The display will show
your selection for a few seconds, then the outside
temperature will be displayed. If you push the AUTO
button, the system will control the fan speed and airflow.
For the automatic system to function, the temperature
must be set between 61
F (16
C) and 89
F (31
C).
The driver's temperature and passenger's temperature
settings will be automatically maintained even if manual
overrides have been selected except for settings at
60
F (15
C) and 90
F (32
C).

3-5
Setting the temperature to 90
F (32
C) will lock control
in full hot, direct air to the floor, and increase the fan speed
to high. The system will not return to automatic temperature
control until the temperature setting is lowered.
Setting the temperature to 60
F (15
C) will lock control
in full cold, recirculate interior air, direct air to outlets on
panel and increase blower speed to high. The system will
not return to automatic temperature control until the
temperature setting is raised.
Passenger's Temperature Control
The PASSENGER CONTROL buttons with the arrows
adjust the temperature on the passenger's side so it is
warmer or cooler than the temperature for the driver's
side. Push the DUAL button so that the indicator light is
lit. Press the right arrow button to raise the temperature.
Press the left arrow button to lower the temperature.
The display will not show the passenger's temperature,
only that of the driver. Indicators in the passenger control
section will show passenger's side temperature relative to
the driver's set temperature.

The amber light indicates the same temperature as
set for the driver.

The red lights indicate a warmer temperature than
that of the driver.

The blue lights indicate a cooler temperature than
that of the driver.Hot Weather Example: When you start the vehicle
in hot weather, 80F (27C) or after being parked
during the day in full sun, if your driver set temperature
is 75F (23C) and you are in full automatic mode,
the system will automatically move the temperature to
full cold. The fan will be at low speed momentarily
and then go to the high speed. The air intake will be
recirculated for maximum cooling performance.
As the interior of the vehicle cools down to your
desired comfort point, the fan speed will decrease and
the temperature will move to a warmer position to
maintain your desired comfort. As the interior cools
down or the sun load decreases the system could switch
to air delivered to A/C vents and the floor.
Cold Weather Example: When you start the vehicle
in cold weather, (below freezing) or after being parked
overnight. If your Driver Set Temperature is 75F (23C)
and you are in Full Automatic mode, the system will
automatically move the temperature doors to full hot.
The fan will start out at a low speed and will increase to
a higher speed as the engine warms up. The air will be
delivered to the floor. As the interior of the vehicle
warms up to your desired comfort point, the fan speed
will decrease and the temperature will move to a cooler
position to maintain your desired comfort. As the cabin
warms up or the sun load increases the system could
switch to air delivered to the windshield and the floor
(DEFOG mode).

3-6
Manual Control
If you prefer to manually control the heating, cooling and
ventilation in your vehicle, you can select airflow direction,
fan speed, outside or recirculated air, air compressor and
temperature operation with the following:
AIR FLOW: This control has several settings to control
the direction of airflow when the system is not in AUTO.
To access the various modes available, continue to press
the AIR FLOW rocker button up or down until the
desired mode appears in the display:
WINDSHIELD/FLOOR: This setting directs half of
the air to the floor ducts and half to the defroster and
side window vents. The air conditioning compressor
will run automatically in this setting unless the outside
temperature is below 40
F (4
C).
MID/FLOOR: This setting directs half of the air
through the instrument panel outlets. Most of the
remaining air is directed through the floor ducts and
a little to the defroster and side window vents.
MID: This setting directs air through the instrument
panel outlets.FLOOR: This setting sends most of the air through
the ducts near the floor. The rest comes out of the
defroster and side window vents. When in this setting
and the RECIRC setting, the windows can fog up.
See ªRECIRCº in the Index.
FRONT: This setting brings in outside air
and directs most of the air through the defrost vent.
Some of the air also goes to the floor ducts and the side
window defogger outlets. The indicator on the button
will light and WINDSHIELD will be lit in the display.
The air conditioning compressor will run automatically
in this setting unless the outside temperature is below
40
F (4
C).
VENT: This setting turns the air conditioning
compressor on and off. The indicator is lit when the
compressor is turned off. Recirculation is not permitted
when the compressor is off. The system will try to
control the temperature automatically, but without
the compressor.
VENT is not permitted in FRONT defrost mode. If the
VENT button is pushed while in FRONT defrost mode,
the indicator will light briefly and then turn off.

3-7
RECIRC: This setting recirculates much of the air
inside your vehicle. This setting is not permitted in
FRONT defrost mode and is only permitted in
WINDSHIELD/FLOOR mode if the compressor
is turned on. The indicator light will be lit when
recirculation is engaged, but will light briefly and
then turn off if selected when not permitted.
Operating the climate control system in the RECIRC
mode may cause fogging of the vehicle's windows
when the weather is cold and damp. To clear the fog,
switch the system to either WINDSHIELD/FLOOR
or WINDSHIELD mode and increase the fan speed.
To avoid re
-fogging of the windows, operate the
system with RECIRC disengaged.
Defogging and Defrosting
If you have the DUAL COMFORTEMP CLIMATE
CONTROL, your system has two settings for clearing
the front and side windows. To defrost the windows
quickly, press the DEF button with the temperature
knob all the way in the red area.
For maximum defroster performance, set both driver and
passenger temperature controls to the warmest setting.
To warm passengers while keeping the windows clear,
use BLEND.
If you have the DUAL AUTOMATIC COMFORTEMP
CLIMATE CONTROL, your system has two settings
for clearing the front and side windows. To defrost the
windows quickly, press the FRONT button; set the
temperature to 90
F (32
C), select high fan speed
and turn the DUAL button off. To warm passengers
while keeping the windows clear, push the AIR FLOW
button until WINDSHIELD/FLOOR appears in the
display. Select fan speed for comfort and windshield
clearing performance.

3-11
RECALL: Press the upper knob briefly to recall the
station being played or to display the clock. To change
what is normally shown on the display (station or time),
press the knob until you see the display you want, then
hold the knob until the display flashes. If you press the
knob when the ignition is off, the clock will show for a
few seconds.
Finding a Station
AM
-FM: Press the AM-FM button to switch between
AM, FM1 and FM2. The display shows your selection.
TUNE: Turn the lower knob to choose radio stations.
SEEK: Press the right or left arrow to go to the next
higher or lower station and stay there. The sound will
mute while seeking.
SCAN: Press one of the SEEK arrows for two seconds,
and SCAN will appear on the display. Use SCAN to
listen to stations for a few seconds. The radio will go to
a station, stop for a few seconds, then go on to the next
station. Press one of the SEEK arrows again to stop
scanning. The sound will mute while scanning.PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2). Just:
1. Turn the radio on.
2. Press the AM
-FM button to select the band.
3. Tune in the desired station.
4. Press and hold one of the six numbered buttons.
The sound will mute. When it returns, release the
button. Whenever you press that numbered button,
the station you set will return.
5. Repeat the steps for each pushbutton.
P SCAN: Press this button to listen to each of your
preset stations for a few seconds. The radio will go to
the first preset station, stop for a few seconds, then go
on to the next preset station. Press P SCAN again to
stop scanning. The radio will not stop at a preset station
if the station is weak.

3-13
RECALL: Press the upper knob briefly to recall the
station being played or to display the clock. To change
what is normally shown on the display (station or time),
press the knob until you see the display you want, then
hold the knob until the display flashes. If you press the
knob when the ignition is off, the clock will show for a
few seconds.
Finding a Station
AM
-FM: Press the lower knob to switch between AM,
FM1 and FM2. The display shows your selection.
TUNE: Turn the lower knob to choose radio stations.
SEEK: Press the right or left arrow to go to the next
higher or lower station and stay there. The sound will
mute while seeking.
SCAN: Press one of the SEEK arrows for two seconds,
and SCAN will appear on the display. Use SCAN to
listen to stations for a few seconds. The radio will go to
a station, stop for a few seconds, then go on to the next
station. Press one of the SEEK arrows again to stop
scanning. The sound will mute while scanning.PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2). Just:
1. Turn the radio on.
2. Press AM
-FM to select the band.
3. Tune in the desired station.
4. Press and hold one of the six numbered buttons.
The sound will mute. When it returns, release the
button. Whenever you press that numbered button,
the station you set will return.
5. Repeat the steps for each pushbutton.
P SCAN: Press this button to listen to each of your
preset stations for a few seconds. The radio will go to
the first preset station, stop for a few seconds, then go
on to the next preset station. Press P SCAN again to
stop scanning. The radio will not stop at a preset if the
station is weak.

3-14
Setting the Tone
BASS: Press this knob lightly so it extends.
Turn the knob to increase or decrease bass.
TREB: Press this knob lightly so it extends.
Turn the knob to increase or decrease treble.
If a station is weak or noisy, you may want to
decrease the treble.
Push these knobs back into their stored positions
when you're not using them.
Adjusting the Speakers
BAL: Turn the control behind the upper knob to move
the sound to the left or right speakers. The middle
position balances the sound between the speakers.
FADE: Turn the control behind the lower knob to move
the sound to the front or rear speakers. The middle
position balances the sound between the speakers.
Playing a Cassette Tape
The longer side with the tape visible should face to the
right. If the ignition and the radio are on, the tape can be
inserted and will begin playing. If you hear nothing or
hear a garbled sound, the tape may not be in squarely.
Press EJECT to remove the tape and start over.While the tape is playing, use the VOLUME, FADE,
BAL, BASS and TREB controls just as you do for the
radio. Other controls may have different functions when
a tape is inserted. The display will show an arrow to
show which side of the tape is playing.
If you want to insert a tape when the ignition or radio
is off, first press EJECT or RECALL. Cassette tape
adapter kits for portable compact disc players will work
in your cassette tape player.
Your tape bias is set automatically.
If E and a number appear on the radio display, the tape
won't play because of an error.

E10: The tape is tight and the player can't turn
the tape hubs. Remove the tape. Hold the tape with
the open end down and try to turn the right hub
counterclockwise with a pencil. Turn the tape over
and repeat. If the hubs do not turn easily, your tape
may be damaged and should not be used in the
player. Try a new tape to make sure your player is
working properly.

E11: The tape is broken. Try a new tape.
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer. If your radio
displays an error number, write it down and provide
it to your dealer when reporting the problem.

3-15
PREV (1): Press this button to search for the previous
selection on the tape. Your tape must have at least
three seconds of silence between each selection for
PREV to work. The sound will mute while seeking.
NEXT (2): Press this button to search for the next
selection on the tape. Your tape must have at least
three seconds of silence between each selection for
NEXT to work. The sound will mute while seeking.
The SEEK left and right arrows will also find the
previous and next selections on the tape.
 (3): Press this button to reverse the tape rapidly.
Press it again to return to playing speed. The radio will
play while the tape reverses.


(4): Press this button to advance quickly to
another part of the tape. Press the button again to
return to playing speed. The radio will play while the
tape advances.
SIDE (5): Press this button to change the side of the
tape that is playing.
(6): Press this button to reduce background noise.
The display will show either OFF or ON for a few
seconds when you press the button.
Dolby Noise Reduction is manufactured under a
license from Dolby Laboratories Licensing Corporation.
Dolby and the double
-D symbol are trademarks of
Dolby Laboratories Licensing Corporation.
EJECT: Press this button to remove the tape.
The radio will play.
CLN: If this message appears on the display, the
cassette tape player needs to be cleaned. It will still play
tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index. After you
clean the player, press and hold EJECT for five seconds
to reset the CLN indicator. The radio will display
--- to
show the indicator was reset.
