Circuit
BreakersUsage
TIRE RESET Tire In ation Monitor Reset Button
PWR/WNDW
PWR S/ROOFPower Windows, Power Sunroof
R/DEFOG Rear Window Defogger
PWR/ SEAT Power Seat
Blank Not Used
Fuses Usage
PRK/LCK Ignition Key Solenoid
Blank Not Used
Blank Not Used
PCM, BCM,
U/HIgnition Signal: Hot in Run and Start,
Powertrain Control Module, Body
Control Module, Underhood Relay
RADIO PREM.
SOUNDNot Used
PWR MIR Power Mirrors
Blank Not Used
INT/ILLUM Panel Dimming
Blank Not Used
IGN 0: CLSTR,
PCM & BCMIgnition Signal: Hot in Run,
Unlock and Start; Cluster,
Powertrain Control Module,
Body Control Module
Blank Not Used
Blank Not Used
Blank Not Used
ACCY PWR
BUSInterior Lamps
DR/ LCK Door Locks
5-92
Underhood Fuse Block
Some fuses and relays are located in the underhood
fuse block on the passenger’s side of the vehicle in the
engine compartment. SeeEngine Compartment
Overview on page 5-12for more information on location.
Fuses Usage
1 Anti-Lock Brake System
2 Starter Solenoid
3 Power Seat, Rear Window Defogger
4High Blower, Hazard Flasher,
Stoplamps, Power Mirror,
Door Locks
Fuses Usage
5Ignition Switch, Stoplamps,
Anti-Lock Brake System, Turn
Signals, Cluster, Air Bag, Daytime
Running Lamps Module
6 Cooling Fan
7Retained Accessory Power,
Remote Keyless Entry, Data Link,
Heating, Ventilation, and Air
Conditioning Head; Cluster, Radio,
Cigarette Lighter
8Ignition Switch, Wipers, Audio
Steering Wheel Controls, Body
Control Module, Power Windows,
Sunroof, Heating, Ventilation, and
Air Conditioning Controls; Daytime
Running Lamps, Rear Window
Defogger Relay
Relays Usage
9 Cooling Fan 2
10 Cooling Fan 3
11 Starter Solenoid
12 Cooling Fan 1
13 Ignition Main
14 Air Pump (Optional)
5-94
Relays Usage
15 Not Used
16 Horn
17 Fog Lamps
18 Not Used
19 Fuel Pump
Fuses Usage
20 Not Used
21 Generator
22 Engine Control Module
23 Air Conditioner Compressor Clutch
24 Cooling Fan
25 Electronic Ignition
26 Transaxle
27 Horn
28 Fuel Injector
29 Oxygen Sensor
Fuses Usage
30 Engine Emissions
31 Fog Lamps
32 Right Headlamp
33 Rear Compartment Release
34 Parking Lamps
35 Fuel Pump
36 Left Headlamp
37 Not Used
38 Not Used
39 Not Used
40 Not Used
41 Not Used
42 Not Used
43 Not Used
§Air Conditioner Compressor
Clutch Diode
5-95
