Page 177 of 366

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
176 Infotainment System
transferred. The connection process
can take up to two minutes after the
ignition is turned to ON/RUN.
Transferring Audio from the
Bluetooth System to a Cell Phone
During a call with the audio in the
vehicle:1. Press
b/g.
2. Say “Transfer Call.”
Transferring Audio to the
Bluetooth System from a Cell
Phone
During a call with the audio on the
cell phone, press
b/g. The audio
transfers to the vehicle. If the audio
does not transfer to the vehicle, use
the audio transfer feature on the cell
phone. See your cell phone
manufacturer's user guide for more
information.
Voice Pass-Thru
Voice pass-thru allows access to the
voice recognition commands on the
cell phone. See your cell phone
manufacturer's user guide to see if
the cell phone supports this feature. To access contacts stored in the cell
phone:
1. Press
b/g.
2. Say “Bluetooth.” This command
can be skipped.
3. Say “Voice.”The system
responds “OK, accessing
The cell phone's normal prompt
messages will go through their cycle
according to the phone's operating
instructions.
Dual Tone Multi-Frequency
(DTMF) Tones
The Bluetooth system can send
numbers and the numbers stored as
name tags during a call. You can
use this feature when calling a
menu-driven phone system.
Account numbers can also be
stored for use.
Sending a Number or Name Tag
During a Call
1. Press
b/g. The system
responds “Ready,”followed by
a tone. 2. Say
“Dial.”
3. Say the number or name tag to send.
Clearing the System
Unless information is deleted out of
the in-vehicle Bluetooth system, it
will be retained indefinitely. This
includes all saved name tags in the
phone book and phone pairing
information. For information on how
to delete this information, see the
previous section “Deleting a Paired
Phone” and the previous sections
on deleting name tags.
Other Information
The Bluetooth®word mark and
logos are owned by the Bluetooth®
SIG, Inc. and any use of such marks
by General Motors is under license.
Other trademarks and trade names
are those of their respective owners.
See Radio Frequency
Statement 0340.
Page 180 of 366

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
Climate Controls 179
Climate Controls
Climate Control Systems
Dual Automatic ClimateControl System . . . . . . . . . . . . . 179
Rear Climate Control System . . . . . . . . . . . . . . . . . . . . . . 184
Rear Climate Control System (with Rear Seat Audio) . . . . . . 185
Air Vents
Air Vents . . . . . . . . . . . . . . . . . . . . . 186
Maintenance
Passenger Compartment AirFilter . . . . . . . . . . . . . . . . . . . . . . . . 186
Service . . . . . . . . . . . . . . . . . . . . . . . 187
Climate Control Systems
Dual Automatic Climate Control System
The heating, cooling, and ventilation in the vehicle can be controlled with this
system.
1. Driver and Passenger Side
Temperature Controls
2. Air Delivery Mode Controls
3. SYNC (Synchronized Temperature)
4. AUTO (Automatic Operation)
5. REAR (Rear Climate Control) 6. A/C (Air Conditioning)
7. Recirculation
8. Fan Control
9. Rear Window Defogger
10. Defrost
Page 183 of 366

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
182 Climate Controls
The A/C does not work when the
outside temperature is below 4 °C
(40 °F). If A/C is pressed the
indicator flashes three times and
turns off to show that the A/C mode
is not available. If the A/C is on and
the outside temperature drops
below a temperature which is too
cool for air conditioning to be
effective, the A/C indicator turns off
to show that the A/C mode has
been canceled.
On hot days, open the windows
briefly to let hot inside air escape.
This helps reduce the time it takes
for the interior of the vehicle to
cool down.
The air conditioning system
removes moisture from the air, so
water might drip under the vehicle
while idling or after turning off the
engine. This is normal.
@:Press to alternate between
recirculating air inside the vehicle or
pulling in outside air. An indicator
light comes on when recirculation
mode is active. With each ignition
cycle, the recirculation mode is
reset to automatic. When the engine is turned on, outside air or
recirculation is automatically
selected for better performance.
When recirculation is activated, the
air conditioning compressor comes
on and helps to quickly cool the air
inside the vehicle. This mode also
helps to reduce the outside air and
odors that may enter the vehicle.
The recirculation mode cannot be
used with floor, defog, or defrosting
modes. If recirculation is selected in
these modes, the indicator flashes
three times and turns off. While in
recirculation mode the windows can
fog when the weather is cold and
damp. To clear the fog, select either
the defog or defrost mode and
increase the fan speed.
REAR :
Press to turn the rear
heating and air conditioning on or
off. See Rear Climate Control
System 0184 orRear Climate
Control System (with Rear Seat
Audio) 0185.
Rear Window Defogger
The rear window defogger uses a
warming grid to remove fog from the
rear window.
R
1:Press to turn the rear window
defogger on or off. An indicator light
on the button comes on to show that
the rear window defogger is on. Do
not drive the vehicle until all the
windows are clear.
The defogger only works when the
vehicle is in ON/RUN. The defogger
will turn off if the vehicle is
turned off.
If equipped with heated outside
rearview mirrors, fog or frost is
cleared from the surface of the
mirror when the rear window defog
button is pressed.
Caution
Using a razor blade or sharp
object to clear the inside rear
window can damage the rear
window defogger. Repairs would
(Continued)
Page 186 of 366

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
Climate Controls 185
Rear Climate Control System (with Rear Seat Audio)
1. Fan Control
2. Air Delivery Mode Control
3. Temperature Control
If equipped with the rear climate
control system, the controls are on
the rear of the center console.
Press the REAR button on the front
climate control system to control the
rear climate control system. The
system also turns on if any of the
rear controls, except
C, are
pressed. The display is activated
when the rear system is on. The system can also be turned off
by pressing
Cuntil the fan goes off.
Sync Mode : This mode matches
the rear climate control to the front
climate control settings. It comes on
when REAR is pressed.
Independent Mode : This mode
directs rear seating airflow
according to the settings of the rear
controls. It comes on when any rear
control is adjusted.
DandC: Press the fan up or down
buttons to increase or decrease the
fan speed. Temperature Control :
Press + or
− to increase or decrease the air
temperature. The temperature
settings will display in
0-12 increments, going from the
coolest (0) to the warmest (12)
setting.
N: Press to manually change the
direction of the airflow. Repeatedly
press the button until the desired
mode appears on the display.
H: Air is directed through the
overhead outlets.
): Air is directed through the rear
floor outlets, as well as the
overhead outlets.
6: Air is directed through the floor
outlets. The rear system floor
outlets are under the third row
seats.
Page 204 of 366

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
Driving and Operating 203
{Warning
Improper use of the heater cord
or an extension cord can damage
the cord and may result in
overheating and fire.. Plug the cord into a
three-prong electrical utility
receptacle that is protected
by a ground fault detection
function. An ungrounded
outlet could cause an
electric shock.
. Use a weatherproof,
heavy-duty, 15 amp-rated
extension cord if needed.
Failure to use the
recommended extension
cord in good operating
condition, or using a
damaged heater or
extension cord, could make
(Continued)
Warning (Continued)
it overheat and cause a fire,
property damage, electric
shock, and injury.
. Do not operate the vehicle
with the heater cord
permanently attached to the
vehicle. Possible heater
cord and thermostat
damage could occur.
. While in use, do not let the
heater cord touch vehicle
parts or sharp edges. Never
close the hood on the
heater cord.
. Before starting the vehicle,
unplug the cord, reattach
the cover to the plug, and
securely fasten the cord.
Keep the cord away from
any moving parts.
4. Before starting the engine, be sure to unplug and store the
cord as it was before to keep it away from moving engine
parts. If you do not, it could be
damaged.
The length of time the heater should
remain plugged in depends on
several factors. Ask a dealer in the
area where you will be parking the
vehicle for the best advice on this.
Retained Accessory
Power (RAP)
These vehicle accessories can be
used for up to 10 minutes after the
ignition key is turned off:
. Audio System
. Power Windows
. Sunroof (if equipped)
Power to the windows and sunroof
will work up to 10 minutes or until a
door is opened.
The radio continues to work for
10 minutes or until the driver door is
opened.
For an additional 10 minutes of
operation, close all the doors and
turn the key to ON/RUN and then
back to LOCK/OFF.
Page 350 of 366

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
OnStar 349
OnStar Additional
Information
In-Vehicle Audio Messages
Audio messages may play important
information at the following times:
.Prior to vehicle purchase.
Press
Qto set up an account.
. With the OnStar Basic Plan,
every 60 days.
. After change in ownership and
at 90 days.
Transferring Service
PressQto request account transfer
eligibility information. The Advisor
can cancel or change account
information.
Selling/Transferring the
Vehicle
Call 1-888-4ONSTAR
(1-888-466-7827) immediately to
terminate your OnStar services if
the vehicle is disposed of, sold,
transferred, or if the lease ends.
Reactivation for Subsequent
Owners
PressQand follow the prompts to
speak to an Advisor as soon as
possible. The Advisor will update
vehicle records and explain OnStar
service options.
How OnStar Service Works
Automatic Crash Response,
Emergency Services, Crisis Assist,
Stolen Vehicle Assistance,
Advanced Vehicle Diagnostics,
Remote Services, Roadside
Assistance, Turn-by-Turn
Navigation, and Hands-Free Calling
are available on most vehicles. Not
all OnStar services are available
everywhere or on all vehicles. For
more information, a full description
of OnStar services, system
limitations, and OnStar User Terms,
Privacy Statement, and Software
Terms:
. Call 1-888-4ONSTAR
(1-888-466-7827).
. See www.onstar.com (U.S.).
. See www.onstar.ca (Canada). .
Call TTY 1-877-248-2080.
. Press
Qto speak with an
Advisor.
OnStar services cannot work unless
the vehicle is in a place where
OnStar has an agreement with a
wireless service provider for service
in that area. The wireless service
provider must also have coverage,
network capacity, reception, and
technology compatible with OnStar
services. Service involving location
information about the vehicle cannot
work unless GPS signals are
available, unobstructed, and
compatible with the OnStar
hardware. OnStar services may not
work if the OnStar equipment is not
properly installed or it has not been
properly maintained. If equipment or
software is added, connected,
or modified, OnStar services may
not work. Other problems beyond
the control of OnStar —such as
hills, tall buildings, tunnels, weather,
electrical system design and
architecture of the vehicle, damage
Page 356 of 366

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
Index 355
Armrest Storage . . . . . . . . . . . . . . . . . 98
Assistance Program,Roadside . . . . . . . . . . . . . . . . . . . . . . 334
Audio Theft-Deterrent Feature . . . . . . . 155
Audio Players CD . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
MP3 . . . . . . . . . . . . . . . . . . . . . . . . . . 165
Automatic Dimming Mirrors . . . . . . . . . . . . . . . . 41
Door Locks . . . . . . . . . . . . . . . . . . . . . 33
Transmission . . . . . . . . . . . . . . . . . 207
Transmission Fluid . . . . . . . . . . . 244
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . 208
Shift Lock Control FunctionCheck . . . . . . . . . . . . . . . . . . . . . . . 256
Auxiliary Devices . . . . . . . . . . . . . . . . . . . . . . . 167
Avoiding Untrusted Media Devices . . . . . . . . . . . . . . . . . . . . . . . 164
B
Battery
Load Management . . . . . . . . . . . . 152
Power Protection . . . . . . . . . . . . . 153 Battery (cont'd)
Voltage and Charging
Messages . . . . . . . . . . . . . . . . . . . 127
Battery - North America . . . . 255, 297
Blade Replacement, Wiper . . . . . 257
Bluetooth
Overview . . . . . . . . . . . . . . . . . . . . . 170
Brake System Warning Light . . . . . . . . .118
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 253 Antilock . . . . . . . . . . . . . . . . . . . . . . . 210
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 212
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Parking . . . . . . . . . . . . . . . . . . . . . . . .211
System Messages . . . . . . . . . . . . 127
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 190
Break-In, New Vehicle . . . . . . . . . . 199
Bulb Replacement . . . . . . . . . . . . . . 260 Headlamp Aiming . . . . . . . . . . . . . 258
Headlamps . . . . . . . . . . . . . . . . . . . 259
High Intensity Discharge(HID) Lighting . . . . . . . . . . . . . . . 259
License Plate Lamps . . . . . . . . . 259
Taillamps, Turn Signal, and
Stoplamps . . . . . . . . . . . . . . . . . . 259
Buying New Tires . . . . . . . . . . . . . . . 282
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 105
California Fuel Requirements . . . . . . . . . . . 225
Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . 237
California Proposition
65 Warning . . . . . . . . . .237, 255, 297
Camera
Rear Vision (RVC) . . . . . . . . . . . . 216
Canadian Vehicle Owners . . . . . . . . 2
Capacities and Specifications . . . . . . . . . . . . . . . . . 328
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 206
Liftgate . . . . . . . . . . . . . . . . . . . . . . . . . 34
Winter Driving . . . . . . . . . . . . . . . . 193
Cargo
Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Management System . . . . . . . . . . . 99
Tie-Downs . . . . . . . . . . . . . . . . . . . . . . 99
Caution, Danger, and Warning . . . . 2
CD Player . . . . . . . . . . . . . . . . . . . . . . 164
Center Console Storage . . . . . . . . . 98
Chains, Tire . . . . . . . . . . . . . . . . . . . . 286
Charging System Light . . . . . . . . . 115
Page 362 of 366

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
Index 361
Operating ModeOverheated Engine
Protection . . . . . . . . . . . . . . . . . . . 251
Operation Infotainment System . . . . . . . . . . 156
Ordering Service Publications . . . . . . . . . . 339
Outlets Power . . . . . . . . . . . . . . . . . . . . . . . . 108
Overheated Engine Protection Operating Mode . . . . 251
Overheating, Engine . . . . . . . . . . . . 250
Overview . . . . . . . . . . . . . . . . . . . . . . . 156
P
Parade Dimming . . . . . . . . . . . . . . . . 152
Park Shifting Into . . . . . . . . . . . . . . . . . . . 204
Shifting Out of . . . . . . . . . . . . . . . . 205
Tilt Mirrors . . . . . . . . . . . . . . . . . . . . . . 41
Parking
Brake . . . . . . . . . . . . . . . . . . . . . . . . . .211
Brake and P (Park)Mechanism Check . . . . . . . . . . 257
Over Things That Burn . . . . . . . 205
Parking Assist . . . . . . . . . . . . . . . . . . 218
Passenger Airbag Status
Indicator . . . . . . . . . . . . . . . . . . . . . . 114 Passenger Compartment Air
Filter . . . . . . . . . . . . . . . . . . . . . . . . . . 186
Passenger Sensing System . . . . . 72
Perchlorate Materials Requirements, California . . . . . . 237
Personalization Vehicle . . . . . . . . . . . . . . . . . . . . . . . 136
Phone Bluetooth . . . . . . . . . . . . . . . . . . . . . 170
Power Door Locks . . . . . . . . . . . . . . . . . . . . . 33
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Outlets . . . . . . . . . . . . . . . . . . . . . . . 108
Protection, Battery . . . . . . . . . . . . 153
Retained Accessory (RAP) . . . 203
Seat Adjustment . . . . . . . . . . . . . . . . 48
Steering Fluid . . . . . . . . . . . . . . . . . 252
Windows . . . . . . . . . . . . . . . . . . . . . . . 42
Pregnancy, Using Safety Belts . . . 63
Privacy Vehicle Data Recording . . . . . . . 341
Program Courtesy Transportation . . . . . . 336
Proposition 65 Warning,
California . . . . . . . . . . . .237, 255, 297
R
Radio Frequency Statement . . . . 340
Radio Reception . . . . . . . . . . . . . . . . 162
RadiosAM-FM Radio . . . . . . . . . . . . . . . . . 159
Satellite . . . . . . . . . . . . . . . . . . . . . . . 162
Reading Lamps . . . . . . . . . . . . . . . . . 151
Rear Climate Control System . . . . . . . . . . . . . . . . . . . 184, 185
Rear Seat Audio (RSA)
System . . . . . . . . . . . . . . . . . . . . . . . . 169
Rear Seats . . . . . . . . . . . . . . . . . . . . . . 53
Rear Vision Camera (RVC) . . . . . 216
Rear Window Washer/Wiper . . . . 105
Rearview Mirrors Automatic Dimming . . . . . . . . . . . . . 41
Reclining Seatbacks . . . . . . . . . . . . . 49
Recommended Fluids and Lubricants . . . . . . . . . . . . . . . . . . . . . 324
Records Maintenance . . . . . . . . . . . . . . . . . . 326
Recreational Vehicle Towing . . . . 300
Reimbursement Program, GM Mobility . . . . . . . . . . . . . . . . . . . 334
Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . . . . . . . . . . . . 29
Remote Vehicle Start . . . . . . . . . . . . 31
Replacement Bulbs . . . . . . . . . . . . . 260
Page 364 of 366

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
Index 363
Shift Lock Control FunctionCheck, Automatic
Transmission . . . . . . . . . . . . . . . . . . 256
Shifting Into Park . . . . . . . . . . . . . . . . . . . . . . 204
Out of Park . . . . . . . . . . . . . . . . . . . 205
Side Blind Zone Alert (SBZA) . . . 221
Signals, Turn and
Lane-Change . . . . . . . . . . . . . . . . . 149
Spare Tire Compact . . . . . . . . . . . . . . . . . . . . . . 296
Special Application Services . . . . 321
Specifications and Capacities . . . . . . . . . . . . . . . . . . . . . 328
Speedometer . . . . . . . . . . . . . . . . . . . 111
StabiliTrak Indicator Light . . . . . . . . . . . . . . . . .119
Start Assist, Hill . . . . . . . . . . . . . . . . . 212
Start Vehicle, Remote . . . . . . . . . . . 31
Starter Switch Check . . . . . . . . . . . 256
Starting the Engine . . . . . . . . . . . . . 201
Steering . . . . . . . . . . . . . . . . . . . . . . . . 190 Fluid, Power . . . . . . . . . . . . . . . . . . 252
Wheel Adjustment . . . . . . . . . . . . 103
Wheel Controls . . . . . . . . . . . . . . . 104
Storage Areas Armrest . . . . . . . . . . . . . . . . . . . . . . . . . 98
Cargo Cover . . . . . . . . . . . . . . . . . . . . 99 Storage Areas (cont'd)
Cargo Management System . . . . 99
Center Console . . . . . . . . . . . . . . . . . 98
Convenience Net . . . . . . . . . . . . . 100
Glove Box . . . . . . . . . . . . . . . . . . . . . . 97
Instrument Panel . . . . . . . . . . . . . . . 97
Roof Rack System . . . . . . . . . . . . 100
Storage Compartments . . . . . . . . . . 97
Stuck Vehicle . . . . . . . . . . . . . . . . . . . 195
Summer Tires . . . . . . . . . . . . . . . . . . 269
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . 44
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Forward CollisionAlert (FCA) . . . . . . . . . . . . . . . . . . 220
Infotainment . . . . . . . . . . . . . 154, 343
Rear Seat Audio (RSA) . . . . . . . 169
Roof Rack . . . . . . . . . . . . . . . . . . . . 100
T
Tachometer . . . . . . . . . . . . . . . . . . . . . 111
Taillamps Turn Signal and Stoplamps . . . 259
Text Telephone (TTY) Users . . . . 333
Theft-Deterrent Systems . . . . . . . . . 38 Immobilizer . . . . . . . . . . . . . . . . . . . . . 38
Third-Row Seats . . . . . . . . . . . . . . . . . 55
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107 Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
All-Season . . . . . . . . . . . . . . . . . . . . 268
Buying New Tires . . . . . . . . . . . . . 282
Chains . . . . . . . . . . . . . . . . . . . . . . . . 286
Changing . . . . . . . . . . . . . . . . . . . . . 288
Compact Spare . . . . . . . . . . . . . . . 296
Designations . . . . . . . . . . . . . . . . . 272
Different Size . . . . . . . . . . . . . . . . . 283
If a Tire Goes Flat . . . . . . . . . . . . 287
Inspection . . . . . . . . . . . . . . . . . . . . 280
Messages . . . . . . . . . . . . . . . . . . . . 133
Pressure . . . . . . . . . . . . . . . . . . . . . . 275
Pressure Light . . . . . . . . . . . . . . . . 120
Pressure Monitor Operation . . 277
Pressure Monitor System . . . . . 276
Rotation . . . . . . . . . . . . . . . . . . . . . . 280
Sidewall Labeling . . . . . . . . . . . . . 270
Terminology and Definitions . . 272
Uniform Tire Quality
Grading . . . . . . . . . . . . . . . . . . . . . 284
Wheel Alignment and Tire
Balance . . . . . . . . . . . . . . . . . . . . . 285
Wheel Replacement . . . . . . . . . . 286
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 281
Winter . . . . . . . . . . . . . . . . . . . . . . . . 269
Tow/Haul Mode . . . . . . . . . . . . . . . . . 209
Tow/Haul Mode Light . . . . . . . . . . . 119
