roof rack BUICK ENCLAVE 2017 Owner's Manual

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
Keys, Doors, and Windows 45
Dirt and debris may collect on the
sunroof seal or in the track. This
could cause an issue with sunroof
operation or noise. It could also plug
the water drainage system.
Periodically open the sunroof and
remove any obstacles or loose
debris. Wipe the sunroof seal and
roof sealing area using a clean
cloth, mild soap, and water. Do not
remove grease from the sunroof.
If water is seen dripping into the
water drainage system, this is
normal.
Manual Sunshade
The sunshades must be opened
and closed manually. To open the
sunshade, press the button on the
sunshade handle to release it and
guide it back. To close the
sunshade, pull the sunshade
forward until it latches.

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
Storage 97
Storage
Storage Compartments
Storage Compartments . . . . . . . . 97
Instrument Panel Storage . . . . . . 97
Glove Box . . . . . . . . . . . . . . . . . . . . . 97
Cupholders . . . . . . . . . . . . . . . . . . . . 97
Armrest Storage . . . . . . . . . . . . . . . 98
Center Console Storage . . . . . . . 98
Additional Storage Features
Cargo Cover . . . . . . . . . . . . . . . . . . . 99
Cargo Tie-Downs . . . . . . . . . . . . . . 99
Cargo Management System . . . 99
Convenience Net . . . . . . . . . . . . . 100
Roof Rack System
Roof Rack System . . . . . . . . . . . 100
Storage
Compartments
{Warning
Do not store heavy or sharp
objects in storage compartments.
In a crash, these objects may
cause the cover to open and
could result in injury.
Instrument Panel Storage
This vehicle has an instrument
panel storage area. To open, press
the button on the cover.The vehicle has an auxiliary input
jack on the upper right side of the
faceplate and a USB port in the
instrument panel storage. See
Auxiliary Devices
0167.
Glove Box
Lift the glove box handle to open it.
Use the key to lock and unlock the
glove box.
Cupholders
There are two cupholders, with
removable liners, in front of the
center console. There may be
cupholders in the second row seat
armrest. To access, pull the armrest
down. There are additional
cupholders on each side of the third
row seat and in each door.

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
100 Storage
Convenience Net
1. Cargo Cover
2. Cargo Cover Hooks
3. Cargo Tie-Downs
4. Convenience Net
For vehicles with a convenience
net (4), attach it to the vehicle using
only the cargo tie-downs (3) on
each side. The net is used to store
small loads and should not be used
for heavy loads.
The cargo cover hooks (2) are used
to attach the cargo cover (1) to the
vehicle only. Do not use the hooks
to secure loads or other items to the
vehicle as the hooks could be
damaged.Roof Rack System
{Warning
If something is carried on top of
the vehicle that is longer or wider
than the roof rack—like paneling,
plywood, or a mattress —the
wind can catch it while the vehicle
is being driven. The item being
carried could be violently torn off,
and this could cause a collision
and damage the vehicle. Never
carry something longer or wider
than the roof rack on top of the
vehicle unless using a GM
certified accessory carrier.
For vehicles with a roof rack, the
rack can be used to load items. For
roof racks that do not have
crossrails included, GM Certified
crossrails can be purchased as an
accessory. See your dealer for
additional information.

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
Storage 101
Caution
Loading cargo on the roof rack
that weighs more than 91 kg
(200 lb) or hangs over the rear or
sides of the vehicle may damage
the vehicle. Load cargo so that it
rests evenly between the
crossrails and fasten cargo
securely.
To prevent damage or loss of cargo
when driving, check to make sure
crossrails and cargo are securely
fastened. Loading cargo on the roof
rack will make the vehicle’ s center
of gravity higher. Avoid high speeds,
sudden starts, sharp turns, sudden
braking, or abrupt maneuvers;
otherwise it may result in loss of
control. If driving for a long distance,
on rough roads, or at high speeds,
occasionally stop the vehicle to
make sure the cargo remains in its
place. Do not exceed the maximum
vehicle capacity when loading the
vehicle.
See Vehicle Load Limits 0195.

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
Service and Maintenance 317
.Check automatic transmission
shift lock control function. See
Automatic Transmission Shift
Lock Control Function
Check 0256.
. Check ignition transmission lock.
See Ignition Transmission Lock
Check 0257.
. Check parking brake and
automatic transmission park
mechanism. See Park Brake and
P (Park) Mechanism
Check 0257.
. Check accelerator pedal for
damage, high effort, or binding.
Replace if needed.
. Visually inspect gas strut for
signs of wear, cracks, or other
damage. Check the hold open
ability of the strut. See your
dealer if service is required.
. Inspect sunroof track and seal,
if equipped. See Sunroof044.

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
362 Index
Replacement PartsAirbags . . . . . . . . . . . . . . . . . . . . . . . . . 77
Maintenance . . . . . . . . . . . . . . . . . . 325
Replacing Airbag System . . . . . . . . 77
Replacing LATCH System Parts after a Crash . . . . . . . . . . . . . 91
Replacing Safety Belt System
Parts after a Crash . . . . . . . . . . . . . 65
Reporting Safety Defects Canadian Government . . . . . . . . 341
General Motors . . . . . . . . . . . . . . . 341
U.S. Government . . . . . . . . . . . . . 340
Restraints Where to Put . . . . . . . . . . . . . . . . . . . 84
Retained Accessory Power (RAP) . . . . . . . . . . . . . . . . . . 203
Ride Control Systems Messages . . . . . . . . . . . . . . . . . . . . 132
Roads Driving, Wet . . . . . . . . . . . . . . . . . . 192
Roadside Assistance
Program . . . . . . . . . . . . . . . . . . . . . . . 334
Roof Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . 44
Roof Rack System . . . . . . . . . . . . . . 100
Rotation, Tires . . . . . . . . . . . . . . . . . . 280 Routing, Engine Drive Belt . . . . . . 329
Running the Vehicle While
Parked . . . . . . . . . . . . . . . . . . . . . . . . 206
S
Safety Belts . . . . . . . . . . . . . . . . . . . . . 57Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Extender . . . . . . . . . . . . . . . . . . . . . . . . 64
How to Wear Safety Belts
Properly . . . . . . . . . . . . . . . . . . . . . . . 58
Lap-Shoulder Belt . . . . . . . . . . . . . . 59
Reminders . . . . . . . . . . . . . . . . . . . . .113
Replacing after a Crash . . . . . . . . 65
Use During Pregnancy . . . . . . . . . . 63
Safety Defects Reporting Canadian Government . . . . . . . . 341
General Motors . . . . . . . . . . . . . . . 341
U.S. Government . . . . . . . . . . . . . 340
Safety Locks . . . . . . . . . . . . . . . . . . . . . 34
Safety System Check . . . . . . . . . . . . 64
Satellite Radio . . . . . . . . . . . . . . . . . . 162
Scheduling Appointments . . . . . . . 336
Seats Head Restraints . . . . . . . . . . . . . . . . 47
Lumbar Adjustment, Front . . . . . . 49
Memory . . . . . . . . . . . . . . . . . . . . . . . . . 50
Power Adjustment, Front . . . . . . . 48 Seats (cont'd)
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Reclining Seatbacks . . . . . . . . . . . . 49
Third Row Seat . . . . . . . . . . . . . . . . . 55
Securing Child Restraints . . . . 92, 94
Security Light . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Messages . . . . . . . . . . . . . . . . . . . . 133
OnStar
®. . . . . . . . . . . . . . . . . . . . . . 345
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . 37
Vehicle Alarm . . . . . . . . . . . . . . . . . . . 37
Service . . . . . . . . . . . . . . . . . . . . . . . . . 187 Accessories andModifications . . . . . . . . . . . . . . . . 237
Doing Your Own Work . . . . . . . . 238
Engine Soon Light . . . . . . . . . . . . .116
Maintenance Records . . . . . . . . 326
Maintenance, General Information . . . . . . . . . . . . . . . . . . 314
Parts Identification Label . . . . . 327
Publications Ordering Information . . . . . . . . . . . . . . . . . . 339
Scheduling Appointments . . . . . 336
Vehicle Messages . . . . . . . . . . . . 133
Services Special Application . . . . . . . . . . . 321
Servicing the Airbag . . . . . . . . . . . . . 76
Settings . . . . . . . . . . . . . . . . . . . . . . . . 177

Buick Enclave Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
9955666) - 2017 - crc - 8/4/16
Index 363
Shift Lock Control FunctionCheck, Automatic
Transmission . . . . . . . . . . . . . . . . . . 256
Shifting Into Park . . . . . . . . . . . . . . . . . . . . . . 204
Out of Park . . . . . . . . . . . . . . . . . . . 205
Side Blind Zone Alert (SBZA) . . . 221
Signals, Turn and
Lane-Change . . . . . . . . . . . . . . . . . 149
Spare Tire Compact . . . . . . . . . . . . . . . . . . . . . . 296
Special Application Services . . . . 321
Specifications and Capacities . . . . . . . . . . . . . . . . . . . . . 328
Speedometer . . . . . . . . . . . . . . . . . . . 111
StabiliTrak Indicator Light . . . . . . . . . . . . . . . . .119
Start Assist, Hill . . . . . . . . . . . . . . . . . 212
Start Vehicle, Remote . . . . . . . . . . . 31
Starter Switch Check . . . . . . . . . . . 256
Starting the Engine . . . . . . . . . . . . . 201
Steering . . . . . . . . . . . . . . . . . . . . . . . . 190 Fluid, Power . . . . . . . . . . . . . . . . . . 252
Wheel Adjustment . . . . . . . . . . . . 103
Wheel Controls . . . . . . . . . . . . . . . 104
Storage Areas Armrest . . . . . . . . . . . . . . . . . . . . . . . . . 98
Cargo Cover . . . . . . . . . . . . . . . . . . . . 99 Storage Areas (cont'd)
Cargo Management System . . . . 99
Center Console . . . . . . . . . . . . . . . . . 98
Convenience Net . . . . . . . . . . . . . 100
Glove Box . . . . . . . . . . . . . . . . . . . . . . 97
Instrument Panel . . . . . . . . . . . . . . . 97
Roof Rack System . . . . . . . . . . . . 100
Storage Compartments . . . . . . . . . . 97
Stuck Vehicle . . . . . . . . . . . . . . . . . . . 195
Summer Tires . . . . . . . . . . . . . . . . . . 269
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . 44
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Forward CollisionAlert (FCA) . . . . . . . . . . . . . . . . . . 220
Infotainment . . . . . . . . . . . . . 154, 343
Rear Seat Audio (RSA) . . . . . . . 169
Roof Rack . . . . . . . . . . . . . . . . . . . . 100
T
Tachometer . . . . . . . . . . . . . . . . . . . . . 111
Taillamps Turn Signal and Stoplamps . . . 259
Text Telephone (TTY) Users . . . . 333
Theft-Deterrent Systems . . . . . . . . . 38 Immobilizer . . . . . . . . . . . . . . . . . . . . . 38
Third-Row Seats . . . . . . . . . . . . . . . . . 55
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107 Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
All-Season . . . . . . . . . . . . . . . . . . . . 268
Buying New Tires . . . . . . . . . . . . . 282
Chains . . . . . . . . . . . . . . . . . . . . . . . . 286
Changing . . . . . . . . . . . . . . . . . . . . . 288
Compact Spare . . . . . . . . . . . . . . . 296
Designations . . . . . . . . . . . . . . . . . 272
Different Size . . . . . . . . . . . . . . . . . 283
If a Tire Goes Flat . . . . . . . . . . . . 287
Inspection . . . . . . . . . . . . . . . . . . . . 280
Messages . . . . . . . . . . . . . . . . . . . . 133
Pressure . . . . . . . . . . . . . . . . . . . . . . 275
Pressure Light . . . . . . . . . . . . . . . . 120
Pressure Monitor Operation . . 277
Pressure Monitor System . . . . . 276
Rotation . . . . . . . . . . . . . . . . . . . . . . 280
Sidewall Labeling . . . . . . . . . . . . . 270
Terminology and Definitions . . 272
Uniform Tire Quality
Grading . . . . . . . . . . . . . . . . . . . . . 284
Wheel Alignment and Tire
Balance . . . . . . . . . . . . . . . . . . . . . 285
Wheel Replacement . . . . . . . . . . 286
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 281
Winter . . . . . . . . . . . . . . . . . . . . . . . . 269
Tow/Haul Mode . . . . . . . . . . . . . . . . . 209
Tow/Haul Mode Light . . . . . . . . . . . 119
