Page 76 of 377
Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032235) - 2019 - CRC - 6/27/18
Seats and Restraints 75
Warning (Continued)
Occupants should not lean on or
sleep against the door or side
windows in seating positions with
seat-mounted side impact airbags
and/or roof-rail airbags.
{Warning
Children who are up against,
or very close to, any airbag when
it inflates can be seriously injured
or killed. Always secure children
properly in the vehicle. To read
how, seeOlder Children 086 or
Infants and Young Children 088.
There is an airbag readiness light
on the instrument cluster, which
shows the airbag symbol. The
system checks the airbag electrical
system for malfunctions. The light
tells you if there is an electrical
problem. See Airbag Readiness
Light 0130.
Where Are the Airbags?
The driver frontal airbag is in the
center of the steering wheel.
The front outboard passenger
frontal airbag is in the passenger
side instrument panel.
The driver knee airbag is below the
steering column. The front outboard
passenger knee airbag is below the
glove box.
Page 106 of 377
Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032235) - 2019 - CRC - 6/27/18
Storage 105
Storage
Storage Compartments
Storage Compartments . . . . . . . 105
Glove Box . . . . . . . . . . . . . . . . . . . . 105
Cupholders . . . . . . . . . . . . . . . . . . . 105
Front Storage . . . . . . . . . . . . . . . . . 106
Sunglasses Storage . . . . . . . . . . 106
Rear Storage . . . . . . . . . . . . . . . . . 106
Center Console Storage . . . . . . 107
Additional Storage Features
Cargo Cover . . . . . . . . . . . . . . . . . . 108
Cargo Tie-Downs . . . . . . . . . . . . . 108
Cargo ManagementSystem . . . . . . . . . . . . . . . . . . . . . . 109
Convenience Net . . . . . . . . . . . . . 110
Roof Rack System
Roof Rack System . . . . . . . . . . . . 110
Storage
Compartments
{Warning
Do not store heavy or sharp
objects in storage compartments.
In a crash, these objects may
cause the cover to open and
could result in injury.
Glove Box
Open the glove box by lifting up on
the lever.
Cupholders
Front
There are two cupholders in the
center console. Rear
Cupholders may be located in the
second row seat armrest. To
access, pull the armrest down.
Page 175 of 377
Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032235) - 2019 - CRC - 6/27/18
174 Climate Controls
Air Vents
1. Slider Knob
2. Thumbwheel
Use the slider knobs (1) on the air
vents to change the direction of the
airflow.
Use the thumbwheels (2) near the
air vents to control the amount of
airflow or to shut off the airflow. Operation Tips
.
Clear away any ice, snow,
or leaves from the air inlets at
the base of the windshield that
can block the flow of air into the
vehicle.
. Clear snow off the hood to
improve visibility and help
decrease moisture drawn into
the vehicle.
. Keep all outlets open whenever
possible for best system
performance.
. Keep the path under all seats
clear of objects to help circulate
the air inside the vehicle more
effectively.
. Use of non-GM approved hood
deflectors can adversely affect
the performance of the system.
Maintenance
Passenger Compartment
Air Filter
The filter removes dust, pollen, and
other airborne irritants from outside
air that is pulled into the vehicle.
The filter should be replaced as part
of routine scheduled maintenance;
see Maintenance Schedule 0323.
To find out what type of filter to use,
see Maintenance Replacement
Parts 0333.
1. Open the glove box.
Page 176 of 377
Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032235) - 2019 - CRC - 6/27/18
Climate Controls 175
2. Remove the glove boxrear wall.
3. Disconnect the glove box door damper string from the glove
box door assembly. A pen or
pencil may be inserted through
the end of the damper string to
prevent the string from slipping
inside the housing assembly.
4. Squeeze both sides of the glove box bin inward to lower
beyond the stops.5. Release the latches on eitherside of the service door. Open
the service door and remove
the old filter.
6. Install the new air filter.
7. Close the service door completely.
8. Reverse the steps to reinstall the glove box.
See your dealer if additional
assistance is needed.
Service
All vehicles have a label underhood
that identifies the refrigerant used in
the vehicle. The refrigerant system
should only be serviced by trained
and certified technicians. The air
conditioning evaporator should
never be repaired or replaced by
one from a salvage vehicle.
It should only be replaced by a new
evaporator to ensure proper and
safe operation.
During service, all refrigerants
should be reclaimed with proper
equipment. Venting refrigerants
directly to the atmosphere is harmful
to the environment and may also
create unsafe conditions based on
inhalation, combustion, frostbite,
or other health-based concerns.
The air conditioning system requires
periodic maintenance. See
Maintenance Schedule 0323.
Page 275 of 377
Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032235) - 2019 - CRC - 6/27/18
274 Vehicle Care
Instrument Panel Fuse
Block
The instrument panel fuse block is
in the glove box. To access the
fuses, open the fuse panel door
from the passenger side by pulling
it out.
To reinstall the door, insert the tabs
on the top of the door into the
console first, then push the door
back into its original location.
The vehicle may not be equipped
with all of the fuses, relays, and
features shown.
FusesUsage
F1 –
F2 Front HVAC blower
F3 Power seat
F4 Lighter (China only)
F5 –
F6 Front power windows Fuses
Usage
F7 –
F8 Mid accessory power outlet
F9 Body control module 8
F10 Rear power windows F11 –
Page 370 of 377
Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032235) - 2019 - CRC - 6/27/18
Index 369
Frequency StatementRadio . . . . . . . . . . . . . . . . . . . . . . . . . 349
Front Fog Lamp Light . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Front Seats Heated and Ventilated . . . . . . . . . . 61
Front Storage . . . . . . . . . . . . . . . . . . . 106
Fuel
Additives . . . . . . . . . . . . . . . . . . . . . 231
Economy Driving . . . . . . . . . . . . . . . 25
Filling a Portable FuelContainer . . . . . . . . . . . . . . . . . . . 233
Filling the Tank . . . . . . . . . . . . . . . 232
Foreign Countries . . . . . . . . . . . . 231
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 126
Low Fuel Warning Light . . . . . . . 138
Prohibited Fuels . . . . . . . . . . . . . . 231
Recommended . . . . . . . . . . . . . . . 230
Top Tier . . . . . . . . . . . . . . . . . . . . . . 230
Fuses Engine Compartment Fuse
Block . . . . . . . . . . . . . . . . . . . . . . . . 271
Fuses and Circuit Breakers . . . 271
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 274
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 275G
Garage Door Opener . . . . . . . . . . . 157Programming . . . . . . . . . . . . . . . . . 157
Gas Strut(s) . . . . . . . . . . . . . . . . . . . . 267
Gauges Engine CoolantTemperature . . . . . . . . . . . . . . . . 128
Engine Oil Temperature . . . . . . . 127
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Odometer . . . . . . . . . . . . . . . . . . . . . 125
Speedometer . . . . . . . . . . . . . . . . . 125
Tachometer . . . . . . . . . . . . . . . . . . . 125
Trip Odometer . . . . . . . . . . . . . . . . 125
Voltmeter . . . . . . . . . . . . . . . . . . . . . 129
Warning Lights and Indicators . . . . . . . . . . . . . . . . . . . 121
General Information Service and Maintenance . . . . . 321
Towing . . . . . . . . . . . . . . . . . . . . . . . . 234
Vehicle Care . . . . . . . . . . . . . . . . . . 244
Glove Box . . . . . . . . . . . . . . . . . . . . . . 105
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 343
H
Halogen Bulbs . . . . . . . . . . . . . . . . . . 269
Hazard Warning Flashers . . . . . . . 163
Head Restraints . . . . . . . . . . . . . . . . . 54
Head-up Display . . . . . . . . . . . . . . . . 145
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . 268
Automatic . . . . . . . . . . . . . . . . . . . . . 163
Bulb Replacement . . . . . . . . . . . . 269
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . 162
Flash-to-Pass . . . . . . . . . . . . . . . . . 162
High Intensity Discharge (HID) Lighting . . . . . . . . . . . . . . . 269
High-Beam On Light . . . . . . . . . . 139
High/Low Beam Changer . . . . . 162
Lamps On Reminder . . . . . . . . . 139
Washer . . . . . . . . . . . . . . . . . . . . . . . .116
Heated
Rear Seats . . . . . . . . . . . . . . . . . . . . . 65
Steering Wheel . . . . . . . . . . . . . . . .113
Heated and Ventilated Front Seats . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Heated Mirrors . . . . . . . . . . . . . . . . . . . 47
Heater
Engine . . . . . . . . . . . . . . . . . . . . . . . . 193
Heating . . . . . . . . . . . . . . . . . . . . 169, 172
High-Beam On Light . . . . . . . . . . . . 139
Page 375 of 377
Buick Envision Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
12032235) - 2019 - CRC - 6/27/18
374 Index
Steering (cont'd)Wheel Adjustment . . . . . . . . . . . . .113
Wheel Controls . . . . . . . . . . . . . . . .113
Stop/Start System . . . . . . . . . . . . . . 191
Storage
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Storage Areas Cargo Cover . . . . . . . . . . . . . . . . . . 108
Cargo ManagementSystem . . . . . . . . . . . . . . . . . . . . . . 109
Center Console . . . . . . . . . . . . . . . 107
Convenience Net . . . . . . . . . . . . . .110
Front . . . . . . . . . . . . . . . . . . . . . . . . . 106
Glove Box . . . . . . . . . . . . . . . . . . . . 105
Roof Rack System . . . . . . . . . . . . .110
Sunglasses . . . . . . . . . . . . . . . . . . . 106
Storage Compartments . . . . . . . . . 105
Struts Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Stuck Vehicle . . . . . . . . . . . . . . . . . . . 184
Summer Tires . . . . . . . . . . . . . . . . . . 279
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . 50
Sunglass Storage . . . . . . . . . . . . . . . 106
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Forward CollisionAlert (FCA) . . . . . . . . . . . . . . . . . . 222 System (cont'd)
Infotainment . . . . . . . . . . . . . 168, 352
Roof Rack . . . . . . . . . . . . . . . . . . . . .110
Systems
Driver Assistance . . . . . . . . . . . . . 215
T
Tachometer . . . . . . . . . . . . . . . . . . . . . 125
Text Telephone (TTY) Users . . . . 342
Theft-Deterrent Systems . . . . . . . . . 46Immobilizer . . . . . . . . . . . . . . . . . . . . . 46
Thigh Support Adjustment . . . . . . . 57
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . 277 All-Season . . . . . . . . . . . . . . . . . . . . 278
Buying New Tires . . . . . . . . . . . . . 293
Chains . . . . . . . . . . . . . . . . . . . . . . . . 297
Changing . . . . . . . . . . . . . . . . . . . . . 299
Compact Spare . . . . . . . . . . . . . . . 304
Designations . . . . . . . . . . . . . . . . . 281
Different Size . . . . . . . . . . . . . . . . . 294
If a Tire Goes Flat . . . . . . . . . . . . 297
Inspection . . . . . . . . . . . . . . . . . . . . 291
Pressure . . . . . . . . . . . . . . . . . . . . . . 284
Pressure Light . . . . . . . . . . . . . . . . 137
Pressure Monitor Operation . . 287
Pressure Monitor System . . . . . 286
Rotation . . . . . . . . . . . . . . . . . . . . . . 291 Tires (cont'd)
Sidewall Labeling . . . . . . . . . . . . . 279
Terminology and Definitions . . 282
Uniform Tire Quality
Grading . . . . . . . . . . . . . . . . . . . . . 294
Wheel Alignment and Tire Balance . . . . . . . . . . . . . . . . . . . . . 296
Wheel Replacement . . . . . . . . . . 296
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 292
Winter . . . . . . . . . . . . . . . . . . . . . . . . 278
Top Tier Fuel . . . . . . . . . . . . . . . . . . . 230
Towing Driving Characteristics . . . . . . . . 234
Equipment . . . . . . . . . . . . . . . . . . . . 240
General Information . . . . . . . . . . 234
Recreational Vehicle . . . . . . . . . . 309
Trailer . . . . . . . . . . . . . . . . . . . . . . . . 238
Vehicle . . . . . . . . . . . . . . . . . . . . . . . 307
Traction Control System(TCS)/StabiliTrak Light . . . . . . 137
Off Light . . . . . . . . . . . . . . . . . . . . . . 136
Traction Control/Electronic Stability Control . . . . . . . . . . . . . . . 203
Trailer Towing . . . . . . . . . . . . . . . . . . . . . . . . 238
