6-26 How to Check Power Steering Fluid
When the engine compartment is cool, wipe the cap and
the top of the reservoir clean, then unscrew the cap and
wipe the dipstick with a clean rag. Replace the cap and
completely tighten it. Then remove the cap again and
look at the fluid level on the dipstick.
The level should be at the FULL COLD mark. If
necessary, add only enough fluid to bring the level up to
the mark.
What to Use
To determine what kind of fluid to use, see
ªRecommended Fluids and Lubricantsº in the Index.
Always use the proper fluid. Failure to use the proper
fluid can cause leaks and damage hoses and seals.
Windshield Washer Fluid
What to Use
When you need windshield washer fluid, be sure to read
the manufacturer's instructions before use. If you will be
operating your vehicle in an area where the temperature
may fall below freezing, use a fluid that has sufficient
protection against freezing.
Adding Washer Fluid
Open the cap labeled WASHER FLUID ONLY. Add
washer fluid until the tank is full.

yellowblue
6-66 L36 Engine Accessory Belt
The L36 engine uses an engine accessory belt. This
diagram shows the features connected and the routing.
See ªMaintenance Scheduleº in the Index for when to
check the belt.
A. Power Steering
B. Generator
C. Air Conditioning
D. Crank
E. Coolant Pump
F. Tensioner

Short Trip/City Scheduled Maintenance
yellowblue
7-7
The services shown in this schedule up to 100,000 miles
(166 000 km) should be performed after 100,000 miles
(166 000 km) at the same intervals. The services shown
at 150,000 miles (240 000 km) should be performed at
the same interval after 150,000 miles (240 000 km).
See ªOwner Checks and Servicesº and ªPeriodic
Maintenance Inspectionsº following.
Footnotes

The U.S. Environmental Protection Agency or the
California Air Resources Board has determined that the
failure to perform this maintenance item will not nullify
the emission warranty or limit recall liability prior to the
completion of the vehicle's useful life. We, however,
urge that all recommended maintenance services be
performed at the indicated intervals and the maintenance
be recorded.# Lubricate the suspension and steering linkage,
transaxle shift linkage, parking brake cable guides and
underbody contact points.
* If your vehicle has an Engine Oil Life Monitor, the
monitor will show you when to change the oil
-- usually
between 3,000 miles (5 000 km) and 7,500 miles
(12 500 km) since your last oil change. Under severe
conditions, the indicator may come on before
3,000 miles (5 000 km). Never drive your vehicle more
than 7,500 miles (12 500 km) or 12 months, (whichever
occurs first), without an oil change.

Long Trip/Highway Scheduled Maintenance
yellowblue
7-23
The services shown in this schedule up to 100,000 miles
(166 000 km) should be performed after 100,000 miles
(166 000 km) at the same intervals. The services shown
at 150,000 miles (240 000 km) should be performed at
the same interval after 150,000 miles (240 000 km).
See ªOwner Checks and Servicesº and ªPeriodic
Maintenance Inspectionsº following.
Footnotes

The U.S. Environmental Protection Agency or the
California Air Resources Board has determined that the
failure to perform this maintenance item will not nullify
the emission warranty or limit recall liability prior to the
completion of the vehicle's useful life. We, however,
urge that all recommended maintenance services be
performed at the indicated intervals and the maintenance
be recorded.# Lubricate the suspension and steering linkage,
transaxle shift linkage, parking brake cable guides and
underbody contact points.
* If your vehicle has an Engine Oil Life Monitor, the
monitor will show you when to change the engine oil
and filter
-- usually between 3,000 miles (5 000 km) and
7,500 miles (12 500 km) since your last oil change.
Under severe conditions, the indicator may come on
before 3,000 miles (5 000 km). Never drive your vehicle
more than 7,500 miles (12 500 km) or 12 months
without an oil and filter change.

yellowblue
7-33
Part B: Owner Checks and Services
Listed in this part are owner checks and services which
should be performed at the intervals specified to help
ensure the safety, dependability and emission control
performance of your vehicle.
Be sure any necessary repairs are completed at once.
Whenever any fluids or lubricants are added to your
vehicle, make sure they are the proper ones, as shown in
Part D.
At Each Fuel Fill
It is important for you or a service station attendant to
perform these underhood checks at each fuel fill.
Engine Oil Level Check
Check the engine oil level and add the proper oil if
necessary. See ªEngine Oilº in the Index for
further details.Engine Coolant Level Check
Check the engine coolant level and add DEX
-COOL

coolant mixture if necessary. See ªEngine Coolantº in
the Index for further details.
Windshield Washer Fluid Level Check
Check the windshield washer fluid level in the
windshield washer tank and add the proper fluid if
necessary. See ªWindshield Washer Fluidº in the Index
for further details.
At Least Once a Month
Tire Inflation Check
Make sure tires are inflated to the correct pressures.
See ªTiresº in the Index for further details.
Cassette Deck Service
Clean cassette deck. Cleaning should be done every
50 hours of tape play. See ªAudio Systemsº in the Index
for further details.

yellowblue
7-35
Starter Switch Check
CAUTION:
When you are doing this check, the vehicle could
move suddenly. If it does, you or others could be
injured. Follow the steps below.
1. Before you start, be sure you have enough room
around the vehicle.
2. Firmly apply both the parking brake (see ªParking
Brakeº in the Index if necessary) and the
regular brake.
NOTE: Do not use the accelerator pedal, and be
ready to turn off the engine immediately if it starts.
3. Try to start the engine in each gear. The starter
should work only in PARK (P) or NEUTRAL (N).
If the starter works in any other position, your
vehicle needs service.Brake
-Transaxle Shift Interlock (BTSI) Check
CAUTION:
When you are doing this check, the vehicle could
move suddenly. If it does, you or others could be
injured. Follow the steps below.
1. Before you start, be sure you have enough
room around the vehicle. It should be parked on a
level surface.
2. Firmly apply the parking brake (see ªParking Brakeº
in the Index if necessary).
NOTE: Be ready to apply the regular brake
immediately if the vehicle begins to move.
3. With the engine off, turn the key to the RUN
position, but don't start the engine. Without
applying the regular brake, try to move the shift
lever out of PARK (P) with normal effort. If the shift
lever moves out of PARK (P), your vehicle's BTSI
needs service.

yellowblue
7-36
Ignition Transaxle Lock Check
While parked, and with the parking brake set, try to turn
the ignition key to LOCK in each shift lever position.

The key should turn to LOCK only when the shift
lever is in PARK (P).

The key should come out only in LOCK.
Parking Brake and Automatic Transaxle PARK (P)
Mechanism Check
CAUTION:
When you are doing this check, your vehicle
could begin to move. You or others could be
injured and property could be damaged. Make
sure there is room in front of your vehicle in case
it begins to roll. Be ready to apply the regular
brake at once should the vehicle begin to move.
Park on a fairly steep hill, with the vehicle facing
downhill. Keeping your foot on the regular brake, set the
parking brake.

To check the parking brake's holding ability: With
the engine running and transaxle in NEUTRAL (N),
slowly remove foot pressure from the regular brake
pedal. Do this until the vehicle is held by the parking
brake only.

To check the PARK (P) mechanism's holding ability:
With the engine running, shift to PARK (P). Then
release all brakes.
Underbody Flushing Service
At least every spring, use plain water to flush any
corrosive materials from the underbody. Take care to
clean thoroughly any areas where mud and other debris
can collect.

yellowblue
8-11
CURRENT PUBLICATIONS FOR 1999 BUICK
SERVICE MANUALS
Service Manuals have the diagnosis and repair information
on engines, transmission, axle, suspension, brakes,
electrical, steering, body, etc.
RETAIL SELL PRICE: $90.00
TRANSMISSION, TRANSAXLE, TRANSFER CASE
UNIT REPAIR MANUAL
This manual provides information on unit repair service
procedures, adjustments and specifications for the
1999 GM transmissions, transaxles and transfer cases.
RETAIL SELL PRICE: $50.00
SERVICE BULLETINS
Service Bulletins give technical service information needed
to knowledgeably service General Motors cars and trucks.
Each bulletin contains instructions to assist in the
diagnosis and service of your vehicle.OWNER'S INFORMATION
Owner publications are written directly for Owners and
intended to provide basic operational information about the
vehicle. The owner's manual will include the Maintenance
Schedule for all models.
In-Portfolio: Includes a Portfolio, Owner's Manual and
Warranty Booklet.
RETAIL SELL PRICE: $15.00
Without Portfolio: Owner's Manual only.
RETAIL SELL PRICE: $10.00
CURRENT & PAST MODEL ORDER FORMS
Service Publications are available for current and past
model GM vehicles. To request an order form, please
specify year and model name of the vehicle.
PLEASE COMPLETE THE ORDER FORM SHOWN ON
THE FOLLOWING PAGE AND MAIL TO:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207OR ORDER TOLL FREE: 1-800-551-4123
Monday-Friday 8:00 AM ± 6:00 PM Eastern Time
For Credit Card Orders Only (VISA±MasterCard±Discover)
1999 BUICK SERVICE PUBLICATIONS ORDERING INFORMATION
The following publications covering the operation and servicing of your vehicle can be purchased by filling out
the Service Publication Order Form in this book and mailing it in with your check, money order,
or credit card information to Helm, Incorporated (address below.)

9-
First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
9-1
Section 9 Index
A
ir Bag 1-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
How Does it Restrain 1-22 . . . . . . . . . . . . . . . . . . . . . . . . . .
How it Works 1-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Location 1-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Readiness Light 1-20, 2-60 . . . . . . . . . . . . . . . . . . . . . . . . .
Servicing 1-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
What Makes it Inflate 1-22 . . . . . . . . . . . . . . . . . . . . . . . . . .
What Will You See After it Inflates 1-23 . . . . . . . . . . . . . . .
When Should it Inflate 1-22 . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner 6-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning Refrigerants 6-64 . . . . . . . . . . . . . . . . . . . . .
Air Control, Climate Control System 3-2, 3-4 . . . . . . . . . . . . .
Alarm, Instant, Keyless Entry 2-10 . . . . . . . . . . . . . . . . . . . . .
Alarm, Universal Theft-Deterrent 2-16 . . . . . . . . . . . . . . . . . .
Alignment and Balance, Tire 6-46 . . . . . . . . . . . . . . . . . . . . . .
Aluminum Wheels, Cleaning 6-54 . . . . . . . . . . . . . . . . . . . . . .
Antenna, Heated Backlite 3-36 . . . . . . . . . . . . . . . . . . . . . . . .
Antifreeze 6-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock
Brake System Warning Light 2-62, 4-7 . . . . . . . . . . . . . . . .
Brakes 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti-Theft, Radio 3-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appearance Care 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Appearance Care Materials Chart 6-56 . . . . . . . . . . . . . . . . . .
Arbitration Program 8-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Armrest, Storage 2
-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ashtrays 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Audio Equipment, Adding 3-34 . . . . . . . . . . . . . . . . . . . . . . . .
Audio, Steering Wheel Touch Controls 3-32 . . . . . . . . . . . . . .
Audio Systems 3-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Automatic Dimming/Heated Outside Mirror 2-51 . . . . . . . . . .
Automatic Transaxle 2-24
Check 7-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid 6-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operation 2-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shifting 2-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overdrive 2-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Park Mechanism Check 7-36 . . . . . . . . . . . . . . . . . . . . . . . .
Battery 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacement, Remote Keyless Entry 2-12 . . . . . . . . . . . . . .
Rundown Protection 2-45 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warning Light 2-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Warnings 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BBB Auto Line 8-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Belt, Engine Accessory 6-66 . . . . . . . . . . . . . . . . . . . . . . . . . .
Better Business Bureau Mediation 8-3 . . . . . . . . . . . . . . . . . . .
Blizzard 4-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
9-2
Brake
Adjustment 6-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Anti-lock System Warning Light 2-62, 4-7 . . . . . . . . . . . . .
Fluid 6-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Master Cylinder 6-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parking 2-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pedal Travel 6-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing System Parts 6-30 . . . . . . . . . . . . . . . . . . . . . . . .
System Warning Light 2-61 . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer 4-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Transaxle Shift Interlock Check 2-24, 7-35 . . . . . . . . . . . . .
Wear 6-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brakes, Anti-Lock 4-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Braking in Emergencies 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . .
Break-In, New Vehicle 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . .
Brightness Control 2-43 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BTSI Check 2-24, 7-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canadian Roadside Assistance 8-6 . . . . . . . . . . . . . . . . . . . .
Capacities and Specifications 6-64 . . . . . . . . . . . . . . . . . . . . . .
Carbon Monoxide 2-15, 2-33, 2-34, 4-28, 4-35 . . . . . . . . . .
Cassette Deck Service 7-33 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cassette Tape Player 3-17, 3-21, 3-25 . . . . . . . . . . . . . . . . . .
Care 3-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Errors 3-16, 3-20, 3-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center Passenger Position 1-25 . . . . . . . . . . . . . . . . . . . . . . . .
Certification Label 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Safety 4-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chains, Tire 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Change Oil Soon Light 2
-69 . . . . . . . . . . . . . . . . . . . . . . . . . .
Changing a Flat Tire 5-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check Engine Light 2-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check Oil Level Light 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking Your Restraint Systems 1-50 . . . . . . . . . . . . . . . . . .
Chemical Paint Spotting 6-55 . . . . . . . . . . . . . . . . . . . . . . . . . .
Child Restraints 1-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Securing in a Rear Outside Seat Position 1-41 . . . . . . . . . . .
Securing in the Center Rear Seat Position 1-43 . . . . . . . . . .
Securing in the Right Front Seat Position 1-45 . . . . . . . . . .
Top Strap 1-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Where to Put 1-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cigarette Lighter 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Circuit Breakers and Fuses 6-59 . . . . . . . . . . . . . . . . . . . . . . .
Cleaner, Air 6-16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning
Aluminum Wheels 6
-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior Lamps/Lenses 6-53 . . . . . . . . . . . . . . . . . . . . . . . .
Fabric 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Glass Surfaces 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside of Your Vehicle 6-49 . . . . . . . . . . . . . . . . . . . . . . . . .
Instrument Panel 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Plastic Components 6-51 . . . . . . . . . . . . . . . . . . . . .
Leather 6-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside of Your Vehicle 6-52 . . . . . . . . . . . . . . . . . . . . . . . .
Special Problems 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stains 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tires 6-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vinyl 6-50 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield and Wiper Blades 6-51 . . . . . . . . . . . . . . . . . . .
