NOTICE:
When replacing the battery, use care not to touch
any of the circuitry. Static from your body
transferred to these surfaces may damage
the transmitter.
For battery replacement, use one Duracell
battery, type
DL
-2032, or a similar type.To replace the battery:
1. Insert a coin into the notch near the key ring. Turn
the coin counterclockwise to separate the two halves
of the transmitter.
2. Once the transmitter is separated, use a pencil eraser
to remove the old battery. Do not use a metal object.
3. Remove and replace the battery. Replace it as the
instructions inside the cover indicate.
4. Snap the transmitter back together tightly to be sure
no moisture can enter.
5. Test the operation of the transmitter with your
vehicle. If the transmitter does not work,
resynchronize the transmitter.
Resynchronization
After replacing the battery in your transmitter, or if only
the instant alarm works, the transmitter needs to be
resynchronized to the receiver. Do this by pressing and
holding both the LOCK and UNLOCK buttons at the
same time for about eight seconds. You must be within
range of the vehicle.
Once the transmitter has been resynchronized, the horn
will chirp and the exterior lamps will flash once. The
system should now operate properly.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-2
Comfort Controls
This section describes how to operate your climate
control system. Your climate control system uses
ozone
-friendly R-134a refrigerant.
With these systems, you can control the heating, cooling
and ventilation in your vehicle. Your vehicle also has a
flow
-through ventilation system described later in
this section.
Electronic Touch Climate Control
C±43±0376±S
If your vehicle has this climate control system, the
following information tells you how it works.Fan Button
The FAN control is used to select the speed of the
blower fan and the force of air you want. There are four
speeds to choose from. Moving the lever between LOW
and HIGH will decrease or increase the fan speed. The
fan will be off when the system is off.
Temperature Lever
This lever adjusts the temperature of the air coming
through the system. Move the TEMPERATURE lever to
change the temperature of the air coming through your
outlets. Move the lever between COOL and WARM to
lower or raise the temperature.
Mode Controls
The buttons on your system allow you to choose
settings to deliver air through the lower, middle or
windshield outlets.
RECIRC: Press this button to limit the amount of
outside air entering your vehicle. This is helpful when
you are trying to cool the interior of the vehicle quickly,
or limit the amount of outside air entering your vehicle.
To turn off RECIRC, press the button again. If you
select FRONT defrost or BLEND while RECIRC is
selected, the system will automatically turn off RECIRC
to prevent fogging.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-3
VENT: This setting directs outside air through the
middle instrument panel outlets. The air conditioning
compressor is not working when VENT is selected.
HTR: This button directs air out of the heater outlets.
Most of the air will come from the floor outlets while
some air will flow through the windshield and side
window outlets. The air conditioning compressor is not
working when HTR is selected.
BLEND: When BLEND is selected, the airflow will be
split between the windshield and the floor outlets. The
air conditioning compressor will be operating.
FRONT: This setting directs most of the airflow toward
the windshield.
OFF: The ventilation system always allows fresh air to
flow through your vehicle when it is moving. The
system will try to keep the air at a previously chosen
temperature. When the system is off, the blower fan is
also off.
MAX: This setting directs airflow through the middle
instrument panel outlets. The amount of outside air
entering your vehicle is limited with this setting. The air
conditioning compressor is on in this mode.NORM: This setting cools the outside air entering your
vehicle and directs it through the middle instrument
panel outlets. The air conditioner is on in this mode.
BI
-LEV: This setting directs warm air to the floor and
cooler air to the middle instrument panel outlets. The air
conditioner is on in this mode.
Dual Automatic Comfortemp
Climate Control (If Equipped)
If your vehicle has the Dual Automatic Comfortemp
Climate Control option, the following information tells
you how it works.
You will hear a beep each time a button is pushed and a
light on the button will indicate which function is active.
The lights are on all buttons except TEMP, FAN and
AIR FLOW. The display will show fan speed, comfort
level setting and airflow direction for a few seconds
whenever AUTO is selected, and then it will display the
outside temperature. The outside temperature reading is
most accurate when the vehicle is moving. During stops,
the display shows the previous temperature for best
accuracy and system control.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-5
Automatic Operation
Press the AUTO button when you want the system to
automatically adjust to changes in the temperature inside
the vehicle, the outside temperature and the sun load on
the vehicle. When the system is set for automatic
operation, air will come from the floor, middle or
windshield outlets depending on the temperature inside
the vehicle, the outside temperature and sun load. Fan
speed will vary as the system gets to and maintains the
comfort setting you have selected through the use of the
TEMP button.
To find your comfort setting, start with the system in
AUTO mode and the TEMP button adjusted to 75
F
(24
C), give the vehicle about 20 minutes to stabilize,
and adjust your comfort setting if necessary, by using
the TEMP button. The display will show the comfort
setting for a few seconds and then it will display the
outside temperature. If you want to see your current
automatic fan speed, airflow direction and comfort
setting, press the AUTO button.
In cold weather, the system will delay turning on the
fan, to avoid blowing cold air. The length of the delay
depends on the engine coolant temperature and the
outside temperature. Pushing the FAN, AIR FLOW or
FRONT buttons will override this delay, turn off the
AUTO setting and change the fan speed.Manual Operation
You may also manually adjust the air delivery or
fan speed.
AIR FLOW: This button is used to change the direction
of the airflow. The airflow choices available are FLOOR,
FLOOR
-MID, MID and WINDSHIELD-FLOOR. If the
system is set for AUTO, pressing the AIR FLOW button
will display the current airflow direction and the comfort
setting. Press the AIR FLOW up or down button again to
change the direction of the airflow.
If the AIR FLOW up button is selected while in the
FRONT defrost mode, the system will direct the air
toward the windshield and the floor. If the AIR FLOW
down button is selected while in the FRONT defrost
mode, the system will direct the air toward the floor, and
the FRONT defrost mode will cancel. Notice the arrows
in the display.
OFF: If the passenger comfort control is turned on, it can be
turned off by pressing the OFF button once. Pressing the OFF
button a second time will turn off the main system. Turning
off the main system causes the fan to turn off and the airflow
to be directed toward the floor. The system will still try to
keep the interior of the vehicle at the previous chosen
comfort setting. The outside temperature will show on the
display when the system is OFF.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-7
On sunny days, when the air is moderately warm or
cool, use BI
-LEV to deliver warm air to the floor and
cooler air to the middle instrument panel outlets. On
days like these, the sun may adequately warm your
upper body, but your lower body may not be warm
enough. To warm or cool the air delivered, adjust the
TEMPERATURE lever.
The amount of fresh air entering the vehicle is limited
when RECIRC is selected. This is helpful when you are
trying to cool the air in your vehicle or limit the air
entering the vehicle.
If your vehicle has the Dual Automatic Comfortemp
system and it is set for AUTO, on very hot days, the
system will automatically enter the RECIRC mode and
the temperature door will be positioned at the full cold
position for maximum cooling. If the system is not in
the AUTO mode, RECIRC should be selected to provide
maximum cooling. You can choose the extreme comfort
setting of 60
F (16
C), but the system will not cool any
faster by choosing the extreme comfort setting.
When the air conditioner is on, you may sometimes
notice slight changes in your vehicle's engine speed and
power. This is normal because the system is designed to
cycle the compressor on and off to keep the
desired temperature.Heating
If your vehicle has the electronic touch system, on
cold days, use HTR with the TEMPERATURE lever
toward WARM.
If your vehicle has the Dual Automatic Comfortemp
system, and on cold days, if the AUTO mode is selected,
the system will automatically direct the air toward the
floor and the temperature door will be positioned at the
full hot position. You can choose the extreme comfort
setting of 90
F (32
C) but the system will not warm up
any faster by selecting the extreme comfort setting. If
the outside temperature is cold, the fan will be delayed
to avoid blowing cold air. Pushing the FAN, AIR FLOW
or FRONT buttons will override this delay, turn off the
AUTO mode and change the fan speed.
With each system, outside air will be brought in and sent
through the floor outlets. The heater works best if you
keep your windows closed while using it.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-9
Do not attach a temporary vehicle license, tape or decals
across the defogger grid on the rear window.
NOTICE:
Do not try to clear frost or other material from
the inside of the rear window with a razor blade
or anything else that is sharp. This may damage
the rear defogger grid. The repairs wouldn't be
covered by your warranty.
Passenger Control (If Equipped)
C±43±5387±M
If you have the Dual
Automatic Comfortemp
system, the front seat
passenger can control the
air temperature in their
seating area.
The temperature can be set up to 5
F or 3
C cooler or
warmer than the primary setting. To activate the
passenger control, simply press the COOL or WARM
buttons located on the passenger's door.
The indicator lights above the control will show the
difference from the main temperature setting.
If the passenger control has been turned on, it can be
turned off by pressing the OFF button once. Pressing the
OFF button a second time will turn off the main system.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-13
Finding a Station
AM
-FM: Press the AM-FM button to switch between
AM, FM1 and FM2. The display shows your selection.
TUNE: Turn the lower knob to choose radio stations.
SEEK: Press the right or left arrow to go to the next
higher or lower station and stay there. The sound will
mute while seeking.
SCAN: Press one of the SEEK arrows for two seconds,
and SCAN will appear on the display. Use SCAN to
listen to stations for a few seconds. The radio will go to
a station, stop for a few seconds, then go on to the next
station. Press one of the SEEK arrows again to stop
scanning. The sound will mute while scanning.
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2). Just:
1. Turn the radio on.
2. Press the AM
-FM button to select the band.
3. Tune in the desired station.
4. Press and hold one of the six numbered buttons. The
sound will mute. When it returns, release the button.
Whenever you press that numbered button, the
station you set will return.
5. Repeat the steps for each pushbutton.P SCAN: Press this button to listen to each of your
preset stations for a few seconds. The radio will go to
the first preset station, stop for a few seconds, then go
on to the next preset station. Press P SCAN again to stop
scanning. The radio will not stop at a preset station if the
station is weak.
Setting the Tone
BASS: Press this knob lightly so it extends. Turn the
knob to increase or decrease bass.
TREB: Press this knob lightly so it extends. Turn the
knob to increase or decrease treble. If a station is weak
or noisy, you may want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.
Adjusting the Speakers
BAL: Turn the control behind the upper knob to move
the sound to the left or right speakers. The middle
position balances the sound between the speakers.
FADE: Turn the control behind the lower knob to move
the sound to the front or rear speakers. The middle
position balances the sound between the speakers.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-15
PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2). Just:
1. Turn the radio on.
2. Press AM
-FM to select the band.
3. Tune in the desired station.
4. Press and hold one of the six numbered buttons. The
sound will mute. When it returns, release the button.
Whenever you press that numbered button, the
station you set will return.
5. Repeat the steps for each pushbutton.
P SCAN: Press this button to listen to each of your
preset stations for a few seconds. The radio will go to
the first preset station, stop for a few seconds, then go
on to the next preset station. Press P SCAN again to stop
scanning. The radio will not stop at a preset if the station
is weak.Setting the Tone
BASS: Press this knob lightly so it extends. Turn the
knob to increase or decrease bass.
TREB: Press this knob lightly so it extends. Turn the
knob to increase or decrease treble. If a station is weak
or noisy, you may want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.
Adjusting the Speakers
BAL: Turn the control behind the upper knob to move
the sound to the left or right speakers. The middle
position balances the sound between the speakers.
FADE: Turn the control behind the lower knob to move
the sound to the front or rear speakers. The middle
position balances the sound between the speakers.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-18
RECALL: Press this button briefly to recall the station
being played or to display the clock. To change what is
normally shown on the display (station or time), press
this button until you see the display you want, then hold
the button until the display flashes. If you press the
button when the ignition is off, the clock will show for a
few seconds.
Finding a Station
AM
-FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE: Press the up or down arrow to choose
radio stations.
SEEK: Press the up or down arrow to go to the next
higher or lower station and stay there. The sound will
mute while seeking.
SCAN: Press one of the SEEK arrows for two seconds
and SCAN will appear on the display. Use SCAN to
listen to stations for a few seconds. The radio will go to
a station, stop for a few seconds, then go on to the next
station. Press one of the SEEK buttons again to stop
scanning. The sound will mute while scanning.PUSHBUTTONS: The six numbered pushbuttons let
you return to your favorite stations. You can set up to
18 stations (six AM, six FM1 and six FM2). Just:
1. Turn the radio on.
2. Press AM
-FM to select the band.
3. Tune in the desired station.
4. Press TONE to select the setting you prefer.
5. Press and hold one of the six numbered buttons. The
sound will mute. When it returns, release the button.
Whenever you press that numbered button, the
station you set will return and the tone you selected
will be automatically selected for that button.
6. Repeat the steps for each pushbutton.
P SCAN: Press this button to listen to each of your
preset stations for a few seconds. The radio will go to
the first preset station, stop for a few seconds, then go
on to the next preset station. Press P SCAN again to stop
scanning. If a preset station has weak reception, the
radio will not stop at the preset station.

First Edition for Buick LeSabre Owner's Manual ± 1999
yellowblue
3-19
AUTO SET: Press this button and the system will seek
and set the 12 strongest FM or the 6 strongest AM
stations on your preset buttons (depending on which
band (AM or FM) you are listening to). AUTO SET will
flash while seeking and will remain on until this
function is complete. To return to the stations you
manually set, press AUTO SET again.
Setting the Tone
BASS: Press this knob lightly so it extends. Turn the
knob to increase or decrease bass.
TREB: Press this knob lightly so it extends. Turn the
knob to increase or decrease treble. If a station is weak
or noisy, you may want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.
TONE: This feature allows you to choose preset bass
and treble equalization settings designed for classical,
pop, rock, jazz, talk and country/western stations.
CLASS will appear on the display when you first press
TONE. Each time you press it, another setting will
appear on the display. Press it again after C & W
appears and MANUAL will appear. Tone control will
return to the BASS and TREB knobs. Also, if you use
the BASS and TREB knobs, control will return to them
and MANUAL will appear.Adjusting the Speakers
BAL: Press this knob lightly so it extends. Turn the knob
to move the sound to the left or right speakers. The middle
position balances the sound between the speakers.
FADE: Press this knob lightly so it extends. Turn the
knob to move the sound to the front or rear speakers. The
middle position balances the sound between the speakers.
Push these knobs back into their stored positions when
you're not using them.
Playing a Cassette Tape
The longer side with the tape visible should face to the
right. If the ignition and the radio are on, the tape can be
inserted and will begin playing. If you hear nothing or
hear a garbled sound, the tape may not be in squarely.
Press EJECT to remove the tape and start over.
While the tape is playing, use the VOLUME, FADE,
BAL, BASS and TREB controls just as you do for the
radio. Other controls may have different functions when
a tape is inserted. The display will show an arrow to
show which side of the tape is playing.
If you want to insert a tape when the ignition or radio is
off, first press EJECT or RECALL. Note that the
cassette tape adapter kits for portable compact disc
players will work in your cassette tape player.
