BUICK LESABRE 2000 Owner's Manual

yellowblue
2-84
SERVICE STABILITY SYSTEM - 54: If you ever
see the SERVICE STABILITY SYSTEM message, it
means there may be a problem with your stability
enhancement system. If you see this message, try to
reset the system (stop; turn off the engine; then start the
engine again). If the SERVICE STABILITY SYSTEM
message still comes on, it means there is a problem. You
should see your dealer for service. Reduce your speed
and drive accordingly.
STABILITY SYSTEM ACTIVE
- 55: You may see
the STABILITY SYSTEM ACTIVE message on the
Driver Information Center. It means that an advanced,
computer
-controlled system has come on to help your
vehicle continue to go in the direction in which you're
steering. This stability enhancement system activates when
the computer senses that your vehicle is just starting to
spin, as it might if you hit a patch of ice or other slippery
spot on the road. When the system is on, you may hear a
noise or feel a vibration in the brake pedal. This is normal.
When the STABILITY SYSTEM ACTIVE message is
on, you should continue to steer in the direction you
want to go. The system is designed to help you in bad
weather or other difficult driving situations by making
the most of whatever road conditions will permit. If the
STABILITY SYSTEM ACTIVE message comes on,
you'll know that something has caused your vehicle to
start to spin, so you should consider slowing down.
DIC Personal Choice Programming
The DIC can be used to program the following personal
choice features available with your vehicle:

Automatic Door Locks

Window Lockout

Security Feedback

Delayed Locking

Perimeter Lighting

Memory Seats

Tilt Mirrors (If Equipped)

Driver ID ON/OFF
For vehicles not equipped with a DIC, see
ªPersonal Choice Programmingº in the Index.
The personal choice settings displayed on the
DIC are determined by the transmitter used to enter
the vehicle. Each remote keyless entry transmitter was
pre
-programmed to belong to DRIVER 1 or DRIVER 2
and is numbered on the back. After the button with the
unlock symbol on a remote keyless entry transmitter is
pressed and the ignition is in RUN, the DIC will display
the identified driver and recall the settings previously
programmed for that driver. The settings can also be
recalled by briefly pressing one of the MEMORY
buttons located on the driver's door.

yellowblue
2-85
If you unlock the vehicle using your door key instead of
your transmitter, the DIC will not change drivers and
will recall the information from the last transmitter used
or the last driver using the memory seat controls. If this
happens and you were not the last driver of the vehicle,
simply press your correct driver number on the memory
seat controls or press the button with the unlock symbol
on your remote keyless entry transmitter.
Use the following steps for personal choice
programming instructions.
1. Turn the ignition on and keep the transaxle in
PARK (P).
2. Inform the DIC which driver you are by pressing the
button with the unlock symbol on your remote
keyless entry transmitter or the appropriate memory
seat control.
3. Press and hold the ENG/MET button for five
seconds. WELCOME TO BUICK OPTION
FEATURE will appear in the display.4. The first choice to be made will be DRIVER ID 1
or 2. Press the ENG/MET button to toggle between
your selections within a display and RESET to
choose the current selection and move on to the next
personal choice feature.
If you would like to exit the selection mode without
moving through each of the personal choice features,
simply press a different button on the DIC or turn off the
ignition. Whatever personal choices you made will still
be retained, even without passing through each of
the features.
If you happen to move past a selection you would like to
make a personal choice for, press the button with the
unlock symbol on your remote keyless entry transmitter
or press the appropriate driver number on the seat
control. This will return you to the beginning of the
option feature programming mode.

yellowblue
2-86
Automatic Door Locks
The door lock modes when shifting in and out of
PARK (P), can be changed through the DIC. You can
change these modes by different selections of the
following DIC displays:

AUTO DOOR LOCKS
- OFF/ON

UNLOCK
- OFF/ON

UNLOCK
- KEY OFF/PARK

DOOR TO UNLOCK
- DRIVER/ALL
If you choose OFF for AUTO DOOR LOCKS, your door
locks will operate normally with no automatic feature.
If you choose ON for AUTO DOOR LOCKS, ON for
UNLOCK and KEY OFF, your doors will lock every
time you shift out of PARK (P), and the doors will
unlock every time you stop and turn the ignition to OFF.
If you choose ON for AUTO DOOR LOCKS, ON for
UNLOCK and PARK, your doors will lock every time
you shift out of PARK (P), and the doors will unlock
every time you stop and shift into PARK (P).
If you choose ON for AUTO DOOR LOCKS, and OFF
for UNLOCK, your doors will lock every time you shift
out of PARK (P), and there will be no automatic door
unlock when shifting back into PARK (P).If you choose ON for UNLOCK and DRIVER for DOOR
TO UNLOCK, only the driver's door will automatically
unlock when shifting into PARK or turning the key to OFF.
If you choose ON for UNLOCK and ALL for DOOR
TO UNLOCK, all doors will automatically unlock when
shifting into PARK or turning the key to OFF.
To change modes:
1. Move the arrow on the display between the
selections by pressing the ENG/MET button.
2. Once you have made your selection, press the RESET
button and your choice will be retained in memory.
See ªAutomatic Door Locksº in the Index for more
information about this feature.
Window Lockout
The number of passenger windows locked out by the
WINDOW LOCKOUT switch can be programmed
through the DIC.
If you choose R + PASS, all three passenger window
switches will be inactive when the WINDOW
LOCKOUT switch is enabled.
If you choose REAR, only the two rear passenger
window switches will be locked out when the
WINDOW LOCKOUT switch is enabled.

yellowblue
2-87
To change modes:
1. Move the arrow on the display between R + PASS
and REAR by pressing the ENG/MET button.
2. Once you have made your selection, press the RESET
button. Your choice will be retained in memory.
For more information on this feature, see ªWindow
Lockº in the Index.
Security Feedback
By choosing different combinations of these selections,
you can choose the type of transmitter activated
feedback when locking and unlocking your vehicle with
your transmitter. Each time you make a selection by
pressing the ENG/MET button, press the RESET button
to record your choice.

KEYLESS FEEDBACK
- OFF/ON

LIGHTS FEEDBACK
- OFF/ON

HORN FEEDBACK
- OFF/ON
If you choose ON for KEYLESS FEEDBACK you will
also need to choose LIGHTS and/or HORN FEEDBACK.You can select the following modes:

If you choose OFF for KEYLESS FEEDBACK, you
will receive no security feedback when locking or
unlocking your vehicle.

If you choose ON for KEYLESS FEEDBACK and
ON for LIGHTS FEEDBACK, the exterior lamps
will flash twice when unlocking your vehicle and
once when locking your vehicle.

If you choose ON for KEYLESS FEEDBACK and
ON for HORN FEEDBACK, your horn will chirp
when locking and unlocking your vehicle.

If you choose ON for KEYLESS, LIGHTS and
HORN FEEDBACK, your exterior lamps will flash
and your horn will chirp twice when unlocking your
vehicle and once when locking your vehicle.
For more information on this feature, see
ªSecurity Feedbackº in the Index.

yellowblue
2-88
Delayed Locking
The delayed locking feature, which delays the actual locking
of the vehicle, can be made active or inactive through
the DIC. When DELAYED LOCKING
- OFF - ON appears
on the display, use the ENG/MET button to toggle the arrow
between OFF and ON. When you have made your choice,
press the RESET button to record your selection.
For more information on this feature, see ªDelayed
Lockingº in the Index.
Perimeter Lighting
When the button with the unlock symbol on the
transmitter is pressed, the Daytime Running Lamps
(high
-beams at reduced intensity), parking lamps and
back
-up lamps will turn on if it is dark enough
according to the Twilight Sentinel
.
You can control activation of this feature by choosing
OFF or ON when the PERIMETER LIGHTS choice is
displayed on the DIC. Make your choice by pressing the
ENG/MET button and record your choice by pressing
the RESET button. You will then be prompted to choose
a TIMEOUT period. See ªExterior Lightsº later in this
section for more information.
For more information on this feature, see ªPerimeter
Lightingº in the Index.Exterior Lights
The EXTERIOR LIGHTS/TIMEOUT feature can be
changed to desired setting by using the ENG/MET to
toggle from 5 to 30 seconds. Each toggle will increase
the time by 5 seconds. Once the desired timeout is
displayed, press RESET to record your choice and move
on to the next personal choice feature.
Memory Seat Recall
This feature recalls the position of your seat. When this
feature is active, the memory seat and mirror positions
will be recalled for the identified driver when the remote
keyless entry transmitter is used to enter the vehicle.
You can program this feature to be active by choosing
ON when the SEAT RECALL choice appears, or
inactive by choosing OFF when the SEAT RECALL
choice appears on the DIC. Make your choices by
pressing the ENG/MET button and store them to
memory by pressing the RESET button.

yellowblue
2-89
You can also program this feature to recall your
memory seat position or the exit seat position.

Memory Position: Choose ON when the SEAT
RECALL choice appears, and then choose MEMORY
when the RECALL POSITION choice appears.

Exit Position: Choose ON when the SEAT RECALL
choice appears, and then choose EXIT when the
RECALL POSITION choice appears. The seat will
move when you enter the vehicle after unlocking it
with a remote keyless entry transmitter. This will
allow for easy entry.
For more information on this feature, see
ªMemory Seatsº in the Index.Parallel Park Assist (If Equipped)
The parallel park assist mirror, which tips the passenger
mirror down while the vehicle is in REVERSE (R), can
be made active or inactive through the DIC. When TILT
MIRRORS
-OFF/ON appears on the display, use the
ENG/MET button to toggle the arrow between OFF and
ON. When you have made your choice, press the
RESET button to record your selection. For more
information on this feature, see ªParallel Park Assist
Mirrorº in the Index.
Driver ID
This feature displays the DRIVER ID, as identified by
the DIC. If this feature is ON, the DRIVER ID will be
displayed every time the ignition is turned on. If the
DRIVER ID is OFF, the DRIVER ID can be displayed
by pressing either a button on the remote keyless entry
transmitter or a memory seat button. Vehicles are
delivered with this feature ON.

yellowblue
2-90
-NOTES

3-
yellowblue
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle.
Be sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-7 Air Conditioning
3
-8 Heating
3
-8 Defogging and Defrosting
3
-9 Rear Window Defogger
3
-9 Ventilation System
3
-11 Passenger Control (If Equipped)
3
-12 Steering Wheel Controls for Climate Control
(If Equipped)
3
-12 Audio Systems
3
-12 Setting the Clock
3
-13 AM-FM Stereo
3
-15 AM-FM Stereo with Cassette Tape Player
(If Equipped)
3
-18 AM-FM Stereo with Cassette Tape Player and
Automatic Tone Control (If Equipped)3
-22 AM-FM Stereo with Compact Disc Player and
Automatic Tone Control (If Equipped)
3
-26 AM-FM Stereo with Cassette Tape and
Compact Disc Player with Automatic Tone
Control (If Equipped)
3
-32 Trunk-Mounted CD Changer (Option)
3
-35 Personal Choice Radio Controls
(If Equipped)
3
-35 Theft-Deterrent Feature (If Equipped)
3
-36 Audio Steering Wheel Controls (If Equipped)
3
-37 Understanding Radio Reception
3
-37 Tips About Your Audio System
3
-38 Care of Your Cassette Tape Player
3
-39 Care of Your Compact Discs
3
-39 Care of Your Compact Disc Player
3
-39 Diversity Antenna System

yellowblue
3-2
Comfort Controls
This section describes how to operate your climate
control system. Your climate control system uses
ozone
-friendly air conditioning refrigerant.
With these systems, you can control the heating, cooling
and ventilation in your vehicle. Your vehicle also has a
flow
-through ventilation system described later in
this section.
Electronic Touch Climate Control
If your vehicle has this climate control system, the
following information tells you how it works.Fan Lever
The FAN control is used to select the speed of the
blower fan and the force of air you want. Moving the
lever between LOW and HIGH will decrease or increase
the fan speed. The fan will be off when the system is off.
Temperature Lever
This lever adjusts the temperature of the air coming
through the system. Move the TEMPERATURE lever to
change the temperature of the air coming through your
outlets. Move the lever between COOL and WARM to
lower or raise the temperature.
Mode Controls
The buttons on your system allow you to choose
settings to deliver air through the lower, middle or
windshield outlets.
RECIRC: Press this button to limit the amount of
outside air entering your vehicle. This is helpful when
you are trying to cool the interior of the vehicle quickly,
or limit the amount of outside air entering your vehicle.
To turn off RECIRC, press the button again. If you
select FRONT defrost or BLEND while RECIRC is
selected, the system will automatically turn off RECIRC
to prevent fogging. If you select RECIRC while in
FRONT defrost, the RECIRC light will flash three times
to let you know this is not allowed.

yellowblue
3-3
VENT: This setting directs outside air through the
middle instrument panel outlets. The air conditioning
compressor is not working when VENT is selected. If
you select VENT while in FRONT defrost, the VENT
light will flash three times to let you know this is not
allowed. This is to prevent fogging.
HTR: This button directs air out of the heater outlets.
Most of the air will come from the floor outlets while
some air will flow through the windshield and side
window outlets. The air conditioning compressor is not
working when HTR is selected.
BLEND: When BLEND is selected, the airflow will
be split between the windshield and the floor outlets.
The air conditioning compressor will be operating.
FRONT: This setting directs most of the airflow
toward the windshield.OFF: The ventilation system always allows fresh air to
flow through your vehicle when it is moving. The system
will try to keep the air at a previously chosen temperature.
When the system is off, the blower fan is also off.
MAX: This setting directs airflow through the middle
instrument panel outlets. The amount of outside air
entering your vehicle is limited with this setting. The air
conditioning compressor is on in this mode.
NORM: This setting cools the outside air entering your
vehicle and directs it through the middle instrument
panel outlets. The air conditioning compressor is on in
this mode.
BI
-LEV: This setting directs warm air to the floor and
cooler air to the middle instrument panel outlets. The air
conditioning compressor is on in this mode.
