6-62
Mini
fuse Usage
1 Not Used
2 Accessory
3 Windshield Wipers
4 Not Used
5 Left Low
-Beam Headlamp
6 Right Low
-Beam Headlamp
7 Instrument PanelMini
fuse Usage
8 Powertrain Control Module Battery
9 Right High
-Beam Headlamp
10 Left High
-Beam Headlamp
11 Ignition 1
12 Not Used
13 Transaxle
14 Cruise Control
15 Direct Ignition System
16 Injector Bank #2
17 Not Used
18 Not Used
19 Powertrain Control Module Ignition
20 Oxygen Sensor
21 Injector Bank #1
22 Auxiliary Power
23 Cigarette Lighter
24 Fog Lamps/Daytime Running Lamps
25 Horn
26 Air Conditioner Clutch

yellowblue
6-63
Micro Relays Usage
27 High
-Beam Headlamp
28 Low
-Beam Headlamp
29 Fog Lamps
30 Daytime Running Lamps
31 Horn
32 Air Conditioner Clutch
33 HVAC Solenoid
Mini Relays Usage
34 Accessory
35 Air Pump
36 Starter 1
37 Cooling Fan 2
38 Ignition 1
39 Cooling Fan Series/Parallel
40 Cooling Fan 1Maxibreaker Usage
41 Starter
MaxiFuses Usage
42 AIR
43 ABS
44 Air Pump B
45 Air Pump A
46 Cooling Fan 2
47 Cooling Fan 1
Spare Fuses Usage
48 Spare
49 Not Used
50 Not Used
51 Not Used
52 Not Used
53 Fuse Puller

yellowblue
6-64
Removing the Rear Seat Cushion
NOTICE:
The battery and main fuse boxes are located under
the rear seat cushion. The battery's ground
terminal and some relay wires are exposed. To help
avoid damage to the battery and wires, be careful
when removing or reinstalling the seat cushion. Do
not remove covers from covered parts. Do not store
anything under the seat, as objects could touch
exposed wires and cause a short.
To remove the rear seat cushion:
1. Pull up on the front of the cushion to release the
front hooks.
2. Pull the cushion up and out toward the front
of the vehicle.To reinstall the rear seat cushion:

yellowblue
6-65
CAUTION:
A safety belt that isn't properly routed through
the seat cushion or is twisted won't provide the
protection needed in a crash. If the safety belt
hasn't been routed through the seat cushion at
all, it won't be there to work for the next
passenger. The person sitting in that position
could be badly injured. After reinstalling the seat
cushion, always check to be sure that the safety
belts are properly routed and are not twisted.
1. Buckle the center passenger position safety belt, then
route the safety belts through the proper slots in the
seat cushion. Don't let the safety belts get twisted.
2. Slide the rear of the cushion up and under the
seatback so the rear
-locating guides hook into the
wire loops on the back frame.3. With the seat cushion lowered, push rearward and
then press down on the seat cushion until the spring
locks on both ends engage.
4. Check to make sure the safety belts are properly
routed and that no portion of any safety belt is
trapped under the seat. Also make sure the seat
cushion is secured.
Rear Underseat Bussed Electrical Center (BEC)
The rear BEC is located
beneath the rear seat on the
driver's side. The rear seat
cushion must be removed to
access the BEC. See
ªRemoving the Rear Seat
Cushionº in the Index.

yellowblue
6-66
Minifuses Usage
1 Fuel Pump
2 HVAC Blower
3 Memory
4 ALDL
5 Rear Fog Lamps
6CD
7 Driver's Door Module
8 Air Bag System (SIR)
9 Not UsedMinifuses Usage
10 Right Parking Lamp
11 Vent Solenoid
12 Ignition 1
13 Left Parking Lamp
14 Dimmer
15 Not Used
16 Left Front Heated Seat
17 Not Used
18 Rear Door Module
19 Stoplamp
20 NSBU
21 Audio
22 Retained Accessory Power (RAP)
23 Not Used
24 Not Used
25 Passenger Door Module
26 Body
27 Interior Lamps
28 Not Used
29 Ignition Switch
30 Not Used

yellowblue
6-67
Minifuses Usage
31 Right Front Heated Seat
32 Not Used
33 HVAC
34 Ignition 3 Rear
35 Anti
-Lock Brake System (ABS)
36 Turn Signal/Hazard
37 HVAC Battery
38 Dimmer
Micro Relays Usage
39 Fuel Pump
40 Parking Lamp
41 Ignition 1
42 Rear Fog Lamp
43 Not Used
44 Park
45 Reverse
46 Retained Accessory Power (RAP)
47 Fuel Tank Door LockMicro Relays Usage
48 Not Used
49 Ignition 3
50 Fuel Tank Door Release
51 Interior Lamps
52 Trunk Release
53 Front Courtesy Lamps
54 Not Used
55 Electronic Level Control (ELC)
Circuit
BreakersUsage
56 Power Seats
57 Power Windows
Mini Relays Usage
58 Cigar
59 Rear Defogger

yellowblue
6-68
MaxiFuses Usage
60 Not Used
61 Rear Defog
62 Not Used
63 Audio Amplifier
64 Electronic Level Control (ELC)
65 Cigar
66 Not Used
Spare Fuses Usage
67 Not Used
68 Not Used
69 Not Used
70 Not Used
71 Not Used
72 Not Used
73 Not Used
74 Not Used
75 Fuse PullerReplacement Bulbs
Front Outside Lamps Bulb
Cornering Lamps . . . . . . . . . . . . . . . 3157
Halogen Headlamps
Low Beam . . . . . . . . . . . . . . . . . 9006
High Beam . . . . . . . . . . . . . . . . . 9005
Parking/Turn Signal Lamps . . . . . . . 3157
Rear Outside Lamps
Back
-Up Lamps . . . . . . . . . . . . . . . . 3057
Tail . . . . . . . . . . . . . . . . . . . . . . . . . . 194
Tail/Stop/Turn Signal lamps . . . . . . 3357
For service information on other bulbs, contact your
dealer's service department.

yellowblue
6-69
Capacities and Specifications
The following approximate capacities are given in English
and metric conversions. Please refer to ªRecommended
Fluids and Lubricantsº in the Index for more information.
Engine Specifications
VIN Engine Code K. . . . . . . . . . . . . . . . . . . . . . . . . . .
Type V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 3.8 L. . . . . . . . . . . . . . . . . . . . . . . . . . .
Horsepower 205. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 195
F (91
C) . . . . . . . . . . .
Wheel Nut Torque
100 1b-ft (140 N´m)
Capacities
Transaxle
Pan Removal and Replacement 6.0 quarts (5.7 L). . .
After Complete Overhaul 10.0 quarts (9.5 L). . . . . . .
When draining or replacing torque convertor, more fluid
may be needed.
Engine Cooling System 13.0 quarts (12.3 L). . . . . . .
Crankcase
(Engine Oil with Filter Change) 4.5 quarts (4.3 L).
Fuel Tank 17.5 gallons (66.2 L). . . . . . . . . . . . . . . . . .
Air Conditioning
Refrigerant See refrigerant. . . . . . . . . . . . . . . . . . . .
charge label under the hood.
NOTE: All capacities are approximate. When adding, be
sure to fill to the appropriate level, as recommended in
this manual. Recheck fluid level after filling.

yellowblue
6-70
Normal Maintenance
Replacement Parts
Air Cleaner/Filter AC Type A-1096C . . . . . . . . . . . . .
Passenger Compartment
Air Filter GM Part No. 25654414. . . . . . . . . . . . . . .
Engine Oil Filter AC Type PF
-47 . . . . . . . . . . . . . . . .
Fuel Filter AC Type GF
-627 . . . . . . . . . . . . . . . . . . . .
Transaxle Filter GM Part No. 8651909. . . . . . . . . . . .
Spark Plugs AC Type 41
-921 . . . . . . . . . . . . . . . . . .
Gap: 0.060 inch (1.52 mm)
Windshield Wiper Blades
(Shepherd's Hook Type) 22.0 inches (56.0 cm). . . . .
Vehicle Dimensions
Length 200.0 inches (508.0 cm). . . . . . . . . . . . . . . . .
Width 75.9 inches (192.8 cm). . . . . . . . . . . . . . . . . . .
Height 57.9 inches (147.1 cm). . . . . . . . . . . . . . . . . . .
Wheelbase 112.2 inches (285.0 cm)c. . . . . . . . . . . . .
Tread Width
Front 60.4 inches (153.4 cm). . . . . . . . . . . . . . . . . . . .
Rear 60.2 inches (152.9 cm). . . . . . . . . . . . . . . . . . . .
Engine Accessory Belt
The engine uses an engine accessory belt.
This diagram shows the features connected and the
routing. See ªMaintenance Scheduleº in the Index for
when to check the belt.
A. Power Steering
B. Generator
C. Air Conditioning
D. Crankshaft
E. Coolant Pump
F. Tensioner

7-
yellowblue
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-3 How This Section is Organized
7
-4 Part A: Scheduled Maintenance Services
7
-4 Using Your Maintenance Schedule
7
-4 Selecting the Right Schedule
7
-7 Short Trip/City Scheduled Maintenance7
-20 Long Trip/Highway Scheduled Maintenance
7
-27 Part B: Owner Checks and Services
7
-31 Part C: Periodic Maintenance Inspections
7
-32 Part D: Recommended Fluids and Lubricants
7
-34 Part E: Maintenance Record
