2-74
Did you just drive through a deep puddle of water?
If so, your electrical system may be wet. The condition
will usually be corrected when the electrical system
dries out. A few driving trips should turn the light off.
Have you recently changed brands of fuel?
If so, be sure to fuel your vehicle with quality fuel
(see ªFuelº in the Index). Poor fuel quality will cause
your engine not to run as efficiently as designed. You
may notice this as stalling after start
-up, stalling when
you put the vehicle into gear, misfiring, hesitation
on acceleration or stumbling on acceleration. (These
conditions may go away once the engine is warmed up.)
This will be detected by the system and cause the light
to turn on.
If you experience one or more of these conditions,
change the fuel brand you use. It will require at least one
full tank of the proper fuel to turn the light off.
If none of the above steps have made the light turn off,
have your dealer or qualified service center check the
vehicle. Your dealer has the proper test equipment and
diagnostic tools to fix any mechanical or electrical
problems that may have developed.Emissions Inspection and Maintenance Programs
Some state/provincial and local governments have or may
begin programs to inspect the emission control equipment
on your vehicle. Failure to pass this inspection could
prevent you from getting a vehicle registration.
Here are some things you need to know in order to help
your vehicle pass an inspection:
Your vehicle will not pass this inspection if the SERVICE
ENGINE SOON light is on or not working properly.
Your vehicle will not pass this inspection if the OBD
(on
-board diagnostic) system determines that critical
emission control systems have not been completely
diagnosed by the system. The vehicle would be
considered not ready for inspection. This can happen if
you have recently replaced your battery or if your
battery has run down. The diagnostic system is designed
to evaluate critical emission control systems during
normal driving. This may take several days of routine
driving. If you have done this and your vehicle still does
not pass the inspection for lack of OBD system
readiness, see your dealer or qualified service center to
prepare the vehicle for inspection.

yellowblue
2-75 Oil Pressure Light
If your vehicle has the
standard instrument panel
cluster, this light will come
on if there is a problem with
your engine oil pressure.
If your vehicle has the optional gage cluster, you can
read your oil pressure directly from the Driver
Information Center (DIC). See ªDIC Displays and
Controlsº in the Index.
The oil light will come on briefly when you turn your
key to RUN. That's just a check to be sure the light
works. If it doesn't, be sure to have it fixed so it will be
there to warn you if something goes wrong.
But, when this light comes on and stays on, and a chime
sounds, it means oil isn't going through your engine
properly. You could be low on oil, or you might have
some other oil problem. See your dealer for service.CAUTION:
Don't keep driving if the oil pressure is low.
If you do, your engine can become so hot that it
catches fire. You or others could be burned.
Check your oil as soon as possible and have your
vehicle serviced.
NOTICE:
Damage to your engine from neglected oil
problems can be costly and is not covered by
your warranty.

yellowblue
2-76 Service Vehicle Soon Light
This light will come on and
stay on if you have certain
non
-emission related
vehicle problems.
These problems may not be obvious and may affect vehicle
performance or durability. Consult a qualified dealership for
necessary repairs to maintain top vehicle performance.
This light will also come on briefly when your ignition
is turned on to show that the system is working properly.
Cruise Light
The cruise light comes on
whenever you set your
cruise control. See ªCruise
Controlº in the Index.
Fuel Gage
Standard Cluster Gage Cluster
Your fuel gage shows about how much fuel is in your
tank. It works only when the engine is on. When the
indicator nears the edge of the low fuel warning band,
the low fuel light will turn on and a chime will sound.
You still have a little fuel left, however you need to
refuel right away.

yellowblue
2-80
If the ignition is on and you can't see the HUD image,
check to see if:

Something is covering the HUD unit.

The HUD dimmer control is adjusted properly.

The HUD image is adjusted to the proper height.

A fuse is blown. See ªFuses and Circuit Breakersº
in the Index.
Keep in mind that your windshield is part of the HUD
system. If you ever have to have your windshield
replaced, be sure to get one that is designed for HUD or
your HUD image may look blurred or out of focus.
Driver Information Center (DIC)
(If Equipped)
Your vehicle may be equipped with a Driver Information
Center (DIC). The DIC will display information about
how your vehicle is functioning, as well as warning
messages if a system problem is detected. This feature also
allows two different drivers to store and recall their own
personal choice settings. See ªDIC Personal Choice
Programmingº later in this section.
DIC Displays and Controls
There are two lines in the DIC display. The DIC displays
the driver number identified when entering the vehicle.
You can have your dealer program your name to appear on
this display line. See your dealer for more information.
When you turn the ignition on, the DIC will display your
DRIVER NUMBER. The system will then perform a status
check and display any messages if a problem is detected.
If there are no problems detected, the display will return
to the mode selected by that driver the last time the
ignition was turned off.
If a problem is detected, a diagnostic message will
appear in the display. The following pages will show the
messages you may see on the DIC display.
The message center is continuously updated with the
vehicle's performance status.

yellowblue
2-82

GAGE INFO: Use this button to display oil pressure,
oil life, coolant temperature, tire pressure and
battery information.
Press the GAGE INFO button until OIL PRESSURE
appears in the display. If there are no problems
detected with the oil pressure, the display will show
OIL PRESSURE NORMAL. If a low oil pressure
condition is detected, the display will show OIL
PRESSURE LOW. If you see the OIL PRESSURE
LOW message, your vehicle could be low on oil or
the oil is not going through the engine properly.
See your dealer for service.
Press the GAGE INFO button until COOLANT
TEMP appears in the display. If there are no
problems detected with the temperature, COOLANT
TEMP NORMAL will appear in the display. If the
temperature is too high, COOLANT TEMP HOT
will appear in the display. If you see the COOLANT
TEMP HOT message, the engine is overheated. You
should pull off the road, stop your vehicle and turn
off your engine as soon as possible. This manual
explains what to do. See ªEngine Overheatingº in
the Index.Press the GAGE INFO button until the display
shows BATTERY STATE. If the voltage is normal
the display will show BATTERY STATE NORMAL.
If the voltage drops below 10.5 volts, the display will
show BATTERY STATE LOW. If the voltage is
above 16 volts, the display will show BATTERY
STATE HIGH. If the display shows the high or low
message, you need to have your battery and charging
system checked.
Press the GAGE INFO button until OIL LIFE
INDEX appears in the display. The OIL LIFE
INDEX NORMAL display will show an estimate of
the oil's remaining useful life. When the oil life
index is less than 10%, the display will show OIL
LIFE INDEX CHANGE OIL. When you have the
oil changed according to the maintenance schedule
(see ªMaintenance Scheduleº in the Index), you will
have to reset the oil life monitor. To reset the Oil
Life System (Index), see ªOil Life Systemº or
ªEngine Oil, When to Changeº in the Index.

yellowblue
2-83
Press the GAGE INFO button until TIRE PRESSURE
appears in the display. TIRE PRESSURE NORMAL is
displayed when the Check Tire Pressure System
believes your vehicle's tire pressures are normal. If a
potential tire pressure problem is detected, the display
will show TIRE PRESSURE LOW: CHECK TIRES.
If you see the TIRE PRESSURE LOW: CHECK
TIRES message, you should stop as soon as you can
and check all your tires for damage. (If a tire is flat, see
ªIf a Tire Goes Flatº in the Index.) Also check the
tire pressure in all four tires as soon as you can.
See ªInflation
-- Tire Pressureº and ªCheck Tire
Pressure Systemº in the Index. There are times
when you will have to reset (calibrate) the Check
Tire Pressure System. See ªCheck Tire Pressure
Systemº in the Index.

RESET: This button, used along with other buttons,
will reset system functions.

ENG/MET: Use this button to change the display
between English and metric units.
DIC Warnings and Messages
Other messages or warnings may appear in the DIC
display. For Canadian drivers, in addition to the DIC
message your DIC will display EXP with a number after
it which reflects the following messages:EXP (Export ID) Warning Message
2 ENG COOLANT LOW
- CHECK LEVEL . . . . . .
20 TURN SIGNAL STILL ON?. . . . . . . . . . . . . . . .
24 TRUNK AJAR. . . . . . . . . . . . . . . . . . . . . . . . . . .
25 WINDSHIELD WASHER FLUID LOW. . . . . . .
27 BATTERY SAVER ACTIVE. . . . . . . . . . . . . . . .
36 ENGINE OIL LOW
- CHECK LEVEL . . . . . . . .
40 THEFT ATTEMPT DETECTED. . . . . . . . . . . . .
54 SERVICE STABILITY SYSTEM. . . . . . . . . . . .
55 STABILITY SYSTEM ACTIVE. . . . . . . . . . . . .
61 GAS CAP LOOSE
- CHECK CAP . . . . . . . . . . .
81 CHANGE ENGINE OIL SOON. . . . . . . . . . . . .
91 TRACTION CONTROL SYSTEM ACTIVE. . .
102 CHECK CHARGE SYSTEM. . . . . . . . . . . . . . .
139 DOOR AJAR. . . . . . . . . . . . . . . . . . . . . . . . . . .
144 CHECK TIRE PRESSURE. . . . . . . . . . . . . . . .
The EXP codes are used to make translation from
English to other languages easier.
Pressing any of the DIC control buttons will remove the
messages or warnings from the DIC display.

yellowblue
2-84
SERVICE STABILITY SYSTEM - 54: If you ever
see the SERVICE STABILITY SYSTEM message, it
means there may be a problem with your stability
enhancement system. If you see this message, try to
reset the system (stop; turn off the engine; then start the
engine again). If the SERVICE STABILITY SYSTEM
message still comes on, it means there is a problem. You
should see your dealer for service. Reduce your speed
and drive accordingly.
STABILITY SYSTEM ACTIVE
- 55: You may see
the STABILITY SYSTEM ACTIVE message on the
Driver Information Center. It means that an advanced,
computer
-controlled system has come on to help your
vehicle continue to go in the direction in which you're
steering. This stability enhancement system activates when
the computer senses that your vehicle is just starting to
spin, as it might if you hit a patch of ice or other slippery
spot on the road. When the system is on, you may hear a
noise or feel a vibration in the brake pedal. This is normal.
When the STABILITY SYSTEM ACTIVE message is
on, you should continue to steer in the direction you
want to go. The system is designed to help you in bad
weather or other difficult driving situations by making
the most of whatever road conditions will permit. If the
STABILITY SYSTEM ACTIVE message comes on,
you'll know that something has caused your vehicle to
start to spin, so you should consider slowing down.
DIC Personal Choice Programming
The DIC can be used to program the following personal
choice features available with your vehicle:

Automatic Door Locks

Window Lockout

Security Feedback

Delayed Locking

Perimeter Lighting

Memory Seats

Tilt Mirrors (If Equipped)

Driver ID ON/OFF
For vehicles not equipped with a DIC, see
ªPersonal Choice Programmingº in the Index.
The personal choice settings displayed on the
DIC are determined by the transmitter used to enter
the vehicle. Each remote keyless entry transmitter was
pre
-programmed to belong to DRIVER 1 or DRIVER 2
and is numbered on the back. After the button with the
unlock symbol on a remote keyless entry transmitter is
pressed and the ignition is in RUN, the DIC will display
the identified driver and recall the settings previously
programmed for that driver. The settings can also be
recalled by briefly pressing one of the MEMORY
buttons located on the driver's door.

yellowblue
2-86
Automatic Door Locks
The door lock modes when shifting in and out of
PARK (P), can be changed through the DIC. You can
change these modes by different selections of the
following DIC displays:

AUTO DOOR LOCKS
- OFF/ON

UNLOCK
- OFF/ON

UNLOCK
- KEY OFF/PARK

DOOR TO UNLOCK
- DRIVER/ALL
If you choose OFF for AUTO DOOR LOCKS, your door
locks will operate normally with no automatic feature.
If you choose ON for AUTO DOOR LOCKS, ON for
UNLOCK and KEY OFF, your doors will lock every
time you shift out of PARK (P), and the doors will
unlock every time you stop and turn the ignition to OFF.
If you choose ON for AUTO DOOR LOCKS, ON for
UNLOCK and PARK, your doors will lock every time
you shift out of PARK (P), and the doors will unlock
every time you stop and shift into PARK (P).
If you choose ON for AUTO DOOR LOCKS, and OFF
for UNLOCK, your doors will lock every time you shift
out of PARK (P), and there will be no automatic door
unlock when shifting back into PARK (P).If you choose ON for UNLOCK and DRIVER for DOOR
TO UNLOCK, only the driver's door will automatically
unlock when shifting into PARK or turning the key to OFF.
If you choose ON for UNLOCK and ALL for DOOR
TO UNLOCK, all doors will automatically unlock when
shifting into PARK or turning the key to OFF.
To change modes:
1. Move the arrow on the display between the
selections by pressing the ENG/MET button.
2. Once you have made your selection, press the RESET
button and your choice will be retained in memory.
See ªAutomatic Door Locksº in the Index for more
information about this feature.
Window Lockout
The number of passenger windows locked out by the
WINDOW LOCKOUT switch can be programmed
through the DIC.
If you choose R + PASS, all three passenger window
switches will be inactive when the WINDOW
LOCKOUT switch is enabled.
If you choose REAR, only the two rear passenger
window switches will be locked out when the
WINDOW LOCKOUT switch is enabled.

yellowblue
2-87
To change modes:
1. Move the arrow on the display between R + PASS
and REAR by pressing the ENG/MET button.
2. Once you have made your selection, press the RESET
button. Your choice will be retained in memory.
For more information on this feature, see ªWindow
Lockº in the Index.
Security Feedback
By choosing different combinations of these selections,
you can choose the type of transmitter activated
feedback when locking and unlocking your vehicle with
your transmitter. Each time you make a selection by
pressing the ENG/MET button, press the RESET button
to record your choice.

KEYLESS FEEDBACK
- OFF/ON

LIGHTS FEEDBACK
- OFF/ON

HORN FEEDBACK
- OFF/ON
If you choose ON for KEYLESS FEEDBACK you will
also need to choose LIGHTS and/or HORN FEEDBACK.You can select the following modes:

If you choose OFF for KEYLESS FEEDBACK, you
will receive no security feedback when locking or
unlocking your vehicle.

If you choose ON for KEYLESS FEEDBACK and
ON for LIGHTS FEEDBACK, the exterior lamps
will flash twice when unlocking your vehicle and
once when locking your vehicle.

If you choose ON for KEYLESS FEEDBACK and
ON for HORN FEEDBACK, your horn will chirp
when locking and unlocking your vehicle.

If you choose ON for KEYLESS, LIGHTS and
HORN FEEDBACK, your exterior lamps will flash
and your horn will chirp twice when unlocking your
vehicle and once when locking your vehicle.
For more information on this feature, see
ªSecurity Feedbackº in the Index.

yellowblue
2-88
Delayed Locking
The delayed locking feature, which delays the actual locking
of the vehicle, can be made active or inactive through
the DIC. When DELAYED LOCKING
- OFF - ON appears
on the display, use the ENG/MET button to toggle the arrow
between OFF and ON. When you have made your choice,
press the RESET button to record your selection.
For more information on this feature, see ªDelayed
Lockingº in the Index.
Perimeter Lighting
When the button with the unlock symbol on the
transmitter is pressed, the Daytime Running Lamps
(high
-beams at reduced intensity), parking lamps and
back
-up lamps will turn on if it is dark enough
according to the Twilight Sentinel
.
You can control activation of this feature by choosing
OFF or ON when the PERIMETER LIGHTS choice is
displayed on the DIC. Make your choice by pressing the
ENG/MET button and record your choice by pressing
the RESET button. You will then be prompted to choose
a TIMEOUT period. See ªExterior Lightsº later in this
section for more information.
For more information on this feature, see ªPerimeter
Lightingº in the Index.Exterior Lights
The EXTERIOR LIGHTS/TIMEOUT feature can be
changed to desired setting by using the ENG/MET to
toggle from 5 to 30 seconds. Each toggle will increase
the time by 5 seconds. Once the desired timeout is
displayed, press RESET to record your choice and move
on to the next personal choice feature.
Memory Seat Recall
This feature recalls the position of your seat. When this
feature is active, the memory seat and mirror positions
will be recalled for the identified driver when the remote
keyless entry transmitter is used to enter the vehicle.
You can program this feature to be active by choosing
ON when the SEAT RECALL choice appears, or
inactive by choosing OFF when the SEAT RECALL
choice appears on the DIC. Make your choices by
pressing the ENG/MET button and store them to
memory by pressing the RESET button.
