3-33
CD TAPE: Press this button to play a cassette tape or a
CD when listening to the radio.
(Eject): Press this button to eject a tape.
Cassette Tape Messages
If an error message appears while trying to play
a cassette tape, it could be for one of the
following reasons:

TIGHT TAPE: The tape is tight and the player can't
turn the tape hubs. Remove the tape. Hold the tape
with the open end down and try to turn the right hub
counterclockwise with a pencil. Turn the tape over
and repeat. If the hubs do not turn easily, your tape
may be damaged and should not be used in the
player. Try a new tape to make sure your player is
working properly.

BROKEN TAPE: The tape is broken. Try a
new tape.
CLEAN PLAYER: If this message appears on the
display, the cassette tape player needs to be cleaned. It
will still play tapes, but you should clean it as soon as
possible to prevent damage to the tapes and player. See
ªCare of Your Cassette Tape Playerº in the Index.If any error occurs repeatedly or if an error can't be
corrected, contact your dealer. If your radio displays an
error number, write it down and provide it to your dealer
when reporting the problem.
CD Adapter Kits
It is possible to use a portable CD player adapter kit
with your cassette tape player after activating the bypass
feature on your tape player.
To activate the bypass feature, use the following steps:

Turn the ignition to RUN or ACCESSORY.

Turn the radio off.

Insert the adapter into the cassette slot.

Press and hold the CD TAPE button until READY
is displayed.
This override routine will remain active until the eject
button is pressed.

3-34
Playing a Compact Disc
Insert a disc partway into the slot, label side up. The
player will pull it in. The disc should begin playing. If
you want to insert a CD while the ignition or the radio is
off, first press the eject button or DISP.
If you turn off the ignition or radio with a disc in the
player, it will stay in the player. When you turn on the
ignition or system, the disc will start playing where it
stopped, if it was the last selected audio source.
If an error appears on the display, see ªCompact Disc
Messagesº later in this section.
1
(Reverse): Press and hold this pushbutton to
quickly reverse within a track. You will hear sound.
2
(Forward): Press and hold this pushbutton to
quickly advance within a track. You will hear sound.
4 RDM (Random): Press this pushbutton to hear the
tracks in random, rather than sequential, order. Press
RDM again to turn off random play.
DISP (Display): Press this button to see which track is
playing. Press it again within five seconds to see how
long it has been playing. To change what is normally
shown on the display (track or elapsed time), press this
button until you see the display you want, then hold the
button until the display flashes.
SEEK : Press the left SEEK button to go to the
start of the current track if more than eight seconds have
played. If you hold the button or press it more than once,
the player will continue moving back through the disc.
Press the right SEEK button to go to the next track. If
you hold the button or press it more than once, the
player will continue moving forward through the disc.
The sound will mute while seeking.
To scan CD tracks, press and hold one of the SEEK
arrows for two seconds until SCAN appears on the
display. You will hear a beep. The disc will go to the
next track, play for a few seconds, then go on to the
next track. Press one of the SEEK arrows again to stop
scanning. The sound will mute and SCAN and the track
number will appear on the display while scanning. The
disc will only scan forward.
AM FM: Press this button to listen to the radio when
a cassette tape or CD is playing.
CD TAPE: Press this button to change to playing a
cassette tape or a CD when listening to the radio.
(Eject): Press this button to eject a CD.

3-35
Compact Disc Errors
CHECK CD: If this message appears on the radio
display, it could be due to one of the following reasons:

The road is too rough. The disc should play when the
road is smoother.

The disc is dirty, scratched, wet or upside down.

The air is very humid. If so, wait about an hour and
try again.
If the CD is not playing correctly, for any other reason,
try a known good CD.
If any error occurs repeatedly or if an error can't be
corrected, contact your dealer. If your radio displays an
error number, write it down and provide it to your dealer
when reporting the problem.Trunk-Mounted CD Changer (Option)
With the optional compact disc changer, you can play up
to 12 discs continuously. Normal size discs may be
played using the trays supplied in the magazine.
NOTICE:
Place large objects appropriately in the trunk so
that they will not come into contact with the CD
changer. Damage could result that wouldn't be
covered by your warranty.

3-37
Close the door by sliding it all the way to the right.
When the door is closed, the changer will begin
checking for discs in the magazine. This will continue
for up to one and a half minutes depending on the
number of discs loaded.
To eject the magazine from the player, slide the CD
changer door all the way open (to the left). The
magazine will automatically eject. Remember to keep
the door closed whenever possible to keep dirt and dust
from getting inside the changer.Whenever a CD magazine with discs is loaded in the
changer and the door is closed, the CD changer stack
symbol will appear on the radio display. If the CD
changer is checking the magazine for CDs, the CD
changer stack symbol will flash on the display until the
changer is ready to play. When a CD begins playing, the
disc and track number will be displayed. The disc
numbers are listed on the front of the magazine.
All of the CD functions are controlled by the radio
buttons except for ejecting the magazine.
Playing a Compact Disc
If an error appears on the display, see ªCompact Disc
Messagesº later in this section.
1 (Reverse): Press and hold this pushbutton to
quickly reverse within a track. As the CD reverses,
elapsed time will be displayed to help you find the
correct passage.
2
(Forward): Press and hold this pushbutton to
quickly advance within a track. As the CD advances,
elapsed time will be displayed to help you find the
correct passage.

3-38
4 RDM (Random): Press this pushbutton to enter the
random play mode. RAND will appear on the display.
While in this mode, tracks and discs will be played in
random order. Press this pushbutton again to turn off the
random feature and return to normal operation.
6 SIDE: Press this pushbutton to select the next disc in
the magazine. Each time you press SIDE, the disc
number on the radio display will go to that of the next
available CD.
DISP (Display): Press this button to see how long the
current track has been playing. Press this button again to
display the disc and track number. To change what is
normally shown on the display (track or elapsed time),
press this button until you see the display you want, then
hold this button until the display flashes and a chime is
heard. While elapsed time is showing, CD TIME will
appear on the display. SEEK : Press the left arrow while playing a CD
to go back to the start of the current track if more than
eight seconds have played. If you press it more than
once, the player will continue moving backward through
the disc. Press the right arrow and it will go to the next
track on the disc. If you press it more than once, the
player will continue moving forward through the disc.
The sound will mute while seeking.
When you press the left SEEK arrow for two seconds
you will hear a beep. The disc will play the first few
seconds of each track on each disc. The sound will
mute while scanning and DISC SCAN will appear
on the display. Press the left SEEK arrow again to
stop scanning.
AM FM: Press this button to return to listening to the
radio while a CD is playing.
TAPE/CD/CD TAPE: Press this button to play a
CD if you have a magazine loaded in the changer when
listening to the radio. You can also press this button to
switch between a cassette tape, CD or the CD changer if
all three are loaded.

3-39
Compact Disc Changer Errors
E (Error): If this message and a number appear on the
display, an error has occurred.
If the error occurred while trying to play a CD in the
compact disc player or changer, the following conditions
may have caused the error:

E30: The road is too rough. The disc should play
when the road is smoother.

E30: The disc is dirty, scratched, wet or
upside down.

E30: The air is very humid. If so, wait about an hour
and try again.

E34: The CD changer door is open. Completely
close the door to restore normal operation.

E35: An empty magazine is inserted in the CD
changer. Try the magazine again with a disc loaded
on one of the trays.
If any error occurs repeatedly or if an error cannot be
corrected, contact your dealer. If your radio displays
an error number other than the error codes listed
previously, write it down and provide it to your dealer
when reporting the problem.Personal Choice Radio Controls
(If Equipped)
This feature enables two drivers to store and recall personal
settings for AM and FM presets, last tuned station, volume,
tone and audio source (radio, cassette or CD).
The memory buttons (1 or 2) for this feature are located
on the driver's door panel and correspond to the
numbers (1 or 2) found on the back of each remote
keyless entry transmitter.
To recall audio sources, press the unlock button on the
remote keyless entry transmitter and put the ignition in
RUN. The source last listened to will be recalled for the
identified driver (1 or 2).
To program this feature, do the following:
1. Set all radio preferences. For more information see
ªSetting Preset Stationsº and ªSetting the Toneº
listed for your particular radio.
2. Locate the memory buttons on the driver's door panel.
3. Press one of the memory buttons (1 or 2) until you
hear two beeps. The beeps confirm that your
selection has been saved and can now be recalled.
Follow these steps each time you want to change the
stored settings.

3-40 Theft-Deterrent Feature (If Equipped)
THEFTLOCK
is designed to discourage theft of your
radio. It works by using a secret code to disable all radio
functions whenever battery power is removed and the
radio is placed in a different vehicle. This feature
requires no user input to be activated. It is automatically
armed when it is put into the vehicle for the first time.
When the ignition is turned off, the blinking red light
indicates that THEFTLOCK is armed.
If THEFTLOCK is activated, your radio will not operate
if stolen. The radio will display LOCKED and a red
LED indicator light will come on above the key symbol
to indicate a locked condition. If this occurs, the radio
will have to be returned to the dealer.
Audio Steering Wheel Controls
(If Equipped)
If your vehicle has this feature, you can control certain
radio functions using the buttons on your steering wheel.
SOURCE: Press this button to play a cassette tape or
compact disc when listening to the radio. If a cassette
tape and a compact disc are both loaded, the system will
go to the tape play first.
MUTE: Press this button to silence the system. Press it
again to turn on the sound.
VOL
(Volume): Press the up or down arrow to
increase or decrease volume.

3-42
NOTICE:
Before you add any sound equipment to your
vehicle
-- like a tape player, CB radio, mobile
telephone or two
-way radio -- be sure you can
add what you want. If you can, it's very
important to do it properly. Added sound
equipment may interfere with the operation of
your vehicle's engine, Delphi Electronics radio or
other systems, and even damage them. Your
vehicle's systems may interfere with the
operation of sound equipment that has been
added improperly.
So, before adding sound equipment, check with
your dealer and be sure to check federal rules
covering mobile radio and telephone units.
Care of Your Cassette Tape Player
A tape player that is not cleaned regularly can cause
reduced sound quality, ruined cassettes or a damaged
mechanism. Cassette tapes should be stored in their
cases away from contaminants, direct sunlight and
extreme heat. If they aren't, they may not operate
properly or may cause failure of the tape player.
Your tape player should be cleaned regularly after
every 50 hours of use. Your radio may display CLEAN
PLAYER to indicate that you have used your tape player
for 50 hours without resetting the tape clean timer. If
this message appears on the display, your cassette tape
player needs to be cleaned. It will still play tapes, but
you should clean it as soon as possible to prevent
damage to your tapes and player. If you notice a
reduction in sound quality, try a known good cassette
to see if it is the tape or the tape player at fault. If this
other cassette has no improvement in sound quality,
clean the tape player.
The recommended cleaning method for your cassette
tape player is the use of a scrubbing action,
non
-abrasive cleaning cassette with pads which scrub
the tape head as the hubs of the cleaner cassette turn.
The recommended cleaning cassette is available through
your dealer (GM Part No. 12344789).

3-43
When cleaning the cassette tape player with the
recommended non
-abrasive cleaning cassette, it is
possible that the cassette may eject, because the cut tape
detection feature on your radio may recognize it as a
broken tape. If the cleaning cassette ejects, insert the
cassette at least three times to ensure thorough cleaning.
You may also choose a non
-scrubbing action, wet-type
cleaner which uses a cassette with a fabric belt to clean
the tape head. This type of cleaning cassette will not
eject on its own. A non
-scrubbing action cleaner may
not clean as thoroughly as the scrubbing type cleaner.
The use of a non
-scrubbing action, dry-type cleaning
cassette is not recommended.
After you clean the player, press and hold the eject
button for five seconds to reset the CLEAN PLAYER
indicator. The radio will display
--- to show the
indicator was reset.
Cassettes are subject to wear and the sound quality
may degrade over time. Always make sure the cassette
tape is in good condition before you have your tape
player serviced.
Care of Your Compact Discs
Handle discs carefully. Store them in their original cases
or other protective cases and away from direct sunlight
and dust. If the surface of a disc is soiled, dampen a
clean, soft cloth in a mild, neutral detergent solution and
clean it, wiping from the center to the edge.
Be sure never to touch the signal surface when handling
discs. Pick up discs by grasping the outer edges or the
edge of the hole and the outer edge.
Care of Your Compact Disc Player
The use of CD lens cleaner discs is not advised, due to
the risk of contaminating the lens of the CD optics with
lubricants internal to the CD mechanism.

3-44 Diversity Antenna System
Your AM-FM antennas are located in the front
windshield and rear window. Be sure that the inside
surfaces of the front windshield and rear window are
not scratched and that the lines on the glass are not
damaged. If the inside surfaces are damaged, they
could interfere with radio reception. Also, for proper
radio reception, the antenna connectors at the top
-center
of the front and rear windows need to be properly
attached to the posts on the glass.
Do not apply aftermarket glass tinting. The metallic film
in some tinting materials will interfere with or distort the
incoming radio reception.
NOTICE:
Do not try to clear frost or other material from
the inside of the rear window with a razor blade
or anything else that is sharp. This may damage
the rear defogger grid and affect your radio's
ability to pick up stations clearly. The repairs
wouldn't be covered by your warranty.
If, when you turn on your rear window defogger, you
hear static on your radio station, it could mean that a
defogger grid line has been damaged. If this is true, the
grid line must be repaired.
If you choose to add an aftermarket cellular telephone to
your vehicle, and the antenna needs to be attached to the
glass, be sure that you do not damage the grid lines for
the AM
-FM antennas or place the cellular telephone
antenna over the grid lines.
Chime Level Adjustment
The volume level of the vehicle's chimes can be
controlled by the radio. To change the volume level,
press and hold pushbutton 1 with the ignition on and the
radio power off. The chime volume level will change
from the soft level to loud, and LOd will be displayed
on the radio. To change back to the soft level setting,
press and hold pushbutton 1 again. The chime level
will change from the loud level to soft, and Sf will
be displayed.
