Wheel Replacement
Replace any wheel that is bent, cracked or badly rusted
or corroded. If wheel nuts keep coming loose, the
wheel, wheel bolts and wheel nuts should be replaced.
If the wheel leaks air, replace it (except some
aluminum wheels, which can sometimes be repaired).
See your dealer if any of these conditions exist.
Your dealer will know the kind of wheel you need.
Each new wheel should have the same load-carrying
capacity, diameter, width, offset and be mounted
the same way as the one it replaces.
If you need to replace any of your wheels, wheel bolts
or wheel nuts, replace them only with new GM
original equipment parts. This way, you will be sure to
have the right wheel, wheel bolts and wheel nuts
for your vehicle.{CAUTION:
Using the wrong replacement wheels, wheel
bolts or wheel nuts on your vehicle can be
dangerous. It could affect the braking and
handling of your vehicle, make your tires lose
air and make you lose control. You could have
a collision in which you or others could be
injured. Always use the correct wheel, wheel
bolts and wheel nuts for replacement.
Notice:The wrong wheel can also cause problems
with bearing life, brake cooling, speedometer or
odometer calibration, headlamp aim, bumper height,
vehicle ground clearance and tire or tire chain
clearance to the body and chassis.
SeeChanging a Flat Tire on page 5-79for more
information.
5-74

Electrical System
Add-On Electrical Equipment
Notice:Don’t add anything electrical to your vehicle
unless you check with your dealer rst. Some
electrical equipment can damage your vehicle and
the damage wouldn’t be covered by your warranty.
Some add-on electrical equipment can keep other
components from working as they should.
Your vehicle has an air bag system. Before attempting
to add anything electrical to your vehicle, seeServicing
Your Air Bag-Equipped Vehicle on page 1-55.
Headlamps
The headlamp wiring is protected by four fuses.
An electrical overload will cause a lamp to go on and off.
If this happens, have your headlamp wiring checked
right away.
Windshield Wiper Fuses
The windshield wiper motor is protected by a circuit
breaker and a fuse. If the motor overheats due to heavy
snow or ice, the wiper will stop until the motor cools.
If the overload is caused by some electrical problem,
be sure to get it xed.
Power Windows and Other Power
Options
Circuit breakers protect the power windows and other
power accessories. When the current load is too heavy,
the circuit breaker opens and closes, protecting the
circuit until the problem is xed or goes away.
5-102

Fuses Usage
1Electrically-Controlled Air
Suspension
2Passenger’s Side High-Beam
Headlamp
3Passenger’s Side Low-Beam
Headlamp
4 Back-Up-Trailer Lamps
5 Driver’s Side High-Beam Headlamp
6 Driver’s Side Low-Beam Headlamp
7 Wash
8 Automatic Transfer Case
9 Windshield Wipers
10 Powertrain Control Module B
11 Fog Lamps
12 Stop Lamp
13 Cigarette Lighter
14 Ignition Coils
15 Blank
16 TBD-Ignition 1
17 CrankFuses Usage
18 Air Bag
19 Electric Brake
20 Cooling Fan
21 Horn
22 Ignition E
23 Electronic Throttle Control
24Instrument Panel Cluster,
Driver Information Center
25 Automatic Shift Lock Control System
26 Engine 1
27 Back-Up
28 Powertrain Control Module 1
29 Oxygen Sensor
30 Air Conditioning
31 Truck Body Controller
32 Trailer
33 Anti-Lock Brakes (ABS)
34 Ignition A
35 Blower Motor
5-105

Fuses Usage
36 Ignition B
50 Passenger’s Side Trailer Turn
51 Driver’s Side Trailer Turn
52 Hazard Flashers
53 Electric Adjustable Pedal
54 A.I.R. Solenoid
56 A.I.R. Pump
Relays Usage
37 Blank or Headlamp Wash
38 Rear Window Washer
39 Fog Lamps
40 HornFuses Usage
41 Fuel Pump
42 Windshield Wipers/Washer
43 High-Beam Headlamp
44 Air Conditioning
45 Cooling Fan
46 Headlamp Driver Module
47 Starter
49 Electric Adjustable Pedal
55 A.I.R. Solenoid
Miscellaneous Usage
48 Instrument Panel Battery
49 Blank
5-106

Fuses Usage
1Electrically-Controlled Air
Suspension
2Passenger’s Side High-Beam
Headlamp
3Passenger’s Side Low-Beam
Headlamp
4 Back-Up-Trailer Lamps
5 Driver’s Side High-Beam Headlamp
6 Driver’s Side Low-Beam Headlamp
7 Wash
8 Automatic Transfer Case
9 Windshield Wipers
10 Powertrain Control Module B
11 Fog Lamps
12 Stop Lamp
13 Cigarette Lighter
14 Ignition Coils
15 Cannister Vent
16 TBD-Ignition 1
17 CrankFuses Usage
18 Air Bag
19 Electric Brake
20 Cooling Fan
21 Horn
22 Ignition E
23 Electronic Throttle Control
24Instrument Panel Cluster,
Driver Information Center
25 Automatic Shift Lock Control System
26 Engine 1
27 Back-Up
28 Powertrain Control Module 1
30 Air Conditioning
31 Truck Body Controller 1
32 Trailer
33 Anti-Lock Brakes (ABS)
34 Ignition A
35 Blower Motor
36 Ignition B
5-108

Fuses Usage
50 Passenger’s Side Trailer Turn
51 Driver’s Side Trailer Turn
52 Hazard Flashers
53 Oxygen Sensor Bank A
54 Oxygen Sensor Bank B
55 Injector Bank A
56 Injector Bank B
57 Electric Adjustable Pedal
Relays Usage
37 Headlamp Washer
38 Rear Window Washer
39 Fog LampsFuses Usage
40 Horn
41 Fuel Pump
42 Windshield Wipers/Washer
43 High-Beam Headlamp
44 Air Conditioning
45 Cooling Fan
46 Headlamp Driver Module
47 Starter
49 Electric Adjustable Pedal
58 Ignition 1
Miscellaneous Usage
48 Instrument Panel Battery
5-109

Audio System(s) (cont.)
Care of Your CDs and DVDs.......................3-115
Chime Level Adjustment.............................3-116
Fixed Mast Antenna...................................3-116
Navigation/Radio System..............................3-99
Audio Systems
Radio Personalization.................................3-112
Audio System(s)
Radio with Cassette and CD.........................3-68
Radio with CD............................................3-57
Radio with Six-Disc CD................................3-84
Rear Seat Audio (RSA)...............................3-111
Setting the Time..........................................3-56
Theft-Deterrent Feature...............................3-112
Understanding Radio Reception...................3-114
XMâ„¢ Satellite Radio Antenna System...........3-116
Automatic Headlamp System............................3-15
Automatic Transmission
Fluid..........................................................5-24
Operation...................................................2-24
B
Backglass Wiper Blade Replacement.................5-58
Backing Up....................................................4-60
Battery..........................................................5-44BATTERY NOT CHARGING.............................3-53
Battery Replacement......................................... 2-7
Battery Run-Down Protection............................3-18
Before Leaving on a Long Trip.........................4-36
Before You Drive............................................3-99
Before You Go Off-Roading..............................4-16
Brake
Parking......................................................2-26
System Warning Light..................................3-32
Brake Adjustment............................................5-43
Brake Fluid....................................................5-41
Brake Pedal, Throttle.......................................2-22
Brake Pedal Travel.........................................5-43
Brake Wear...................................................5-43
Brakes..........................................................5-41
Braking........................................................... 4-6
Braking in Emergencies..................................... 4-9
Break-In, New Vehicle.....................................2-19
Bulb Replacement...........................................5-54
Headlamps.................................................5-54
Replacement Bulbs......................................5-55
Taillamps and Turn Signal Lamps..................5-54
Buying New Tires...........................................5-71
2

E
Electrical System
Add-On Equipment.....................................5-102
Fuses and Circuit Breakers.........................5-103
Headlamps...............................................5-102
Power Windows and Other Power Options....5-102
Windshield Wiper Fuses.............................5-102
Electronically Controlled Air Suspension System....4-52
Emergency Release for Opening Liftgate............2-14
Emissions Inspection and Maintenance
Programs...................................................3-38
Engine
Air Cleaner/Filter.........................................5-23
Battery.......................................................5-44
Change Engine Oil Light...............................3-39
Check and Service Engine Soon Light............3-35
Coolant......................................................5-27
Coolant Heater............................................2-23
Coolant Temperature Gage...........................3-34
Drive Belt Routing.......................................6-15
Engine Compartment Overview......................5-14
Exhaust.....................................................2-29
Fan Noise..................................................5-38
Oil .............................................................5-18
Overheating................................................5-29Engine (cont.)
Reduced Power Light...................................3-40
Starting......................................................2-21
Engine Compartment Fuse Block.....................5-103
ENGINE COOLANT HOT/ENGINE
OVERHEATED............................................3-53
Engine Oil Additives........................................5-21
Entertainment System
Cleaning the Video Screen..........................3-116
DVD Distortion..........................................3-114
Entry Lighting.................................................3-18
Environmental Concerns..................................4-18
Erasing HomeLink
®Buttons..............................2-39
Event Data Records (EDR)..............................7-10
Exit Lighting...................................................3-18
Express Down Window....................................2-16
Extender, Safety Belt.......................................1-25
Exterior Lamps...............................................3-14
F
Filter
Engine Air Cleaner......................................5-23
Finding a Program Type (PTY)
Station (RDS and XMâ„¢)..............3-61, 3-72, 3-88
6

H
Hazard Warning Flashers................................... 3-6
Head Restraints............................................... 1-5
Headlamp High/Low-Beam Changer.................... 3-9
Headlamps....................................................5-54
Bulb Replacement.......................................5-54
Electrical System.......................................5-102
Headphones.................................................3-106
Heated Seats................................................... 1-3
Highway Hypnosis...........................................4-37
Hill and Mountain Roads..................................4-38
Hitches..........................................................4-57
HomeLink
®Transmitter....................................2-36
HomeLink®Transmitter, Programming................2-37
Hood
Checking Things Under................................5-12
Release.....................................................5-12
Horn............................................................... 3-7
How to Add Coolant to the Coolant
Recovery Tank............................................5-34
How to Add Coolant to the Radiator..................5-36
How to Add Fluid............................................5-26
How to Check........................................5-25, 5-68
How to Check Lubricant...................................5-52How to Check Power Steering Fluid..................5-39
How to Inspect...............................................5-24
How to Use This Manual...................................... ii
How to Wear Safety Belts Properly...................1-13
Hydroplaning..................................................4-32
I
ICE POSSIBLE..............................................3-54
If No Steam Is Coming From Your Engine..........5-31
If Steam Is Coming From Your Engine...............5-30
If the Light is Flashing.....................................3-36
If the Light Is On Steady.................................3-37
If You Are Caught in a Blizzard.........................4-42
If You Are Stuck in Sand, Mud, Ice or Snow.......4-44
If You Do Decide To Pull A Trailer.....................4-54
Ignition Positions.............................................2-20
Infants and Young Children, Restraints...............1-28
Ination - Tire Pressure...................................5-67
Instrument Panel
Cluster.......................................................3-28
Overview..................................................... 3-4
Instrument Panel Brightness.............................3-17
Interior Lamps................................................3-17
8
