BUICK RANDEZVOUS 2004 Owner's Guide

To recline the seatback, lift up on the recliner lever
located on the outboard side of the seatback. Use the
recliner lever to move the seatback to the desired
position.
It is easier to raise or lower the seatback if you lean
forward and take the weight off the seatback.
The seatbacks on the second row captain’s chairs fold
forward the same way.
After raising a seatback to an upright position, push and
pull on the seatback to check that it is locked upright.
Removing the Captain’s Chairs
1. Make sure that the seatback is in the upright
position.
2. Lift the seatback recliner lever to fold the seatback
forward.
3. Pull up on the lever, located at the base on the
outboard side of the seat, to release the rear
latches from the oor pins.
1-15

4. The seat can then be lifted off the front oor pins.
5. Remove the seat by rocking it slightly toward
the rear of the vehicle and then pulling it out.
Repeat these steps for the other captain’s chair.
Replacing the Captain’s Chairs
{CAUTION:
If the seatback isn’t locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
press rearward on the seatback to be sure it is
locked.
{CAUTION:
A seat that isn’t locked into place properly can
move around in a collision or sudden stop.
People in the vehicle could be injured. Be sure
to lock the seat into place properly when
installing it.
1-16

{CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted won’t provide the
protection needed in a crash. The person
wearing the belt could be seriously injured.
After installing the seat, always check to be
sure that the safety belts are properly routed
and attached, and are not twisted.
Make sure that the seatback is in the folded forward
position and that the safety belts are on the correct side
of the chair.
Don’t put the chairs in so that they face rearward
because they won’t latch that way.
The captain’s chairs have seat position labels, located
on the back of each section, showing where the section
must go.
The seat must be placed in the proper location for the
legs to attach correctly.1. Hook the front latches over the front oor pins.
1-17

2. Push the rear of the seat down to lock the rear
latches onto the rear set of oor pins.
3. Push and pull on the seat to check that it is
properly attached.
Stowable Seat
The stowable seat is a two passenger bench seat and
comes with the rear convenience center. SeeRear
Convenience Center on page 2-44for more information.
The stowable seat can be removed and replaced or,
with the seatback folded, it can lie at with the
convenience center.
Folding the Seatback
{CAUTION:
If the seatback isn’t locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
press rearward on the seatback to be sure it is
locked.
1-18

To fold the seatback down,
pull up on the lever located
on the back of the seat.
Push down on the
seatback until it is locked
into place.
Push and pull on the seatback to make sure that it is
locked into place.
To raise the seatback, do one of the following:
From the rear of the vehicle, pull up on the lever to
release the seatback. Then pull the strap, located
on the right side of the seat, to pull the seatback up.
The seatback has a pocket to stow the strap on
the side of the seatback when not in use, or
from the passenger’s side door, pull up on the lever
to release the seatback. Then push up on the
seatback to raise the seat.
Push and pull on the seatback to make sure that it is
locked into the upright position.
Removing the Stowable Seat
1. Remove the convenience center, if it is in the
vehicle. SeeRear Convenience Center on
page 2-44for more information.
2. Make sure all items are off the stowable seat.
3. If the seatback is down, put the seatback in
its upright position before removing the seat.
See “Folding the Seatback” listed previously.
4. From the front of the bench seat, remove the two
nuts from the brackets, located on the oor on
each side.
5. From behind the bench seat, fold the
seatback down.
6. Remove the rear nuts located on the oor
on each side.
7. Remove the seat by rocking it slightly toward the
rear of the vehicle and then pulling it out through
the rear of the vehicle. This should be done in one
motion.
8. Put the nuts back onto the screws so the nuts do
not get misplaced.
1-19

Replacing the Stowable Seat
{CAUTION:
If the seatback isn’t locked, it could move
forward in a sudden stop or crash. That could
cause injury to the person sitting there. Always
press rearward on the seatback to be sure it is
locked.
{CAUTION:
A seat that isn’t locked into place properly can
move around in a collision or sudden stop.
People in the vehicle could be injured. Be sure
to lock the seat into place properly when
installing it.
{CAUTION:
A safety belt that is improperly routed, not
properly attached, or twisted won’t provide the
protection needed in a crash. The person
wearing the belt could be seriously injured.
After installing the seat, always check to be
sure that the safety belts are properly routed
and attached, and are not twisted.
Do not put the stowable seat in so that it faces rearward.
The stowable seat has to go in before the rear
convenience center. SeeRear Convenience Center on
page 2-44for more information.
1-20

The stowable seat has seat position labels, located on
the back of the seat, showing where the seat must go.
The seat must be placed in the proper location for the
legs to attach correctly.
Make sure that the seatback is folded forward before
beginning this procedure.
1. Remove the nuts from the screws.
2. Place the stowable seat on the vehicle oor so that
the brackets are placed over the screws.3. Reinstall the nuts back onto the screws. Torque to
approximately 18 lb ft (25Y).
4. Try to raise the seat to make sure that it is
locked down.
5. Raise the seatback to its upright position.
Push and pull on the seatback to make sure that it
is locked into place.
1-21

Safety Belts
Safety Belts: They Are for Everyone
This part of the manual tells you how to use safety
belts properly. It also tells you some things you should
not do with safety belts.
{CAUTION:
Don’t let anyone ride where he or she can’t
wear a safety belt properly. If you are in a
crash and you’re not wearing a safety belt,
your injuries can be much worse. You can hit
things inside the vehicle or be ejected from it.
You can be seriously injured or killed. In the
same crash, you might not be, if you are
buckled up. Always fasten your safety belt,
and check that your passengers’ belts are
fastened properly too.
{CAUTION:
It is extremely dangerous to ride in a cargo
area, inside or outside of a vehicle. In a
collision, people riding in these areas are more
likely to be seriously injured or killed. Do not
allow people to ride in any area of your vehicle
that is not equipped with seats and safety
belts. Be sure everyone in your vehicle is in a
seat and using a safety belt properly.
1-22

Your vehicle has a light
that comes on as a
reminder to buckle up. See
Safety Belt Reminder
Light on page 3-43.
In most states and in all Canadian provinces, the law
says to wear safety belts. Here’s why:They work.
You never know if you’ll be in a crash. If you do have a
crash, you don’t know if it will be a bad one.
A few crashes are mild, and some crashes can be so
serious that even buckled up, a person wouldn’t survive.
But most crashes are in between. In many of them,
people who buckle up can survive and sometimes walk
away. Without belts they could have been badly hurt
or killed.
After more than 30 years of safety belts in vehicles, the
facts are clear. In most crashes buckling up does
matter... a lot!Why Safety Belts Work
When you ride in or on anything, you go as fast as
it goes.
Take the simplest vehicle. Suppose it’s just a seat on
wheels.
1-23

Put someone on it. Get it up to speed. Then stop the vehicle. The rider
doesn’t stop.
1-24
