odometer BUICK RANDEZVOUS 2005 Owner's Manual

Instrument Panel Overview...............................3-4
Hazard Warning Flashers................................3-6
Other Warning Devices...................................3-6
Horn.............................................................3-6
Tilt Wheel.....................................................3-6
Turn Signal/Multifunction Lever.........................3-7
Turn and Lane-Change Signals........................3-7
Headlamp High/Low-Beam Changer..................3-8
Flash-to-Pass.................................................3-8
Windshield Wipers..........................................3-9
Windshield Washer.........................................3-9
Cruise Control..............................................3-10
Exterior Lamps.............................................3-14
Daytime Running Lamps (DRL).......................3-14
Automatic Headlamp System..........................3-15
Fog Lamps..................................................3-15
Interior Lamps..............................................3-16
Instrument Panel Brightness...........................3-16
Interior Lamps Control...................................3-16
Headlamp Exit Delay.....................................3-17
Entry Lighting...............................................3-17
Delayed Lighting...........................................3-18
Exit Lighting.................................................3-18
Perimeter Lighting.........................................3-19
Front Reading Lamps....................................3-19
Rear Reading Lamps....................................3-19
Cargo Lamp.................................................3-19Battery Run-Down Protection..........................3-20
Instrument Panel Switchbank..........................3-20
Head-Up Display (HUD).................................3-21
Ultrasonic Rear Parking Assist (URPA)............3-24
Accessory Power Outlets...............................3-26
Ashtrays and Cigarette Lighter........................3-27
Climate Controls............................................3-28
Climate Control System.................................3-28
Dual Climate Control System..........................3-30
Dual Automatic Climate Control System...........3-33
Outlet Adjustment.........................................3-36
Warning Lights, Gages, and Indicators............3-37
Instrument Panel Cluster................................3-38
Speedometer and Odometer...........................3-39
Trip Odometer..............................................3-39
Tachometer.................................................3-40
Safety Belt Reminder Light.............................3-41
Airbag Readiness Light..................................3-41
Passenger Airbag Status Indicator...................3-42
Brake System Warning Light..........................3-44
Anti-Lock Brake System Warning Light.............3-45
Traction Control System (TCS) Warning Light......3-45
Engine Coolant Temperature Gage..................3-46
Malfunction Indicator Lamp.............................3-46
Highbeam On Light.......................................3-49
Fuel Gage...................................................3-50
Section 3 Instrument Panel
3-1

Battery Run-Down Protection
Your vehicle has a feature to help prevent you from
draining the battery, in case you accidentally leave the
interior or exterior lamps on. If the interior lamps are
left on while the ignition is in OFF, they will automatically
turn off after 10 minutes. If the exterior lamps are left
on while the ignition is in OFF with all doors and
the liftgate closed, they will automatically turn off after
10 minutes.
If your vehicle has less than 14 miles (24 km) on the
odometer, the battery saver will turn off the lamps after
only three minutes.
If the interior lamps are turned off as a result of the
battery saver feature, they may be turned back on by
turning the interior lamp control to OFF and then back to
ON. The battery saver will not turn the interior lamps
off automatically after doing this. They will have to
be turned off manually.
Instrument Panel Switchbank
There is an instrument panel switchbank located below
the comfort controls. It contains switches or blanks
that will vary with the options that are on your vehicle.
The switches you may have are:
Rear Window Wiper/Washer. SeeWindshield
Washer on page 3-9.
Traction Disable. SeeTraction Control System (TCS)
on page 4-10.
Park Aid Disable. SeeUltrasonic Rear Parking
Assist (URPA) on page 3-24.
Heated Seats. SeeHeated Seats on page 1-5.
3-20

Speedometer and Odometer
Your speedometer lets you see your speed in both
miles per hour (mph) and kilometers per hour (km/h).
Your odometer shows how far your vehicle has
been driven, in either miles (used in the United States)
or kilometers (used in Canada). However, a Canadian
odometer will remain in metric units only.
Your vehicle has a tamper-resistant odometer.
You may wonder what happens if your vehicle needs a
new odometer installed. If the new one can be set to
the mileage total of the old odometer, then that will
be done. If it cannot, then it is set at zero and a label
must be put on the driver’s door to show the old mileage
reading when the new odometer was installed.
If your vehicle is equipped with the Driver Information
Center (DIC), you may toggle the odometer to
display either miles, available only in the United States,
or kilometers. SeeDriver Information Center (DIC)
on page 3-62.
Trip Odometer
In addition to the standard odometer, the cluster can
also display a trip odometer. The display can be toggled
between the odometer and the trip odometer by
quickly pressing and releasing the trip/reset button
located to the right of the temperature gage. The trip
odometer will continue to keep track of miles or
kilometers driven even if they are not currently
displayed. A Canadian trip odometer will remain in
metric units only. To reset the trip odometer to zero (0),
push and hold the trip/reset button for at least one
and a half seconds, but less than three seconds. The
trip odometer that is showing in the display will be reset.
3-39

Retro-Active Reset
The trip odometer has a feature called retro-active reset.
This feature can be used to set the trip odometer to the
number of miles or kilometers driven since the ignition
was last turned on. This can be used if you forget to reset
your trip odometer at the beginning of a trip. To use the
retro-active reset feature, push and hold the trip/reset
button for at least three seconds. The trip odometer will
then display the number of miles or kilometers driven
since the ignition was last turned on and you began
driving. If you use the retro-active reset feature after you
have started the vehicle, but before you begin moving,
the display will show the number of miles or kilometers
you drove during the last ignition cycle. Once you begin
driving, the trip odometer will accumulate mileage. For
example, if you have driven 5.0 miles (8.0 km) since you
started your vehicle, and then activate the retro-active
reset feature, the display will show 5.0 miles (8.0 km).
As you drive, the display will then increase to
5.1 miles (8.2 km), 5.2 miles (8.4 km), etc.
Tachometer
The tachometer displays the engine speed in revolutions
per minute (rpm).
3-40

FUEL USED:The fuel used display will show you how
much fuel has been used since the last time it was
reset. To reset the fuel used to zero, press and hold the
SET button while the fuel used is displayed on the
DIC and until the display goes to zero.
AVG SPEED (Average Speed):The average speed
display will show your average speed from when
you rst started your vehicle. To reset the average
speed, press and hold the SET button while the average
speed is displayed on the DIC and until the speed
resets to your current speed.
OIL LIFE LEFT HOLD SET TO RESET:This message
displays the current percentage of the oil life by the
engine oil life system. Be careful not to reset this display
other than when the oil has been changed. See “How
to Reset the Engine Oil Life System” underEngine
Oil Life System on page 5-19for more information.
In addition to the engine oil life system monitoring the
oil life, additional maintenance is recommended in
the Maintenance Schedule in this manual. See
Scheduled Maintenance on page 6-4andEngine Oil
on page 5-16.TIRE PRESSURE:The check tire pressure system can
alert you to a large change in the pressure of one
tire. If the tire pressure is normal, TIRE PRESSURE
NORMAL will display. If the tire pressure is low,
LOW TIRE PRESSURE will display. You must begin
driving before the system will detect a low tire pressure.
SeeCheck Tire Pressure System on page 5-62.
USE SET TO SELECT ENGLISH METRIC:You can
use this display to select English or metric. Press
the SET button to toggle between English or metric.
The DIC, the odometer, the trip odometer and head-up
display will change. A Canadian odometer and trip
odometer will remain in metric units only.
OFF:No driver information will be displayed in this
mode. If the DIC is left in this mode for more than three
seconds, the display will turn off. Press the MODE
button to start the DIC.
3-65

If you need to replace any of your wheels, wheel bolts
or wheel nuts, replace them only with new GM
original equipment parts. This way, you will be sure to
have the right wheel, wheel bolts and wheel nuts
for your vehicle.
{CAUTION:
Using the wrong replacement wheels, wheel
bolts or wheel nuts on your vehicle can be
dangerous. It could affect the braking and
handling of your vehicle, make your tires lose
air and make you lose control. You could have
a collision in which you or others could be
injured. Always use the correct wheel, wheel
bolts and wheel nuts for replacement.
Notice:The wrong wheel can also cause problems
with bearing life, brake cooling, speedometer or
odometer calibration, headlamp aim, bumper height,
vehicle ground clearance and tire or tire chain
clearance to the body and chassis.
SeeChanging a Flat Tire on page 5-72for more
information.
Used Replacement Wheels
{CAUTION:
Putting a used wheel on your vehicle is
dangerous. You can’t know how it’s been used
or how far it’s been driven. It could fail
suddenly and cause a crash. If you have to
replace a wheel, use a new GM original
equipment wheel.
5-69

Maintenance Record
After the scheduled services are performed, record the date, odometer reading, who performed the service and the
type of services performed in the boxes provided. SeeMaintenance Requirements on page 6-2in this section.
Any additional information fromOwner Checks and Services on page 6-8can be added on the following record pages.
Also, you should retain all maintenance receipts.
Maintenance Record
DateOdometer
ReadingServiced ByMaintenanceIor
MaintenanceIIServices Performed
6-14

Maintenance Record (cont’d)
DateOdometer
ReadingServiced ByMaintenanceIor
MaintenanceIIServices Performed
6-15

Maintenance Record (cont’d)
DateOdometer
ReadingServiced ByMaintenanceIor
MaintenanceIIServices Performed
6-16

Message (cont.)
Low Oil Pressure.........................................3-54
Low Tire .....................................................3-56
Low Washer Fluid Warning...........................3-58
Park Lamp Warning.....................................3-61
PASS-Key
®III Security.................................3-57
Program Mode............................................3-60
Rear Hatch Ajar Warning..............................3-56
Reduced Engine Power................................3-53
Remote Keyless Entry Transmitter Battery
Low Warning...........................................3-60
Service Traction System Warning...................3-51
Service Vehicle Soon...................................3-59
Traction Active............................................3-52
Mirrors
Manual Rearview Mirror................................2-31
Outside Convex Mirror.................................2-32
Outside Curb View Assist Mirror....................2-32
Outside Heated Mirrors................................2-32
Outside Power Mirror...................................2-31
MyGMLink.com................................................ 7-3
N
Navigation/Radio System................................3-130
New Vehicle Break-In......................................2-19
Normal Maintenance Replacement Parts............6-13
O
Odometer......................................................3-39
Odometer, Trip...............................................3-39
Off-Road Recovery..........................................4-14
Oil
Engine.......................................................5-16
Pressure Message.......................................3-54
Older Children, Restraints................................1-43
Online Owner Center........................................ 7-3
OnStar
®System.............................................2-33
Other Warning Devices...................................... 3-6
Outlet Adjustment............................................3-36
Outside
Convex Mirror.............................................2-32
Curb View Assist Mirror................................2-32
Heated Mirrors............................................2-32
Power Mirror...............................................2-31
Overhead Console..........................................2-39
Overheated Engine Protection Operating Mode.....5-30
Owner Checks and Services.............................. 6-8
Owners, Canadian............................................... ii
10
