fuse box BUICK RANDEZVOUS 2006 Owner's Manual

The main components of the instrument panel are the following:
A. Exterior/Interior Lamps Control. SeeExterior Lamps
on page 3-14andInterior Lamps on page 3-16.
B. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 3-7.
C. Hazard Warning Flasher Button. SeeHazard
Warning Flashers on page 3-6.
D. Instrument Panel Cluster. SeeInstrument Panel
Cluster on page 3-38.
E. Shift Lever. SeeAutomatic Transaxle Operation
on page 2-23.
F. Instrument Panel Outlets. SeeOutlet Adjustment
on page 3-36.
G. Audio System. SeeAudio System(s) on page 3-74.
H. Audio Steering Wheel Controls. SeeAudio
Steering Wheel Controls on page 3-132.
I. Head-Up Display Switch and Driver Information
Center (DIC) Controls (If Equipped). SeeHead-Up
Display (HUD) on page 3-21andDIC Controls
and Displays on page 3-62.J. Hood Release. SeeHood Release on page 5-9.
K. Ignition Switch. SeeIgnition Positions on page 2-20.
L. Climate Controls. SeeClimate Control System
on page 3-28,Dual Climate Control System
on page 3-30orDual Automatic Climate Control
System on page 3-33.
M. Instrument Panel Switchbank. SeeInstrument Panel
Switchbank on page 3-20.
N. Front Armrest Storage. SeeFront Armrest Storage
Area on page 2-39.
O. Ashtray/Cigarette Lighter/Accessory Power
Outlet/Cell Phone Storage/Cupholders. See
Ashtray(s) and Cigarette Lighter on page 3-27,
Accessory Power Outlet(s) on page 3-26,Cell Phone
Storage Area on page 2-39,Floor Console Storage
Area on page 2-39andCupholder(s) on page 2-38.
P. Floor Console Fuse Block. SeeFloor Console
Fuse Block on page 5-101.
Q. Glove Box. SeeGlove Box on page 2-38.
3-5

Accessory Inator
Your vehicle may have an accessory inator. With it,
you can inate things like air mattresses and basketballs,
and you can also use it to bring your tires up to the
proper pressure.
The accessory inator is located in the rear compartment
on the driver’s side. To remove the cover, pull the tab on
the cover and pull it off.
This is the symbol on the
accessory inator switch.
There may be an accessory inator kit stored in the
glove box. It includes a 20-foot (6 m) hose with an
air pressure gage and nozzle adapters.{CAUTION:
Inating something too much can make it
explode, and you or others could be injured. Be
sure to read the inator instructions, and inate
any object only to its recommended pressure.
To use your accessory inator system, do the following:
1. Turn the ignition to ACCESSORY or ON.
2. Attach the appropriate nozzle adapter, if required,
to the end of the hose that has the pressure gage.
3. Attach that end of the hose to the object you wish
to inate.
4. Remove the protective cap covering the outlet.
5. Attach the other end of the hose to the outlet.
6. Press the accessory inator switch. The light in the
switch will come on to show the system is working.
If the accessory inator system does not turn on or the
light does not come on, the fuse may be blown or
installed incorrectly. SeeFuses and Circuit Breakers
on page 5-101or see your dealer for service.
Your accessory inator will automatically shut off after
about 10 minutes. The light in the switch will blink. After
about one minute you can use the system again. Press
the inator switch and the indicator light will come on.
5-68

Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected from
short circuits by a combination of fuses, circuit breakers,
and fusible thermal links.
Look at the silver-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the identical
size and rating.
If you ever have a problem on the road and do not have
a spare fuse, you can borrow one that has the same
amperage. Just pick a feature of your vehicle that
you can get along without – like the radio or cigarette
lighter - and use its fuse, if it is the right amperage.
Replace it as soon as you can.
There are two fuse blocks in your vehicle: the oor
console fuse block and the underhood fuse and
relay center.
Floor Console Fuse Block
The oor console fuse block is located to the left of the
glove box near the oor. Pull the door open to access
the fuse block.
5-101

Fuses
Floor Console Fuse Block...........................5-101
Fuses and Circuit Breakers.........................5-101
Underhood Fuse Block...............................5-103
Windshield Wiper.......................................5-100
G
Gage
Engine Coolant Temperature.........................3-46
Fuel..........................................................3-50
Speedometer..............................................3-39
Tachometer.................................................3-40
Garage Door Opener.......................................2-34
Gas, Check Cap Message...............................3-56
Gasoline
Octane........................................................ 5-5
Specications............................................... 5-5
Glove Box.....................................................2-38
GM Mobility Reimbursement Program.................. 7-5
H
Hatch Ajar Warning Message............................3-55
Hazard Warning Flashers................................... 3-6
Head Restraints............................................... 1-8
Headlamp Wiring...........................................5-100Headlamps
Automatic Headlamp System.........................3-15
Bulb Replacement.......................................5-44
Daytime Running Lamps...............................3-14
Exit Delay..................................................3-17
Flash-to-Pass............................................... 3-8
Halogen Bulbs............................................5-44
Headlamps, Front Turn Signal, Sidemarker,
and Parking Lamps..................................5-45
High/Low Beam Changer................................ 3-8
Head-Up Display (HUD)...................................3-21
Heated Seats................................................... 1-5
Heater...................................................3-28, 3-30
Heater...........................................................3-33
Highbeam Out Warning Message......................3-60
Highway Hypnosis...........................................4-24
Hill and Mountain Roads..................................4-24
Hood
Checking Things Under.................................. 5-9
Release....................................................... 5-9
Horn............................................................... 3-6
How to Use This Manual...................................... ii
How to Wear Safety Belts Properly...................1-27
