BUICK REGAL 2001 Owners Manual

2-52 Power Outside Foldaway Mirrors
The power mirror
controls are located near
the driver's side window,
on the armrest.
To choose either the left or right outside mirror, move
the top switch from left through neutral to right.
Press any of the four buttons located on the control
pad below the top switch to move the mirrors in the
desired direction.Adjust each mirror so you can see the side of your
vehicle and the area behind your vehicle.
These mirrors can also be folded rearward manually.
This feature is particularly useful in automatic car
washes and when maneuvering your vehicle in
narrow spaces.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex
mirror's surface is curved so you can see more from
the driver's seat.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.
ProCarManuals.com

2-53 Automatic Dimming/Heated Outside
Rearview Mirror (If Equipped)
With this feature, the driver's side outside mirror will
adjust for the glare of headlamps behind you. This
feature is controlled by the on and off settings on the
electrochromic automatic dimming rearview mirror.
(See ªElectrochromic Automatic Dimming Rearview
Mirrorº earlier in this section.)
The left and right outside mirrors are also heated when
you activate the rear window defogger. (See ªRear
Window Defoggerº in the Index.)
Both outside mirrors can be folded forward or
rearward. This feature is particularly useful in
automatic car washes.
Storage Compartments
Glove Box
Use the door key to lock and unlock the glove box.
To open, lift the latch.
Center Console
The console has cupholders, a cassette tape storage area
and a coinholder. To open the console's storage area,
press the latch located toward the front of the console lid
on the driver's side of the vehicle and pull up.
ProCarManuals.com

2-54
To access the cupholders, pull on the top of the
cupholder door, located just behind the console shift
lever. Two cupholders will pop into an upright position.
Rear Storage Armrest (If Equipped)
If your vehicle is equipped with a split folding rear seat
it will also be equipped with a rear storage armrest. To
access the rear storage armrest, pull down on the cloth
strap located toward the top of the center back seat
cushion. To open, pull up on the lever at the end of the
armrest and lift. You will then have access to the storage
compartment and dual oversized cupholders.
Trunk Convenience Net (If Equipped)
Your vehicle may have a convenience net. You'll see it
on the back wall of the trunk.
Put small loads, like grocery bags, behind the net. It can
help keep them from falling over during sharp turns or
quick starts and stops.
The net isn't for larger, heavier loads. Store those in the
trunk as far forward as you can.
You can unhook the net so that it will lie flat when
you're not using it.
ProCarManuals.com

2-55
Ashtrays and Lighter
The center front ashtray is located just below the
instrument panel's comfort controls at the front of the
console, behind the front compartment storage door.
To remove the ashtray, open the storage door. Then
open the small black door, lift up on the ashtray and
pull it out.
The rear ashtray is located within a small door at the
rear of the console. Push on the right side of the door.
The ashtray will then pivot to the right for usage.
You can only access the ashtray by pushing on the
door's right side. To remove the ashtray, push down
on the snuffer located in the middle of the ashtray and
lift it out.
NOTICE:
Don't put papers and other things that burn into
your ashtrays. If you do, cigarettes or other
smoking materials could set them on fire,
causing damage.
To use the lighter, just push it in all the way and let go.
When it's ready, it will pop back out by itself.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.
Sun Visors
To block out glare, you can swing down the visors. You
can also move them from side to side. The visors also
have extenders that you can pull out for added coverage.
Visor Vanity Mirrors
Open the cover on the visor to expose the vanity mirror.
If your vehicle has the optional lighted vanity mirrors,
the lamps come on when you open the cover.
ProCarManuals.com

2-56
Auxiliary Power Outlet
Your vehicle is equipped with a 12-volt outlet. It is
located on the console's passenger's side, near the
floor. Open the cover to use the outlet. This feature
can be used to add aftermarket electrical equipment to
your vehicle.Certain power auxiliary plugs may not be compatible to
the power auxiliary outlet and could result in blown
vehicle or adapter fuses. If you experience a problem,
see your dealer for additional information on the power
accessory plugs.
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by your
warranty. Check with your dealer before adding
electrical equipment, and never use anything that
exceeds the fuse rating.
ProCarManuals.com

2-57
Auxiliary Power Connection
(Power Drop)
Your vehicle is equipped
with an auxiliary
power connection.It is located on the passenger's side of the vehicle, under
the glove box, and is labeled with a wire function and
fuse rating. This feature provides power, ground and
accessory wires which can be accessed to add
aftermarket electrical equipment to your vehicle. For
information on accessing the connection and electrical
hookup, please refer to your service manual. To order a
service manual, see ªService Publications, Orderingº in
the Index.
NOTICE:
Adding some electrical equipment to your vehicle
can damage it or keep other things from working
as they should. This wouldn't be covered by your
warranty. Check with your dealer before adding
electrical equipment, and never use anything that
exceeds the fuse rating.
ProCarManuals.com

2-58
OnStar
System (If Equipped)
OnStar is a vehicle communications system that
offers a variety of services and provides a hands
-free
communication link between you and the OnStar Center.
A service subscription agreement and fee are required in
order to receive OnStar service. Services are available
24 hours a day, 7 days a week. For more information,
call 1
-888-ONSTAR-7 (1-888-667-8277).
OnStar Services Button: Press this button once
to contact an advisor who will be able to assist you with
these services. If you are not quickly connected, the
system will automatically reset and redial. This ensures
connection to the center; there is no additional action
required. Press the Call Answer/End button to cancel
the automatic redial.
Emergency Button: In an emergency situation,
press the emergency service button. Upon receiving the
call, an advisor at the center will locate your vehicle and
assess the situation. If necessary, the advisor will alert
the nearest emergency service provider.
Call ANSWER/END Button: Use this button to
answer a call. (If you are receiving a call, the audio
system will mute, and the ring will be heard). Press this
button at the end of a call to disconnect and return the
audio system to its previous settings. This button will
also cancel a call if one of the buttons is accidentally
pressed or if the automatic redial function is activated.
Volume Control: You can control the volume of the
OnStar System using either the volume control knob
on the radio or using the steering wheel volume control
(if equipped).
Telltale Light: This light will indicate the status of
the system. A solid green light will come on when you
start the vehicle to let you know that the system is on
and is ready to make or receive calls.
If the light blinks green it means that an incoming
or outgoing call is in progress. Press the Call
ANSWER/END button if you notice the light blinking
and you are not on a call.
ProCarManuals.com

2-59
The light will be red in the event of an OnStar system
malfunction. If this occurs press the OnStar button to
attempt to contact an advisor. If the connection is made,
the advisor will assist you with steps to take to make
sure that the system is functioning properly. If you
cannot contact the advisor, take your vehicle to your
dealership as soon as possible for assistance.
Safety and Security Services

Automatic Notification of Air Bag
Deployment
-- If an air bag deploys, a priority
emergency signal is automatically sent to the center.
An advisor will locate your vehicle's position, try to
contact you and assist you in the situation. If the
center is unable to contact you, an emergency service
provider will be contacted.

Stolen Vehicle Tracking
-- Call the center at
1
-888-4-ONSTAR (1-888-466-7827) to report your
vehicle stolen. The system can then locate and track
your vehicle and the advisor will be able to notify
the proper authorities.

Roadside Assistance with Location
-- For vehicle
breakdowns, press the OnStar button. An advisor
will contact the appropriate help.
Remote Diagnostics
-- If an instrument panel light
comes on, the center can perform a check of the
engine on
-board computer. An advisor can then
recommend what action needs to be taken.

OnStar MED
-NET -- Med-Net can store your
personal medical history and provide it to emergency
personnel if necessary.

Accident Assist
-- An advisor can provide
step
-by-step guidance following an accident.

Remote Door Unlock
-- To contact the center, call
1
-888-4-ONSTAR. You will be required to provide
your security information. An advisor will send a
command to your vehicle to unlock itself. The
advisor can delay unlocking your vehicle. Remote
Door Unlock is disabled 48 hours after the vehicle is
parked to maintain the battery charge.

Vehicle Locator Service
-- To contact the center,
call 1
-888-4-ONSTAR. You will be required to
provide your security information. An advisor will
send a command to your vehicle to sound the horn
and/or flash the lamps.
In order to provide you with excellent service, calls with
the OnStar Center may be monitored or recorded.
ProCarManuals.com

2-60 Premium Services
(Includes Safety and Security Services)

Route Support -- An advisor can provide directions
or guidance to anywhere you want to go. In addition,
they can help you locate gas stations, rest areas,
ATMs, hospitals, hotels, stores, eateries and more.

Concierge Services
-- The concierge advisor can
obtain tickets, reservations, or help with vacation/trip
planning and other unique items and services.

Ride Assist
-- An advisor can locate transportation
in the event that you are unable to drive.
OnStar System Limitations
Complete limitations can be found on the Subscriber
Services Agreement.
OnStar Service is:

available in the 48 contiguous United States, Alaska,
Hawaii and Canada;

available when the vehicle is within the operating
range of a cellular provider;
subject to limitations caused by atmospheric
conditions, such as severe weather or topographical
conditions, such as mountainous terrain;

subject to cellular carrier equipment limitations.
Global positioning capabilities used to deliver
OnStar Service will not be available if satellite signals
are obstructed.
OnStar will not function if the vehicle's battery is
discharged or disconnected. It may also be inoperative
if the vehicle is in an accident and the OnStar or vehicle
electrical system components are damaged.
Safety and security services are provided by existing
governmental emergency service providers. OnStar will
use reasonable efforts to contact the appropriate
emergency service provider and request assistance but
cannot promise that they will respond to the call in a
timely manner or at all.
ProCarManuals.com

2-61
Sunroof (If Equipped)
Your vehicle may be equipped with an express-open
sunroof. It includes a sliding glass panel and a one
-piece
sunshade. The control switch works only when the
ignition or retained accessory power is on. See
ªRetained Accessory Powerº in the Index. The control
switch is located overhead on the headliner.
To open the sunroof to the vent position only, push
and hold the front of the switch. You will need to open
the sunshade by hand. To close the sunroof from the
vent position, push and hold the rear (indented part) of
the switch.
To open the sunroof, push the rear (indented part) of the
switch once. The sunroof and sunshade will open by
themselves. This is the express
-open feature.
To close the sunroof, push and hold the front of the
switch until the sunroof motor stops. The sunshade
can only be closed by hand.
ProCarManuals.com
