BUICK REGAL 2001 Owners Manual

6-70
Underhood Electrical Center -- Passenger's Side
Some fuses and relays are located in the underhood
electrical center on the passenger's side of the engine
compartment. See ªEngine Compartment Overviewº in
the Index for more information on location.Maxi fuse Description
1 ABS
2 Starter Solenoid
3 Power Seats, Rear Defog, Heated Seats
4 High Blower, Hazard Flasher,
Stoplamps, Power Mirror, Door Locks
5 Ignition Switch, BTSI, Stoplamps,
ABS, Turn Signals, Cluster, Air Bag,
DRL Module
6 Cooling Fan
7 Interior Lamps, Retained Accessory
Power, Keyless Entry, CEL TEL,
Data Link, HVAC Head, Cluster,
Radio, AUX Power (Power Drop),
Cigarette Lighter
8 Ignition Switch, Wipers, Radio,
Steering Wheel Controls, Body Control
Module, AUX Power (Power Drop),
Power Windows, Sunroof, HVAC
Controls, DRL, Rear Defog Relay
ProCarManuals.com

6-71
Mini relay Description
9 Cooling Fan 2
10 Cooling Fan 3
11 Starter Solenoid
12 Cooling Fan 1
13 Ignition Main
14 Air Pump (Optional)
Mini relay Description
15 A/C Clutch
16 Horn
17 Fog Lamps
18 Fuel Pump, Speed Control (L67 only)
19 Fuel PumpMini fuse Description
20 Air Pump (Optional)
21 Generator
22 ECM
23 A/C Compressor Clutch
24 Cooling Fan
25 Electronic Ignition
26 Transaxle
27 Horn
28 Fuel Injector
29 Oxygen Sensor
30 Engine Emissions
31 Fog Lamps
32 Headlamp (Right)
33 Rear Compartment Release
ProCarManuals.com

6-72
Mini fuse Description
34 Parking Lamps
35 Fuel Pump
36 Headlamp (Left)
37 Spare
38 Spare
39 Spare
40 Spare
41 Spare
42 Spare
43 Fuse Puller
SYMBOL A/C Compressor Clutch DiodeReplacement Bulbs
Exterior Lamps Bulb Number
Back
-up 1156. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stop 3155. . . . . . . . . . . . . . . .
Front Parking/Turn Signal 4157NAK. . . . . . . . . . . . .
Headlamp, High Beam 9005. . . . . . . . . . . . . . . . . . . .
Headlamp, Low Beam 9006. . . . . . . . . . . . . . . . . . . .
Stop/Tail/Turn Signal 3057. . . . . . . . . . . . . . . . . . . . .
Tail (Applique) 194. . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps Bulb Number
Dome Lamp 9425542. . . . . . . . . . . . . . . . . . . . . . . . .
For service information on these bulbs, contact your
dealer service department.
ProCarManuals.com

6-73
Capacities and Specifications
Automatic Transaxle
Pan Removal and Replacement 7.4 quarts (7.0 L). . .
After Complete Overhaul 10.0 quarts (9.5 L). . . . .
When draining/replacing converter, more fluid will
be needed.
Cooling System Including Reservoir
3800 V6 11.7 quarts (11.0 L). . . . . . . . . . . . . . . . . . .
3800 Supercharged V6 11.7 quarts (11.0 L). . . . . . .
Refrigerant, Air ConditioningSee the refrigerant . .
label under the hood.
Engine Crankcase
Oil and Filter Change 4.5 quarts (4.3 L). . . . . . . . .
Wheel Nut Torque100 lb
-ft (140 N´m) . . . . . . . . . .
Fuel Tank17 U.S. gallons (64 L) . . . . . . . . . . . . . . .
All capacities are approximate. When adding, be sure to
fill to the approximate level, as recommended in this
manual. See ªFluids and Lubricantsº in the Index.
Engine Specifications
Type 3800 V6 (VIN Engine Code K). . . . . . . . . . . . .
3800 Supercharged V6 (VIN Engine Code 1)
Displacement 231 CID. . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 195
F (91
C) . . . . . . . . . . .
Horsepower
3800 V6 200 @ 5200 rpm. . . . . . . . . . . . . . . . . . . . .
3800 Supercharged V6 240 @ 5200 rpm. . . . . . . . .
ProCarManuals.com

6-74
Normal Maintenance
Replacement Parts
Engine Air Cleaner/FilterACDelco
. . . . . . . . . . .
Type A1208C
Passenger Compartment Air Filter10406026 . . . .
Battery
3800 V6 ACDelco

. . . . . . . . . . . . . . . . . . . . . . . . .
Type 690 CCA
3800 Supercharged V6 ACDelco

. . . . . . . . . . . . .
Type 770 CCA
Engine Oil FilterACDelco

. . . . . . . . . . . . . . . . . . .
Type PF47
Radiator CapACDelco

. . . . . . . . . . . . . . . . . . . . .
Type RC27
Remote Keyless
Entry BatteriesType CR2032 (2) . . . . . . . . . . . . .
or equivalentSpark Plugs
3800 V6 ACDelco

. . . . . . . . . . . . . . . . . . . . . . . . .
Type 41
-921
Gap: 0.060 inches (1.52 mm)
3800 Supercharged V6 ACDelco

. . . . . . . . . . . . .
Type 41
-921
or NGK Type PTR4B
-15
Gap: 0.060 inches (1.52 mm)
Wiper Blade
Type Hook. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Length 22.0 inches (56.0 cm). . . . . . . . . . . . . . . . . .
Vehicle Dimensions
Wheelbase 109.1 inches (277.1 cm). . . . . . . . . . . . . .
Front Tread 62.0 inches (157.6 cm). . . . . . . . . . . . . . .
Rear Tread 61.3 inches (155.6 cm). . . . . . . . . . . . . . .
Length 196.2 inches (498.4 cm). . . . . . . . . . . . . . . . .
Width 72.7 inches (184.5 cm). . . . . . . . . . . . . . . . . . .
Height 56.6 inches (143.8 cm). . . . . . . . . . . . . . . . . . .
ProCarManuals.com

7-
7-1
Section 7 Maintenance Schedule
This section covers the maintenance required for your vehicle. Your vehicle needs these services to retain its safety,
dependability and emission control performance.
7
-2 Introduction
7
-4 Part A: Scheduled Maintenance Services
7
-16 Part B: Owner Checks and Services7
-21 Part C: Periodic Maintenance Inspections
7
-23 Part D: Recommended Fluids and Lubricants
7
-25 Part E: Maintenance Record
ProCarManuals.com

7-2
Have you purchased the GM Protection Plan? The Plan
supplements your new vehicle warranties. See your
Warranty and Owner Assistance booklet or your dealer
for details.
Introduction
Your Vehicle and the Environment
Proper vehicle maintenance not only helps to keep your
vehicle in good working condition, but also helps the
environment. All recommended maintenance procedures
are important. Improper vehicle maintenance can even
affect the quality of the air we breathe. Improper fluid
levels or the wrong tire inflation can increase the level
of emissions from your vehicle. To help protect our
environment, and to keep your vehicle in good
condition, please maintain your vehicle properly.
Maintenance Requirements
Maintenance intervals, checks, inspections and
recommended fluids and lubricants as prescribed in this
manual are necessary to keep your vehicle in good
working condition. Any damage caused by failure to
follow recommended maintenance may not be covered
by warranty.
ProCarManuals.com

7-3 How This Section is Organized
This maintenance schedule is divided into five parts:
ªPart A: Scheduled Maintenance Servicesº shows
what to have done and how often. Some of these
services can be complex, so unless you are technically
qualified and have the necessary equipment, you should
let your dealer's service department or another qualified
service center do these jobs.
CAUTION:
Performing maintenance work on a vehicle can
be dangerous. In trying to do some jobs, you can
be seriously injured. Do your own maintenance
work only if you have the required know
-how
and the proper tools and equipment for the job.
If you have any doubt, have a qualified
technician do the work.
If you want to get the service information, see ªService
and Owner Publicationsº in the Index.ªPart B: Owner Checks and Servicesº tells you what
should be checked and when. It also explains what you
can easily do to help keep your vehicle in good condition.
ªPart C: Periodic Maintenance Inspectionsº explains
important inspections that your dealer's service department
or another qualified service center should perform.
ªPart D: Recommended Fluids and Lubricantsº lists
some recommended products necessary to help keep
your vehicle properly maintained. These products, or
their equivalents, should be used whether you do the
work yourself or have it done.
ªPart E: Maintenance Recordº is a place for you to
record and keep track of the maintenance performed on
your vehicle. Keep your maintenance receipts. They may
be needed to qualify your vehicle for warranty repairs.
ProCarManuals.com

7-4
Part A: Scheduled
Maintenance Services
Using Your Maintenance Schedule
We at General Motors want to help you keep your vehicle
in good working condition. But we don't know exactly
how you'll drive it. You may drive very short distances
only a few times a week. Or you may drive long distances
all the time in very hot, dusty weather. You may use your
vehicle in making deliveries. Or you may drive it to work,
to do errands or in many other ways.
Because of all the different ways people use their
vehicles, maintenance needs vary. You may need more
frequent checks and replacements. So please read the
following and note how you drive. If you have any
questions on how to keep your vehicle in good
condition, see your dealer.This part tells you the maintenance services you should
have done and when you should schedule them. If you
go to your dealer for your service needs, you'll know
that GM
-trained and supported service people will
perform the work using genuine GM parts.
The proper fluids and lubricants to use are listed in Part D.
Make sure whoever services your vehicle uses these. All
parts should be replaced and all necessary repairs done
before you or anyone else drives the vehicle.
This schedule is for vehicles that:

carry passengers and cargo within recommended
limits. You will find these limits on your vehicle's
Tire
-Loading Information label. See ªLoading Your
Vehicleº in the Index.

are driven on reasonable road surfaces within legal
driving limits.

use the recommended fuel. See ªFuelº in the Index.
ProCarManuals.com

Scheduled Maintenance
7-5
The services shown in this schedule up to 100,000 miles
(166 000 km) should be performed after 100,000 miles
(166 000 km) at the same intervals. The services shown
at 150,000 miles (240 000 km) should be performed at
the same interval after 150,000 miles (240 000 km).
See ªOwner Checks and Servicesº and ªPeriodic
Maintenance Inspectionsº following.Footnotes

The U.S. Environmental Protection Agency or the
California Air Resources Board has determined that the
failure to perform this maintenance item will not nullify
the emission warranty or limit recall liability prior to
the completion of the vehicle's useful life. We, however,
urge that all recommended maintenance services be
performed at the indicated intervals and the
maintenance be recorded.
@ Whenever the tires are rotated, the Tire Inflation
Monitor System must be reset.
+ A good time to check your brakes is during tire
rotation. See ªBrake System Inspectionº under
ªPeriodic Maintenance Inspectionsº in Part C of
this schedule.
