key BUICK REGAL 2002 Owner's Guide

2-27
3. If your engine still won't start (or starts but then
stops), it could be flooded with too much gasoline.
Try pushing your accelerator pedal all the way to
the floor and holding it there as you hold the key
in START for about three seconds. If the vehicle
starts briefly but then stops again, do the same
thing. This time keep the pedal down for five or
six seconds to clear the extra gasoline from the
engine. After waiting about 15 seconds, repeat the
normal starting procedure.
NOTICE:
Your engine is designed to work with the
electronics in your vehicle. If you add electrical
parts or accessories, you could change the way
the engine operates. Before adding electrical
equipment, check with your dealer. If you don't,
your engine might not perform properly.
Engine Coolant Heater (If Equipped)
In very cold weather, 0
F (-18
C) or colder, the
engine coolant heater can help. You'll get easier starting
and better fuel economy during engine warm
-up.
Usually, the coolant heater should be plugged in a
minimum of four hours prior to starting your vehicle.
At temperatures above 32
F (0
C), use of the
coolant heater is not required.

2-34
Shifting Into PARK (P)
CAUTION:
It can be dangerous to get out of your vehicle if
the shift lever is not fully in PARK (P) with the
parking brake firmly set. Your vehicle can roll.
If you have left the engine running, the vehicle
can move suddenly. You or others could be
injured. To be sure your vehicle won't move,
even when you're on fairly level ground, use
the steps that follow. If you're pulling a trailer,
see ªTowing a Trailerº in the Index.
1. Hold the brake pedal down with your right foot and
set the parking brake with your left foot.
2. Move the shift lever into
PARK (P) by holding in
the button on the lever
and then pushing the
lever all the way toward
the front of your vehicle.
Then turn the ignition
key to LOCK.
3. Remove the key and take it with you. If you can
leave your vehicle with the ignition key in your
hand, your vehicle is in PARK (P).

2-36
Shifting Out of PARK (P)
Your vehicle has an automatic transaxle shiftlock
control system. You must fully apply your regular
brakes before you can shift from PARK (P) when the
ignition is in RUN. See ªAutomatic Transaxle
Operationº in the Index.
If you cannot shift out of PARK (P), ease pressure on
the shift lever by pushing it all the way into PARK (P)
while keeping the brake pedal pushed down. Then move
the shift lever out of PARK (P).
If you ever hold the brake pedal down but still can't
shift out of PARK (P), try this:
1. Turn the ignition key to OFF.
2. Apply and hold the brake until the end of Step 4.
3. Shift to NEUTRAL (N).
4. Start the engine and shift to the drive gear you want.
5. Have the vehicle fixed as soon as you can.
Shift Lock Release
Your vehicle is equipped with an electric park lock
system. The system is designed to prevent ignition key
removal unless the shift lever is in PARK (P) (with the
shift lever button fully released).
The system also prevents the shift lever from moving out
of PARK (P) when the ignition is in OFF or in LOCK.
The park lock system is always functional except in the
case of a dead or low voltage (less than 9 V) battery.
If your vehicle has a dead battery or a battery with low
voltage, there are two override access slots that will
allow you to override the park lock system.
The first access slot is located underneath the steering
column below the lock cylinder. To use this slot, do
the following:
1. Verify that the shift lever is in PARK (P) (with the
shift lever button released.)
2. Remove the override access slot cap, which will then
show the override mechanism release button.
3. Insert a key or tool into the access slot and then press
in and hold the override mechanism release button.
4. Turn the ignition key to OFF.
5. Remove the key from the ignition switch.
6. Put the override access slot cap back on.

2-37
You will not be able to remove your key from the
ignition unless the shift lever is in PARK (P) with the
shift lever button fully released.
The second override access
slot is located on the upper
right side of the shift panel.
To use this slot, do the following:
1. Remove the override access slot cap.
2. Insert a key or tool into the access slot, press in and
hold the override mechanism release button.
3. Move the shift lever into the desired gear position.
4. Put the override access slot cap back on.
Parking Over Things That Burn
CAUTION:
Things that can burn could touch hot exhaust
parts under your vehicle and ignite. Don't park
over papers, leaves, dry grass or other things that
can burn.

2-48
You can turn the feature on and off when you perform
the following sequence:
1. Turn the ignition key to RUN.
2. Close all the doors.
3. Press and hold the power door lock switch. While
holding the door lock switch, cycle the exterior
lamps control on and then off two times.
4. Release the power door lock switch. These
operations must be carried out in a time period
of less than 10 seconds, followed by a delay period
of no more than 10 seconds.
5. Then, press and hold the power door unlock switch.
While holding the door unlock switch, turn the
exterior lamps control on and then off two times.
Release the courtesy door unlock switch. These
steps must be carried out in a time period of less
than 10 seconds.
After releasing the door unlock switch, a single chime
will be heard if the delayed headlamp illumination
function has been disabled; two chimes will be heard
if the feature has been enabled. Disconnecting the
vehicle's battery for up to a year will not change the
programmed operation for this feature.Fog Lamps
To turn the fog lamps on,
press the fog lamps button
located below the exterior
lamps control on the left
side of the steering column.
A light will glow in the button to let you know that the
fog lamps are on. (Your parking lamps or low
-beam
headlamps must be on or your fog lamps won't come
on.) Press the button again to turn the fog lamps off.
The fog lamps will go off whenever you change to
high
-beam headlamps. When you return to low beams,
the fog lamps will come on again.
Cornering Lamps
The cornering lamps are designed to come on when you
signal a turn. This will provide more light for cornering
at night.

2-49
Interior Lamps
Instrument Panel Brightness Control
This feature control the brightness of the instrument
panel lights.
You can brighten or dim the instrument panel lights by
adjusting the exterior lamps control located to the right
of the exterior lamps control.
If you turn to control clockwise the interior lamps will
come on and become brighter as the control is turned
further to MAX. Turning the control all the way
clockwise turns on the courtesy lamps. If you turn the
control counterclockwise the lamps will begin to dim
and continue to get dimmer as the control is turned
closer toward LIGHTS MIN. If the control is turned
all the way counterclockwise, the lamps and lights will
turn off.
Courtesy Lamps
When any door is opened, several lamps come on. These
lamps are courtesy lamps. They make it easy for you to
enter and leave your vehicle. You can also turn these
lamps on by turning the exterior lamps control
clockwise to MAX.
Illuminated Entry
Your courtesy lamps will come on and stay on for a
set time whenever you press UNLOCK on the remote
keyless entry transmitter.
If you open a door, the lamps will stay on while it's open
and then turn off automatically about 25 seconds after
you close it. If you press UNLOCK and don't open a
door, the lamps will turn off after about 40 seconds.
Illuminated entry includes a feature called theater
dimming. With theater dimming, the lamps don't just
turn off at the end of the delay time. Instead, they slowly
dim after the delay time until they go out. The delay
time is canceled if you turn the ignition key to RUN or
START, so the lamps will dim right away.
When the ignition is on, illuminated entry is inactive,
which means the courtesy lamps won't come on unless
a door is opened.

2-50 Delayed Entry Lighting
Delayed entry lighting lights your vehicle's interior for a
period of time after all the doors have been closed.
The ignition must be off for delayed entry lighting to
work. Just after all the doors have been closed, the
delayed entry lighting feature will continue to work until
one of the following occurs:

The ignition is in RUN, or

the doors are locked, or

an illumination period of 25 seconds has elapsed.
If during the illumination period a door is opened, the
timed illumination period will be canceled and the
interior lamps will remain on.
Delayed Exit Lighting
This feature illuminates the interior for a period of time
after the ignition key is removed from the ignition.
The ignition must be off for delayed exit lighting to
work. When the ignition key is removed, interior
illumination will activate and remain on until one of the
following occurs:

The ignition is in RUN, or

the power door locks are activated, or

an illumination period of 25 seconds has elapsed.
If during the illumination period a door is opened, the
timed illumination period will be canceled and the
interior lamps will remain on.
Perimeter Lighting
Perimeter lighting provides a period of exterior vehicle
lighting as the driver and passengers approach the
vehicle. Perimeter lighting is only activated when the
function is enabled, the doors are closed, the ignition is
in OFF and the security feedback feature is in Mode 3
or 4. (See ªSecurity Feedbackº in the Index for more
information.) The vehicle headlamps and back
-up lamps
are then activated for a period of 25 seconds or until the
ignition switch is turned to RUN.

2-51
You may enable or disable the perimeter lighting feature
when the driver performs the following sequence with
the engine not running and the doors closed:
1. Turn the ignition to RUN.
2. Close all the doors.
3. Apply your brakes.
4. Press and hold the power door lock switch. While
holding the door lock switch press and release the
panic button on the remote keyless entry transmitter.
This will initialize the customization mode. While in the
customization mode, the feature will sound the number
of chimes corresponding to the current mode. In Mode
1, one chime means the feature is disabled. In Mode 2,
two chimes signal that the perimeter lighting feature is
enabled. Each additional press will advance the mode by
one, starting from the current mode. During this
procedure, the feature will sound the number of chimes
corresponding to the mode. When the lock switch is
released, the vehicle will remain in the last mode.
Disconnecting the vehicle's battery for up to a year will
not change the programmed operation for this feature.Rearview Mirror Reading Lamps
The reading lamps are located on the underside of the
rearview mirror.
Use the button next to each lamp to turn them on
and off.
Dome Lamp (If Equipped)
The dome lamp will come on when you open a door.
Battery Rundown Protection
Your vehicle has a feature to help prevent you from
draining the battery in case you accidentally leave
the interior courtesy lamps, reading/map lamps, visor
vanity lamps, trunk lamp, underhood lamp or glove box
lamps on. If you leave any of these lamps on, they will
automatically turn off after 20 minutes, if the ignition is
in OFF. The lamps won't come back on again until you
do one of the following:

Turn the ignition on,

turn the exterior lamps control off, then on, or

open a door.
If your vehicle has less than 15 miles (25 km) on the
odometer, the battery saver will turn off the lamps after
only three minutes.

2-56
Storage Compartments
Glove Box
Use the door key to lock and unlock the glove box.
To open, lift the latch.
Center Console
The console has cupholders, a cassette tape storage area
and a coinholder.
To open the console's storage area, press the latch
located toward the front of the console lid on the
driver's side of the vehicle and pull up.
To access the cupholders, pull on the top of the
cupholder door, located just behind the console shift
lever. Two cupholders will pop into an upright position.
Rear Storage Armrest
To access the rear storage armrest, pull down on the
cloth strap located toward the top of the center back seat
cushion. To open, pull up on the lever at the end of the
armrest and lift. You will then have access to the storage
compartment and dual oversized cupholders.
To use the cupholders, lift up and place the cupholders
in the front of the storage compartment. Replace when
not in use.

2-68
Warning Lights, Gages
and Indicators
This part describes the warning lights and gages that
may be on your vehicle. The pictures will help you
locate them.
Warning lights and gages can signal that something is
wrong before it becomes serious enough to cause an
expensive repair or replacement. Paying attention to
your warning lights and gages could also save you or
others from injury.
Warning lights come on when there may be or is a
problem with one of your vehicle's functions. As you
will see in the details on the next few pages, some
warning lights come on briefly when you start the
engine just to let you know they're working. If you
are familiar with this section, you should not be alarmed
when this happens.
Gages can indicate when there may be or is a problem
with one of your vehicle's functions. Often gages and
warning lights work together to let you know when
there's a problem with your vehicle.When one of the warning lights comes on and stays on
when you are driving, or when one of the gages shows
there may be a problem, check the section that tells you
what to do about it. Please follow this manual's advice.
Waiting to do repairs can be costly
-- and even
dangerous. So please get to know your warning lights
and gages. They're a big help.
Your vehicle may also have a driver information center
that works along with the warning lights and gages.
See ªDriver Information Centerº in the Index.
Safety Belt Reminder Light
When the key is turned to RUN or START, a chime will
come on for about eight seconds to remind people to
fasten their safety belts, unless the driver's safety belt is
already buckled.
The safety belt light will
also come on and stay on
for about 20 seconds, then
it will flash for about
55 seconds.
If the driver's belt is already buckled, neither the chime
nor the light will come on.
