buttons BUICK REGAL 2002 Owner's Manual

2-52
Mirrors
Adjust all the mirrors so you can see clearly when you
are sitting in a comfortable driving position.
Inside Day/Night Rearview Mirror
To reduce glare from lamps behind you, pull the lever
at the bottom of the mirror toward you (to the night
position). To return the mirror to the day position, push
the lever away from you.
Inside Day/Night Rearview Mirror with
OnStar
and Map Lamps (If Equipped)
This mirror has a lever located at the bottom of the
mirror between the two map lamps. This lever is used to
change the mirror from day to night position. To reduce
glare from headlamps behind you while driving at night,
turn the lever 90. To return the mirror to the day
position, return the lever to its original position.
There are two map lamps located on the bottom of the
mirror. Each lamp is turned on and off by pressing the
button next to the lamp.
There are also three OnStar buttons located at the
bottom of the mirror face. See your dealer for more
information on the system and how to subscribe to
OnStar. See ªOnStar Systemº in the Index for more
information about the services OnStar provides.

2-53 Electrochromic Automatic Dimming
Rearview Mirror (If Equipped)
Your vehicle may have an electrochromic day/night
rearview mirror. Push the button in the center of the
mirror to turn this feature on. The mirror will darken
gradually to reduce glare from headlamps behind you.
This may take a few moments.
The mirror's two outer buttons operate the lights on the
bottom sides of the mirror.One photocell on the front of the mirror senses when
it is becoming dark outside. Another photocell, facing
rearward, senses headlamps behind you. To turn the
electrochromic feature off, press the button in the
center of the mirror again.
To keep the photocells operating well, occasionally
clean them with a cotton swab and glass cleaner.
Electrochromic Day/Night Rearview
Mirror with OnStar
and Map Lamps
(If Equipped)
Your vehicle may have an automatic electrochromic
day/night rearview mirror with the OnStar System.
The automatic dimming feature is turned on or off by
pressing the far left button, located on the lower part
of the mirror face, for up to three seconds. When
turned on, this mirror functions exactly like the
electrochromic mirror described previously. See
ªMirrors, Electrochromic Automatic Dimmingº
listed previously in this section for more information.

2-54
There are two map lamps located on the bottom of the
mirror. Each lamp is turned on and off by pressing the
button next to the lamp.
There are also three OnStar buttons located at the
bottom of the mirror face. See your dealer for more
information on the system and how to subscribe to
OnStar. See ªOnStar

Systemº in the Index for
more information about the services OnStar provides.
Power Outside Foldaway Rearview Mirrors
The power mirror
controls are located
on the driver's
door armrest.
To choose either the left or right outside mirror,
move the selector switch located above the control pad
to the left or the right. Then use the four
-way arrows
located on the control pad to move the mirrors in the
desired direction.
Adjust each mirror so you can see the side of your
vehicle and the area behind your vehicle.
These mirrors can also be folded rearward manually.

2-61
(Emergency Button): In an emergency situation,
press the emergency service button. Upon receiving the
call, an advisor at the center will locate your vehicle and
assess the situation. If necessary, the advisor will alert
the nearest emergency service provider.
(Communication Button): Press this button at
the end of a call. Also press this button to answer a
call from the center, or cancel a call if one of the other
buttons is accidentally pressed. This button is also
used to access OnStar Personal Calling and Virtual
Advisor services. See the OnStar owner package for
more information.
(Volume Control): You can control the volume
of the OnStar System using either the volume knob
on the radio or using the steering wheel volume control
(If equipped).
(Telltale Light): This light will indicate the status
of the system. A solid green light will come on when
you start the vehicle to let you know that the system is
on and is ready to make or receive calls.If the light blinks green it means that an incoming or
outgoing call is in progress. Press the Communication
button if you notice the light blinking and you are not
on a call.
The light will be red in the event of an OnStar system
malfunction. If this occurs press the OnStar button to
attempt to contact an advisor. If the connection is made,
the advisor will assist you with steps to take to make
sure that the system is functioning properly. If you
cannot contact the advisor, take your vehicle to your
dealership as soon as possible for assistance.
Cellular Antenna
The cellular antenna on the outside of your vehicle is
critical to effective communications using the OnStar
system. Optimum cellular reception can be obtained
when the mast is straight up and down.

2-83
3800 V6 Supercharged Engine
Control Buttons
The Driver Information Center has three buttons that
control its functions.
The English/Metric (E/M), RESET and MODE
buttons for the Driver Information Center are located to
the left of the steering wheel, just below the instrument
panel cluster.
E/M (English/Metric): Press this button to change
the display from English to metric units or metric
to English.
RESET: Press this button for one second to reset the
mode displayed.
MODE: Press this button to change the mode
being displayed.

3-11
Playing the Radio
ON/OFF: Push this knob to turn the system on and off.
VOLUME: Turn the knob clockwise to increase volume.
Turn it counterclockwise to decrease the volume.
RECALL: Press this button to display the station being
played or to display the clock. To change what is
normally shown on the display (station or time), press
this button until you see the display you want, then hold
the button until the display flashes. If you press the
button when the ignition is off, the clock will show for a
few seconds.
Finding a Station
AM
-FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE : Press the up or down arrow to choose
radio stations.
SEEK : Press the up or down arrow to go to the
next or previous station and stay there. The radio will
seek to stations with a strong signal only. The sound will
mute while seeking.To scan stations, press and hold one of the SEEK arrows
for two seconds and SCAN will appear on the display.
The radio will go to a station, play for a few seconds,
then go on to the next station. Press one of the SEEK
arrows again to stop scanning. The radio will scan to
stations with a strong signal only. The sound will mute
while scanning.
P SCAN (Preset Scan): Press this button to listen to
each of your preset stations for a few seconds. The radio
will go to the first preset station, play for a few seconds,
then go on to the next preset station. Press P SCAN
again to stop scanning. The radio will scan preset
stations with a strong signal only. The sound will mute
while scanning.
AUTO (Automatic) SET: Press this button and the
system will seek and set the 12 strongest FM or the
6 strongest AM stations on your preset pushbuttons
(depending on which band (AM or FM) you are
listening to). AUTO SET will flash while seeking and
will remain on until this function is complete. To return
to the stations you manually set, press AUTO
SET again.

3-12
Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press AM
-FM to select the band.
3. Tune in the desired station.
4. Press TONE to select the setting you prefer.
5. Press and hold one of the six numbered pushbuttons.
The sound will mute. When it returns, release the
pushbutton. Whenever you press that numbered
pushbutton, the station you set will return and the
tone you selected will be automatically selected for
that button.
6. Repeat the steps for each pushbutton.Setting the Tone (Bass/Treble)
BASS: Press this knob lightly so it extends. Turn the
knob to increase or decrease bass.
TREB (Treble): Press this knob lightly so it extends.
Turn the knob to increase or decrease treble. If a station
is weak or noisy, you may want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.
TONE: This feature allows you to choose preset
bass and treble equalization settings designed for
country/western, jazz, talk, pop and classical stations.
CLASS will appear on the display when you first
press TONE.
Each time you press the TONE button, this feature will
switch to one of these program types.
To return the bass and treble to the manual mode, either
press TONE, BASS or TREB until MANUAL appears.
See ªSetting Preset Stationsº listed previously to
program the auto tone feature.

3-16
SEEK : Press the up or down arrow to go to the
next or previous station and stay there. The radio will
seek to stations with a strong signal only. The sound will
mute while seeking.
To scan, press one of the SEEK arrows for two seconds
and SCAN will appear on the display. The radio will go
to a station, play for a few seconds, then go on to the
next station. Press one of the SEEK arrows again to stop
scanning. The radio will scan to stations with a strong
signal only. The sound will mute while scanning.
P SCAN (Preset Scan): Press this button to listen to
each of your preset stations for a few seconds. The radio
will go to the first preset station, play for a few seconds,
then go on to the next preset station. Press P SCAN
again to stop scanning. The radio will scan preset
stations with a strong signal only. The sound will mute
while scanning.
AUTO (Automatic) SET: Press this button and the
system will seek and set the 12 strongest FM or the
6 strongest AM stations on your preset pushbuttons
(depending on which band (AM or FM) you are
listening to). AUTO SET will flash while seeking and
will remain on until this function is complete. To return
to the stations you manually set, press AUTO
SET again.Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press AM
-FM to select the band.
3. Tune in the desired station.
4. Press TONE to select the setting you prefer.
5. Press and hold one of the six numbered pushbuttons.
The sound will mute. When it returns, release the
pushbutton. Whenever you press that numbered
pushbutton, the station you set will return and the
tone you selected will be automatically selected for
that button.
6. Repeat the steps for each pushbutton.

3-21 Theft-Deterrent Feature
THEFTLOCK
is designed to discourage theft of your
radio. It works by using a secret code to disable all radio
functions whenever battery power is removed.
If THEFTLOCK is active, the THEFTLOCK indicator
will flash when the ignition is off.
The THEFTLOCK feature for the radio may be used or
ignored. If ignored, the system plays normally and the
radio is not protected by the feature. If THEFTLOCK is
activated, your radio will not operate if stolen.
When THEFTLOCK is activated, the radio will display
LOC to indicate a locked condition anytime battery
power is removed. If your battery loses power for any
reason, you must unlock the radio with the secret code
before it will operate.
Activating the Theft
-Deterrent Feature
The instructions which follow explain how to enter your
secret code to activate the THEFTLOCK system. It is
recommended that you read through all nine steps
before starting the procedure.
If you allow more than 15 seconds to elapse between
any steps, the radio automatically reverts to time and
you must start the procedure over at Step 4.1. Write down any three or four
-digit number
from 000 to 1999 and keep it in a safe place separate
from the vehicle.
2. Turn the ignition to ACCESSORY or RUN.
3. Turn the radio off.
4. Press the 1 and 4 pushbuttons at the same time.
Hold them down until
--- shows on the display.
Next you will use the secret code number which you
have written down.
5. Press MIN and 000 will appear on the display.
6. Press MIN again to make the last two digits agree
with your code.
7. Press HRS to make the first one or two digits agree
with your code.
8. Press AM
-FM after you have confirmed that the
code matches the secret code you have written down.
The display will show REP to let you know that you
need to repeat Steps 5 through 7 to confirm your
secret code.
9. Press AM
-FM and this time the display will show
SEC to let you know that your radio is secure.

3-22
Unlocking the Theft-Deterrent Feature After a
Power Loss
Enter your secret code as follows; pause no more than
15 seconds between steps:
1. Turn the ignition on. LOC will appear on the display.
2. Press MIN and 000 will appear on the display.
3. Press MIN again to make the last two digits agree
with your code.
4. Press HRS to make the first one or two digits agree
with your code.
5. Press AM
-FM after you have confirmed that the
code matches the secret code you have written down.
The display will show SEC, indicating the radio is
now operable and secure.
If you enter the wrong code eight times, INOP will
appear on the display. You will have to wait an hour
with the ignition on before you can try again. When
you try again, you will only have three more chances
(eight tries per chance) to enter the correct code before
INOP appears.
If you lose or forget your code, contact your dealer.Disabling the Theft
-Deterrent Feature
Enter your secret code as follows; pause no more than
15 seconds between steps:
1. Turn the ignition to ACCESSORY or RUN.
2. Turn the radio off.
3. Press the 1 and 4 pushbuttons at the same time.
Hold them down until SEC shows on the display.
4. Press MIN and 000 will appear on the display.
5. Press MIN again to make the last two digits agree
with your code.
6. Press HRS to make the first one or two digits agree
with your code.
7. Press AM
-FM after you have confirmed that the
code matches the secret code you have written down.
The display will show
---, indicating that the radio
is no longer secured.
If the code entered is incorrect, SEC will appear on the
display. The radio will remain secured until the correct
code is entered.
When battery power is removed and later applied to a
secured radio, the radio won't turn on and LOC will
appear on the display.
To unlock a secured radio see ªUnlocking the
Theft
-Deterrent Feature After a Power Lossº earlier
in this section.
