manual radio set BUICK REGAL 2002 Owner's Manual

3-11
Playing the Radio
ON/OFF: Push this knob to turn the system on and off.
VOLUME: Turn the knob clockwise to increase volume.
Turn it counterclockwise to decrease the volume.
RECALL: Press this button to display the station being
played or to display the clock. To change what is
normally shown on the display (station or time), press
this button until you see the display you want, then hold
the button until the display flashes. If you press the
button when the ignition is off, the clock will show for a
few seconds.
Finding a Station
AM
-FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE : Press the up or down arrow to choose
radio stations.
SEEK : Press the up or down arrow to go to the
next or previous station and stay there. The radio will
seek to stations with a strong signal only. The sound will
mute while seeking.To scan stations, press and hold one of the SEEK arrows
for two seconds and SCAN will appear on the display.
The radio will go to a station, play for a few seconds,
then go on to the next station. Press one of the SEEK
arrows again to stop scanning. The radio will scan to
stations with a strong signal only. The sound will mute
while scanning.
P SCAN (Preset Scan): Press this button to listen to
each of your preset stations for a few seconds. The radio
will go to the first preset station, play for a few seconds,
then go on to the next preset station. Press P SCAN
again to stop scanning. The radio will scan preset
stations with a strong signal only. The sound will mute
while scanning.
AUTO (Automatic) SET: Press this button and the
system will seek and set the 12 strongest FM or the
6 strongest AM stations on your preset pushbuttons
(depending on which band (AM or FM) you are
listening to). AUTO SET will flash while seeking and
will remain on until this function is complete. To return
to the stations you manually set, press AUTO
SET again.

3-12
Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press AM
-FM to select the band.
3. Tune in the desired station.
4. Press TONE to select the setting you prefer.
5. Press and hold one of the six numbered pushbuttons.
The sound will mute. When it returns, release the
pushbutton. Whenever you press that numbered
pushbutton, the station you set will return and the
tone you selected will be automatically selected for
that button.
6. Repeat the steps for each pushbutton.Setting the Tone (Bass/Treble)
BASS: Press this knob lightly so it extends. Turn the
knob to increase or decrease bass.
TREB (Treble): Press this knob lightly so it extends.
Turn the knob to increase or decrease treble. If a station
is weak or noisy, you may want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.
TONE: This feature allows you to choose preset
bass and treble equalization settings designed for
country/western, jazz, talk, pop and classical stations.
CLASS will appear on the display when you first
press TONE.
Each time you press the TONE button, this feature will
switch to one of these program types.
To return the bass and treble to the manual mode, either
press TONE, BASS or TREB until MANUAL appears.
See ªSetting Preset Stationsº listed previously to
program the auto tone feature.

3-16
SEEK : Press the up or down arrow to go to the
next or previous station and stay there. The radio will
seek to stations with a strong signal only. The sound will
mute while seeking.
To scan, press one of the SEEK arrows for two seconds
and SCAN will appear on the display. The radio will go
to a station, play for a few seconds, then go on to the
next station. Press one of the SEEK arrows again to stop
scanning. The radio will scan to stations with a strong
signal only. The sound will mute while scanning.
P SCAN (Preset Scan): Press this button to listen to
each of your preset stations for a few seconds. The radio
will go to the first preset station, play for a few seconds,
then go on to the next preset station. Press P SCAN
again to stop scanning. The radio will scan preset
stations with a strong signal only. The sound will mute
while scanning.
AUTO (Automatic) SET: Press this button and the
system will seek and set the 12 strongest FM or the
6 strongest AM stations on your preset pushbuttons
(depending on which band (AM or FM) you are
listening to). AUTO SET will flash while seeking and
will remain on until this function is complete. To return
to the stations you manually set, press AUTO
SET again.Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press AM
-FM to select the band.
3. Tune in the desired station.
4. Press TONE to select the setting you prefer.
5. Press and hold one of the six numbered pushbuttons.
The sound will mute. When it returns, release the
pushbutton. Whenever you press that numbered
pushbutton, the station you set will return and the
tone you selected will be automatically selected for
that button.
6. Repeat the steps for each pushbutton.

3-17
Setting the Tone (Bass/Treble)
BASS: Press this knob lightly so it extends. Turn the
knob to increase or decrease bass.
TREB (Treble): Press this knob lightly so it extends.
Turn the knob to increase or decrease treble. If a station
is weak or noisy, you may want to decrease the treble.
Push these knobs back into their stored positions when
you're not using them.
TONE: This feature allows you to choose preset bass
and treble equalization settings designed for
country/western, jazz, talk, pop and classical stations.
CLASS will appear on the display when you first
press TONE.
Each time you press the TONE button, this feature will
switch to one of these program types.
To return the bass and treble to the manual mode, either
press TONE until MANUAL appears or press and
release the BASS or TREB knob and turn it until the
display goes blank. See ªSetting Preset Stationsº listed
previously to program the auto tone feature.Adjusting the Speakers (Balance/Fade)
BAL (Balance): Press this knob lightly so it extends.
Turn the knob to move the sound to the left or right
speakers. The middle position balances the sound
between the speakers.
FADE: Press this knob lightly so it extends. Turn the
knob to move the sound to the front or rear speakers.
The middle position balances the sound between
the speakers.
Push these knobs back into their stored positions when
you're not using them.
Playing a Cassette Tape
The longer side with the tape visible should face to the
right. If the ignition and the radio are on, the tape can
be inserted and will begin playing. If you hear nothing
or hear a garbled sound, the tape may not be in squarely.
Press EJECT to remove the tape and start over.
While the tape is playing, use the VOLUME, SEEK,
FADE, BAL, BASS and TREB controls just as you
do for the radio. Other controls may have different
functions when a tape is inserted. The display will show
an arrow to show which side of the tape is playing.

5-4
2. Get the vehicles close enough so the jumper cables
can reach, but be sure the vehicles aren't touching
each other. If they are, it could cause a ground
connection you don't want. You wouldn't be able to
start your vehicle, and the bad grounding could
damage the electrical systems.
To avoid the possibility of the vehicles rolling, set
the parking brake firmly on both vehicles involved in
the jump start procedure. Put an automatic transaxle
in PARK (P) or a manual transaxle in NEUTRAL
before setting the parking brake.
NOTICE:
If you leave your radio on, it could be badly
damaged. The repairs wouldn't be covered by
your warranty.
3. Turn off the ignition on both vehicles. Unplug
unnecessary accessories plugged into the cigarette
lighter or in the auxiliary power outlet. Turn off the
radio and all lamps that aren't needed. This will
avoid sparks and help save both batteries. And it
could save your radio!
4. Open the hoods and locate the batteries. Find the
positive (+) and negative (
-) terminal location on each
vehicle. You will not need to access your battery for
jump starting. Your vehicle has a remote positive (+)
jump starting terminal for that purpose. The terminal is
located on the same side of the engine compartment as
your battery. See ªEngine Compartment Overviewº in
the Index for more information on location.
To uncover the remote positive (+) terminal, squeeze
the sides of the red plastic cap and pull the cap
upward. You should always use the remote
positive (+) terminal instead of the positive (+)
terminal on your battery.
