remote start BUICK REGAL 2002 Owner's Manual

2-
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Windows
2
-4 Keys
2
-6 Door Locks
2
-10 Remote Keyless Entry
2
-17 Trunk
2
-22 Theft
2
-23 PASS-Key
II
2
-24 New Vehicle ªBreak-Inº
2
-25 Ignition Positions
2
-26 Starting Your Engine
2
-27 Engine Coolant Heater (If Equipped)
2
-28 Automatic Transaxle Operation
2
-33 Parking Brake
2
-34 Shifting Into PARK (P)
2
-36 Shifting Out of PARK (P)
2
-37 Parking Over Things That Burn
2
-38 Engine Exhaust
2
-38 Running Your Engine While You're Parked2
-39 Horn
2
-39 Tilt Wheel
2
-40 Turn Signal/Multifunction Lever
2
-46 Exterior Lamps
2
-49 Interior Lamps
2
-52 Mirrors
2
-56 Storage Compartments
2
-58 Sun Visors
2
-58 Auxiliary Power Outlet
2
-59 Auxiliary Power Connection (Power Drop)
2
-60 OnStar
System (If Equipped)
2
-64 Sunroof (Option)
2
-65 The Instrument Panel -- Your
Information System
2
-66 Instrument Panel Cluster
2
-68 Warning Lights, Gages and Indicators
2
-82 Driver Information Center (Option)

2-12
Programmable Modes
Your vehicle can be programmed to one of the
following modes.
Mode 1: No Verification
Mode 2: Horn Chirp only
Mode 3: Headlamp Flash only
Mode 4: Horn Chirp and Headlamp Flash
Before your vehicle was shipped from the factory, it
was programmed to Mode 3. The mode to which your
vehicle was programmed may have been changed since
it left the factory. To determine which security feedback
lock mode your vehicle is programmed to or to program
your vehicle to a different mode, do the following:
1. Close all doors and turn the ignition key to RUN.
2. Press and hold the power door lock switch in the
lock position.3. While holding the door lock switch in the lock
position, press and release the remote keyless
entry transmitter LOCK button. This will start the
customization mode. While in the customization
mode, the feature will sound the number of chimes
corresponding to the current lock mode. (If you
do not wish to change the current mode, you can
either exit the programming mode by following the
instructions listed here or program the next feature
available on your vehicle.)
4. Each additional press of the remote keyless entry
transmitter LOCK button will cause your vehicle to
advance the lock mode by one, starting from the
current lock mode.
5. If cycled beyond Mode 4, the vehicle will enter
Mode 1. When the door lock switch is released,
the vehicle will remain in the most recent lock mode.

2-13
Before your vehicle was shipped from the factory, it was
programmed to Mode 3. The mode to which your vehicle
was programmed may have been changed since it left the
factory. To determine which security feedback unlock
mode your vehicle is programmed to or to program
your vehicle to a different mode, do the following:
1. Close all doors and turn the ignition key to RUN.
2. Press and hold the power door lock switch in the
unlock position. While holding the door lock switch
in the unlock position, press and release the remote
keyless entry transmitter UNLOCK button. This
will start the customization mode. While in the
customization mode, the feature will sound the
number of chimes corresponding to the current
unlock mode. (If you do not wish to change the
current mode, you can either exit the programming
mode by following the instructions listed here or
program the next feature available on your vehicle.)
3. Each additional press of the remote keyless entry
transmitter UNLOCK button will cause your vehicle
to advance the unlock mode by one, starting from the
current unlock mode.
4. If cycled beyond unlock Mode 4, the vehicle will
enter unlock Mode 1. When the door lock switch is
released, the vehicle will remain in the most recent
unlock mode.The mode you selected is now set. You can either
exit the programming mode by following the previous
instructions or program the next feature available on
your vehicle.
Disconnecting the vehicle's battery for up to a year will
not change the programmed mode for the lock and
unlock security feedback features.
Delayed Locking
Delayed locking allows the doors to be locked while
the passengers are exiting the vehicle. This feature also
allows a brief time period for you to re
-enter the vehicle
after the doors have been closed and locked. Delayed
locking is user programmable for enabling or disabling
the feature.
Delayed locking is activated when a door lock switch is
pressed while the key is not in the vehicle's ignition, and
a door is open. The door lock switch may be either the
lock switch on the door or on the remote keyless entry
transmitter (see ªRemote Keyless Entryº earlier in this
section for more details). The doors do not lock when
the lock switch is pressed, but instead, three chimes are
heard. These chimes indicate that the delayed locking
function has been activated.

2-49
Interior Lamps
Instrument Panel Brightness Control
This feature control the brightness of the instrument
panel lights.
You can brighten or dim the instrument panel lights by
adjusting the exterior lamps control located to the right
of the exterior lamps control.
If you turn to control clockwise the interior lamps will
come on and become brighter as the control is turned
further to MAX. Turning the control all the way
clockwise turns on the courtesy lamps. If you turn the
control counterclockwise the lamps will begin to dim
and continue to get dimmer as the control is turned
closer toward LIGHTS MIN. If the control is turned
all the way counterclockwise, the lamps and lights will
turn off.
Courtesy Lamps
When any door is opened, several lamps come on. These
lamps are courtesy lamps. They make it easy for you to
enter and leave your vehicle. You can also turn these
lamps on by turning the exterior lamps control
clockwise to MAX.
Illuminated Entry
Your courtesy lamps will come on and stay on for a
set time whenever you press UNLOCK on the remote
keyless entry transmitter.
If you open a door, the lamps will stay on while it's open
and then turn off automatically about 25 seconds after
you close it. If you press UNLOCK and don't open a
door, the lamps will turn off after about 40 seconds.
Illuminated entry includes a feature called theater
dimming. With theater dimming, the lamps don't just
turn off at the end of the delay time. Instead, they slowly
dim after the delay time until they go out. The delay
time is canceled if you turn the ignition key to RUN or
START, so the lamps will dim right away.
When the ignition is on, illuminated entry is inactive,
which means the courtesy lamps won't come on unless
a door is opened.

2-51
You may enable or disable the perimeter lighting feature
when the driver performs the following sequence with
the engine not running and the doors closed:
1. Turn the ignition to RUN.
2. Close all the doors.
3. Apply your brakes.
4. Press and hold the power door lock switch. While
holding the door lock switch press and release the
panic button on the remote keyless entry transmitter.
This will initialize the customization mode. While in the
customization mode, the feature will sound the number
of chimes corresponding to the current mode. In Mode
1, one chime means the feature is disabled. In Mode 2,
two chimes signal that the perimeter lighting feature is
enabled. Each additional press will advance the mode by
one, starting from the current mode. During this
procedure, the feature will sound the number of chimes
corresponding to the mode. When the lock switch is
released, the vehicle will remain in the last mode.
Disconnecting the vehicle's battery for up to a year will
not change the programmed operation for this feature.Rearview Mirror Reading Lamps
The reading lamps are located on the underside of the
rearview mirror.
Use the button next to each lamp to turn them on
and off.
Dome Lamp (If Equipped)
The dome lamp will come on when you open a door.
Battery Rundown Protection
Your vehicle has a feature to help prevent you from
draining the battery in case you accidentally leave
the interior courtesy lamps, reading/map lamps, visor
vanity lamps, trunk lamp, underhood lamp or glove box
lamps on. If you leave any of these lamps on, they will
automatically turn off after 20 minutes, if the ignition is
in OFF. The lamps won't come back on again until you
do one of the following:

Turn the ignition on,

turn the exterior lamps control off, then on, or

open a door.
If your vehicle has less than 15 miles (25 km) on the
odometer, the battery saver will turn off the lamps after
only three minutes.

5-4
2. Get the vehicles close enough so the jumper cables
can reach, but be sure the vehicles aren't touching
each other. If they are, it could cause a ground
connection you don't want. You wouldn't be able to
start your vehicle, and the bad grounding could
damage the electrical systems.
To avoid the possibility of the vehicles rolling, set
the parking brake firmly on both vehicles involved in
the jump start procedure. Put an automatic transaxle
in PARK (P) or a manual transaxle in NEUTRAL
before setting the parking brake.
NOTICE:
If you leave your radio on, it could be badly
damaged. The repairs wouldn't be covered by
your warranty.
3. Turn off the ignition on both vehicles. Unplug
unnecessary accessories plugged into the cigarette
lighter or in the auxiliary power outlet. Turn off the
radio and all lamps that aren't needed. This will
avoid sparks and help save both batteries. And it
could save your radio!
4. Open the hoods and locate the batteries. Find the
positive (+) and negative (
-) terminal location on each
vehicle. You will not need to access your battery for
jump starting. Your vehicle has a remote positive (+)
jump starting terminal for that purpose. The terminal is
located on the same side of the engine compartment as
your battery. See ªEngine Compartment Overviewº in
the Index for more information on location.
To uncover the remote positive (+) terminal, squeeze
the sides of the red plastic cap and pull the cap
upward. You should always use the remote
positive (+) terminal instead of the positive (+)
terminal on your battery.

5-7
8. Now connect the
negative (
-) cable to the
negative (
-) terminal of
the good battery. Use a
remote negative (
-)
terminal if the vehicle
has one.
Don't let the other end touch anything until the next
step. The other end of the negative (
-) cable doesn't
go to the dead battery. It goes to a heavy, unpainted
metal part, or to the remote negative (
-) terminal on
the vehicle with the dead battery.
9. Connect the other end of the negative (
-) cable at
least 18 inches (45 cm) away from the dead battery,
but not near engine parts that move. The electrical
connection is just as good there, and the chance of
sparks getting back to the battery is much less.
10. Now start the vehicle with the good battery and run
the engine for a while.
11. Try to start the vehicle that had the dead battery.
If it won't start after a few tries, it probably
needs service.

6-67
Fuse Usage
PARK LOCK Ignition Key Solenoid
Blank Not Used
Blank Not Used
PCM, BCM,
U/H RELAYIgnition Signal: Hot in Run
and Start, Powertrain Control
Module, Body Control Module,
Underhood Relay
RADIO
PREM. SOUNDRemote Radio Premium Sound
POWER MIRRORS Power Mirrors
Blank Not Used
PANEL DIMMING Panel Dimming
Blank Not Used
IGN 0, CLUSTER,
PCM, BCMIgnition Signal: Hot in Run,
Unlock and Start, Cluster,
Powertrain Control Module,
Body Control ModuleFuse Usage
Blank Not Used
Blank Not Used
Blank Not Used
INADV
POWER BUS
DOOR LOCKS Door Locks
TRAP ALERT Trap Alert

TAIL LAMPS,
LIC LAMPSTaillamps, License Lamps
RADIO Radio
HEATED MIRROR Heated Mirrors
CRUISE Cruise Control
Blank Not Used
CLUSTER Instrument Panel Cluster
CIGAR LTR Cigarette Lighter,
Auxiliary Power
Connection (Power Drop)
