wiper size BUICK REGAL 2014 Owner's Manual

Black plate (35,1)Buick Regal Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
6081497) - 2014 - CRC 2nd Edition - 11/22/13
Vehicle Care 10-35
Electrical System
Overload
The vehicle has fuses and circuit
breakers to protect against an
electrical system overload.
When the current electrical load is
too heavy, the circuit breaker opens
and closes, protecting the circuit
until the current load returns to
normal or the problem is fixed. This
greatly reduces the chance of circuit
overload and fire caused by
electrical problems.
Fuses and circuit breakers protect
power devices in the vehicle.
Replace a bad fuse with a new one
of the identical size and rating.
If there is a problem on the road and
a fuse needs to be replaced, the
same amperage fuse can be
borrowed. Choose some feature of
the vehicle that is not needed to use
and replace it as soon as possible.
Headlamp Wiring
An electrical overload may cause
the lamps to go on and off, or in
some cases to remain off. Have the
headlamp wiring checked right away
if the lamps go on and off or
remain off.
Windshield Wipers
If the wiper motor overheats due to
heavy snow or ice, the windshield
wipers will stop until the motor cools
and will then restart.
Although the circuit is protected
from electrical overload, overload
due to heavy snow or ice may
cause wiper linkage damage.
Always clear ice and heavy snow
from the windshield before using the
windshield wipers.
If the overload is caused by an
electrical problem and not snow or
ice, be sure to get it fixed.
Fuses and Circuit
Breakers
The wiring circuits in the vehicle are
protected from short circuits by a
combination of fuses and circuit
breakers. This greatly reduces the
chance of damage caused by
electrical problems.
To check a fuse, look at the
silver-colored band inside the fuse.
If the band is broken or melted,
replace the fuse. Be sure to replace
a bad fuse with a new one of the
identical size and rating.
Fuses of the same amperage can
be temporarily borrowed from
another fuse location, if a fuse goes
out. Replace the fuse as soon as
possible.
To identify and check fuses, circuit
breakers, and relays, seeEngine
Compartment Fuse Block on
page 10-36 andInstrument Panel
Fuse Block on page 10-39.

Black plate (12,1)Buick Regal Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
6081497) - 2014 - CRC 2nd Edition - 11/27/13
i-12 INDEX
TransmissionAutomatic . . . . . . . . . . . . . . . . . . . . . 9-27
Fluid, Automatic . . . . . . . . . . . . 10-15
Fluid, Manual . . . . . . . . . . . . . . . 10-15
Messages . . . . . . . . . . . . . . . . . . . . 5-47
Transportation Program, Courtesy . . . . . . . . . . . . . . . . . . . . . 13-7
Trip Odometer . . . . . . . . . . . . . . . . . 5-16
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . 2-14
Turn and Lane-Change Signals . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Turn Signal Bulb Replacement . . . . . . . . . . 10-33
U
Uniform Tire QualityGrading . . . . . . . . . . . . . . . . . . . . . 10-59
Universal Remote System . . . . . 5-54
Operation . . . . . . . . . . . . . . . . . . . . . 5-56
Programming . . . . . . . . . . . . . . . . . 5-54
Up-Shift Light . . . . . . . . . . . . . . . . . . 5-26
Using This Manual . . . . . . . . . . . . . . . . iii
V
Vehicle Alarm System . . . . . . . . . . . . . . . . 2-16
Canadian Owners . . . . . . . . . . . . . . . iii
Control . . . . . . . . . . . . . . . . . . . . . . . . 9-3
IdentificationNumber (VIN) . . . . . . . . . . . . . . . 12-1
Load Limits . . . . . . . . . . . . . . . . . . . 9-10
Messages . . . . . . . . . . . . . . . . . . . . 5-39
Personalization . . . . . . . . . . . . . . . 5-48
Remote Start . . . . . . . . . . . . . . . . . . 2-9
Security . . . . . . . . . . . . . . . . . . . . . . 2-16
Towing . . . . . . . . . . . . . . . . . . . . . . 10-82
Vehicle Ahead Indicator . . . . . . . 5-26
Vehicle Care Storing the Tire Sealant
and Compressor Kit . . . . . . . 10-71
Tire Pressure . . . . . . . . . . . . . . . 10-48
Vehicle Diagnostics OnStar
®. . . . . . . . . . . . . . . . . . . . . . 14-5
Ventilation, Air . . . . . . . . . . . . . . . . . . 8-6
Visors . . . . . . . . . . . . . . . . . . . . . . . . . 2-22
Voltage Devices and Wiring . . . . . . . . . . . . . . . . . . . . . . . 10-34
W
WarningBrake System Light . . . . . . . . . . . 5-24
Lane Departure (LDW) . . . . . . . 9-58
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . . . . . . 5-7
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . iv
Cautions and Danger . . . . . . . . . . . .iv
Hazard Flashers . . . . . . . . . . . . . . . 6-3
Washer Fluid . . . . . . . . . . . . . . . . . 10-23 Messages . . . . . . . . . . . . . . . . . . . . 5-47
Wheels Alignment and TireBalance . . . . . . . . . . . . . . . . . . . 10-60
Different Size . . . . . . . . . . . . . . . 10-58
Replacement . . . . . . . . . . . . . . . 10-61
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . 10-56
Where to Put the Restraint . . . . 3-37
Windows . . . . . . . . . . . . . . . . . . . . . . 2-20 Messages . . . . . . . . . . . . . . . . . . . . 5-47
Power . . . . . . . . . . . . . . . . . . . . . . . . 2-21
Windshield Wiper/Washer . . . . . . . . . . . . . . . . . 5-3
Winter
Driving . . . . . . . . . . . . . . . . . . . . . . . . . 9-8
