BUICK TERRAZA 2007 Owner's Manual

The main components of the instrument panel are the following:
A. Air Outlets. SeeOutlet Adjustment
on page 200.
B. Turn Signal/Multifunction Lever. SeeTurn
Signal/Multifunction Lever on page 173.
C. Audio Steering Wheel Controls (If Equipped).
SeeAudio Steering Wheel Controls on
page 341.
D. Instrument Panel Cluster. SeeInstrument
Panel Cluster on page 208.
E. Driver Information Center (DIC) Controls
(If Equipped). SeeDriver Information
Center (DIC) on page 223.
F. Traction Control System Button (If Equipped).
SeeTraction Control System (TCS) on
page 353.
G. Hazard Warning Flasher Switch. SeeHazard
Warning Flashers on page 172.
H. Passenger Airbag Status And Passenger
Seatbelt Reminder Indicator. SeePassenger
Airbag Status Indicator on page 211and
Passenger Safety Belt Reminder Light
on page 210.I. Audio System. SeeAudio System(s)
on page 258.
J. Exterior Lamps Control. SeeExterior
Lamps on page 181.
K. Interior Lamps Control. SeeInterior Lamps
Control on page 184. Instrument Panel
Brightness Control. SeeInstrument Panel
Brightness on page 183.
L. Hood Release. SeeHood Release
on page 409.
M. Parking Brake. SeeParking Brake
on page 137.
N. Horn. SeeHorn on page 172.
O. Cruise Controls (If Equipped).
SeeCruise Control on page 177.
P. Dual Climate Controls. SeeDual Climate
Control System on page 197.
Q. Heated Seat Controls (If Equipped).
SeeHeated Seats on page 10.
R. Glove Box. SeeGlove Box on page 158.
171

Hazard Warning Flashers
Your hazard warning ashers let you warn others.
They also let police know you have a problem. Your
front and rear turn signal lamps will ash on and off.
The hazard warning
asher button is located
in the center of the
instrument panel.
Your hazard warning ashers work no matter what
position your key is in, and even if the key is
not in the ignition switch.
Press the button to make the front and rear turn
signal lamps ash on and off. Press the button
again to turn the ashers off.
When the hazard warning ashers are on, your
turn signals will not work.
Other Warning Devices
If you carry reective triangles, you can set them
up at the side of the road about 300 feet (100 m)
behind your vehicle.
Horn
Press near or on the horn symbols on your
steering wheel pad to sound the horn.
Tilt Wheel
A tilt wheel allows you to adjust the steering wheel
before you drive. You can raise the steering
wheel to the highest level to give your legs more
room when you enter and exit the vehicle.
The lever that allows you to tilt the steering wheel
is located on the left side of the steering column.
To tilt the wheel, hold the
wheel and pull the lever.
Then move the wheel to
a comfortable position
and release the lever to
lock the wheel in place.
172

Turn Signal/Multifunction Lever
The lever on the left side of the steering column
includes the following:
GTurn and Lane Change Signals. See
Turn and Lane-Change Signals on page 173.
53Headlamp High/Low-Beam Changer.
SeeHeadlamp High/Low-Beam Changer on
page 174.
Flash-to-Pass. SeeFlash-to-Pass on
page 174.
NWindshield Wipers. SeeWindshield
Wipers on page 175.
LWindshield Washer. SeeWindshield
Washer on page 175.
ZRear Window Wiper. SeeWindshield
Washer on page 175.
=Rear Window Washer. SeeWindshield
Washer on page 175.
For information on the headlamps, seeExterior
Lamps on page 181.
Turn and Lane-Change Signals
The turn signal has two upward (for right) and two
downward (for left) positions. These positions
allow you to signal a turn or a lane change.
To signal a turn, move the lever all the way up or
down. When the turn is nished, the lever will
return automatically.
An arrow on the
instrument panel
cluster will ash in the
direction of the turn
or lane change.
173

To signal a lane change, just raise or lower the
lever until the arrow starts to ash. Hold it
there until you complete your lane change. The
lever will return by itself when you release it.
As you signal a turn or a lane change, if the arrow
ashes faster than normal, a signal bulb may be
burned out and other drivers will not see your turn
signal.
If a bulb is burned out, replace it to help avoid an
accident. If the arrows do not go on at all when you
signal a turn, check for burned-out bulbs and check
the fuse. SeeBulb Replacement on page 443and
Fuses and Circuit Breakers on page 497.
If you have a trailer towing option with added
wiring for the trailer lamps, the signal indicator will
ash at a normal rate even if a turn signal bulb
is burned out. Check the front and rear turn signal
lamps regularly to make sure they are working.
Turn Signal On Chime
If either turn signal is left on for more than
3/4 mile (1.2 km), a chime will sound to let the
driver know to turn it off. If you need to leave the
signal on for more than 3/4 mile (1.2 km), turn
off the signal and then turn it back on.
Headlamp High/Low-Beam Changer
To change the headlamps from low beam to
high beam, push the turn signal/multifunction lever
away from you.
When the high beams
are on, this light
will appear on the
instrument panel cluster.
To change the headlamps from high beam to low
beam, pull the turn signal/multifunction lever
toward you.
Flash-to-Pass
When the headlamps are off, pull the lever toward
you to momentarily turn on the high beams.
This will signal that you are going to pass. When
you release the lever, they will turn off.
174

Windshield Wipers
You control the windshield wipers by turning the
band with the wiper symbol on it.
8(Mist):For a single wiping cycle, turn the band
to mist. Hold it there until the wipers start. Then let
go. The wipers will stop after one wipe. If you want
more wipes, hold the band on mist longer.
9(Off):To stop the wipers, move the band to off.
N(Delay):You can set the wiper speed for a long
or short delay between wipes. This can be very
useful in light rain or snow. Turn the band to choose
the delay time. The closer to the top of the lever, the
shorter the delay.
6(Low Speed):For steady wiping at low
speed, turn the band away from you to the rst solid
band past the delay settings. For high-speed
wiping, turn the band further, to the second solid
band past the delay settings. To stop the wipers,
move the band to off.
1(High Speed):For high-speed wiping, turn
the band further, to the second solid band past the
delay settings.Be sure to clear ice and snow from the wiper
blades before using them. If they are frozen to the
windshield, carefully loosen or thaw them. If
your blades do become worn or damaged, get
new blades or blade inserts.
Windshield Washer
LQ(Windshield Washer):Press and hold the
windshield washer paddle with this symbol on
it to wash your windshield. The washers and
wipers will operate.
When you release the paddle, the washers will
stop, and the wipers will continue to operate
for two cycles, unless your wipers had already
been on. In that case, the wipers will resume the
wiper speed you had selected earlier.
{CAUTION:
In freezing weather, do not use your
washer until the windshield is warmed.
Otherwise the washer uid can form ice
on the windshield, blocking your vision.
175

Rear Window Wiper/Washer
{CAUTION:
In freezing weather, do not use your
washer until the windshield is warmed.
Otherwise the washer uid can form ice
on the windshield, blocking your vision.
The controls for
the rear window
washer/wiper are
located on the
end of the turn
signal/multifunction
lever.
9(Off):Move the lever to this position to turn
the rear washers/wipers off.
Z(Rear Wiper):Move the lever to this position
to turn the rear wipers on.
=(Rear Washer/Wiper):Move the lever to this
position to wash and wipe the rear window.
The rear window washer uses the same uid bottle
as the windshield washer. However, the rear
window washer will run out of uid before
the windshield washer. If you can wash your
windshield but not your rear window, check the
uid level.
176

Cruise Control
{CAUTION:
Cruise control can be dangerous where
you cannot drive safely at a steady speed.
So, do not use your cruise control on
winding roads or in heavy traffic.
Cruise control can be dangerous on
slippery roads. On such roads, fast
changes in tire traction can cause
excessive wheel slip, and you could lose
control. Do not use cruise control on
slippery roads.The cruise control lever
is located below the
windshield wiper control
on the right side of
the steering wheel.
QRES + (Resume/Accelerate):Push the lever
up to resume the cruise control speed, or to
accelerate when passing another vehicle.
J(CRUISE CONTROL) ON/OFFq:Press the
button on the end of the lever to turn the cruise
control on. Press it again to turn cruise control off.
RSET — (Set/Coast/Decelerate):Push the
lever down to set the cruise speed. If the cruise
speed is already set this position can be used
to coast or decelerate from a higher speed.
CANCEL
R:Pull the lever to cancel the cruise
control speed.
177

Cruise control allows a speed of approximately
25 mph (40 km/h) or more to be maintained
without keeping your foot on the accelerator. This
is helpful on long trips. Cruise control does not
work at speeds below about 25 mph (40 km/h).
When the brakes are applied, the cruise control
shuts off.
If the vehicle is in cruise control and the Traction
Control System (TCS) begins to limit wheel
spin, the cruise control will automatically
disengage. SeeTraction Control System (TCS)
on page 353. When road conditions allow,
the cruise control can be used again.Setting Cruise Control
{CAUTION:
If you leave your cruise control on when
you are not using cruise, you might hit a
button and go into cruise when you do not
want to. You could be startled and even
lose control. Keep the cruise control switch
off until you want to use cruise control.
1. Push the button at the end of the cruise
control lever to turn the cruise control on.
2. Accelerate to the desired speed.
3. Push down on the cruise control lever and
release it. This will set the speed in cruise
control.
4. Remove your foot from the accelerator pedal.
This symbol will appear
on the instrument panel
cluster when the
cruise control is set.
178

This symbol will disappear when the brakes are
applied or the cruise control is cancelled. It will
reappear when the set cruise speed is resumed.
Resuming a Set Speed
If the cruise control is set at a desired speed and
then the brakes are applied, the cruise control shuts
off. But the cruise control does not need to be reset.
Once the vehicle is traveling approximately
25 mph (40 km/h) or more, the cruise control
lever can be pushed upward toward the plus
(resume/accelerate) position to return to the
preset cruise speed.
The vehicle will return to and stay at the preset
cruise speed. If the cruise control lever is pushed
up and held toward the plus (resume/accelerate)
position, the vehicle speed will increase until the
lever is released or the brakes are applied.
Do not continue to hold the lever in the plus
(resume/accelerate) position, unless a faster
speed is desired.
Increasing Speed While Using
Cruise Control
There are two ways to go to a higher speed:
Use the accelerator pedal to get to the higher
speed. Push up on the cruise control lever
toward the plus (resume/accelerate) position,
then release the lever and take your foot
off the accelerator pedal. The vehicle will now
cruise at the higher speed.
Push up and hold the cruise control lever
toward the plus (resume/accelerate) position
until the vehicle reaches the desired speed.
Then release the cruise control lever. To
increase the vehicle’s speed in very small
amounts, push up briey on the cruise control
lever and release it. Each time this is done,
the vehicle will speed up approximately
one mph (1.6 km/h).
The acceleration feature will only work after the
cruise control speed has been set by pushing the
cruise control lever down to the set position.
179

Reducing Speed While Using
Cruise Control
There are two ways to reduce the vehicle’s speed
while using cruise control:
Push the cruise control lever downward toward
the minus (set/coast/decelerate) position until
a lower speed is reached, then release it.
To slow down in very small amounts, push
the cruise control lever downward toward the
minus (set/coast/decelerate) position briey.
Each time this is done, the vehicle will slow
down approximately one mph (1.6 km/h).
Passing Another Vehicle While
Using Cruise Control
Use the accelerator pedal to increase the vehicle’s
speed. When you take your foot off the pedal,
the vehicle will slow down to the cruise control
speed set earlier.
Using Cruise Control on Hills
How well the cruise control will work on hills
depends upon the vehicle’s speed, its load, and
the steepness of the hills. When going up steep
hills, the accelerator pedal might have to be
used in order to maintain the vehicle’s speed.When going downhill, the brakes might have to be
applied, or the transaxle might have to be shifted
to a lower gear to keep the vehicle’s speed down.
Doing either of these things will take the vehicle out
of cruise. It may be better not to use the cruise
control if the brakes constantly have to be applied,
or the vehicle continuously needs to be shifted to
a lower gear.
Cancelling Cruise Control
To cancel a cruise control session, pull the cruise
control lever forward, or step lightly on the
brake pedal.
Doing either of these things will only end the
current cruise control session, but the set speed
will be retained in memory.
Push the button at the end of the cruise control
lever to turn the system off.
Erasing Speed Memory
When the cruise control or the ignition is turned
off, the cruise control set speed memory is erased.
180
