headlamp BUICK VERANO 2017 Owner's Guide

Buick Verano Owner Manual (GMNA- Localizing-U.S./Canada-10122753) -
2017 - crc - 5/16/16
Vehicle Care 255
RelaysUsage
6 High-beam headlamps
7 –
8 –
9 –
10 EGR/Coolant pump/ AIR solenoid valve
11 Engine cooling fan (RPO LEA)
12 Engine cooling fan (RPO LEA)
13 Engine cooling fan (RPO LEA)
14 Run/CrankInstrument Panel Fuse
Block
The instrument panel fuse block is
on the driver side of the instrument
panel. To access: 1. Open the storage compartment.
2. Pull straight down and out to remove the storage
compartment.
3. Remove the cover.
To reinstall the cover, line up the
retainers and push into place.
Instrument Panel Fuse Block

Buick Verano Owner Manual (GMNA- Localizing-U.S./Canada-10122753) -
2017 - crc - 5/16/16
Vehicle Care 277
Wheel Replacement
Replace any wheel that is bent,
cracked, or badly rusted or
corroded. If wheel nuts keep coming
loose, the wheel, wheel bolts, and
wheel nuts should be replaced.
If the wheel leaks air, replace it.
Some aluminum wheels can be
repaired. See your dealer if any of
these conditions exist.
Your dealer will know the kind of
wheel that is needed.
Each new wheel should have the
same load-carrying capacity,
diameter, width, offset, and be
mounted the same way as the one it
replaces.
Replace wheels, wheel bolts, wheel
nuts, or Tire Pressure Monitor
System (TPMS) sensors with new
GM original equipment parts.
{Warning
Using the wrong replacement
wheels, wheel bolts, or wheel
nuts can be dangerous. It could(Continued)
Warning (Continued)
affect the braking and handling of
the vehicle. Tires can lose air,
and cause loss of control, causing
a crash. Always use the correct
wheel, wheel bolts, and wheel
nuts for replacement.
Caution
The wrong wheel can also cause
problems with bearing life, brake
cooling, speedometer or
odometer calibration, headlamp
aim, bumper height, vehicle
ground clearance, and tire or tire
chain clearance to the body and
chassis.
Used Replacement Wheels
{Warning
Replacing a wheel with a used
one is dangerous. How it has
been used or how far it has been
driven may be unknown. It could
fail suddenly and cause a crash.
When replacing wheels, use a
new GM original equipment
wheel.
Tire Chains
{Warning
Do not use tire chains. There is
not enough clearance. Tire chains
used on a vehicle without the
proper amount of clearance can
cause damage to the brakes,
suspension, or other vehicle
parts. The area damaged by the
tire chains could cause loss of
control and a crash.(Continued)

Buick Verano Owner Manual (GMNA- Localizing-U.S./Canada-10122753) -
2017 - crc - 5/16/16
Service and Maintenance 311
Hoses
Hoses transport fluids and should
be regularly inspected to ensure
that there are no cracks or leaks.
With a multi-point inspection, your
dealer can inspect the hoses and
advise if replacement is needed.
Lamps
Properly working headlamps,
taillamps, and brake lamps are
important to see and be seen on
the road.
.Signs that the headlamps need
attention include dimming, failure
to light, cracking, or damage.
The brake lamps need to be
checked periodically to ensure
that they light when braking.
. With a multi-point inspection,
your dealer can check the lamps
and note any concerns. Shocks and Struts
Shocks and struts help aid in control
for a smoother ride.
.
Signs of wear may include
steering wheel vibration, bounce/
sway while braking, longer
stopping distance, or uneven
tire wear.
. As part of the multi-point
inspection, trained dealer
technicians can visually inspect
the shocks and struts for signs
of leaking, blown seals,
or damage, and can advise
when service is needed.
Tires
Tires need to be properly inflated,
rotated, and balanced. Maintaining
the tires can save money and fuel,
and can reduce the risk of tire
failure.
. Signs that the tires need to be
replaced include three or more
visible treadwear indicators; cord
or fabric showing through the
rubber; cracks or cuts in the
tread or sidewall; or a bulge or
split in the tire. .
Trained dealer technicians can
inspect and recommend the right
tires. Your dealer can also
provide tire/wheel balancing
services to ensure smooth
vehicle operation at all speeds.
Your dealer sells and services
name brand tires.
Vehicle Care
To help keep the vehicle looking like
new, vehicle care products are
available from your dealer. For
information on how to clean and
protect the vehicle’s interior and
exterior, see Interior Care 0297 and
Exterior Care 0292.
Wheel Alignment
Wheel alignment is critical for
ensuring that the tires deliver
optimal wear and performance.
. Signs that the alignment may
need to be adjusted include
pulling, improper vehicle
handling, or unusual tire wear.
. Your dealer has the required
equipment to ensure proper
wheel alignment.

Buick Verano Owner Manual (GMNA- Localizing-U.S./Canada-10122753) -
2017 - crc - 5/16/16
344 Index
AudioTheft-Deterrent Feature . . . . . . . 140
Audio Players CD . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
Automatic Door Locks . . . . . . . . . . . . . . . . . . . . . 37
Headlamp System . . . . . . . . . . . . 135
Transmission . . . . . . . . . . . . . . . . . 197
Transmission Fluid . . . . . . . . . . . 235
Automatic Transmission Manual Mode . . . . . . . . . . . . . . . . . 199
Shift Lock Control Function
Check . . . . . . . . . . . . . . . . . . . . . . . 245
Auxiliary Devices . . . . . . . . . . . . . . . . . . . . . . . 153
Avoiding Untrusted Media
Devices . . . . . . . . . . . . . . . . . . . . . . . 151
B
Backglass Antenna . . . . . . . . . . . . . 151
BatteryExterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 138
Power Protection . . . . . . . . . . . . . 138
Voltage and Charging Messages . . . . . . . . . . . . . . . . . . . .118
Battery - North America . . . . 244, 286
Blade Replacement, Wiper . . . . . 246 Bluetooth
Overview . . . . . . . . . . . 156, 158, 161
Brake Parking, Electric . . . . . . . . . . . . . . 201
System Warning Light . . . . . . . . 109
Brakes . . . . . . . . . . . . . . . . . . . . . . . . . . 242 Antilock . . . . . . . . . . . . . . . . . . . . . . . 200
Assist . . . . . . . . . . . . . . . . . . . . . . . . . 203
Fluid . . . . . . . . . . . . . . . . . . . . . . . . . . 243
System Messages . . . . . . . . . . . . .119
Braking . . . . . . . . . . . . . . . . . . . . . . . . . 178
Break-In, New Vehicle . . . . . . . . . . 187
Bulb Replacement . . . . . . . . . . . . . . 251
Fog Lamps . . . . . . . . . . . . . . . . . . . 248
Halogen Bulbs . . . . . . . . . . . . . . . . 247
Headlamp Aiming . . . . . . . . . . . . . 247
Headlamps . . . . . . . . . . . . . . . . . . . 247
Headlamps, Front TurnSignal, and Parking
Lamps . . . . . . . . . . . . . . . . . . . . . . 247
License Plate Lamps . . . . . . . . . 250
Taillamps, Turn Signal,
Stoplamps, and Back-up
Lamps . . . . . . . . . . . . . . . . . . . . . . 249
Buying New Tires . . . . . . . . . . . . . . . 273
C
Calibration . . . . . . . . . . . . . . . . . . . . . . 100
California
Fuel Requirements . . . . . . . . . . . 217
Perchlorate MaterialsRequirements . . . . . . . . . . . . . . . 227
California Proposition
65 Warning . . . . . . . . . .227, 244, 286
Camera
Rear Vision (RVC) . . . . . . . . . . . . 208
Canadian Vehicle Owners . . . . . . . . 2
Capacities and Specifications . . . . . . . . . . . . . . . . . 317
Carbon Monoxide Engine Exhaust . . . . . . . . . . . . . . . 196
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Winter Driving . . . . . . . . . . . . . . . . 181
Caution, Danger, and Warning . . . . 2
CD Player . . . . . . . . . . . . . . . . . . . . . . 151
Center Console Storage . . . . . . . . . 95
Chains, Tire . . . . . . . . . . . . . . . . . . . . 277
Charging System Light . . . . . . . . . 107
Check
Ignition Transmission Lock . . . 245
Malfunction IndicatorEngine Light . . . . . . . . . . . . . . . . 107

Buick Verano Owner Manual (GMNA- Localizing-U.S./Canada-10122753) -
2017 - crc - 5/16/16
Index 347
Fuel (cont'd)Filling a Portable Fuel
Container . . . . . . . . . . . . . . . . . . . 219
Filling the Tank . . . . . . . . . . . . . . . 218
Foreign Countries . . . . . . . . . . . . 217
Gauge . . . . . . . . . . . . . . . . . . . . . . . . 104
Low Fuel Warning Light . . . . . . . .113
Requirements, California . . . . . 217
System Messages . . . . . . . . . . . . 121
Fuses Engine Compartment FuseBlock . . . . . . . . . . . . . . . . . . . . . . . . 252
Fuses and Circuit Breakers . . . 252
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 255
Rear Compartment Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 257
G
Garage Door Opener . . . . . . . . . . . 130Programming . . . . . . . . . . . . . . . . . 130
Gauges Engine CoolantTemperature . . . . . . . . . . . . . . . . 105
Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Odometer . . . . . . . . . . . . . . . . . . . . . 104
Speedometer . . . . . . . . . . . . . . . . . 104
Tachometer . . . . . . . . . . . . . . . . . . . 104
Trip Odometer . . . . . . . . . . . . . . . . 104 Gauges (cont'd)
Warning Lights and
Indicators . . . . . . . . . . . . . . . . . . . 102
General Information
Service and Maintenance . . . . . 302
Towing . . . . . . . . . . . . . . . . . . . . . . . . 220
Vehicle Care . . . . . . . . . . . . . . . . . . 227
Glove Box . . . . . . . . . . . . . . . . . . . . . . . 94
GM Mobility Reimbursement Program . . . . . . . . . . . . . . . . . . . . . . . 323
H
Halogen Bulbs . . . . . . . . . . . . . . . . . . 247
Hazard Warning Flashers . . . . . . . 135
Head Restraints . . . . . . . . . . . . . . . . . 50
HeadlampsAiming . . . . . . . . . . . . . . . . . . . . . . . . 247
Automatic . . . . . . . . . . . . . . . . . . . . . 135
Bulb Replacement . . . . . . . . . . . . 247
Daytime RunningLamps (DRL) . . . . . . . . . . . . . . . . 134
Flash-to-Pass . . . . . . . . . . . . . . . . . 134
High-Beam On Light . . . . . . . . . . .114
High/Low Beam Changer . . . . . 134
Lamps On Reminder . . . . . . . . . .114
Heated Steering Wheel . . . . . . . . . . . . . . . . . 99
Heated Front Seats . . . . . . . . . . . . . . 54
Heated Mirrors . . . . . . . . . . . . . . . . . . . 44 Heater
Engine . . . . . . . . . . . . . . . . . . . . . . . . 192
Heating . . . . . . . . . . . . . . . . . . . . . . . . . 171
High-Beam On Light . . . . . . . . . . . . 114
Hill and Mountain Roads . . . . . . . . 181
Hill Start Assist (HSA) . . . . . . . . . . 203
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . 229
Horn . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
How to Wear Safety Belts Properly . . . . . . . . . . . . . . . . . . . . . . . . 58
HVAC . . . . . . . . . . . . . . . . . . . . . . . . . . . 171I
Ignition Positions . . . . . . . . . . 187, 189
Ignition Transmission Lock
Check . . . . . . . . . . . . . . . . . . . . . . . . . 245
Immobilizer . . . . . . . . . . . . . . . . . . . . . . 41
Indicator
Vehicle Ahead . . . . . . . . . . . . . . . . . 111
Infants and Young Children, Restraints . . . . . . . . . . . . . . . . . . . . . . 77
Infotainment . . . . . . . . . . . . . . . . . . . . 139
Infotainment System . . . . . . . . . . . . 332
Instrument Cluster . . . . . . . . . . . . . . 103
Instrument Panel Storage Area . . . . . . . . . . . . . . . . . . . 94
Instrument Panel Overview . . . . . . . 6
Interior Rearview Mirrors . . . . . . . . . 44
Introduction . . . . . . . . . . . . . . . . . . . . . . . 2

Buick Verano Owner Manual (GMNA- Localizing-U.S./Canada-10122753) -
2017 - crc - 5/16/16
348 Index
J
Jump Starting - NorthAmerica . . . . . . . . . . . . . . . . . . . . . . . 286
K
Key and Lock Messages . . . . . . . . 121
Keyless EntryRemote (RKE) System . . . . . . . . . 28
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
L
Labeling, Tire Sidewall . . . . . . . . . . 260
Lamps Courtesy . . . . . . . . . . . . . . . . . . . . . . 137
Daytime Running (DRL) . . . . . . 134
Dome . . . . . . . . . . . . . . . . . . . . . . . . . 137
Exterior Controls . . . . . . . . . . . . . . 133
Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . 138
Front Fog . . . . . . . . . . . . . . . . . . . . . 136
Headlamps, Front Turn Signal, and Parking
Lamps . . . . . . . . . . . . . . . . . . . . . . 247
License Plate . . . . . . . . . . . . . . . . . 250
Malfunction Indicator . . . . . . . . . 107
On Reminder . . . . . . . . . . . . . . . . . .114 Lamps (cont'd)
Reading . . . . . . . . . . . . . . . . . . . . . . 137
Lane Departure Warning (LDW) . . . . . . . . . . . . . . . . 215
Lane Departure Warning Light . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Lap-Shoulder Belt . . . . . . . . . . . . . . . 59
LATCH System Replacing Parts after a
Crash . . . . . . . . . . . . . . . . . . . . . . . . . 88
LATCH, Lower Anchors and Tethers for Children . . . . . . . . . . . . 82
Lighting Entry . . . . . . . . . . . . . . . . . . . . . . . . . 138
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Illumination Control . . . . . . . . . . . 137
Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . 111 Airbag Readiness . . . . . . . . . . . . . 106
Antilock Brake System
(ABS) Warning . . . . . . . . . . . . . . .110
Brake System Warning . . . . . . . 109
Charging System . . . . . . . . . . . . . 107
Cruise Control . . . . . . . . . . . . . . . . .114
Door Ajar . . . . . . . . . . . . . . . . . . . . . .114
Electric Parking Brake . . . . . . . . .110
Engine Oil Pressure . . . . . . . . . . .113
Flash-to-Pass . . . . . . . . . . . . . . . . . 134
Front Fog Lamp . . . . . . . . . . . . . . .114 Lights (cont'd)
High-Beam On . . . . . . . . . . . . . . . . .114
High/Low Beam Changer . . . . . 134
Lane Departure Warning . . . . . . . 111
Low Fuel Warning . . . . . . . . . . . . .113
Safety Belt Reminders . . . . . . . . 105
Security . . . . . . . . . . . . . . . . . . . . . . .113
StabiliTrak
®OFF . . . . . . . . . . . . . . 111
Tire Pressure . . . . . . . . . . . . . . . . . .112
Traction Control System
(TCS)/StabiliTrak
®. . . . . . . . . . .112
Traction Off . . . . . . . . . . . . . . . . . . . . 111
Locks Automatic Door . . . . . . . . . . . . . . . . . 37
Delayed Locking . . . . . . . . . . . . . . . . 37
Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Lockout Protection . . . . . . . . . . . . . . 37
Power Door . . . . . . . . . . . . . . . . . . . . . 37
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Loss of Control . . . . . . . . . . . . . . . . . 179
Low Fuel Warning Light . . . . . . . . . 113
Low-Profile Tires . . . . . . . . . . . . . . . . 260
Lower Anchors and Tethers for Children (LATCH
System) . . . . . . . . . . . . . . . . . . . . . . . . 82
Lumbar Adjustment . . . . . . . . . . . . . . 53 Front Seats . . . . . . . . . . . . . . . . . . . . . 53
