Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
VEHICLE CARE 299
1. Passenger Side EngineCompartment Fuse Block. See
Engine Compartment Fuse Block
0323.
2. Engine Coolant Surge Tank and Pressure Cap. See Cooling System
0 307.
3. Passenger Side Engine Air Cleaner/Filter. See Engine Air
Cleaner/Filter 0304.
4. Engine Oil Fill Cap. See Engine Oil
0 299.
5. Engine Oil Dipstick. See Engine
Oil 0299.
6. Engine Cooling Fan (Out of View). See Cooling System 0307.
7. Driver Side Engine Air Cleaner/ Filter. See Engine Air Cleaner/
Filter 0304.
8. Remote Positive (+) Battery Terminal. See Jump Starting -
North America 0367.
9. Brake Fluid Reservoir. See Brake
Fluid 0315. 10. Windshield Washer Fluid
Reservoir. See Washer Fluid
0 313.
11. Driver Side Engine Compartment Fuse Block. See Engine
Compartment Fuse Block 0323.
12. Remote Negative (-) Battery Terminal. See Jump Starting -
North America 0367.
Engine Oil
To ensure proper engine performance
and long life, careful attention must
be paid to engine oil. Following these
simple, but important steps will help
protect your investment:
.
Use engine oil approved to the
proper specification and of the
proper viscosity grade. See
“Selecting the Right Engine Oil” in
this section.
. Check the engine oil level regularly
and maintain the proper oil level.
See “Checking Engine Oil” and
“When to Add Engine Oil” later in
this section. .
Change the engine oil at the
appropriate time. See Engine Oil
Life System 0302.
. Always dispose of engine oil
properly. See “What to Do with
Used Oil” in this section.
Checking Engine Oil
Check the engine oil level regularly,
every 650 km (400 mi), especially prior
to a long trip. The engine oil dipstick
handle is a loop. See Engine
Compartment Overview 0292 for the
location.
{Warning
The engine oil dipstick handle may
be hot; it could burn you. Use a
towel or glove to touch the dipstick
handle.
If a low oil Driver Information Center
(DIC) message displays, check the oil
level.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
368 VEHICLE CARE
2.0L L4 Engine Shown, 3.0L
V6 Engine, and 3.6L V6 Engine Similar
1. Discharged Remote Battery
Positive Terminal
2. Discharged Remote Battery Negative Ground Terminal
3. Good Battery Negative Terminal
4. Good Battery Positive Terminal
4.2L V8 Engine
1. Discharged Remote Battery
Positive Terminal
2. Discharged Remote Battery Negative Ground Terminal
3. Good Battery Negative Terminal
4. Good Battery Positive Terminal
The jump start remote positive
terminal (1) and the remote negative
ground terminal (2) for the discharged
battery are on the driver side of the
vehicle. The jump start negative terminal (3)
and positive terminal (4) are on the
battery of the vehicle providing the
jump start.
The positive jump start connection for
the discharged battery is under a red
cover. Remove the cover to expose the
terminal.
1. Check the other vehicle. It must have a 12-volt battery with a
negative ground system.
Caution
If the other vehicle does not have a
12-volt system with a negative
ground, both vehicles can be
damaged. Only use a vehicle that
has a 12-volt system with a
negative ground for jump starting.
2. Position the two vehicles so that they are not touching.
3. Set the parking brake and shift to P (Park). See Shifting Into Park
0 206.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
VEHICLE CARE 369
Caution
If any accessories are left on or
plugged in during the jump starting
procedure, they could be damaged.
The repairs would not be covered
by the vehicle warranty. Whenever
possible, turn off or unplug all
accessories on either vehicle when
jump starting.
4. Turn the ignition off. Turn off all lights and accessories in both
vehicles, except the hazard
warning flashers if needed.
{Warning
An electric fan can start up even
when the engine is not running and
can injure you. Keep hands,
clothing, and tools away from any
underhood electric fan.
{Warning
Using a match near a battery can
cause battery gas to explode. People
have been hurt doing this, and
some have been blinded. Use a
flashlight if you need more light.
Battery fluid contains acid that can
burn you. Do not get it on you.
If you accidentally get it in your
eyes or on your skin, flush the place
with water and get medical help
immediately.
{Warning
Fans or other moving engine parts
can injure you badly. Keep your
hands away from moving parts
once the engine is running.
5. Connect one end of the red positive (+) cable to the remote
positive (+) terminal on the
discharged battery. 6. Connect the other end of the red
positive (+) cable to the
positive (+) terminal of the good
battery.
7. Connect one end of the black negative (–) cable to the
negative (–) terminal of the good
battery.
8. Connect the other end of the black negative (–) cable to the
remote negative (–) ground
terminal on the driver side shock
tower for the discharged battery.
9. Start the engine in the vehicle with the good battery and run
the engine at idle speed for at
least four minutes.
10. Try to start the vehicle that had the dead battery. If it will not
start after a few tries, it probably
needs service.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
416 ONSTAR
Security
If equipped, OnStar provides these
services:
.With Stolen Vehicle Assistance,
OnStar Advisors can use GPS to
pinpoint the vehicle and help
authorities quickly recover it.
. With Remote Ignition Block,
if equipped, OnStar can block the
engine from being restarted.
. With Stolen Vehicle Slowdown,
if equipped, OnStar can work with
law enforcement to gradually slow
the vehicle down.
Theft Alarm Notification
If equipped, if the doors are locked
and the vehicle alarm sounds, a
notification by text, e-mail, or phone
call will be sent. If the vehicle is
stolen, an OnStar Advisor can work
with authorities to recover the vehicle.
OnStar Additional
Information
In-Vehicle Audio Messages
Audio messages may play important
information at the following times:
.Prior to vehicle purchase. Press
Q
to set up an account.
. After change in ownership and at
90 days.
Transferring Service
PressQto request account transfer
eligibility information. The Advisor
can cancel or change account
information.
Selling/Transferring the Vehicle
Call 1-888-4ONSTAR (1-888-466-7827)
immediately to terminate your OnStar
or connected services if the vehicle is
disposed of, sold, transferred, or if the
lease ends.
Reactivation for Subsequent
Owners
PressQand follow the prompts to
speak to an Advisor as soon as
possible. The Advisor will update
vehicle records and explain OnStar or
connected service options.
How OnStar Service Works
Automatic Crash Response,
Emergency Services, Crisis Assist,
Stolen Vehicle Assistance, Remote
Services, Roadside Assistance, and
Hands-Free Calling are available on
most vehicles. Not all OnStar services
are available everywhere or on all
vehicles. For more information, a full
description of OnStar services, system
limitations, and OnStar User Terms,
Privacy Statement, and Software
Terms:
. Call 1-888-4ONSTAR
(1-888-466-7827).
. See www.onstar.com (U.S.).
. See www.onstar.ca (Canada).
. Call TTY 1-877-248-2080.
. Press
Qto speak with an Advisor.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
418 ONSTAR
Potential Issues
OnStar cannot perform Remote Door
Unlock or Stolen Vehicle Assistance
after the vehicle has been off
continuously for 10 days without an
ignition cycle. If the vehicle has not
been started for 10 days, OnStar can
contact Roadside Assistance or a
locksmith to help gain access to the
vehicle.
Global Positioning System (GPS)
.Obstruction of the GPS can occur
in a large city with tall buildings;
in parking garages; around
airports; in tunnels and
underpasses; or in an area with
very dense trees. If GPS signals are
not available, the OnStar system
should still operate to call OnStar.
However, OnStar could have
difficulty identifying the exact
location.
. In emergency situations, OnStar
can use the last stored GPS
location to send to emergency
responders. A temporary loss of GPS can cause
loss of the ability to send a
Turn-by-Turn Navigation route. The
Advisor may give a verbal route or
may ask for a call back after the
vehicle is driven into an open area.
Cellular and GPS Antennas
Cellular reception is required for
OnStar to send remote signals to the
vehicle. Do not place items over or
near the antenna to prevent blocking
cellular and GPS signal reception.
Unable to Connect to OnStar
Message
If there is limited cellular coverage or
the cellular network has reached
maximum capacity, this message may
come on. Press
Qto try the call again
or try again after driving a few miles
into another cellular area.
Vehicle and Power Issues
OnStar services require a vehicle
electrical system, wireless service, and
GPS satellite technologies to be
available and operating for features to function properly. These systems may
not operate if the battery is
discharged or disconnected.
Add-on Electrical Equipment
The OnStar system is integrated into
the electrical architecture of the
vehicle. Do not add any electrical
equipment. See
Add-On Electrical
Equipment 0287. Added electrical
equipment may interfere with the
operation of the OnStar system and
cause it to not operate.
Vehicle Software Updates
OnStar or GM may remotely deliver
software updates or changes to the
vehicle without further notice or
consent. These updates or changes
may enhance or maintain safety,
security, or the operation of the
vehicle or the vehicle systems.
Software updates or changes may
affect or erase data or settings that
are stored in the vehicle, such as
OnStar Hands-Free Calling name tags,
saved navigation destinations,
or pre-set radio stations. Neither
OnStar nor GM is responsible for any
affected or erased data or settings.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
424 CONNECTED SERVICES
On some vehicles, Wi-Fi can also be
managed from the Wi-Fi
Hotspot menu.
MyCadillac Mobile App (If Available)
Download the myCadillac mobile app
to compatible Apple and Android
smartphones. Cadillac users can
access the following services from a
smartphone:
.Remotely start/stop the vehicle,
if factory-equipped.
. Lock/unlock doors, if equipped
with automatic locks.
. Activate the horn and lamps.
. Check the vehicle’s fuel level, oil
life, or tire pressure,
if factory-equipped with the Tire
Pressure Monitor System.
. Send destinations to the vehicle.
. Locate the vehicle on a map (U.S.
market only).
. Turn the vehicle's Wi-Fi hotspot
on/off, manage settings, and
monitor data consumption,
if equipped. .
Locate a dealer and schedule
service.
. Request roadside assistance.
. Set a parking reminder with pin
drop, take a photo, make a note,
and set a timer.
. Connect with Cadillac on social
media.
Features are subject to change. For
myCadillac mobile app information
and compatibility, see my.cadillac.com.
An active OnStar or connected service
plan may be required. A compatible
device, factory-installed remote start,
and power locks are required. Data
rates apply. See www.onstar.com for
details and system limitations.
Remote Services
Contact an OnStar Advisor to unlock
the doors or sound the horn and flash
the lamps.
Marketplace
OnStar Advisors can provide offers
from restaurants and retailers on your
route, help locate hotels, or book a
room. These services vary by market.
OnStar Hands-Free Calling
Make and receive calls with the
built-in wireless calling service, which
requires available minutes.
Functionality of the Voice Command
button may vary by vehicle and
region. For some vehicles, press
=to
open the OnStar app on the
infotainment display, then select
Hands-Free calling. For other vehicles
press
=as follows.
Make a Call
1. Press
=. System responds:
“OnStar ready.”
2. Say “Call.”System responds: “Call.
Please say the name or number
to call.”
3. Say the entire number without pausing, including a “1”and the
area code. System responds: “OK,
calling.”
Calling 911 Emergency
1. Press=. System responds:
“OnStar ready.”

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
INDEX 431
Infotainment System . . . . . . . . . . . . . . . 413
Instrument Cluster . . . . . . . . . . . .127, 130
Instrument PanelStorage Area . . . . . . . . . . . . . . . . . . . . . . 114
Instrument Panel Overview . . . . . . . . . . . 6
Interior Rearview Mirrors . . . . . . . . . . . 54
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
J
Jump Starting - North America . . . . 367
K
Keyless Entry Remote (RKE) System . . . . . . . . . . . . . . 29
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
L
Labeling, Tire Sidewall . . . . . . . . . . . . . 341
Lamps Cornering . . . . . . . . . . . . . . . . . . . . . . . . . . 170
Courtesy . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Daytime Running (DRL) . . . . . . . . . . 168
Dome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Exterior Controls . . . . . . . . . . . . . . . . . . 166
Exterior Lamps Off Reminder . . . . 168
Exterior Lighting BatterySaver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
Malfunction Indicator (Check
Engine) . . . . . . . . . . . . . . . . . . . . . . . . . . 139 Lamps (cont'd)
On Reminder . . . . . . . . . . . . . . . . . . . . . . 149
Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Lane Change Alert (LCA) . . . . . . . . . . . 271
Lane Departure
Warning (LDW) . . . . . . . . . . . . . . . . . . . 272
Lane Keep Assist (LKA) . . . . . . . . . . . . 273
Lane Keep Assist Light . . . . . . . . . . . . . 144
Lap-Shoulder Belt . . . . . . . . . . . . . . . . . . . . 79
LATCH System Replacing Parts after a Crash . . . . 108
LATCH, Lower Anchors and Tethers for Children . . . . . . . . . . . . . . 102
LED Lighting . . . . . . . . . . . . . . . . . . . . . . . . 321
Lighter, Cigarette . . . . . . . . . . . . . . . . . . . 125
Lighting
Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
Illumination Control . . . . . . . . . . . . . . 170
LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 321
Lights Airbag Readiness . . . . . . . . . . . . . . . . . 138
Antilock Brake System (ABS)Warning . . . . . . . . . . . . . . . . . . . . . . . . . 143
Automatic Vehicle Hold . . . . . . . . . . 144
Brake System Warning . . . . . . 141, 142
Charging System . . . . . . . . . . . . . . . . . . 139 Lights (cont'd)
Check Engine (Malfunction
Indicator) . . . . . . . . . . . . . . . . . . . . . . . . 139
Cruise Control . . . . . . . . . . . . . . . . . . . . . 149
Door Ajar . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Driver Mode Control . . . . . . . . . . . . . . 146
Electric Parking Brake . . . . . . . . . . . . 143
Engine Coolant Temperature Warning . . . . . . . . . . . . . . . . . . . . . . . . . 146
Engine Oil Pressure . . . . . . . . . . . . . . . 147
Flash-to-Pass . . . . . . . . . . . . . . . . . . . . . . 168
Gear Shifting . . . . . . . . . . . . . . . . . . . . . . 144
High-Beam On . . . . . . . . . . . . . . . . . . . . 148
High/Low Beam Changer . . . . . . . . . 168
Lane Keep Assist . . . . . . . . . . . . . . . . . . 144
Low Fuel Warning . . . . . . . . . . . . . . . . 148
Seat Belt Reminders . . . . . . . . . . . . . . 137
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Service Electric Parking Brake . . . 143
StabiliTrak OFF . . . . . . . . . . . . . . . . . . . 145
Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 147
Traction Control System (TCS)/StabiliTrak . . . . . . . . . . . . . . . . 146
Traction Off . . . . . . . . . . . . . . . . . . . . . . . 145
Locking Rear Axle . . . . . . . . . . . . . . . . . . 226
Locks Automatic Door . . . . . . . . . . . . . . . . . . . . . 40
Delayed Locking . . . . . . . . . . . . . . . . . . . . 40

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
INDEX 433
Parking or BackingAssistance Systems . . . . . . . . . . . . . . . 253
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Passenger Compartment Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
Passenger Sensing System . . . . . . . . . . 90
Pedestrian Ahead Indicator . . . . . . . . 145
Perchlorate Materials
Requirements, California . . . . . . . . . 290
Personalization
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Power Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Protection, Battery . . . . . . . . . . . . . . . . 173
Retained Accessory (RAP) . . . . . . . . 206
Seat Adjustment . . . . . . . . . . . . . . . . . . . . 65
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Pregnancy, Using Seat Belts . . . . . . . . . 82
Privacy
Vehicle Data Recording . . . . . . . . . . 412
Program Courtesy Transportation . . . . . . . . . 407
Prohibited Fuels . . . . . . . . . . . . . . . . . . . . 277 Proposition
65 Warning,
California . . . . . . . . . . . . . . .289, 316, 367,
Back Cover
Publication Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . 410
R
Radio Frequency Statement . . . . . . . . 411
Reading Lamps . . . . . . . . . . . . . . . . . . . . . 171
Rear AxleLocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226
Rear Camera Mirror . . . . . . . . . . . . . . . . . 54
Rear Pedestrian Alert . . . . . . . . . . . . . . . 260
Rear Seat Pass-Through Door . . . . . . . 75
Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72 Heated and Ventilated . . . . . . . . . . . . . 74
Rear Storage . . . . . . . . . . . . . . . . . . . . . . . . 116
Rear Vision Camera (RVC) . . . . . . . . . 253
Rear Window Sunshade . . . . . . . . . . . . . 59
Rearview Mirrors Automatic Dimming . . . . . . . . . . . . . . . . 54
Reclining Seatbacks . . . . . . . . . . . . . . . . . 67
Recommended Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 277
Recommended Fluids and
Lubricants . . . . . . . . . . . . . . . . . . . . . . . . . 392 Recorder
Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274
Records Maintenance . . . . . . . . . . . . . . . . . . . . . . 395
Recreational Vehicle Towing . . . . . . . 372
Reimbursement Program, GM Mobility . . . . . . . . . . . . . . . . . . . . . . . . . . . . 404
Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Remote Vehicle Start . . . . . . . . . . . . . . . . 36
Replacement Parts Airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Maintenance . . . . . . . . . . . . . . . . . . . . . . 393
Replacing Airbag System . . . . . . . . . . . . 95
Replacing LATCH System Parts after a Crash . . . . . . . . . . . . . . . . . . . . . . . 108
Replacing Seat Belt System Parts after a Crash . . . . . . . . . . . . . . . . . 83
Reporting Safety Defects Canadian Government . . . . . . . . . . . . 411
General Motors . . . . . . . . . . . . . . . . . . . 412
U.S. Government . . . . . . . . . . . . . . . . . . 411
Restraints Where to Put . . . . . . . . . . . . . . . . . . . . . . 101
Retained Accessory
Power (RAP) . . . . . . . . . . . . . . . . . . . . . . . 206
Reverse Tilt Mirrors . . . . . . . . . . . . . . . . . 53

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
434 INDEX
RoadsDriving, Wet . . . . . . . . . . . . . . . . . . . . . . . 193
Roadside Service . . . . . . . . . . . . . . . . . . . . 405
Roof Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Rotation, Tires . . . . . . . . . . . . . . . . . . . . . . 353
Routing, Engine Drive Belt . . . . . . . . . 399
Running the Vehicle While Parked . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 210
S
Safety Defects ReportingCanadian Government . . . . . . . . . . . . 411
General Motors . . . . . . . . . . . . . . . . . . . 412
U.S. Government . . . . . . . . . . . . . . . . . . 411
Safety Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Safety System Check . . . . . . . . . . . . . . . . 82
Scheduling Appointments . . . . . . . . . . 407
Seat Belts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76 Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Extender . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
How to Wear Seat BeltsProperly . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Lap-Shoulder Belt . . . . . . . . . . . . . . . . . . . 79
Reminders . . . . . . . . . . . . . . . . . . . . . . . . . 137
Replacing after a Crash . . . . . . . . . . . . . 83
Use During Pregnancy . . . . . . . . . . . . . . 82 Seats
Head Restraints . . . . . . . . . . . . . . . . . . . . . 63
Heated and Ventilated Front . . . . . . . 70
Heated and Ventilated, Rear . . . . . . . 74
Lumbar Adjustment, Front . . . . . . . . . 65
Lumbar Adjustment, Rear . . . . . . . . . . 74
Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Power Adjustment, Front . . . . . . . . . . 65
Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Reclining Seatbacks . . . . . . . . . . . . . . . . 67
Securing Child Restraints . . . . .108, 111
Security
Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
OnStar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 416
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Vehicle Alarm . . . . . . . . . . . . . . . . . . . . . . . 49
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187 Accessories andModifications . . . . . . . . . . . . . . . . . . . . 290
Doing Your Own Work . . . . . . . . . . . 290
Maintenance Records . . . . . . . . . . . . 395
Maintenance, General Information . . . . . . . . . . . . . . . . . . . . . . 381
Parts Identification Label . . . . . . . . 396
Scheduling Appointments . . . . . . . . 407
Service Electric Parking Brake Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143 Services
Special Application . . . . . . . . . . . . . . . 388
Servicing the Airbag . . . . . . . . . . . . . . . . . 94
Shifting Into Park . . . . . . . . . . . . . . . . . . . . . . . . . . 206
Out of Park . . . . . . . . . . . . . . . . . . . . . . . . 207
Side Blind Zone Alert (SBZA) . . . . . . 270
Signals, Turn and Lane-Change . . . . 170
Spare Tire
Compact . . . . . . . . . . . . . . . . . . . . . . . . . . . 366
Special Application Services . . . . . . . 388
Specifications and Capacities . . . . . . 397
Speedometer . . . . . . . . . . . . . . . . . . . . . . . . 133
StabiliTrak
OFF Light . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Start Assist, Hill . . . . . . . . . . . . . . . . . . . . 219
Start Vehicle, Remote . . . . . . . . . . . . . . . 36
Starter Switch Check . . . . . . . . . . . . . . . 318
Starting the Engine . . . . . . . . . . . . . . . . . 202
Steering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191 Heated Wheel . . . . . . . . . . . . . . . . . . . . . 119
Wheel Adjustment . . . . . . . . . . . . . . . . 119
Wheel Controls . . . . . . . . . . . . . . . . . . . 119
Stop/Start System . . . . . . . . . . . . . . . . . . 203
Storage Rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
Storage Areas Armrest . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
436 INDEX
Trip Odometer . . . . . . . . . . . . . . . . . . . . . . 133
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Turn and Lane-Change Signals . . . . 170
U
Uniform Tire Quality Grading . . . . . . 357
Universal Remote System . . . . . . . . . . 162Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Programming . . . . . . . . . . . . . . . . . . . . . . 162
Using This Manual . . . . . . . . . . . . . . . . . . . . 2
V
Vehicle Alarm System . . . . . . . . . . . . . . . . . . . . . . . 49
Automatic Hold Light . . . . . . . . . . . . 144
Canadian Owners . . . . . . . . . . . . . . . . . . . . 2
Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
Identification Number (VIN) . . . . . 396
Load Limits . . . . . . . . . . . . . . . . . . . . . . . 197
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Personalization . . . . . . . . . . . . . . . . . . . 157
Remote Start . . . . . . . . . . . . . . . . . . . . . . . . 36
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Speed Messages . . . . . . . . . . . . . . . . . . . 156
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 370
Vehicle Ahead Indicator . . . . . . . . . . . . 144 Vehicle Care
Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 346
Vehicle Data Recording and Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 412
Vehicle Hold Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 220
Vehicle Hold (AVH)
Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 220
Ventilation, Air . . . . . . . . . . . . . . . . . . . . . 187
Video Recorder . . . . . . . . . . . . . . . . . . . . . . 274
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Voltmeter Gauge . . . . . . . . . . . . . . . . . . . . 136
W
Warning Brake System Light . . . . . . . . . . 141, 142
Caution and Danger . . . . . . . . . . . . . . . . . 2
Lane Departure (LDW) . . . . . . . . . . . 272
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Warnings
Hazard Flashers . . . . . . . . . . . . . . . . . . . 169
Washer Fluid . . . . . . . . . . . . . . . . . . . . . . . . 313
Wheels Alignment and Tire Balance . . . . . 358
Different Size . . . . . . . . . . . . . . . . . . . . . . 356
Replacement . . . . . . . . . . . . . . . . . . . . . . 358
When It Is Time for New Tires . . . . 354 Where to Put the Restraint . . . . . . . . 101
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Windshield Replacement . . . . . . . . . . . . . . . . . . . . . . 319
Wiper/Washer . . . . . . . . . . . . . . . . . . . . . 120
Winter
Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Winter Tires . . . . . . . . . . . . . . . . . . . . . . . . . 340
Wiper Blade Replacement . . . . . . . . . . 319
Wireless Charging . . . . . . . . . . . . . . . . . . 123
