Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
VEHICLE CARE 377
Use cleaners specifically designed for
the surfaces being cleaned to prevent
permanent damage. Apply all cleaners
directly to the cleaning cloth. Do not
spray cleaners on any switches or
controls. Remove cleaners quickly.
Before using cleaners, read and follow
all safety instructions on the label.
While cleaning the interior, open the
doors and windows to get proper
ventilation.
To prevent damage, do not clean the
interior using the following cleaners
or techniques:
.Never use a razor or any other
sharp object to remove soil from
any interior surface.
. Never use a brush with stiff
bristles.
. Never rub any surface aggressively
or with too much pressure.
. Do not use laundry detergents or
dishwashing soaps with
degreasers. For liquid cleaners, use
approximately 20 drops per 3.8 L
(1 gal) of water. A concentrated
soap solution will create streaks and attract dirt. Do not use
solutions that contain strong or
caustic soap.
. Do not heavily saturate the
upholstery when cleaning.
. Do not use solvents or cleaners
containing solvents.
Interior Glass
To clean, use a terry cloth fabric
dampened with water. Wipe droplets
left behind with a clean dry cloth.
If necessary, use a commercial glass
cleaner after cleaning with plain water.
Caution
To prevent scratching, never use
abrasive cleaners on automotive
glass. Abrasive cleaners or
aggressive cleaning may damage
the rear window defogger.
Cleaning the windshield with water
during the first three to six months of
ownership will reduce tendency to fog.
Speaker Covers
Vacuum around a speaker cover
gently, so that the speaker will not be
damaged. Clean spots with water and
mild soap.
Coated Moldings
Coated moldings should be cleaned.
. When lightly soiled, wipe with a
sponge or soft, lint-free cloth
dampened with water.
. When heavily soiled, use warm
soapy water.
Fabric/Carpet/Suede
Start by vacuuming the surface using
a soft brush attachment. If a rotating
vacuum brush attachment is being
used, only use it on the floor carpet.
Before cleaning, gently remove as
much of the soil as possible:
.Gently blot liquids with a paper
towel. Continue blotting until no
more soil can be removed.
. For solid soils, remove as much as
possible prior to vacuuming.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
378 VEHICLE CARE
To clean:1. Saturate a clean, lint-free colorfast cloth with water.
Microfiber cloth is recommended
to prevent lint transfer to the
fabric or carpet.
2. Remove excess moisture by gently wringing until water does
not drip from the cleaning cloth.
3. Start on the outside edge of the soil and gently rub toward the
center. Fold the cleaning cloth to
a clean area frequently to
prevent forcing the soil in to the
fabric.
4. Continue gently rubbing the soiled area until there is no
longer any color transfer from
the soil to the cleaning cloth.
5. If the soil is not completely removed, use a mild soap
solution followed only by plain
water.
If the soil is not completely removed,
it may be necessary to use a
commercial upholstery cleaner or spot
lifter. Test a small hidden area for colorfastness before using a
commercial upholstery cleaner or spot
lifter. If ring formation occurs, clean
the entire fabric or carpet.
After cleaning, use a paper towel to
blot excess moisture.
Cleaning High Gloss Surfaces
and Vehicle Information and
Radio Displays
Use a microfiber cloth on high gloss
surfaces or vehicle displays. First, use
a soft bristle brush to remove dirt that
can scratch the surface. Then gently
clean by rubbing with a microfiber
cloth. Never use window cleaners or
solvents. Periodically hand wash the
microfiber cloth separately, using mild
soap. Do not use bleach or fabric
softener. Rinse thoroughly and air dry
before next use.
Caution
Do not attach a device with a
suction cup to the display. This may
cause damage and would not be
covered by the vehicle warranty.
Instrument Panel, Leather, Vinyl,
Other Plastic Surfaces, Low
Gloss Paint Surfaces, and
Natural Open Pore Wood
Surfaces
Use a soft microfiber cloth dampened
with water to remove dust and loose
dirt. For a more thorough cleaning,
use a soft microfiber cloth dampened
with a mild soap solution.
Caution
Soaking or saturating leather,
especially perforated leather, as well
as other interior surfaces, may
cause permanent damage. Wipe
excess moisture from these surfaces
after cleaning and allow them to
dry naturally. Never use heat,
steam, or spot removers. Do not use
cleaners that contain silicone or
wax-based products. Cleaners
containing these solvents can
permanently change the appearance
and feel of leather or soft trim, and
are not recommended.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
386 SERVICE AND MAINTENANCE
Footnotes—Maintenance Schedule
Additional Required Services -
Normal
(1) Vehicles with different size front
and rear tires do not have tire
rotation. See Tire Rotation0353.
(2) Or every two years, whichever
comes first. More frequent passenger
compartment air filter replacement
may be needed if driving in areas with
heavy traffic, poor air quality, high
dust levels, or environmental
allergens. Passenger compartment air
filter replacement may also be needed
if there is reduced airf low, window
fogging, or odors. Your GM dealer can
help determine when to replace the
filter. (3)
Visually check all fuel and vapor
lines and hoses for proper attachment,
connection, routing, and condition.
(4) Or every three years, whichever
comes first. If driving in dusty
conditions, inspect the filter at each
oil change or more often as needed.
(5) Or every four years, whichever
comes first. If driving in dusty
conditions, inspect the filter at each
oil change or more often as needed.
(6) Or every five years, whichever
comes first. See Cooling System0307.
(7) Do not directly power wash the
transfer case and/or front/rear axle
output seals. High pressure water can
overcome the seals and contaminate
the transfer case fluid. Contaminated
fluid will decrease the life of the
transfer case and/or axles and should
be replaced. (8)
Or every 10 years, whichever
comes first. Inspect for fraying,
excessive cracking, or damage; replace,
if needed.
(9) Replace brake fluid every five
years for DOT 3 fluid or every three
years for DOT 4 fluid. See Brake Fluid
0 315.
(10) Or every 12 months, whichever
comes first. See Wiper Blade
Replacement 0319.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
388 SERVICE AND MAINTENANCE
Footnotes—Maintenance Schedule
Additional Required Services -
Severe
(1) Vehicles with different size front
and rear tires do not have tire
rotation. See Tire Rotation0353.
(2) Or every two years, whichever
comes first. More frequent passenger
compartment air filter replacement
may be needed if driving in areas with
heavy traffic, poor air quality, high
dust levels, or environmental
allergens. Passenger compartment air
filter replacement may also be needed
if there is reduced airf low, window
fogging, or odors. Your GM dealer can
help determine when to replace the
filter.
(3) Visually check all fuel and vapor
lines and hoses for proper attachment,
connection, routing, and condition.
(4) Or every three years, whichever
comes first. If driving in dusty
conditions, inspect the filter at each
oil change or more often as needed. (5)
Or every four years, whichever
comes first. If driving in dusty
conditions, inspect the filter at each
oil change or more often as needed.
(6) Do not directly power wash the
transfer case and/or front/rear axle
output seals. High pressure water can
overcome the seals and contaminate
the transfer case fluid. Contaminated
fluid will decrease the life of the
transfer case and/or axles and should
be replaced.
(7) Or every five years, whichever
comes first. See Cooling System0307.
(8) Or every 10 years, whichever
comes first. Inspect for fraying,
excessive cracking, or damage; replace,
if needed.
(9) Replace brake fluid every five
years for DOT 3 fluid or every three
years for DOT 4 fluid. See Brake Fluid
0 315.
(10) Or every 12 months, whichever
comes first. See Wiper Blade
Replacement 0319.Special Application
Services
.
Severe Commercial Use Vehicles
Only: Lubricate chassis
components every oil change.
. Have underbody flushing service
performed. See "Underbody
Maintenance" in Exterior Care
0 372.

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
INDEX 433
Parking or BackingAssistance Systems . . . . . . . . . . . . . . . 253
Passenger Airbag Status Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Passenger Compartment Air Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
Passenger Sensing System . . . . . . . . . . 90
Pedestrian Ahead Indicator . . . . . . . . 145
Perchlorate Materials
Requirements, California . . . . . . . . . 290
Personalization
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
Power Door Locks . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Mirrors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Outlets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Protection, Battery . . . . . . . . . . . . . . . . 173
Retained Accessory (RAP) . . . . . . . . 206
Seat Adjustment . . . . . . . . . . . . . . . . . . . . 65
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Pregnancy, Using Seat Belts . . . . . . . . . 82
Privacy
Vehicle Data Recording . . . . . . . . . . 412
Program Courtesy Transportation . . . . . . . . . 407
Prohibited Fuels . . . . . . . . . . . . . . . . . . . . 277 Proposition
65 Warning,
California . . . . . . . . . . . . . . .289, 316, 367,
Back Cover
Publication Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . 410
R
Radio Frequency Statement . . . . . . . . 411
Reading Lamps . . . . . . . . . . . . . . . . . . . . . 171
Rear AxleLocking . . . . . . . . . . . . . . . . . . . . . . . . . . . . 226
Rear Camera Mirror . . . . . . . . . . . . . . . . . 54
Rear Pedestrian Alert . . . . . . . . . . . . . . . 260
Rear Seat Pass-Through Door . . . . . . . 75
Rear Seats . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72 Heated and Ventilated . . . . . . . . . . . . . 74
Rear Storage . . . . . . . . . . . . . . . . . . . . . . . . 116
Rear Vision Camera (RVC) . . . . . . . . . 253
Rear Window Sunshade . . . . . . . . . . . . . 59
Rearview Mirrors Automatic Dimming . . . . . . . . . . . . . . . . 54
Reclining Seatbacks . . . . . . . . . . . . . . . . . 67
Recommended Fuel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 277
Recommended Fluids and
Lubricants . . . . . . . . . . . . . . . . . . . . . . . . . 392 Recorder
Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274
Records Maintenance . . . . . . . . . . . . . . . . . . . . . . 395
Recreational Vehicle Towing . . . . . . . 372
Reimbursement Program, GM Mobility . . . . . . . . . . . . . . . . . . . . . . . . . . . . 404
Remote Keyless Entry (RKE) System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Remote Vehicle Start . . . . . . . . . . . . . . . . 36
Replacement Parts Airbags . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Maintenance . . . . . . . . . . . . . . . . . . . . . . 393
Replacing Airbag System . . . . . . . . . . . . 95
Replacing LATCH System Parts after a Crash . . . . . . . . . . . . . . . . . . . . . . . 108
Replacing Seat Belt System Parts after a Crash . . . . . . . . . . . . . . . . . 83
Reporting Safety Defects Canadian Government . . . . . . . . . . . . 411
General Motors . . . . . . . . . . . . . . . . . . . 412
U.S. Government . . . . . . . . . . . . . . . . . . 411
Restraints Where to Put . . . . . . . . . . . . . . . . . . . . . . 101
Retained Accessory
Power (RAP) . . . . . . . . . . . . . . . . . . . . . . . 206
Reverse Tilt Mirrors . . . . . . . . . . . . . . . . . 53

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
INDEX 435
Storage Areas (cont'd)Center Console . . . . . . . . . . . . . . . . . . . . 116
Convenience Net . . . . . . . . . . . . . . . . . . 117
Glove Box . . . . . . . . . . . . . . . . . . . . . . . . . 114
Instrument Panel . . . . . . . . . . . . . . . . . 114
Storage Compartments . . . . . . . . . . . . . 114
Struts Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 320
Stuck Vehicle . . . . . . . . . . . . . . . . . . . . . . . 196
Summer Tires . . . . . . . . . . . . . . . . . . . . . . . 340
Sun Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Sunroof . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Sunshade Rear Window . . . . . . . . . . . . . . . . . . . . . . . . 59
Super Cruise . . . . . . . . . . . . . . . . . . . . . . . . 237
Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Brake Pad Life . . . . . . . . . . . . . . . . . . . . . 315
Engine Air Filter Life . . . . . . . . . . . . . 304
Forward Collision Alert (FCA) . . . . 262
Infotainment . . . . . . . . . . . . . . . . . 174, 413
Night Vision . . . . . . . . . . . . . . . . . . . . . . . 268
Systems
Driver Assistance . . . . . . . . . . . . . . . . . 252T
Tachometer . . . . . . . . . . . . . . . . . . . . . . . . . 133
Text Telephone (TTY) Users . . . . . . . 403
Theft-Deterrent Systems . . . . . . . . . . . . 51Immobilizer . . . . . . . . . . . . . . . . . . . . . . . . . 51
Thigh Support Adjustment . . . . . . . . . . 66
Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 339 All-Season . . . . . . . . . . . . . . . . . . . . . . . . . 340
Buying New Tires . . . . . . . . . . . . . . . . . 355
Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 359
Changing . . . . . . . . . . . . . . . . . . . . . . . . . . 361
Compact Spare . . . . . . . . . . . . . . . . . . . . 366
Designations . . . . . . . . . . . . . . . . . . . . . . 343
Different Size . . . . . . . . . . . . . . . . . . . . . . 356
If a Tire Goes Flat . . . . . . . . . . . . . . . . 359
Inspection . . . . . . . . . . . . . . . . . . . . . . . . . 353
Low Profile . . . . . . . . . . . . . . . . . . . . . . . . 340
Pressure . . . . . . . . . . . . . . . . . . . . . . 346, 347
Pressure Light . . . . . . . . . . . . . . . . . . . . . 147
Pressure Monitor Operation . . . . . . 349
Pressure Monitor System . . . . . . . . 348
Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . 353
Sidewall Labeling . . . . . . . . . . . . . . . . . 341
Terminology and Definitions . . . . 344
Uniform Tire Quality Grading . . . . 357
Wheel Alignment and TireBalance . . . . . . . . . . . . . . . . . . . . . . . . . . 358 Tires (cont'd)
Wheel Replacement . . . . . . . . . . . . . . 358
When It Is Time for New
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 354
Winter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 340
Top Tier Fuel . . . . . . . . . . . . . . . . . . . . . . . . 276
Towing Driving Characteristics . . . . . . . . . . . 281
Equipment . . . . . . . . . . . . . . . . . . . . . . . . 286
General Information . . . . . . . . . . . . . . 280
Recreational Vehicle . . . . . . . . . . . . . . 372
Trailer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284
Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 370
Track Events and Competitive
Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
Traction Control System(TCS)/StabiliTrak Light . . . . . . . . . 146
Off Light . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Traction Control/Electronic Stability Control . . . . . . . . . . . . . . . . . . . 220
Trailer Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284
Transmission Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 210
Fluid, Automatic . . . . . . . . . . . . . . . . . . 303
Transportation Program, Courtesy . . . . . . . . . . . . . . . . . . . . . . . . . . . 407

Cadillac CT6 Owner Manual (GMNA-Localizing-U.S./Canada-12533370) -
2019 - crc - 1/23/19
436 INDEX
Trip Odometer . . . . . . . . . . . . . . . . . . . . . . 133
Trunk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Turn and Lane-Change Signals . . . . 170
U
Uniform Tire Quality Grading . . . . . . 357
Universal Remote System . . . . . . . . . . 162Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Programming . . . . . . . . . . . . . . . . . . . . . . 162
Using This Manual . . . . . . . . . . . . . . . . . . . . 2
V
Vehicle Alarm System . . . . . . . . . . . . . . . . . . . . . . . 49
Automatic Hold Light . . . . . . . . . . . . 144
Canadian Owners . . . . . . . . . . . . . . . . . . . . 2
Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191
Identification Number (VIN) . . . . . 396
Load Limits . . . . . . . . . . . . . . . . . . . . . . . 197
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Personalization . . . . . . . . . . . . . . . . . . . 157
Remote Start . . . . . . . . . . . . . . . . . . . . . . . . 36
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Speed Messages . . . . . . . . . . . . . . . . . . . 156
Towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . 370
Vehicle Ahead Indicator . . . . . . . . . . . . 144 Vehicle Care
Tire Pressure . . . . . . . . . . . . . . . . . . . . . . 346
Vehicle Data Recording and Privacy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 412
Vehicle Hold Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 220
Vehicle Hold (AVH)
Automatic . . . . . . . . . . . . . . . . . . . . . . . . . 220
Ventilation, Air . . . . . . . . . . . . . . . . . . . . . 187
Video Recorder . . . . . . . . . . . . . . . . . . . . . . 274
Visors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Voltmeter Gauge . . . . . . . . . . . . . . . . . . . . 136
W
Warning Brake System Light . . . . . . . . . . 141, 142
Caution and Danger . . . . . . . . . . . . . . . . . 2
Lane Departure (LDW) . . . . . . . . . . . 272
Warning Lights, Gauges, and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 126
Warnings
Hazard Flashers . . . . . . . . . . . . . . . . . . . 169
Washer Fluid . . . . . . . . . . . . . . . . . . . . . . . . 313
Wheels Alignment and Tire Balance . . . . . 358
Different Size . . . . . . . . . . . . . . . . . . . . . . 356
Replacement . . . . . . . . . . . . . . . . . . . . . . 358
When It Is Time for New Tires . . . . 354 Where to Put the Restraint . . . . . . . . 101
Windows . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Windshield Replacement . . . . . . . . . . . . . . . . . . . . . . 319
Wiper/Washer . . . . . . . . . . . . . . . . . . . . . 120
Winter
Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
Winter Tires . . . . . . . . . . . . . . . . . . . . . . . . . 340
Wiper Blade Replacement . . . . . . . . . . 319
Wireless Charging . . . . . . . . . . . . . . . . . . 123
