language CADILLAC CTS 2007 1.G Owners Manual

GENERAL MOTORS, GM, the GM Emblem,
CADILLAC, the CADILLAC Crest & Wreath, and
the name CTS are registered trademarks and
the name CTS-V is a trademark of General Motors
Corporation.
This manual includes the latest information at
the time it was printed. We reserve the right
to make changes after that time without notice.
For vehicles rst sold in Canada, substitute
the name “General Motors of Canada Limited” for
Cadillac Motor Car Division whenever it appears
in this manual.This manual describes features that may be
available in this model, but your vehicle may not
have all of them. For example, more than one
entertainment system may be offered or your
vehicle may have been ordered without a front
passenger or rear seats.
Keep this manual in the vehicle, so it will be there
if it is needed while you are on the road. If the
vehicle is sold, leave this manual in the vehicle.
Canadian Owners
A French language copy of this manual can be
obtained from your dealer/retailer or from:
Helm, Incorporated
P.O. Box 07130
Detroit, MI 48207
Litho in U.S.A.
Part No. 15864562 B Second Printing
©2006 General Motors Corporation. All Rights Reserved.
3

8(Clock):Use this menu item to set the time on
the clock.
SeeSetting the Time on page 259for more
information.
8/4(Clock/Information Display):Use this
menu item to toggle between the clock display and
the XM™ Information (Song, Artist, Album), if
available.
SeeSetting the Time on page 259and “XM™
Satellite Radio Service” underRadio with CD on
page 260for more information.
SETUP:When you select this menu item, the
following submenu is available:
LANGUAGE
PERSONALIZATION
CONFIGURE DISPLAY KEYS
CONFIGURE SWC (Steering Wheel
Control) KEYS
To change the language displayed on the radio,
select LANGUAGE by pressing the TUNE/SEL
knob. Turn the TUNE/SEL knob to scroll through
the available languages and press the knob tomake your selection. If you accidentally select a
language that you did not want, ENGLISH is
always at the top of the language list.
For more information on the other items in the
SETUP menu, seeDIC Vehicle Personalization on
page 242andRecongurable Steering Wheel
Controls (SWC) (CTS) on page 169.
DIC Warnings and Messages
These messages will appear if there is a problem
detected in one of your vehicle’s systems.
You must acknowledge a message to clear it from
the screen for further use. To clear a message,
press the CLR button.
Be sure to take any message that appears on the
screen seriously and remember that clearing
the message will only make the message
disappear, not the problem.
Battery Not Charging
When this message appears on the display, there
is a problem with the generator and battery
charging systems. Have the electrical system
checked by your dealer as soon as possible.
232

XM Radio Messages
Radio Display Message Condition Action Required
XL (Explicit Language
Channels)XL on the radio display,
after the channel name,
indicates content with
explicit language.These channels, or any others, can be blocked at a
customer’s request, by calling 1-800-852-XMXM (9696).
Updating Updating encryption code The encryption code in the receiver is being updated, and no
action is required. This process should take no longer than
30 seconds.
No Signl Loss of signal The system is functioning correctly, but the vehicle is in a
location that is blocking the XM™ signal. When the vehicle is
moved into an open area, the signal should return.
Loading Acquiring channel audio
(after 4 second delay)The audio system is acquiring and processing audio and text
data. No action is needed. This message should disappear
shortly.
Off Air Channel not in service This channel is not currently in service. Tune in to another
channel.
CH Unavl Channel no longer
availableThis previously assigned channel is no longer assigned.
Tune to another station. If this station was one of the presets,
choose another station for that preset button.
No Info Artist Name/Feature not
availableNo artist information is available at this time on this channel.
The system is working properly.
277
