Automatic Transmission Fluid
How to Check Automatic Transmission
Fluid
It is not necessary to check the transmission uid level.
A transmission uid leak is the only reason for uid loss.
If a leak occurs, take the vehicle to the dealer/retailer
service department and have it repaired as soon as
possible.
There is a special procedure for checking and changing
the transmission uid. Because this procedure is
difficult, it should be done at the dealer/retailer service
department. Contact your dealer/retailer for additional
information or the procedure can be found in the service
manual. To purchase a service manual, seeService
Publications Ordering Information on page 7-15.Notice:Use of the incorrect automatic transmission
uid may damage the vehicle, and the damages
may not be covered by the vehicle’s warranty.
Always use the automatic transmission uid listed in
Recommended Fluids and Lubricants on page 6-14.
Change the uid and lter at the intervals listed in
Additional Required Services on page 6-6, and be sure
to use the uid listed inRecommended Fluids and
Lubricants on page 6-14.
Manual Transmission Fluid
It is not necessary to check the manual transmission uid
level. A transmission uid leak is the only reason for uid
loss. If a leak occurs, take the vehicle to a dealer/retailer
for service. Have it repaired as soon as possible. You
may also have the uid level checked by your dealer/
retailer when the oil is changed. SeeRecommended
Fluids and Lubricants on page 6-14for the proper uid
to use.
5-29

ApplicationCapacities
English Metric
Transmission Fluid
6-Speed Automatic CTS 6.7 qt 6.3 L
6-Speed Automatic CTS-V 6.7 qt 6.3 L
6-Speed Manual CTS 1.9 qt 1.8 L
6-Speed Manual CTS-V 4.0 qt 3.8 L
Wheel Nut Torque 140 lb ft 190Y
All capacities are approximate. When adding, be sure to ll to the approximate level, as recommended in this
manual. Recheck uid level after lling.
Engine Specications
Engine VIN Code Transmission Spark Plug Gap
3.6L V6 Engine 7Automatic
Manual0.043 in (1.1 mm)
3.6L V6 Engine VAutomatic
Manual0.043 in (1.1 mm)
6.2L V8 Engine PAutomatic
Manual0.040 in (1.0 mm)
5-128
