TECHNICAL DATA 335
Technical Data
Vehicle Identification
Vehicle IdentificationNumber (VIN) . . . . . . . . . . . . . . . . . . . 335
Service Parts Identification Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 335
Vehicle Data
Capacities and Specifications . . . . 336
Engine Drive Belt Routing . . . . . . . 338
Vehicle Identification
Vehicle Identification
Number (VIN)
This legal identifier is in the front
corner of the instrument panel, on the
driver side of the vehicle. It can be
seen through the windshield from
outside. The Vehicle Identification
Number (VIN) also appears on the
Vehicle Certification and Service Parts
labels and certificates of title and
registration.
Engine Identification
The eighth character in the VIN is the
engine code. This code identifies the
vehicle's engine, specifications, and
replacement parts. See “Engine
Specifications” underCapacities and
Specifications 0336 for the vehicle's
engine code.
Service Parts Identification
Label
This label, under the floor cover in the
trunk on the passenger side, has the
following information:
. Vehicle Identification
Number (VIN).
. Model designation.
. Paint information.
. Production options and special
equipment.
Do not remove this label from the
vehicle.
Page 337 of 352
Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-MidEast-10293089) -
2017 - crc - 6/22/16
336 TECHNICAL DATA
Vehicle Data
Capacities and Specifications
The following approximate capacities are given in metric and English conversions. SeeRecommended Fluids and Lubricants
0 331 for more information.
Application Capacities
Metric English
Air Conditioning Refrigerant For the air conditioning system refrigerant type and charge amount, see the refrigerant label under thehood. See your dealer for more information.
Cooling System– Engine
2.0L L4 Engine (LTG) 8.8 L 9.3 qt
3.6L V6 Engine (LGX) 10 L 10.7 qt
3.6L V6 Engine (LF3) 12.8 L 13.5 qt
6.2L V8 Engine (V-Series) 12.2 L 12.9 qt
Engine Oil with Filter 2.0L L4 Engine (LTG) RWD 4.7 L5.0 qt
2.0L L4 Engine (LTG) AWD 5.7 L6.0 qt
3.6L V6 Engine (LGX) RWD (with oil cooler) 5.7 L6.0 qt
3.6L V6 Engine (LF3) 6.6 L7.0 qt
6.2L V8 Engine (V-Series) 9.5 L10.0 qt
Page 338 of 352
Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-MidEast-10293089) -
2017 - crc - 6/22/16
TECHNICAL DATA 337
ApplicationCapacities
Metric English
Fuel Tank 72 L 19 gal
Transfer Case –AWD 0.8 L 0.8 qt
Rear Axle (with limited slip) 1.2 L 1.3 qt
Wheel Nut Torque 190 Y140 lb ft
All capacities are approximate. When adding, be sure to fill to the approximate level, as recommended in this manual.
Recheck fluid level after filling.
Engine Specifications
Engine VIN Code Horsepower TorqueSpark Plug Gap
2.0L L4 Engine (LTG) X 203 kW@ 5500 rpm
(272 hp@5500 rpm) 400
Y @3000 rpm
(295 lb ft @ 3000 rpm) 0.75–0.90 mm (0.030–
0.035 in)
3.6L V6 Engine (LGX) S 250 kW@ 6900 rpm
(335 hp@6900 rpm) 372
Y @4800 rpm
(275 lb ft @ 4800 rpm) 0.80–0.90 mm (0.031–
0.035 in)
3.6L V6 Engine (LF3) 8 477 kW@ 6400 rpm
(640 hp@ 6400 rpm) 864
Y @3600 rpm
(637 lb ft @ 3600 rpm) 0.75–0.90 mm (0.030–
0.035 in)
6.2L V8 Engine
(V-Series) 6
485 kW@ 6400 rpm
(650 hp@ 6400 rpm) 861
Y @3600 rpm
(635 lb ft @ 3600 rpm) 0.725–0.875 mm (0.029–
0.034 in)
Page 339 of 352
Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-MidEast-10293089) -
2017 - crc - 6/22/16
338 TECHNICAL DATA
Vehicle Top Speed
Vehicle Top SpeedMetricEnglish
2.0L L4 Engine (LTG) 230 km/h142 mph
3.6L V6 Engine (LGX) 250 km/h155 mph
3.6L V6 Engine (LF3) 280 km/h174 mph
6.2L V8 Engine (V-Series) 322 km/h200 mph
Engine Drive Belt Routing
2.0L L4 Engine
3.6L V6 Engine (LGX)3.6L V6 Engine (LF3)
Page 340 of 352
Cadillac CTS/CTS-V Owner Manual (GMNA-Localizing-MidEast-10293089) -
2017 - crc - 6/22/16
TECHNICAL DATA 339
6.2L V8 Engine
