Downloaded from www.Manualslib.com manuals search engine A: The shoulder belt is worn under the arm. It should be worn over the
shoulder at all times.
I A CAUTION
You can be seriously injured if you wear the shoulder belt under
your
arm. In a crash, your body would move too far forward,
which
would increase the chance of head and neck injury. Also,
the belt would
apply too much force to the ribs, which aren't as
strong as shoulder bones. Y0.u could also severely injure
internal
organs like your liver or spleen.
28

Downloaded from www.Manualslib.com manuals search engine A
Q: What’s wrong with this?
L: The belt is twisted across the body.
A CAUTION:
You can be seriously injured by a twisted belt. In a crash, you
wouldn’t have the full width of the belt to spread impact \
forces.
If a belt is twisted, make it straight
so it can work properly, or
ask your dealer to fix it.
To unlatch the belt, just push the button on the buckle. The belt should
go back out of the way. I-
29

Downloaded from www.Manualslib.com manuals search engine Before you close the door, be sure the belt is out
the door on it,
you can damage both the belt and
of the way. If you slam
your vehicle.
SUPPLEMENTAL INFLATABLE
RESTMNT SYSTEM
(MR BAGS)
This section explains the Supplemental Inflatable Restraint (SIR), or “air
bag,” system. Your Cadillac has an air bag for both the driver and the
right-front passenger.
Here are the most important things to
know:
30

Downloaded from www.Manualslib.com manuals search engine r
I
31

Downloaded from www.Manualslib.com manuals search engine I

Downloaded from www.Manualslib.com manuals search engine Air Bag Readiness Light
There is an air bag readiness light on the instrument panel. The system\

checks for electrical malfunctions, and the light tells you if there is a
problem.
You will see this light flash for a few seconds when you turn your ignition
to “Run” or “Start.” Then the light should
go out, which means the
system
is ready.
Remember,
if the air bag readiness light doesn’t come on when you start \
your vehicle,
or stays on, or comes on when you are driving, your air bag
system may not work properly. Have your vehicle serviced right \
away.
33

Downloaded from www.Manualslib.com manuals search engine How The Air Bag System Works
A
34

Downloaded from www.Manualslib.com manuals search engine Where is the air bag?
The driver’s air bag is in the middle of the steering wheel. The right-front
passenger’s air bag is located in the instrument panel
on the passenger’s
side.
When is an air bag expected to inflate?
The air bag is designed to inflate in moderate to severe frontal or
near-frontal crashes.
The air bag will only inflate if the velocity of the
impact is above the designed threshold level. When impacting straight
into a wall that does not move or deform, the threshold level for most
GM vehicles is between 9 and 15 mph (14 and 23 km/h). However, this
velocity threshold depends
on the vehicle design and may be several
miles-per-hour faster or slower. In addition, this threshold velocity will be
considerably higher
if the vehicle strikes an object such as a parked car
which will move and deform on impact.
The air bag is also not designed
to inflate in rollovers, side impacts, or rear impacts where the inflation
would provide no occupant protection benefit.
It
is possible that in a crash, only one of the two air bags in your Cadillac
will deploy. This is rare, but can happen in a crash just severe enough to
make an
air bag inflate.
In any particular crash, the determination
of whether the air bag should
have inflated cannot be based
solely on the level of damage on the
vehicle(s). Inflation is determined by the angle
of the impact and the
vehicle’s deceleration,
of which vehicle damage is only one indication.
Repair cost is not a good indicator
of whether an air bag should have
deployed.
What makes an air bag inflate?
In a frontal or near-frontal impact of sufficient severity, the air bag
sensing system detects that the vehicle is suddenly stopping as a result
of
a crash. The sensing system triggers a chemical reaction of the sodium
azide sealed in
the inflator. The reaction produces nitrogen gas, which
inflates
a cloth bag. The inflator, cloth bag, and related hardware are all
part
of the air bag inflator modules packed inside the steering wheel and
in the instrument panel in front
of the passenger.
35

Downloaded from www.Manualslib.com manuals search engine How does an air bag restrain?
In moderate to severe frontal or near-frontal collisions, even belted
occupants can contact the steering wheel or the instrument panel.
The air
bag supplements the protection provided by safety belts. Air bags
distribute the force of the impact more evenly over the occupant’s upper
body, stopping the occupant more gradually. But air bags would not
provide protection in many types of collisions, including rollovers and
rear and side impacts, primarily because an occupant’s motion is not
toward the air bag. Air bags should never be regarded as anything more
than a supplement to safety belt protection
in moderate to severe frontal
and near-frontal collisions.
What will you see after an air bag inflation?
After the air bag has inflated, it will then quickly deflate. This occurs so
quickly that some people may not even realize that the air bag inflated.
Some components
of the air bag module in the steering wheel hub for the
driver’s air bag or the instrument panel for the passenger’s bag may be
hot for a short time, but the portion of the bag that comes into contact
with
you will not be hot to the touch. There will be small amounts of
smoke and dust coming from vents in the deflated air bags. The air bag
will
not impede the driver’s vision or ability to steer the vehicle, nor will it
hinder the occupants from exiting the vehicle.
In many crashes severe enough to inflate an air bag, windshields are
broken by vehicle deformation. Additional windshield breakage may
occur in vehicles with passenger air bags because the windshield acts as a
reaction surface for the inflating air bag.
The air bags are designed to inflate only once. After they inflate, you’ll
need some new parts for your air bag system.
If you don’t get them,
the air bag system won’t be there to help protect you in another crash.
A new system will include air bag modules and possibly other parts.
The service manual has information about the need to replace other
parts.
36

Downloaded from www.Manualslib.com manuals search engine 0 Your vehicle is equipped with a diagnostic module, which records
information about the air bag system
if the air bag deploys in a crash.
The module records information about the readiness of the system,
which sensors activated the deployment, and whether the driver’s
safety belt was
in use.
Let only qualified technicians work on your air bag system. Improper
service can mean that your air
.. bag system won’t work properly. See
your dealer for service.
NOTICE:
If you damage the cover for the driver’s or the right-front\

passenger’s air bag, they may not work properly.
You may have
to replace the air bag on the steering wheel or both the air bag
and the instrument panel for the passenger’s air bag.
Do not
open
or break the air bag covers.
Is the smoke from an air bag inflation harmful?
The particles emitted during air bag inflation are not harmful to most
people. Some people with respiratory ailments may experience difficulty
breathing
if they stay in the vehicle with the windows closed after air bag
inflation.
So, if your air bag inflates, you and any passengers should exit
the vehicle
if and when it is safe to do so. If you or your passengers can’t
get out of the vehicle, try to get fresh air by opening a window, turning
on
the fan, or opening a door.
