trunk release CADILLAC DEVILLE 2000 8.G Owners Manual

ii
Table of Contents
Keys and Door Locks
Remote Keyless Entry (RKE) System
Trunk Release
Automatic Transmission
Parking Brake
Windows
Tilt Wheel
Turn Signal/Multifunction Lever
Windshield Wipers
Cruise Control
Interior and Exterior Lamps
MirrorsStorage Compartments
Convenience Net
Accessory Power Outlets
OnStar® System (Option)
Sunroof (Option)
HomeLink® Transmitter (Option)
Instrument Panel, Warning Lights and Gages
Head-Up Display
Driver Information Center
Memory and Personalization/Personal Choice Feature
Oil Life Indicator Seats and Seat Controls
Safety BeltsAir Bag Systems
Child Restraints
Section
1
Section
2
Seats and Restraint Systems
Features and Controls

2-12
Trunk
CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even death.
If you must drive with the trunk lid open or if
electrical wiring or other cable connections must
pass through the seal between the body and the
trunk lid:

Make sure all other windows are shut.

Turn the fan on your heating or cooling
system to its highest speed with the setting
on AUTO or ECON and the temperature
between 65 F (18 C) and 85 F (29 C).
That will force outside air into your vehicle.
See ªComfort Controlsº in the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.
Trunk Lock Release
To use this feature, your
vehicle must be in PARK (P)
or NEUTRAL (N) and the
VALET lockout switch must
be off.
Press the trunk release button, located on the left side of
the instrument panel, to open the trunk.
You can also press the trunk button on the remote
keyless entry transmitter to access the trunk
compartment. To disable the use of this feature, see
ªValet Lockout Switchº in the Index.

2-14
This feature is used to secure the trunk lid if it will not
close completely, such as when carrying large packages
in the trunk.
1. Attach the clip end of the tie down to the ªDº ring on
the trunk lid (see view A).
2. Attach the hook end of the tie down to the striker
located at the center of the trunk sill (see view B).
3. Tighten the tie down by pulling the free end of the
cord until secure.
4. To remove the tie down, press the clip end release
and loosen the cord.

2-15
Theft
Vehicle theft is big business, especially in some cities.
Although your vehicle has a number of theft
-deterrent
features, we know that nothing we put on it can make
it impossible to steal. However, there are ways you
can help.
Key in the Ignition
If you leave your vehicle with the keys inside, it's an
easy target for joy riders or professional thieves
-- so
don't do it.
When you park your vehicle and open the driver's door,
you'll hear a chime reminding you to remove your key
from the ignition and take it with you. Always do this.
Your steering wheel will be locked, and so will your
ignition and transaxle. And remember to lock the doors.
Parking at Night
Park in a lighted spot, close all windows and lock your
vehicle. Remember to keep your valuables out of sight.
Put them in a storage area, or take them with you.
Parking Lots
If you park in a lot where someone will be watching
your vehicle, it's best to lock it up and take your keys.
But what if you have to leave your ignition key?

If possible, park in a busy, well lit area.

Put your valuables in a storage area, like your
trunk or glove box. Be sure to close and lock the
storage area.

Close all windows.

Move the trunk release lockout switch to ON.

Lock the glove box.

Lock all the doors except the driver's.

Then take the door key and remote keyless entry
transmitter with you.

Leave only the valet key.

Take all other keys and the Remote Keyless Entry
transmitter with you.

2-58
Full Floor Console Storage (If Equipped)
The full floor console has an upper and lower storage
area. The lower has two removable that can hold tapes
and/or CDs. There is also a removable coinholder that
attaches to the side of one of the bins. The upper storage
area is available for the optional cellular telephone. A
dual cupholder is located in front of the console. Open
and close by pressing on the cupholder. To open the
console, pull up on either lever to open the upper or
lower storage area.
Rear Storage Center Armrest
Your vehicle is equipped with a rear seat armrest which
includes an open storage compartment and a dual
cupholder. To open, release the latch at the front edge.
Rear Storage Door Trim Armrest
(If Equipped)
Your vehicle may be equipped with a rear storage door
trim armrest. The storage area is located in the rear door
trim under the switch plate lid and includes an accessory
power outlet.
Center Flex Storage Unit (If Equipped)
Your vehicle may be equipped with a center flex storage
unit that includes a front center seat with a lap belt and
an underseat storage compartment. The center seatback
can be used as a fold down armrest with extra space for
CDs or tapes. An optional cellular telephone is located
in the underseat storage compartment. Cupholders are
also located at the front edge of the storage unit.
Convenience Net
The convenience net is located inside the back wall of
the trunk. Put small loads, like grocery bags, behind the
net. It can help keep them from falling over during sharp
turns or quick starts and stops.
The net is not for larger, heavier loads. Store them in the
trunk as far forward as you can. When not using the net,
hook the net to the tabs securing it to the sill plate.

6-6
The fuel door release button
is located to the left of the
steering wheel next to the
headlamp knob.
The button only works in PARK (P) or NEUTRAL (N)
when the ignition key is in any position and the VALET
lockout button is in the OFF position.
An alternate fuel door
release is located inside of
the trunk on the driver's
side. Pull it to release the
fuel door.While refueling, hang the cap by the tether from the
hook on the filler door.
To remove the cap, turn it slowly to the left
(counterclockwise). The cap has a spring in it; if you let
go of the cap too soon, it will spring back to the right.

6-70
Fuse Usage
28 Rear HVAC Blower
29 Ignition Switch
30 Hazard Signal
31 Reverse, Locks
32 Continuous Variable Road
Sensing Suspension
33 Heating, Ventilation,
Air Conditioning
34 Ignition 3 Rear
35 Antilock Braking System
36 Heated Seat, Right Front
37 Heated Seat, Right Rear
38 Dimmer
Micro Relays
Relay Usage
39 Fuel Pump
40 Parking Lamps
41 Ignition 1
42 Park Brake A
43 Park Brake B
44 Park Shift Interlock
45 Reverse LampsRelay Usage
46 Retained Accessory Power
for Sunroof
47 Reverse Lockout
48 CVRSS Dampers
49 Ignition 3
50 Fuel Tank Door Release
51 Interior Lamps
52 Trunk Release
53 Not Used
54 Lock, Cylinder
55 Electronic Level
Control Compressor
Circuit Breakers
Relay Usage
56 Power Seats
57 Power Windows
Mini Relays
Relay Usage
58 Cigar Lighter
59 Right Rear Defog
