buttons CADILLAC DEVILLE 2001 8.G Owners Manual

1-6
If you use the remote keyless entry transmitter to enter
your vehicle, automatic seat and mirror movement will
occur. The numbers on the back of the transmitters,
1 and 2, correspond to the numbers on the buttons
on the door panel.
When the key is placed in the ignition in OFF or when
the unlock button is pressed on the remote keyless entry
transmitter, the seats and mirrors will automatically
adjust to the programmed position.
Programming for automatic seat, steering wheel and
mirror movement is done through the Driver Information
Center (DIC). You can choose to either select or not
select automatic seat and mirror movement using the
remote keyless entry transmitter, placing your key in
the ignition, or by exiting the vehicle. For programming
information, see ªVehicle Programming and
Personalization Featuresº in the Index.Heated Seats (If Equipped)

1-7
Your vehicle may have heated front and rear seats. The
buttons are located on the armrests. The HEAT/OFF
button controls the temperature settings HI, MED
and LO. The other button is to choose BACK ONLY
heating. The LO setting warms the seatback and cushion
until the seat approximates body temperature. The MED
and HI settings heat the seatback and seat cushion to a
slightly higher temperature, and the BACK ONLY heats
only the seatback. The temperature can be adjusted
by pushing the button from HI to LO or, until the
desired setting is reached. You will be able to feel heat
in approximately two minutes. To heat just the seatback,
push the BACK ONLY button once, after first activating
the heated seat feature. To turn off the heat in the
seatback, push the button again. The feature will
also shut off when the ignition is turned to OFF.Reclining Front Seatbacks
Press the recliner control
located on the outboard
side of the seat, forward
or rearward to adjust
the seatback.
Push the recliner control up or down to adjust the
shoulder belt height. See ªShoulder Belt Height
Adjusterº in the Index for more information.

2-67
OnStar
System (If Equipped)
OnStar is a vehicle communications system that
offers a variety of services and provides a hands
-free
communication link between you and the OnStar Center.
A service subscription agreement and fee are required in
order to receive OnStar service. Services are available
24 hours a day, 7 days a week. For more information,
call 1
-888-ONSTAR-7 (1-888-667-8277).
OnStar Services Button: Press this button once
to contact an advisor who will be able to assist you with
these services. If you are not quickly connected, the
system will automatically reset and redial. This ensures
connection to the center; there is no additional action
required. Press the Call Answer/End button to cancel the
automatic redial.
Emergency Button: In an emergency situation,
press the emergency service button. Upon receiving the
call, an advisor at the center will locate your vehicle and
assess the situation. If necessary, the advisor will alert
the nearest emergency service provider.
Call ANSWER/END Button: Use this button
to answer a call. (If you are receiving a call, the audio
system will mute, and the ring will be heard). Press this
button at the end of a call to disconnect and return the
audio system to its previous settings. This button will
also cancel a call if one of the buttons is accidentally
pressed or if the automatic redial function is activated.

2-73
Your vehicle's engine should be turned off while
programming the transmitter. Follow these steps to
program up to three channels:
1. If you have previously programmed a transmitter
channel, proceed to Step 2. Otherwise, hold down
the two outside buttons on the HomeLink
Transmitter until the indicator light begins to flash
rapidly (after 20 seconds). Then release the buttons.
This procedure initializes the memory and erases any
previous settings for all three channels.
2. Decide which one of the three channels you want to
program. Hold the end of the hand
-held transmitter
about 2 to 5 inches (5 to 13) away from the surface
of the HomeLink Transmitter so that you can still see
the indicator light.
3. Using both hands, press the hand
-held transmitter
button and the desired button on the HomeLink
Transmitter. Continue to press both buttons
through Step 4.
4. Hold down both buttons until you see the indicator
light on the HomeLink Transmitter flash slowly and
then rapidly. The rapid flashing indicates that the
HomeLink Transmitter has been programmed.
Release both buttons once the indicator light starts
to flash rapidly.If you have trouble programming the HomeLink
Transmitter, make sure that you have followed the
directions exactly as described. The HomeLink
Transmitter may not work with older garage door
openers that do not meet current Federal Consumer
Safety Standards. If you cannot program the
transmitter after repeated attempts, refer to ªRolling
Code Programmingº later in this section or
contact the HomeLink Transmitter manufacturer
at 1
-800-355-3515.
Be sure to keep the original hand
-held transmitter
in case you need to erase and reprogram the
HomeLink Transmitter.
Canadian Programming: During programming,
the hand
-held transmitter may automatically stop
transmitting after one or two seconds. In this case, you
should press and re
-press the button on the hand-held
transmitter every two seconds without ever releasing the
button on the HomeLink Transmitter. Release both
buttons when the indicator light on the HomeLink
Transmitter begins to flash rapidly.

2-75
3. Return to the HomeLink Transmitter in your vehicle
and firmly press and release the HomeLink
Transmitter button you have already programmed for
two to three seconds. Press and release the button
again (you may need to do this step up to three
times) to make sure that the HomeLink Transmitter
has been trained to the garage door opener motor
head unit. Check that the training was successful.
The garage door opener should now recognize the
HomeLink Transmitter. You may either use the
HomeLink Transmitter or the hand
-held transmitter to
open the garage door.
If after following these instructions, you still have
problems training the garage door opener, contact
the HomeLink Transmitter manufacturer
at 1
-800-355-3515.
Erasing Channels
To erase all three programmed channels, hold down the
two outside buttons until the indicator light begins to
flash (after 20 seconds). Release both buttons.
Accessories
Accessories for the HomeLink Transmitter are available
from the manufacturer of the unit. If you would like
additional information, please call 1
-800-355-3515.

2-77
The main components of the instrument panel are the following:
A. Air Outlets
B. Turn Signal/Multifunction Lever
C. HVAC Steering Wheel Controls (or Cellular
Telephone Controls, If Equipped)
D. Instrument Panel Cluster
E. Audio Steering Wheel Controls
F. Driver Information Center Buttons
G. Electronic Climate Controls
H. Lamp ControlsI. Night Vision Controls (Option)
J. Hood Release
K. Cruise Control
L. Horn
M. Cruise Control
N. Radio
O. Ashtray
P. Glove Box

2-108
Vehicle Programming and
Personalization Features
(If Equipped)
If your vehicle is equipped with personalization,
you can program certain features to a preferred setting
for up to two people. If your vehicle does not have
personalization then some of the features on your
vehicle have been programmed for all drivers. On all
vehicles, other features such as HVAC settings, radio
preset settings, exterior lighting at unlock, remote lock
and unlock confirmation, and automatic door locks have
already been programmed for your convenience. If the
vehicle is equipped with personalization then the seat
position, steering column position (if equipped) and
outside mirror position can also be programmed.
The Navigation screen preferences (if equipped) will
remain at the last set position.
If your vehicle is equipped with personalization the
driver's preferences are recalled by pressing the unlock
button on the remote keyless entry transmitter or by
pressing the appropriate memory button ª1º or ª2º
located on the driver's door. Certain features can be
programmed not to recall until the key is placed in the
ignition. To change feature preferences you must enter
feature programming (see below).
Entering Feature Programming
To begin programming, the ignition must be in ON,
your vehicle in PARK (P), and if your vehicle has
memory, you must press the appropriate memory button
ª1º or ª2º, located on the driver's door panel, prior to
programming. The display will show either ª1º or ª2º,
depending on which was selected. Press the INFO
button one or more times until the FEATURE
PROGRAMMING prompt appears on the DIC display.
Press the ON/OFF button to enter FEATURE
PROGRAMMING. To exit, press the INFO RESET
or INFO buttons.
Remote Recall Memory (If Equipped)
To enter feature programming, follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the REMOTE
RECALL MEMORY prompt appears. To turn the
feature on, press the ON/OFF button until ON is
displayed on the DIC. The seat and mirror memory
settings that have been previously programmed can be
recalled by pressing the unlock button on the remote
keyless entry transmitter. The steering column will
move when the key is inserted in the ignition and turned
to ON. To turn the feature off, press the ON/OFF button
until OFF is displayed.

2-112
Mirror to Curb In Reverse (If Equipped)
Press the down arrow on the INFO button one or more
times until the MIRROR TO CURB IN REV prompts
appears on the DIC display. This feature will move the
passenger's outside rearview mirror to a curb view
position when the shifter is placed in REVERSE (R)
and it will return the mirror to the last known
driving position when the shifter is moved out of
REVERSE (R). To turn this feature on, press the
ON/OFF button until ON is displayed on the DIC.
To turn the feature off, press the ON/OFF button
until OFF is displayed. See ªCurb View Assist Mirrorº
in the Index for more information.
Tire Pressure Display (If Equipped)
To enter feature programming follow the instructions
listed previously, then press the down arrow on the
INFO button one or more times until the TIRE
PRESSURE DISPLAY prompt appears. This feature
will allow each of the four (left front, right front, left
rear, right rear) tire pressure readings to be displayed
when using the INFO button to scroll through the
DIC displays. To turn the feature on, press ON/OFF
until ON is displayed on the DIC. To turn the feature off, press ON/OFF until OFF is
displayed. Even with this feature programmed to be
turned off, a low or high tire pressure condition will still
cause the CHECK TIRE PRESSURE message to be
displayed on the DIC. See ªDriver Information Center
(DIC) Messagesº in the Index for more information.
Driver's Names Set/Recall (If Equipped)
After the FEATURE PROGRAMMING prompt is
displayed on the DIC and the ON/OFF button is pressed,
the prompts DRIVER NO 1 or DRIVER NO 2 will
appear. These prompts correspond to which remote
keyless entry transmitter button or memory recall button
has been pressed on the driver's door armrest. You may
have your name and a second driver's name displayed
here, replacing the prompts DRIVER NO 1 and
DRIVER NO 2. A dealership can program your vehicle
to display the names you want. The names will appear
whenever the key is turned to ON only if remote keyless
entry transmitters 1 or 2 are used to enter the vehicle or
buttons 1 or 2 on the driver's door are pressed.

2-117
Navigation (Option)
Navigation Display Controls
The display screen is located in the center on the
instrument panel. There are seven ªhardº buttons
and a touch sensitive screen.Your vehicle may be equipped with a turn by turn
navigation guidance system that includes a CD ROM
map media covering nine regional areas throughout the
contiguous United States. In addition, the system
includes intersection and freeway entrances, route
planning, a programmable address book, points of
interest, a list of restaurants, emergency phone numbers,
and a list of hotels and motels for all of the major cities
on each regional CD. The navigation system can also
communicate with the radio data system to receive
broadcast announcements on traffic, weather
information and emergency alert communications.
For more information on how to use this system,
see ªNavigationº supplement.

3-8 Rear Climate Control
Your vehicle is equipped with a rear climate control.
With this system, the rear passengers can control the
temperature of the air flow for his/her own zones. The
climate control has three buttons:
MODE: Press this button to adjust the direction of the
airflow. If you press down until ªAUTOº is displayed,
automatic mode will be active. During automatic
operation, the system will decide the mode for you.
Fan: Press the button with the fan symbol on it to adjust
the blower speed. Press up to increase and down to
decrease blower speed. You can turn the system off by
continuing to press down until ªOFFº is displayed.
TEMP: Press this button to adjust the temperature.
Press up to make it warmer and down to make it cooler.
The front system also has an AUTO button that can
automatically change the temperature of the rear seating
area. When this button is pressed, the rear auto mode is
selected and the rear air temperature and mode will
readjust to coincide with the front seat setting.
A PASS
-OFF button located on the front climate control
panel allows the driver to turn off the rear passenger
climate controls from the front seat.
