The rear climate control system is located on the back
of the center console.A. Display
B. Fan Control C. Temperature Control
D. Air Delivery Mode Control
AUX (Auxiliary): Press the AUX button located on
the front climate control panel to turn the rear climate
control system on or off. When turned on the rear
system operates in automatic mode and the
temperature settings selected for the front climate
control panel will also be selected for the rear
passengers. To adjust the rear climate control system, the rear
passenger can select a different temperature, mode
or fan speed. Whenever the rear passengers have
adjusted settings on the rear climate control system,
the AUX light is lit on the front climate control system.
When the front climate control system is turned off or in
defrost mode, the rear climate control system is turned
off. The rear system will turn back on once another front
mode is selected.
For more information on how to use the front climate
control system, see
Dual Climate Control System
on
page 4‑34. For more information on the air outlets, see
Outlet Adjustment on page 4‑40.
Automatic Operation
« A ª(Fan Control): Press until AUTO appears
on the display to place the system in automatic mode.
When automatic operation is active, the system
automatically controls the fan speed. If in auto fan
mode, pressing the up arrow button will cancel
automatic operation and places the system in manual
mode. If in auto mode, pressing the down arrow will
turn the rear climate control system off.
« Nª(Air Delivery Mode Control): Press until
AUTO appears on the display to place the system in
automatic mode. When automatic operation is active,
the system controls the air delivery mode.
4-41
Page 208 of 470

Black plate (46,1)Cadillac DTS Owner Manual - 2011
Speedometer and Odometer
The speedometer shows the speed in both miles
per hour (mph) and kilometers per hour (km/h). See
“MPH (km)”underDIC Operation and Displays
on
page 4‑60for more information.
The odometer mileage can be checked without the
vehicle running. The vehicle's odometer works together
with the driver information center. Trip A and Trip B can
be set on the odometer. See “Trip Fuel”underDIC
Operation and Displays
on page 4‑60for more
information.
If the vehicle ever needs a new odometer installed, the
new one is set to the correct mileage total of the old
odometer.
Tachometer
This gauge indicates
the engine speed
in revolutions per
minute (rpm).
4-46
Page 221 of 470

Black plate (59,1)Cadillac DTS Owner Manual - 2011
Fuel Gauge
The fuel gauge shows
approximately how much
fuel is in the tank. It works
only when the engine
is on.
An arrow on the fuel gauge indicates the side of the
vehicle the fuel door is on.
If the fuel supply gets low, the FUEL LEVEL LOW
message appears in the Driver Information Center
and a single chime sounds. See DIC Warnings and
Messages
on page 4‑65for more information.
Here are a few situations that may occur with the fuel
gauge. All of these situations are normal and do not
indicate that anything is wrong with the fuel gauge:
.At the gas station the gas pump shuts off before
the gauge reads full.
.The gauge may change when the vehicle is
turning, stops quickly or accelerates quickly.
.It takes a little more or less fuel to fill the tank than
the gauge indicated. For example, the gauge may
have indicated that the tank was half full, but it
actually took a little more or less than half the
tank's capacity to fill the tank.
Driver Information Center (DIC)
The Driver Information Center (DIC) gives you the
status of many of your vehicle's systems. The DIC is
also used to display warning/status messages. All
messages will appear in the DIC display located at
the bottom of the instrument panel cluster, below the
tachometer and speedometer. The DIC buttons are
located on the instrument panel, to the left of the
steering wheel.
The DIC comes on when the ignition is on. After a short
delay, the DIC will display the information that was last
displayed before the engine was turned off.
The top line of the DIC display shows the vehicle
system information and the warning/status messages.
The bottom line of the DIC display shows the odometer
on the left side. The bottom line of the DIC display also
shows a digital speedometer on the right side.
If a problem is detected, a warning message will appear
on the display. Be sure to take any message that
appears on the display seriously and remember that
clearing the message will only make the message
disappear, not correct the problem.
4-59
Page 222 of 470

Black plate (60,1)Cadillac DTS Owner Manual - 2011
DIC Operation and Displays
The Driver Information
Center (DIC) has different
displays which can be
accessed by pressing the
DIC buttons located on
the instrument panel, to
the left of the steering
wheel.
3Trip/Fuel:Press this button to scroll through the
trip and fuel displays. See “Trip/Fuel Display Menu
Items” following for more information on these displays.
TVehicle Information: Press this button to scroll
through the vehicle information displays. See “Vehicle
Information Display Menu Items” following for more
information on these displays.
UCustomization: Press this button to scroll through
each of the customization features. See DIC Vehicle
Customization
on page 4‑77for more information on
the customization features.
VSet/Reset: Press this button to reset certain DIC
features and to acknowledge DIC warning messages
and clear them from the DIC display.
y zMenu Up/Down: Press this button to scroll up
and down the menu items.
Trip/Fuel Display Menu Items
3
(Trip/Fuel): The following display menu items can
be displayed by pressing the trip/fuel button:
TRIP A or TRIP B
These displays show the current distance traveled
since the last reset for each trip odometer in either
kilometers (km) or miles (mi). Both odometers can be
used at the same time. Each trip odometer can be reset
to zero separately by pressing and holding the set/reset
button for a few seconds while the desired trip odometer
is displayed.
FUEL RANGE
This display shows the approximate number of
remaining kilometers (km) or miles (mi) you can drive
without refilling the fuel tank. This estimate is based on
the current driving conditions and will change if the
driving conditions change. For example, if you are
driving in traffic and making frequent stops, the display
may read one number, but if you enter the freeway, the
number may change even though you still have the
same amount of fuel in the fuel tank. This is because
different driving conditions produce different fuel
economies. Generally, freeway driving produces better
fuel economy than city driving.
4-60
Page 223 of 470

Black plate (61,1)Cadillac DTS Owner Manual - 2011
Once the range drops below an estimated 64 km
(40 miles) remaining, the display will show FUEL
RANGE LOW.
If your vehicle is low on fuel, the FUEL LEVEL LOW
message will be displayed. See“FUEL LEVEL LOW”
under DIC Warnings and Messages
on page 4‑65for
more information.
AVERAGE ECONOMY (AFE)
This display shows the approximate average liters per
100 kilometers (L/100 km) or miles per gallon (mpg).
This number is calculated based on the number of
L/100 km (mpg) recorded since the last time this display
was reset. To reset this display, press the set/reset
button. The display will return to zero.
INST (Instantaneous) ECONOMY (IFE)
This display shows the current fuel economy in either
liters per 100 kilometers (L/100 km) or miles per
gallon (mpg). This number reflects only the fuel
economy that the vehicle has right now and will
change frequently as driving conditions change.
Unlike average economy, this display cannot be reset.
FUEL USED
This display shows the number of liters (L) or
gallons (gal) of fuel used since the last reset of this
display. To reset this display, press the set/reset button.
The display will return to zero.
TIMER ON/OFF
This display can be used like a stopwatch. You can
record the time it takes to travel from one point to
another. To access the timer, press the trip/fuel button
until 00:00:00 TIMER OFF displays.
To turn on the timer, press the set/reset button until
TIMER ON displays. The timer will then start.
To turn off the timer, press the set/reset button again
until TIMER OFF displays. The timer will stop and
display the end timing value.
To reset the timer, press and hold the set/reset button
after the timer has been stopped. The display will return
to zero.
AVERAGE SPEED
This display shows the average speed of the vehicle
in either kilometers per hour (km/h) or miles per
hour (mph). This average is calculated based on the
various vehicle speeds recorded since the last reset of
this display. To reset this display, press the set/reset
button. The display will return to zero.
4-61
Page 224 of 470

Black plate (62,1)Cadillac DTS Owner Manual - 2011
BATTERY VOLTAGE
This display shows the current battery voltage. If the
voltage is in the normal range, the value will display. For
example, the display may read BATTERY VOLTAGE
13.2 VOLTS. If the voltage is low, the display will show
LOW. If the voltage is high, the display will show HIGH.
Your vehicle's charging system regulates voltage based
on the state of the battery. The battery voltage may
fluctuate when viewing this information on the DIC. This
is normal. SeeCharging System Light
on page 4‑49for
more information.
If there is a problem with the battery charging system,
the DIC will display a message. See DIC Warnings
and Messages
on page 4‑65and Electric Power
Managementon page 4‑32for more information.
Blank Display
This display shows no information.
Vehicle Information Display Menu Items
T
(Vehicle Information): The following display
menu items can be displayed by pressing the vehicle
information button:
OIL LIFE REMAINING
If the vehicle has this display, it shows the estimated oil
life remaining. If you see 99% OIL LIFE REMAINING on
the display, that means that 99% of the current oil life
remains.
When the oil life is depleted, the CHANGE ENGINE OIL
SOON message will appear on the display. You should
change the oil as soon as possible. In addition to the
engine oil life system monitoring the oil life, additional
maintenance is recommended in the Maintenance
Schedule in this manual. See Scheduled Maintenance
on page 7‑3andEngine Oil on page 6‑15.
Remember, you must reset the OIL LIFE yourself after
each oil change. It will not reset itself. Also, be careful
not to reset the OIL LIFE accidentally at any time other
than when the oil has just been changed. It cannot be
reset accurately until the next oil change. To reset the
engine oil life system, See Engine Oil Life System
on
page 6‑18. The display will show 100% when the
system is reset.
4-62
Page 225 of 470

Black plate (63,1)Cadillac DTS Owner Manual - 2011
UNITS
This display allows you to select between English or
Metric units of measurement. Once in this display, press
the set/reset button to select between ENGLISH or
METRIC units.
PARKING ASSIST
If your vehicle has the Ultrasonic Front and Rear
Parking Assist (UFRPA) system, this display allows
the system to be turned on or off. Once in this display,
press the set/reset button to select between ON or OFF.
If you choose ON, the system will be turned on. If you
choose OFF, the system will be turned off. The UFRPA
system automatically turns back on after each vehicle
start. When the UFRPA system is turned off and the
vehicle is shifted out of P (Park), the DIC will display the
PARKING ASSIST OFF message as a reminder that the
system has been turned off. SeeDIC Warnings and
Messages
on page 4‑65and Ultrasonic Front and
Rear Parking Assist (UFRPA)on page 3‑38for more
information.
SIDE BLIND ZONE ALERT
If your vehicle has the Side Blind Zone Alert (SBZA)
system, this display allows the system to be turned on
or off. Once in this display, press the set/reset button
to select between ON or OFF. If you choose ON, the
system will be turned on. If you choose OFF, the system
will be turned off. When the SBZA system is turned off,
the DIC will display the SIDE BLIND ZONE ALERT
SYSTEM OFF message as a reminder that the system
has been turned off. See DIC Warnings and Messages
on page 4‑65andSide Blind Zone Alert (SBZA)on
page 3‑42for more information.
FRONT TIRES or REAR TIRES
On vehicles with the Tire Pressure Monitor System
(TPMS), the pressure for each tire can be viewed in the
DIC. The tire pressure will be shown in either pounds
per square inch (psi) or kilopascals (kPa). Press the
vehicle information button until the DIC displays FRONT
TIRES PSI (kPa) LEFT ## RIGHT ##. Press the vehicle
information button again until the DIC displays REAR
TIRES PSI (kPa) LEFT ## RIGHT ##.
4-63
Page 226 of 470

Black plate (64,1)Cadillac DTS Owner Manual - 2011
If a low tire pressure condition is detected by the
system while driving, a message advising you to add
air to a specific tire will appear in the display. See
Inflation - Tire Pressure
on page 6‑57andDIC
Warnings and Messageson page 4‑65for more
information.
If the tire pressure display shows dashes instead of a
value, there may be a problem with your vehicle. If this
consistently occurs, see your dealer for service.
SPEED LIMIT: XXX MPH (SPEED LIMIT:
XXX Km/h) or ADVISORY: XXX MPH
(ADVISORY: XXX Km/h)
This display will show the speed limit or the advised
speed as determined by the information on the map
disc in the navigation system. If there is no map disc in
the navigation system, this display will not be available.
The speed limit and speed advisory displays on the DIC
are for reference only. There may be segments of road
where speed data has not been captured or times
where incorrect speed data, or no speed data, will be
displayed by the DIC due to the navigation system not
correctly matching the vehicle’s position to the actual
road. Be aware of this and obey posted speed limits
wherever you drive.
SPEED ALERT
This display will allow you to customize the speed alert
warning. You can choose to have no warning display,
or to have it display at the limit, at 5 km/h (mph) over
the limit, or at 10 km/h (mph) over the limit. The DIC
will toggle between OFF, AT LIMIT, +5 , +10 (Km/h or
MPH). Press the reset button to make your selection.
RELEARN REMOTE KEY
This display allows you to match Remote Keyless Entry
(RKE) transmitters to your vehicle. This procedure will
erase all previously learned transmitters. Therefore,
they must be relearned as additional transmitters.
To match an RKE transmitter to your vehicle:
1. Press the vehicle information button until PRESS
VTO RELEARN REMOTE KEY displays.
2. Press the set/reset button until REMOTE KEY LEARNING ACTIVE is displayed.
3. Press and hold the lock and unlock buttons on the first transmitter at the same time for about
15 seconds.
On vehicles with memory recall seats, the
first transmitter learned will match driver 1 and
the second will match driver 2.
A chime will sound indicating that the transmitter is
matched.
4-64
Page 227 of 470

Black plate (65,1)Cadillac DTS Owner Manual - 2011
4. To match additional transmitters at this time,repeat Step 3.
Each vehicle can have a maximum of
eight transmitters matched to it.
5. To exit the programming mode, you must cycle the key to LOCK/OFF.
Blank Display
This display shows no information.
DIC Warnings and Messages
These messages appear if there is a problem detected
in one of your vehicle's systems.
You must acknowledge a message to clear it from the
screen for further use. To clear a message, press the
set/reset button.
Be sure to take any message that appears on the
screen seriously and remember that clearing the
message will only make the message disappear, not
the problem.
ADVISORY XXX MPH (km/h)
This message displays when the Speed Alert has been
turned on through the DIC Information Menu and the
vehicle is at or above the advised speed. See DIC
Operation and Displays on page 4‑60.
AUTOMATIC LIGHT CONTROL OFF
This message displays when the automatic headlamps
are turned off. See Exterior Lampson page 4‑25for
more information.
AUTOMATIC LIGHT CONTROL ON
This message displays when the automatic headlamps
are turned on. See Exterior Lampson page 4‑25for
more information.
BATTERY SAVER ACTIVE
This message displays when the system detects that
the battery voltage is dropping beyond a reasonable
level. The battery saver system starts reducing certain
features of the vehicle that you may be able to notice.
At the point that the features are disabled, this message
is displayed. It means that the vehicle is trying to save
the charge in the battery.
Turn off all unnecessary accessories to allow the
battery to recharge.
The normal battery voltage range is 11.5 to 15.5 volts.
You can monitor battery voltage on the Driver
Information Center (DIC) by pressing the trip/fuel
button until BATTERY VOLTAGE is displayed.
4-65
Page 228 of 470

Black plate (66,1)Cadillac DTS Owner Manual - 2011
CHANGE ENGINE OIL SOON
This message displays when service is required for
your vehicle. See your dealer. SeeEngine Oilon
page 6‑15and Scheduled Maintenanceon page 7‑3for more information.
When you reset the CHANGE ENGINE OIL SOON
message by clearing it from the display, you still must
reset the engine oil life system separately. For more
information on resetting the engine oil life system, see
Engine Oil Life System on page 6‑18.
CHECK TIRE PRESSURE or ADD AIR
TO TIRE
On vehicles with the Tire Pressure Monitor System
(TPMS), this message displays when the pressure in
one or more of the vehicle's tires is low. This message
also displays LEFT FRONT, RIGHT FRONT, LEFT
REAR, or RIGHT REAR to indicate which tire needs to
be checked. The low tire pressure warning light will also
come on. See Tire Pressure Light
on page 4‑54. If a
tire pressure message appears on the DIC, stop as
soon as you can. Have the tire pressures checked and
set to those shown on the Tire Loading Information
label. See Tires
on page 6‑48,Loading the Vehicleon
page 5‑18, and Inflation - Tire Pressureon page 6‑57.You can receive more than one tire pressure message
at a time. To read the other messages that may have
been sent at the same time, press the set/reset button.
The DIC also shows the tire pressure values. See
DIC
Operation and Displays
on page 4‑60.
CLEAN RADAR
This message displays when the Adaptive Cruise
Control (ACC) system and the Forward Collision Alert
(FCA) system are disabled because the radar is
blocked and cannot detect vehicles in your path. It may
also activate during heavy rain or due to road spray. To
clean the system, see “Cleaning the System” under
Adaptive Cruise Control on page 4‑14.
CRUISE SET TO XXX MPH (km/h)
This message displays whenever the cruise control is
set. See Cruise Controlon page 4‑12andAdaptive
Cruise Controlon page 4‑14for more information.
If your vehicle has Adaptive Cruise Control (ACC), after
a few seconds, this message clears and the message
“SET SPD XX” displays at the bottom of the DIC. See
“SET SPD (Speed)” later in this section.
4-66
