2-5 Power Door Locks
Press the power door lock switch to lock or unlock both
doors at once.
Automatic Door Locks
Close your doors and turn on the ignition. Every time
you move the shift lever out of PARK (P), both doors
will lock. The doors will unlock every time you stop the
vehicle and move the shift lever back into PARK (P). If
someone needs to get out while your vehicle is not in
PARK (P), have that person use the manual or powerdoor lock. When the door is closed again, it will not
lock automatically. Use the manual or power door lock
to lock the door again. If you need to lock the doors
before shifting out of PARK (P), use the manual or
power door lock.
Programmable Automatic Door Locks
(If Equipped)
With the ignition in RUN, the door locks can be
programmed through prompts displayed by the Driver
Information Center (DIC). These prompts allow the
driver to choose various lock settings. For programming
information, see ªMemory and Personalization
Featuresº in the Index.
Anti-Lockout Feature
Leaving your key in any ignition position with either
door open will disable the use of the power door lock
switches as well as the lock button on the remote keyless
entry transmitter. If you close the doors, you can lock
them using the remote keyless entry transmitter. It is
always recommended that you remove your ignition
key when locking your vehicle.
Note: The anti
-lockout feature can be overridden by
holding the driver's power door lock switch for three
seconds or longer.

yellowblue
2-6 Leaving Your Vehicle
If you are leaving the vehicle, open the door, set the
locks from the inside, get out and close the door.
Remote Keyless Entry (RKE) System
With this feature, you can
lock and unlock the doors,
unlock the trunk, open the
fuel door and turn on your
vehicle's interior lamps
from about 10 feet (3 m)
away using the remote
keyless entry transmitter
supplied with your vehicle.
Your remote keyless entry system operates on a radio
frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation of the device.
Changes or modifications to this system by other than an
authorized service facility could void authorization to
use this equipment.
The range of this system is about 10 feet (3 m). At times
you may notice a decrease in range. This is normal for
any remote keyless entry transmitter. If the transmitter
does not work or if you have to stand closer to your
vehicle for the transmitter to work, try this:

Check to determine if battery replacement is
necessary. See the instructions that follow.

Check the distance. You may be too far from your
vehicle. You may need to stand closer during rainy
or snowy weather.

Check the location. Other vehicles or objects may be
blocking the signal. Take a few steps to the left or
right, hold the transmitter higher, and try again.

If you're still having trouble, see your dealer or a
qualified technician for service.

yellowblue
2-7 Operation
When you press this button to unlock the driver's
door, the parking lamps on your vehicle will blink twice.
(You can program your vehicle so the parking lamps
will not flash. For more information, see ªLock/Unlock
Confirmationº in the Index.) Pressing it again within
five seconds will unlock the other doors. Pressing this
button will also disarm the theft
-deterrent system (if
equipped) and turn on the interior lamps at night.
When you press this button to lock the doors, the
parking lamps will blink once. (You can program your
vehicle so the parking lamps will not flash. For more
information, see ªLock/Unlock Confirmationº in the
Index.) This also arms the theft
-deterrent system
(if equipped).
Press this symbol to open the trunk. (The
VALET lockout button must be off.)
Press this button to open the fuel door. (The
VALET lockout button must be off.)
The remote keyless entry transmitter can also be used
to recall the memory seats for up to two drivers. For
more information, see ªMemory Seat and Mirrorsº
in the Index.
Matching Transmitter(s) To Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking your vehicle.
If a transmitter is lost or stolen, a replacement can be
purchased through your dealer. Once your dealer has
coded the new transmitter, the lost transmitter will not
unlock your vehicle. Each vehicle can have only up to
four transmitters matched to it.
Battery Replacement
Under normal use, the battery in your remote keyless
entry transmitter should last about four years.
You can tell the battery is weak if the transmitter won't
work at the normal range in any location. If you have to
get close to your vehicle before the transmitter works,
it's probably time to change the battery.
NOTICE:
When replacing the battery, use care not to
touch any of the circuitry. Static from your
body transferred to these surfaces may damage
the transmitter.

yellowblue
2-8
1. Use the round end of the door key or a coin to pry
open the transmitter.2. Once the transmitter is separated, use a pencil (or
similar object) to remove the old battery. Do not use
a metal object.
3. Remove and replace the battery. Insert the new
battery as the instructions under the cover indicate.
Do not use a metal object.
4. Snap the transmitter back together tightly to be sure
no moisture can enter.
5. Resynchronize the transmitter. See instructions under
ªResynchronizationº following.

yellowblue
2-9 Resynchronization
Pressing the remote keyless entry transmitter buttons
numerous times (approximately 250 times) out of the
vehicle's operating range may cause the transmitter not
to work. Replacing the battery and pressing the
transmitter buttons out of range will also cause the
transmitter not to work. If only the fuel door button
works, the transmitter needs to be resynchronized to
the receiver. Do this by pressing and holding both the
LOCK and UNLOCK buttons on the transmitter for
about eight seconds. You must be within range of
the vehicle.
Once the transmitter has been resynchronized, the horn
will chirp and the exterior lamps will flash once. The
system should now operate properly. See your dealer for
service if your transmitter doesn't work properly.
Trunk
CAUTION:
It can be dangerous to drive with the trunk lid
open because carbon monoxide (CO) gas can
come into your vehicle. You can't see or smell
CO. It can cause unconsciousness and even death.
If you must drive with the trunk lid open or if
electrical wiring or other cable connections must
pass through the seal between the body and the
trunk lid:

Make sure all other windows are shut.

Turn the fan on your heating or cooling
system to its highest speed with the setting
on AUTO and the temperature between
65F (18C) and 85F (29C). That will
force outside air into your vehicle. See
ªComfort Controlsº in the Index.

If you have air outlets on or under the
instrument panel, open them all the way.
See ªEngine Exhaustº in the Index.

yellowblue
2-10 Trunk Lock Release
To use this feature, your
vehicle must be in
PARK (P) or NEUTRAL (N)
and the VALET lockout
button must be in the
OFF position. Press the
TRUNK button, located
above the radio on the Driver
Information Center (DIC), to
open the trunk.
You can also press the trunk button on the
remote keyless entry transmitter to access the
trunk compartment.
Trunk Storage System (Option)
The optional trunk storage system can be used to
organize many different items inside the trunk. The
cover (A) is located on top of the spare tire cover (B).
To install the storage system:
1. Pull the carpeting from the floor of the trunk. Turn
the retainer (center dial) on the compact spare tire
cover counterclockwise to remove it.

yellowblue
2-11
2. Place the trunk storage system on the center of the
trunk floor (the cut out portion of the storage system
should be facing the rear of the vehicle).
3. Open the storage system by pulling up on the handle
located in the carpeted area. This allows the unit to
unfold into place. Unfold the divider walls and move
them into the retention slots.
4. Remove the rectangular access panel from the floor
of the storage system. The access panel should
unsnap by hand.
5. Center the storage system access hole over the area
where the spare tire is secured by the retainer.
Position the storage system as needed and then
secure it with the retainer.
6. Replace the access panel.
7. Attach the removable net to the slots located on the
front of the divider walls and attach the hooks to the
holes on each side of the storage system.
Once in place, the storage system can be moved
forward or rearward for convenience and easy access
of stored items.The following steps explain how to remove the trunk
storage system for cleaning or in case you need to access
the spare tire. Follow all of these steps if the storage
system is in the closed position. Begin with Step 2 if the
system is already open.
1. Open the storage system by pulling up on the handle
located in the carpeted area. This allows the unit to
unfold into place. Unfold the divider walls and move
them into the retention slots.
2. Remove the rectangular access panel from the floor
of the storage system. The access panel should
unsnap by hand.
3. Center the storage system access hole over the
area where the spare tire is secured by the retainer.
Position the storage system as needed and then
remove the retainer (turn the retainer
counterclockwise to remove it).
4. Replace the access panel and remove the
storage system.

yellowblue
2-12 Trunk Lid Automatic Pull-Down Feature
CAUTION:
Your car may have an automatic pull-down
feature that helps close the trunk electronically.
Your fingers can be trapped under the trunk lid
as it goes down. Your fingers could be injured,
and you would need someone to help you free
them. Keep your fingers away from the trunk lid
as you close it and as it is going down.
With the automatic pull-down feature, you never have to
slam the trunk lid in order to close the trunk. Instead,
gently lower the trunk lid until it is nearly shut
-- the
automatic pull
-down unit will take over and lock the
trunk firmly.
A. Trunk Lid
B. Lever
If for some reason the trunk lid (A) will not close, it may
be because the trunk pull
-down unit was accidentally
bumped. Even though the trunk lid remains open, the
motor from the pull
-down unit has already cycled down.
If this happens, press the lever (B) on the trunk lid. The
pull
-down unit motor will reset itself, allowing the trunk
lid to close when lowered.

yellowblue
2-13
Theft
Vehicle theft is big business, especially in some cities.
Although your vehicle has a number of theft
-deterrent
features, we know that nothing we put on it can make
it impossible to steal. However, there are ways you
can help.
Key in the Ignition
If you leave your vehicle with the keys inside, it's an
easy target for joy riders or professional thieves
-- so
don't do it.
When you park your vehicle and open the driver's door,
you'll hear a chime reminding you to remove your key
from the ignition and take it with you. Always do this.
Your steering wheel will be locked, and so will your
ignition and transaxle. And remember to lock the doors.
Parking at Night
Park in a lighted spot, close all windows and lock your
vehicle. Remember to keep your valuables out of sight.
Put them in a storage area, or take them with you.
Parking Lots
If you park in a lot where someone will be watching
your vehicle, it's best to lock it up and take your keys.
But what if you have to leave your ignition key?

If possible, park in a busy, well lit area.

Put your valuables in a storage area, like your
trunk or glove box. Be sure to close and lock the
storage area.

Close all windows.

Lock the glove box.

Lock all the doors except the driver's.

Then take the door key and remote keyless entry
transmitter with you.

yellowblue
2-14
Theft-Deterrent System (If Equipped)
If the ignition is off and
either door is open, the
SECURITY light will flash,
reminding you to activate
the system.
The light will also flash if the battery has been
disconnected and reconnected. To activate the
theft
-deterrent system:
1. Open the door.
2. Lock the door using the power door lock or the
remote keyless entry transmitter. The SECURITY
light should come on and stay on.
3. Close both doors. The SECURITY light should go
off within about 30 seconds.
The horn will sound and the lamps will flash for about
30 seconds when a door or the trunk is opened without
the key or the remote keyless entry transmitter. The horn
also sounds if the locks are damaged.Remember, the theft
-deterrent system won't activate if
you lock a door with a key or use the manual door lock.
It activates only if you use a power door lock switch or
the remote keyless entry transmitter.
To avoid activating the alarm by accident:

Always unlock a door with a key or use the remote
keyless entry transmitter. (Pressing the unlock button
on the remote keyless entry transmitter disables the
theft
-deterrent system.) Unlocking a door any other
way will activate the alarm. Cycling the ignition
without disarming the theft
-deterrent system will
also activate the alarm.

The vehicle should be locked with the door key after
the doors are closed if you don't want to activate the
theft
-deterrent system.
If you activate the alarm by accident, unlock either door
with your key. You can also turn off the alarm by using
the unlock button of the remote keyless entry
transmitter. The alarm won't stop if you try to unlock a
door any other way.
