6-68 Wheel Nut Torque
100 lb-ft (140 N´m)
Capacities
Transaxle (4T80-E) 15.0 quarts (14.2 L). . . . . . . . . .
Crankcase (Engine Oil with
Filter Change) 7.5 quarts (7.1 L). . . . . . . . . . . .
Engine Cooling System 12.5 quarts (11.8 L). . . . . . .
Fuel Tank 19.0 U.S. gallons (71.9 L). . . . . . . . . . . . .
All capacities are approximate. When adding, be sure to
fill to the approximate level, as recommended in this
manual. Recheck fluid level after filling.
Normal Maintenance
Replacement Parts
Air Filter Element AC Type A1096C. . . . . . . . . . . . .
Fuel Filter Element AC Type GF
-650 . . . . . . . . . . . .
Engine Oil Filter AC Type PF
-58 . . . . . . . . . . . . . . . .
PCV Valve AC Type CV
-774C . . . . . . . . . . . . . . . . . .
Spark Plugs PT16EPR
-C13 (GM part 12561466) . . .
Gap: 0.050 inches (1.3 mm)
Thermostat AC Type 131
-66 . . . . . . . . . . . . . . . . . . . .
Windshield Wiper
Blade (Pin Type) 22 inches (56.5 cm). . . . . . . . . . . .
Vehicle Dimensions
Wheel Base 108.0 inches (274.3 cm). . . . . . . . . . . .
Length 200.6 inches (509.5 cm). . . . . . . . . . . . . . . .
Height 53.6 inches (136.1 cm). . . . . . . . . . . . . . . . . .
Width 75.5 inches (191.8 cm). . . . . . . . . . . . . . . . . .
Front Tread 60.9 inches (154.6 cm). . . . . . . . . . . . . .
Rear Tread 60.9 inches (154.6 cm). . . . . . . . . . . . . .
