Page 74 of 365
2-17 Testing the Alarm
1. From inside the vehicle, roll down the window,
then get out of the vehicle, keeping the door open.
2. From outside of the vehicle, with the door open,
lock the vehicle using the power door lock or the
remote keyless entry transmitter and close the door.
Wait 30 seconds until the SECURITY light goes off.
3. Reach in and unlock the door using the manual lock
and open the door. The horn will sound and the
headlamps will flash.
If the alarm does not sound when it should, check to
see if the horn works. The horn fuse may be blown.
To replace the fuse, see ªFuses and Circuit Breakersº
in the Index. If the fuse does not need to be replaced,
you may need to have your vehicle serviced.
To reduce the possibility of theft, always activate the
theft
-deterrent system when leaving your vehicle.
Valet Lockout Button
The VALET lockout
button is located inside
the glove box.
Press the button to disable the use of the power trunk,
fuel door and garage door openers.
Press the button again to restore normal function to
these features. Locking the glove box with the door key
will also help to secure your vehicle.
The remote keyless entry transmitter can't be used to
open the trunk or fuel door if the VALET lockout button
is pressed in.
Page 91 of 365
2-34
Turn Signal/Multifunction Lever
The lever on the left side of your steering column
includes the following:
Turn Signal and Lane
-Change Signals
Headlamp High/Low
-Beam Changer
Flash
-to-Pass Feature
Windshield Wipers
Windshield Washer
Cruise Control
For more information on the exterior lamps,
see ªExterior Lampsº later in this section.
Turn and Lane-Change Signals
To signal a turn, move the lever all the way up or down.
The lever returns automatically when the turn is complete.
An arrow located on the
instrument panel cluster
will flash in the direction
of the turn or lane change.
Raise or lower the lever until the arrow starts to flash to
signal a lane change. Hold it there until the lane change
is complete. The lever returns when it's released.
If the turn signal is left on, a warning chime will
sound and the Driver Information Center (DIC) will
display TURN SIGNAL ON (after driving about
1 mile (1.6 km/h)) to remind you to turn it off.
Arrows that flash rapidly when signaling for a turn or
lane change may be caused by a burned
-out signal bulb.
Other drivers won't see the turn signal.
Replace burned
-out bulbs to help avoid possible
accidents. Check the fuse (see ªFuses and Circuit
Breakersº in the Index) and for burned
-out bulbs
if the arrow fails to work when signaling a turn.
Page 92 of 365
2-35 Headlamp High/Low-Beam Changer
This light located on the
instrument panel cluster
will be on when the high
beam headlamps are in use.
Pull the turn signal lever all the way toward you and
then release it to change the headlamps from low beam
to high or from high beam to low.
Flash-To-Pass Feature
This lets you use the high-beam headlamps to
signal the driver in front of you that you want to pass.
Pull the turn signal lever toward you to use.
When you do:
If the headlamps are either off or in the Daytime
Running Lamps (DRL) mode, the high
-beam
headlamps will turn on. They'll stay on as long as
you hold the lever there. Release the lever to turn
them off.
If the headlamps are on low beam, they will shift
to high beam and stay there. Pull the lever toward
you to return to low beam.
If the headlamps are on high beam, they will switch
to low beam. To return to high beam, pull the lever
toward you.
Page 100 of 365
2-43
Headlamps: Pulling the knob to the second position
turns on the headlamps, together with the previously
listed lamps and lights.
Wiper
-Activated Headlamps
This feature activates the headlamps and parking lamps
after the windshield wipers have been in use for
approximately 20 seconds.
In order to operate the wiper
-activated headlamps, the
Twilight Sentinel must be turned on. This feature lights
the way in poor weather and it also makes your vehicle
more visible to other drivers. If the wiper
-activated
headlamps are on, and the ignition switch is turned off,
the wiper
-activated headlamps will immediately turn off.
The wiper
-activated headlamps will deactivate if you
turn off the Twilight Sentinel or if the windshield wipers
have been turned off for a period of one or two seconds.
Lamps On Reminder
If the exterior lamp knob is activated, you will hear a
warning chime if you open either door while leaving the
lamps on. An exception to this is when you're using
Twilight Sentinel.
Daytime Running Lamps
Daytime Running Lamps (DRL) can make it easier
for others to see the front of your vehicle during
the day. DRL can be helpful in many different
driving conditions, but they can be especially helpful
in the short periods after dawn and before sunset.
Fully functional daytime running lamps are required
on all vehicles first sold in Canada.
The DRL system will make the high
-beam headlamps
come on at reduced brightness when:
The ignition is on,
the exterior lamp knob is not in the
headlamp position
the transaxle is not in PARK (P).
When DRL are on, only your high
-beam headlamps
(at reduced brightness) will be on. No other exterior
lamps such as the parking lamps, taillamps, etc., will be
on when the DRL are being used. Your instrument panel
won't be lit up either.
Page 101 of 365
2-44
When the Twilight Sentinel lever is on and it's dark
enough outside, the high
-beam headlamps (at reduced
intensity) will turn off and normal low
-beam headlamp
operation will occur. When the Twilight Sentinel lever is
on and it's bright enough outside, the regular lamps
will go off, and the high
-beam headlamps at reduced
brightness will take over for the DRL.
If it's dark enough outside and the Twilight Sentinel
lever is off, a HEADLAMPS SUGGESTED message
will display on the Driver Information Center (DIC).
This message informs the driver that turning on the
exterior lamps is recommended even though the DRL
are still illuminated (it's become dark enough outside
to require the headlamps and/or other exterior lamps).
Turning on the Twilight Sentinel, the exterior lamp knob
or the fog lamp button will remove the HEADLAMPS
SUGGESTED message.
To idle your vehicle with the DRL off, turn off the
Twilight Sentinel lever and shift the transaxle into
PARK (P). Placing your vehicle in PARK (P) disables
the DRL. The DRL will stay off until you shift out
of PARK (P).
As with any vehicle, you should turn on the regular
headlamp system when you need it.
Fog Lamps
Use the fog lamps for better vision in foggy or
misty conditions.
The fog lamp button is
located to the left of the
steering wheel on the
instrument panel.
When you press the button with the fog lamp symbol,
a small indicator light will tell you that the fog lamps
and the parking lamps are in use. Press the button again
to turn them off. Your ignition must be in RUN for the
fog lamps to illuminate.
If you turn on the high
-beam headlamps, the fog lamps
will turn off. They'll turn back on again when you
switch to low
-beam headlamps.
When the Twilight Sentinel is on and the fog lamp
button is pressed, the fog lamps will remain on as well
as the headlamps and parking lamps.
Page 102 of 365
2-45 Cornering Lamps
The cornering lamps come on when you signal a turn.
They provide more light for cornering.
Twilight Sentinel
This feature automatically turns the exterior lamps on
and off by sensing how dark it is outside.
This lever is located
next to the exterior lamp
control knob.To operate the Twilight Sentinel, leave the exterior lamp
knob off and slide the TWILIGHT lever to any position
except OFF.
If you slide the lever all the way to the right, the lamps
will remain on for approximately three minutes after the
ignition has been turned to OFF or LOCK. If you slide
the lever so it is just on, the lamps will go off quickly
when you move the ignition out of RUN. You can adjust
the delay time from only a few seconds to three minutes.
If it's dark enough outside and Twilight Sentinel is off,
a HEADLAMPS SUGGESTED message will display
on the Driver Information Center (DIC). This message
informs the driver that turning on the exterior lamps is
recommended (it's become dark enough outside to
require the headlamps and/or other exterior lamps).
Turning on the Twilight Sentinel or the headlamps will
remove the HEADLAMPS SUGGESTED message.
Page 103 of 365
2-46
Light Sensor
The light sensor for the Daytime Running Lamps (DRL)
and the Twilight Sentinel is located in the center of the
front defogger grille. If you cover the sensor, it will read
ªdarkº and the lamps will come on.
Exterior Lighting Battery Saver
If the parking lamps have been left on, the exterior lamps
will turn off approximately 10 minutes after the ignition
is turned to LOCK or ACCESSORY. This protects
against draining the battery in case you have accidentally
left the headlamps or parking lamps on. If you need to
purposely leave the lamps on for more than 10 minutes
with the ignition in LOCK or ACCESSORY, turn the
exterior lamps off and then back on. To delay the lamps
from turning off, see ªTwilight Sentinelº in the Index.
Interior Lamps
Instrument Panel Brightness Control
This feature controls the brightness of the instrument
panel lights.
The knob for this feature is located to the left of the
steering wheel on the instrument panel. This knob is also
used to control the exterior lamps. See ªExterior Lampsº
listed previously in this section for more information.
Turn the knob clockwise to brighten the lights or
counterclockwise to dim them.
Illuminated Entry
The illuminated entry system turns on the courtesy
lamps and the backlighting to the door controls and
to the exterior lamp knob when a door is opened or if
you press a remote keyless entry transmitter button.
Since the illuminated entry system has a photocell,
this means that it must be dark outside in order for the
courtesy lamps or backlighting to turn on. The courtesy
lamps turn off approximately 20 seconds after the last
door is closed or after the ignition is turned to RUN.
Page 104 of 365
2-47 Parade Dimming
This feature prohibits the dimming of the instrument
panel lights during daylight while the headlamps
are on. This feature operates with the light sensor for
the Twilight Sentinel and is fully automatic. When the
light sensor reads darkness outside, the instrument
panel lights can be adjusted by turning the exterior
lamp knob counterclockwise to dim and clockwise to
brighten lighting. Backlighting to the instrument panel
will turn on, regardless of light conditions.
Reading Lights
The front reading lights are located either in the
headliner or above the windows if you have a sunroof.
The two rear lights above the rear side windows.
To turn them on, turn the exterior lamp knob all the way
clockwise. These lights and the interior courtesy lights
automatically come on when either door is opened and
it is dark outside.
Press the lens to turn on the lights manually. Press it
again to turn them off.
If the reading lights are left on, they automatically shut
off 10 minutes after the ignition has been turned off.
Inadvertent Power Battery Saver
This feature is designed to protect your vehicle's battery
against drainage from the interior lamps, trunk lamp,
glove box lamp, cigarette lighters or the garage door
opener. When the ignition is turned off, the power to
these features will automatically turn off after 10 minutes
(three minutes if a new car has 15 miles (24 km) or less).
Power will be restored for an additional 10 minutes
if either door is opened, the trunk is opened or the
courtesy lamps are turned on.
Storage Mode Personalization
This feature is for long-term use and must be
programmed through the Driver Information
Center (DIC). This feature protects the battery by
placing your vehicle in a storage mode so that the radio,
amplifiers, instrument panel cluster and remote keyless
entry will not drain the battery over a long period of
time. For programming information, see ªMemory
and Personalization Featuresº in the Index.
Page 107 of 365
2-50 Power Remote Control Mirrors
The control on the driver's
door armrest operates both
outside rearview mirrors.
Press (R) on the selector switch to choose the right
mirror or (L) to choose the left mirror. The center
position is off and will not move the mirrors if the
control pad is touched.
To adjust the mirror, press the arrows on the control pad
in the direction you want the mirror to go. Adjust each
mirror so you can see the side of your vehicle and the
area behind your vehicle.
The mirrors can also be programmed for personalization
if you have the optional memory package. For more
information, see ªMemory Seat and Mirrorsº in the Index.
Driver's Outside Auto-Dimming
Rearview Mirror
Only the driver's side outside mirror will adjust for
the glare of headlamps behind you. This feature
is controlled by the on and off settings on the
electrochromic mirror. See ªElectrochromic Day/Night
Rearview Mirror with Compassº in the Index.
Curb View Assist Mirror (If Equipped)
If your vehicle is equipped with memory mirrors,
it will also be equipped with the curb view assist mirror
feature. This feature will cause the passenger's mirror
to tilt when the vehicle is moving in REVERSE (R).
This feature may be useful in allowing you to view the
curb when you are parallel parking. To turn this feature
on or off, follow the directions included later in this
section. See ªMemory and Personalization Featuresº
in the Index.
When the vehicle is shifted out of REVERSE (R) and a
five second delay has occurred, the passenger's mirror
will return to its original position. If further adjustment
is needed after the mirror is tilted, the mirror switch may
be used. The mirror then returns to its original position.
Page 140 of 365
2-83
ENGINE HOT - A/C OFF - 16: This message
displays when the engine coolant becomes hotter than
the normal operating temperature. To avoid added strain
on a hot engine, the air conditioning compressor is
automatically turned off so that air conditioned air is
not delivered. If the coolant temperature returns to
normal, you must select AC to return to a normal A/C
compressor operation. If this message continues to
appear, have the system repaired as soon as possible to
avoid compressor damage.
ENGINE MISFIRE
-- EASE OFF GAS
PEDAL
- 114: An engine misfire has occurred.
You'll need to ease off the gas pedal.
ENGINE OVERHEATED, STOP ENGINE
- 42:
This message will appear when the engine has overheated.
Stop and turn the engine off immediately to avoid severe
engine damage. See ªEngine Overheatingº in the Index.
A multiple chime will also sound when this message
is displayed.
ENGINE POWER REDUCED
- 41: This message
informs you that your vehicle is reducing engine power
because the transaxle is being placed in gear under
conditions that may cause damage to the vehicle
powertrain or vehicle acceleration.FUEL LEVEL LOW
- 11 : This message serves as
a warning that the fuel level in the tank is critically low.
Stop for fuel soon.
HEADLAMPS SUGGESTED
- 23: If it's dark enough
outside and Twilight Sentinel is off, a HEADLAMPS
SUGGESTED message will display on the DIC.
This message informs the driver that turning on the
exterior lamps is recommended even though the
Daytime Running Lamps (DRL) are still illuminated
(it's become dark enough outside to require the
headlamps and/or other exterior lamps).
ICE POSSIBLE
- 13: This message appears when
the outside air temperature is cold enough to create icy
road conditions.
LOW REFRIG A/C OFF
- 12: This message means
that the air conditioning system detects a refrigerant
level that is low enough to cause damage to the air
conditioning compressor. Have the air conditioning
system serviced if this message appears.
MONITORED SYSTEMS OK
- 1: This message only
appears in the ªrecallº mode by pressing the NO INFO
RESET button. It lets you know that no other messages
are stored or are currently active.
