Page 207 of 352
yellowblue
4-35
If you drive regularly in steep country, or if you're
planning to visit there, here are some tips that can make
your trips safer and more enjoyable. (See ªOff
-Road
Drivingº in the Index for information about
driving off
-road.)
Keep your vehicle in good shape. Check all fluid
levels and also the brakes, tires, cooling system and
transmission. These parts can work hard on
mountain roads.
Know how to go down hills. The most important
thing to know is this: let your engine do some of the
slowing down. Shift to a lower gear when you go
down a steep or long hill.
CAUTION:
If you don't shift down, your brakes could get so
hot that they wouldn't work well. You would then
have poor braking or even none going down a
hill. You could crash. Shift down to let your
engine assist your brakes on a steep
downhill slope.
CAUTION:
Coasting downhill in NEUTRAL (N) or with the
ignition off is dangerous. Your brakes will have to
do all the work of slowing down. They could get so
hot that they wouldn't work well. You would then
have poor braking or even none going down a hill.
You could crash. Always have your engine running
and your vehicle in gear when you go downhill.
Know how to go uphill. You may want to shift down
to a lower gear. The lower gears help cool your engine
and transmission, and you can climb the hill better.
Stay in your own lane when driving on two
-lane
roads in hills or mountains. Don't swing wide or cut
across the center of the road. Drive at speeds that let
you stay in your own lane.
As you go over the top of a hill, be alert. There could
be something in your lane, like a stalled car or
an accident.
You may see highway signs on mountains that warn of
special problems. Examples are long grades, passing or
no
-passing zones, a falling rocks area or winding
roads. Be alert to these and take appropriate action.
Page 223 of 352
yellowblue
4-51
CAUTION:
It can be dangerous to get out of your vehicle if
the shift lever is not fully in PARK (P) with the
parking brake firmly set. Your vehicle can roll.
If you have left the engine running, the vehicle
can move suddenly. You or others could be
injured. To be sure your vehicle won't move, even
when you're on fairly level ground, use the steps
that follow.
Always put the shift lever fully in PARK (P) with
the parking brake firmly set.
If the transfer case on four-wheel drive vehicles is
in NEUTRAL, your vehicle will be free to roll,
even if your shift lever is in PARK (P). So, be
sure the transfer case is in a drive gear
-- not
in NEUTRAL.
When You Are Ready to Leave After
Parking on a Hill
1. Apply your regular brakes and hold the pedal down
while you:
Start your engine;
Shift into a gear; and
Release the parking brake.
2. Let up on the brake pedal.
3. Drive slowly until the trailer is clear of the chocks.
4. Stop and have someone pick up and store the chocks.
Maintenance When Trailer Towing
Your vehicle will need service more often when you're
pulling a trailer. See the Maintenance Schedule booklet
for more on this. Things that are especially important in
trailer operation are automatic transmission fluid (don't
overfill), engine oil, axle lubricant, belt, cooling system
and brake system. Each of these is covered in this
manual, and the Index will help you find them quickly.
If you're trailering, it's a good idea to review these
sections before you start your trip.
Check periodically to see that all hitch nuts and bolts
are tight.
Page 261 of 352
6-
yellowblue
6-1
Section 6 Service and Appearance Care
Here you will find information about the care of your vehicle. This section begins with service and fuel information,
and then it shows how to check important fluid and lubricant levels. There is also technical information about your
vehicle, and a part devoted to its appearance care.
6
-2 Service
6
-3 Fuel
6
-5 Fuels in Foreign Countries
6
-5 Filling Your Tank
6
-8 Filling a Portable Fuel Container
6
-8 Checking Things Under the Hood
6
-11 Engine Oil
6
-15 Engine Air Cleaner/Filter
6
-17 Automatic Transmission Fluid
6
-20 Rear Axle
6
-21 Four-Wheel Drive
6
-23 Radiator Pressure Cap
6
-23 Thermostat
6
-24 Engine Coolant
6
-27 Power Steering Fluid
6
-28 Windshield Washer Fluid
6
-29 Brakes6
-33 Battery
6
-33 Bulb Replacement
6
-38 Windshield Wiper Blade Replacement
6
-38 Tires
6
-47 Appearance Care
6
-47 Cleaning the Inside of Your Vehicle
6
-49 Care of the Safety Belts
6
-50 Cleaning the Outside of Your Vehicle
6
-54 GM Vehicle Care/Appearance Materials
6
-55 Vehicle Identification Number (VIN)
6
-55 Service Parts Identification Number Label
6
-56 Electrical System
6
-62 Replacement Bulbs
6
-63 Capacities and Specifications
6
-65 Air Conditioning Refrigerants
6
-65 Normal Maintenance Replacement Parts
Page 277 of 352
yellowblue
6-17
Refer to the Maintenance Schedule to determine when to
replace the engine air cleaner/filter. See ªOwner Checks
and Servicesº in the Maintenance Schedule booklet.
CAUTION:
Operating the engine with the air cleaner/filter
off can cause you or others to be burned. The air
cleaner not only cleans the air, it stops flame if
the engine backfires. If it isn't there, and the
engine backfires, you could be burned. Don't
drive with it off, and be careful working on the
engine with the air cleaner/filter off.
NOTICE:
If the air cleaner/filter is off, a backfire can cause
a damaging engine fire. And, dirt can easily get
into your engine, which will damage it. Always
have the air cleaner/filter in place when
you're driving.
Automatic Transmission Fluid
When to Check and Change
A good time to check your automatic transmission fluid
level is when the engine oil is changed.
Change both the fluid and filter every 50,000 miles
(83 000 km) if the vehicle is mainly driven under one
or more of these conditions:
In heavy city traffic where the outside temperature
regularly reaches 90F (32C) or higher.
In hilly or mountainous terrain.
When doing frequent trailer towing.
Uses such as found in taxi, police or delivery service.
If you do not use your vehicle under any of these
conditions, change the fluid and filter every
100,000 miles (166 000 km).
See ªScheduled Maintenance Servicesº in the
Maintenance Schedule booklet.
Page 278 of 352
yellowblue
6-18 How to Check
Because this operation can be a little difficult, you
may choose to have this done at the dealership
service department.
If you do it yourself, be sure to follow all the instructions
here, or you could get a false reading on the dipstick.
NOTICE:
Too much or too little fluid can damage your
transmission. Too much can mean that some of
the fluid could come out and fall on hot engine
parts or exhaust system parts, starting a fire. Be
sure to get an accurate reading if you check your
transmission fluid.
Wait at least 30 minutes before checking the
transmission fluid level if you have been driving:
When outside temperatures are above 90F (32C).
At high speed for quite a while.
In heavy traffic
-- especially in hot weather.
While pulling a trailer.To get the right reading, the fluid should be at normal
operating temperature, which is 180F to 200F
(82C to 93C).
Get the vehicle warmed up by driving about 15 miles
(24 km) when outside temperatures are above 50F
(10C). If it's colder than 50F (10C), drive the
vehicle in THIRD (3) until the engine temperature gage
moves and then remains steady for 10 minutes. Then
follow the hot check procedures.
Checking Transmission Fluid Cold
A cold check is made after the vehicle has been sitting
for eight hours or more with the engine off and is used
only as a reference. Let the engine run at idle for five
minutes if outside temperatures are 50F (10C) or
more. If it's colder than 50F (10C), you may have to
idle the engine longer. Should the fluid level be low
during a cold check, you must perform a hot check
before adding fluid. This will give you a more accurate
reading of the fluid level.
Checking the Fluid Level
Park your vehicle on a level place. Keep the
engine running.
With the parking brake applied, place the shift lever
in PARK (P).
Page 279 of 352
yellowblue
6-19
With your foot on the brake pedal, move the shift
lever through each gear range, pausing for about
three seconds in each range. Then, position the shift
lever in PARK (P).
Let the engine run at idle for three minutes or more.
Then, without shutting off the engine, follow these steps:
1. The red transmission dipstick is located at the rear of
the engine compartment, on the passenger's side.
Flip the handle up and then pull out the dipstick and
wipe it with a clean rag or paper towel.2. Push it back in all the way, wait three seconds and
then pull it back out again.
3. Check both sides of the dipstick, and read the lower
level. The fluid level must be in the COLD area,
below the cross
-hatched area, for a cold check or in
the HOT area or cross
-hatched area for a hot check.
4. If the fluid level is in the acceptable range, push the
dipstick back in all the way; then flip the handle
down to lock the dipstick in place.
Page 280 of 352
yellowblue
6-20 How to Add Fluid
Refer to the Maintenance Schedule booklet to determine
what kind of transmission fluid to use. See
ªRecommended Fluids and Lubricantsº in the Index.
Add fluid only after checking the transmission fluid
while it is hot. (A cold check is used only as a
reference.) If the fluid level is low, add only enough of
the proper fluid to bring the level up to the HOT area for
a hot check. It doesn't take much fluid, generally less
than one pint (0.5 L). Don't overfill.
NOTICE:
We recommend you use only fluid labeled
DEXRON-III, because fluid with that label is
made especially for your automatic transmission.
Damage caused by fluid other than DEXRON
-III
is not covered by your new vehicle warranty.
After adding fluid, recheck the fluid level as
described under ªHow to Check.º
When the correct fluid level is obtained, push the
dipstick back in all the way; then flip the handle
down to lock the dipstick in place.
Rear Axle
When to Check and Change Lubricant
Refer to the Maintenance Schedule to determine how
often to check the lubricant and when to change it. See
ªScheduled Maintenance Servicesº in the Maintenance
Schedule booklet.
How to Check Lubricant
Page 345 of 352
yellowblue
8-5
Flat Tire, Changing 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Capacities 6-64, 6-65 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Leak Check 6-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fog Lamps 2-49, 6-36, 6-62 . . . . . . . . . . . . . . . . . . . . . . . . . .
Folding the Rear Seat 1-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign Countries, Fuel 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Four-Wheel Drive 2-29, 6-21 . . . . . . . . . . . . . . . . . . . . . . . . .
Four-Wheel Drive, Automatic Transfer Case 2-29, 6-21 . . . .
Freeway Driving 4-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
French Language Manual ii. . . . . . . . . . . . . . . . . . . . . . . . . . .
Front
Axle 6
-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Axle Locking Feature 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . .
Park/Turn Signal Bulb Replacement 6-35, 6-62 . . . . . . . . .
Sidemarker Lamp Bulb Replacement 6-35, 6-62 . . . . . . . .
Towing 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Canada 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Container 6-8 . . . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gage 2-82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
System Capacity 6-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and Circuit Breakers 6-57 . . . . . . . . . . . . . . . . . . . . . . .
Gages
Engine Coolant Temperature 2-76 . . . . . . . . . . . . . . . . . . . .
Engine Oil Pressure 2-79 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel 2-82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Speedometer 2
-71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tachometer 2-71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltmeter 2-74 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GAWR 4-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gear Positions, Automatic Transmission 2-26 . . . . . . . . . . . . .
Glove Box 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GM Mobility Program for Persons with Disabilities 7-5 . . . . .
GM Vehicle Care/Appearance Materials 6-54 . . . . . . . . . . . . .
Gross Axle Weight Rating 4-41 . . . . . . . . . . . . . . . . . . . . . . . .
Gross Vehicle Weight Rating 4-41 . . . . . . . . . . . . . . . . . . . . . .
Guide en Fran†ais ii. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GVWR 4
-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Halogen Bulbs 6-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hazard Warning Flashers 5-2 . . . . . . . . . . . . . . . . . . . . . . . . . .
Head Restraints 1-5, 1-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamp Delay 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Headlamps 2-47, 6-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Bulb Replacement 6-34, 6-62 . . . . . . . . . . . . . . . . . . . . . . .
High/Low Beam Changer 2-42 . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring 6-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hearing Impaired, Customer Assistance 7-3 . . . . . . . . . . . . . .
Heated Front Seats 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heated Rear Seats 1-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Heating 3-2, 3-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
High-Beam Headlamps 2-42 . . . . . . . . . . . . . . . . . . . . . . . . . .
Highway Hypnosis 4-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hill and Mountain Roads 4-34 . . . . . . . . . . . . . . . . . . . . . . . . .
Hitches, Trailer 4-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Page 348 of 352
yellowblue
8-8
Power (Continued)
Remote Control Mirror 2-55 . . . . . . . . . . . . . . . . . . . . . . . .
Seat 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering 4-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering Fluid 6-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windows 2-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Power Lumbar Adjustment 1-3 . . . . . . . . . . . . . . . . . . . . . . . .
Pregnancy, Use of Safety Belts 1-22 . . . . . . . . . . . . . . . . . . . .
Problems on the Road 5-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Protecting Exterior Bright Metal Parts 6-51 . . . . . . . . . . . . . . .
Publications, Service and Owner 7-11, 7-12 . . . . . . . . . . . . . .
Radiator 5-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radiator Pressure Cap 6-23 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radio 3-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Radio Reception 3-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rain, Driving In 4-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reading Lamps 2-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear
Axle 6
-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Security Locks 2-6 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lamp Bulb Replacement 6-37 . . . . . . . . . . . . . . . . . . . . . . .
Outside Seat Position 1-30 . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Belt Comfort Guides 1-34 . . . . . . . . . . . . . . . . . . . . .
Seat Audio (RSA) 3-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat Passengers 1-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Window Defogger 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Windshield Wiper and Washer 2-44 . . . . . . . . . . . . . . . . . . .
Rear Air Conditioning and Heating Systems 3-3 . . . . . . . . . . . Rear Doors 2
-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Towing 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rearview Mirror 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Electrochromic with Compass/Temperature
Display/Headlamp Delay 2
-52 . . . . . . . . . . . . . . . . . . . . . . .
Inside 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reclining Front Seatbacks 1-4 . . . . . . . . . . . . . . . . . . . . . . . . .
Recovery Hooks 5-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Recovery Tank, Coolant 5-12 . . . . . . . . . . . . . . . . . . . . . . . . . .
Recreational Vehicle Towing 4-40 . . . . . . . . . . . . . . . . . . . . . .
Refrigerants, Air Conditioning 6-65 . . . . . . . . . . . . . . . . . . . .
Remote Compact Disc Player 3-14 . . . . . . . . . . . . . . . . . . . . .
Replacement
Bulbs 6
-62, 6-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Parts 6-65 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel 6-45 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel, Used 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing Safety Belts 1-56 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reporting Safety Defects 7-10 . . . . . . . . . . . . . . . . . . . . . . . . .
Restraints
Checking 1
-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Child 1-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Head 1-5, 1-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Replacing Parts After a Crash 1-56 . . . . . . . . . . . . . . . . . . .
Retained Accessory Power 2-23 . . . . . . . . . . . . . . . . . . . . . . . .
Reverse, Automatic Transmission 2-27 . . . . . . . . . . . . . . . . . .
Right Front Passenger Position 1-23 . . . . . . . . . . . . . . . . . . . .
Roadside Assistance 7-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rocking Your Vehicle 5-33 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Rotation, Tires 6-40 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
